Donexon varmo TZ eco User manual

Bedienungsanleitung und Garantie
Bitte lesen Sie vor dem Anbringen des
Energiesparreglers die Bedienungsanlei-
tung. Bewahren Sie die Unterlagen zum
Nachschlagen auf und geben Sie diese bei
Weitergabe des Gerätes mit.
Lieferumfang
1 varmo TZ eco Energiesparregler
1 Bedienungsanleitung (Teil des Produkts)
1 Schraube für Adapter
3 Adapter (Danfoss RA, RAV, RAVL)
2 Batterie LR6 AA 1,5 V
Sicherheitshinweise
• Das varmo TZ eco ist für die Verwend-
ung in Gebäuden vorgesehen.
• Betreiben Sie das Gerät nur wie in der
Bedienungsanleitung beschrieben.
• Das varmo TZ eco sollte nur an einem
trockenen und staubfreien Ort ohne di-
rekte Sonneneinstrahlung in Gebrauch
genommen werden.
• Betreiben Sie das Gerät nicht weiter,
wenn es offensichtliche Beschädigun-
gen aufweist.
• Das varmo TZ eco darf nicht umge-
baut, modiziert oder geöffnet werden.
Warnhinweis
Batterien niemals wieder auaden, nicht
kurzschließen, nicht auseinander nehmen
– Explosionsgefahr! Erschöpfte Batterien
umgehend aus dem Gerät entfernen.
Keine gebrauchten und neuen Batterien
zusammen verwenden. Batterien und
Gerätekontakte vor dem Einlegen bei
Bedarf reinigen. Batterien von Kindern
fernhalten. Kontakt mit Haut, Augen und
Schleimhäuten vermeiden. Bei Kontakt
mit Batteriesäure die betroffenen Stellen
sofort mit reichlich klarem Wasser spülen
und umgehend einen Arzt aufsuchen.
Batterien einlegen / wechseln
Entfernen Sie den Batteriedeckel, indem
Sie ihn an der markierten Stelle nach oben
drücken und aushängen. Legen Sie nun die
Batterien ein. Achten Sie auf die richtige Po-
larität! Bei einem späteren Batteriewechsel
bleibt die Konguration Ihres varmo TZ eco
erhalten.
Bedien- und Anzeigenelemente
Informiert über mechanische Vorgänge.
Informiert über Funkverbindung und
Hinzufügevorgänge.
Leuchtet auf, wenn das Display eine
Node ID anzeigt.
Leuchtet bei weniger als 15% Batterie-
stand auf.
Leuchtet bei gesetzter Kindersi-
cherung auf.
Leuchtet permanent in Kombination
mit Solltemperaturen.
Leuchtet permanent in Kombination
mit Stellwerten.
Installation
Setzen Sie Ihren primären Z-Wave Cont-
roller in den Inclusion-Modus und folgen
Sie den Schritten.
1.Hinzufügemodus (Inclusion) wird ange-
zeigt
 Boost-Taste betätigen
2.Display zeigt Node-ID
Hinzufügen abgeschlossen
3.Installationsmodus wird angezeigt
 Gerät am Heizkörper montieren
4.Nach erfolgreicher Installation drücken
Sie die grün blinkende Boost-Taste, um
die Adaptierung zu starten. Nach abge-
schlossener Adaptierung zeigt das Display
die Solltemperatur an.
Montage
Im Display erscheint (Installation) und
die Boost-Taste blinkt grün (noch nicht
drücken). Folgen Sie den Schritten zur In-
stallation.
1.Alten Thermostatkopf ganz aufdrehen,
Befestigung lösen und vom Ventil abziehen.
2. Wählen Sie ggf. einen passenden Adapter
und montieren Sie ihn auf das Ventil.
3.Drehen Sie den Energiesparregler auf
das Ventil bzw. auf den Adapter, bis er
einrastet.
 
Ventilvarmo TZ eco VentilAdaptervarmo TZ eco
Falls Sie nicht sicher sind, welches Ventil Sie
haben, schauen Sie unter: www.donexon.
com/service Hier nden Sie eine Liste mit
verschiedenen Ventilen und Adaptern.
C
Bedienen am Gerät
Taste /Zustand Bedeutung
einmal
betätigen Solltemperatur um 0,5° verringern
betätigen
und halten Solltemperatur sofort um 0,5°C verringern, danach um
0,5°C alle 0,5 Sek. verringern
solange Taste gedrückt bleibt
oder Endwert erreicht ist.
einmal
betätigen Solltemperatur um 0,5° erhöhen
betätigen
und halten Solltemperatur sofort um 0,5°C erhöhen, danach um
0,5°C alle 0,5 Sek. erhöhen
solange Taste gedrückt bleibt
oder Endwert erreicht ist.
einmal
betätigen
• Funktion, wie im Display
angezeigt ausführen
•In den Boost-Modus
wechseln.
•Falls im Boost-Modus dann
Boost-Modus beenden.
gedrückt hal-
ten für 3 Sek. Das Display gibt die Netz- werkkennung (Z-Wave
Node ID) aus.
gedrückt hal-
ten für 5 Sek. Der varmo TZ eco reagiert auf Entfern-Befehle des
Gateways. (Exclusion)
gedrückt hal-
ten und Batte-
rien in das Ge-
rät einsetzen
Das Gerät ermöglicht in
diesem Zustand den
Werksreset.
Gleichzeitig
für 3 Sek. ge-
drückt halten
Setzen oder entfernen der
Kindersicherung.
Adapter
Für folgenden Ventile ist kein Adapter
erforderlich:
Heimeier, Junkers Landys+Gyr,
MNG, Honeywell, Braukmann
Gewindemaß von M 30x1,5
Kein Adapter
erforderlich
Danfoss RAV (beiliegender Pin
muss auf Ventilstößel gesteckt
werden)
Danfoss RA
Danfoss RAVL
Warnhinweis
Entfernen Sie die Verbindungsstücke der
Kunststoff-Adapter restlos, bevor Sie einen
der beiliegenden Adapter verwenden!
Info: Weitere kostenpichtige Mes-
sing-Adaptertypen nden Sie unter: www.
donexon.com
Demontage des varmo TZ eco
Entfernen Sie den varmo TZ eco aus dem
Netzwerk, bevor Sie das Gerät demontie-
ren. Hierzu bringen Sie bitte Ihren Z-Wave
Controller in den Entfernmodus (Exclusion).
Danach halten Sie die Boost-Taste für 5
Sekunden gedrückt. Das LCD zeigt bei er-
folgreichem Entfernen Node ID 0 und der
Ventilstößel fährt in Montageposition. War-
ten Sie bis das LCD zeigt.
Drehen Sie nun die Überwurfmutter auf und
nehmen sie varmo TZ eco vom Ventil ab.
Fehlersuche
Problem Ursache/Lösung
Batterien weitgehend verbraucht.
Batterien wechseln.
+ beiliegendem
Pin; nur für RAV!

Installation Guide /
Installationsanleitung
Heizkörper
wird nicht
warm.
Kesselwassertemperatur O.K.? Ventil
öffnet nicht, nach der Sommer-Heiz-
pause – verkalkt?
Kesselwassertemperatur korrigieren,
varmo TZ eco demontieren. Ventil-
stößel mehrmals per Hand/Werkzeug
hin- und herbewegen.
Heizkörper
wird nicht
kalt.
Ventil schließt nicht vollständig.Evtl.
hat sich der Schließpunkt Ihrer Ventil-
dichtung verschoben.
Erneut adaptieren (s.„Adaptieren”)
Ventilstößel mehrmals von Hand be-
wegen – evtl. ist eine Adaption nicht
möglich, da das Ventil evtl. verkalkt
ist oder die Dichtung ihre Funktion
nicht mehr erfüllt.
Druckstück
fällt heraus.
(Dies kann
auch einen
ER1 Fehler
verursa-
chen!)
Durch ein Endlosgewinde kann das
auf der Unterseite sitzende Druck-
stück herausfallen, wenn der Regler
nicht auf dem Ventil aufgebracht
wurde.
Batterien aus dem Gerät entfernen.
Druckstück einsetzten. Batterien ein-
setzen.
ER1-ER3 Die Fehleranzeige kann durch Be-
tätigung der Boost-Taste gelöscht
werden.
ER1 Keine Ventilbewegung möglich.
Ventilstößel frei beweglich?
ERR Hinzufüge-Vorgang (Inclusion).
Z-Wave Controller nicht in Hinzufüg-
modus oder außer Reichweite.
ER2 Kein Ventil erkannt.
Gerät korrekt am Heizkörper montie-
ren. Korrekten Adapter benutzen.
ER3 Schließpunkt nicht erkannt.
Gerät korrekt am Heizkörper montiert?
RECHTLICHE HINWEISE
Umweltschutz:
Ab dem Zeitpunkt der Umsetzung der
europäischen Richtlinien 2012/19/EU
in nationales Recht gilt folgendes:
Elektrische und elektronische Geräte sowie
Batterien dürfen nicht mit dem Hausmüll
entsorgt werden. Der Verbraucher ist gesetz-
lich verpichtet, elektrische und elektroni-
sche Geräte sowie Batterien am Ende ihrer
Lebensdauer an den dafür eingerichteten,
öffentlichen Sammelstellen oder an die Ver-
kaufsstelle zurückzugeben. Einzelheiten dazu
regelt das jeweilige Landesrecht.
Das Symbol auf dem Produkt, der Gebrauchs-
anleitung oder der Verpackung weist auf
diese Bestimmungen hin. Mit der Wieder-
verwertung, der stofichen Verwertung oder
anderen Formen der Verwertung von Altge-
räten/Batterien leisten Sie einen wichtigen
Beitrag zum Schutz unserer Umwelt.
Konformitätserklärung:
Hiermit erklärt die VARIA3 GmbH,
dass der varmo TZ eco Heiz-
körperthermostat der Richtlinie 2014/53/
EU entspricht. Der vollständige Text der
EU-Konformitätserklärung ist unter der fol-
genden Internetadresse verfügbar: https://
donexon.com.
Z-Wave und Z-Wave Plus sind eingetrage-
ne Warenzeichen der Sigma Designs.
Garantiehinweis
Die Garantiezeit beträgt 24 Monate und beginnt
am Tag des Kaufs. Bitte bewahren Sie den Kas-
senbon als Nachweis für den Kauf auf. Wäh-
rend der Garantiezeit können defekte Energie-
sparregler an unten stehende Serviceadresse
gesandt werden. Sie erhalten dann ein neues
oder repariertes Gerät kostenlos zurück. Mit
Reparatur oder Austausch des Gerätes beginnt
kein neuer Garantiezeitraum.
Bitte beachten Sie, dass wir nur Garantie
auf die Funktionen des Gerätes, nicht auf die
Temperatur
verringern
Temperatur
erhöhen
Boost-Taste/
Funktionen
DEUTSCH
Customer Service:
VARIA3 GmbH
Langenfelder Straße 108
36433 Bad Salzungen
E-Mail: [email protected]
Web: www.donexon.com
Stand: 2019/02
varmo TZ eco
Smart Radiator Thermostat

User manual and Guarantee
Please read this User Manual carefully be-
fore installing the varmo TZ eco thermostat
and store this manual for documentation.
Scope of delivery
1 varmo TZ eco energy saving controller
1 Operating instructions (part of the product)
1 Screw for adapter
3 adapter (Danfoss RA, RAV, RAVL)
2 batteries LR6 AA 1,5 V
Safety Instructions
• varmo TZ eco is designed for use in
buildings.
• Operate varmo TZ eco only as de-
scribed in the user manual.
• varmo TZ eco should only be put to use
in a dry and dust-free place, away from
direct sunlight.
• Do not keep using the device when
there is obvious damage.
• varmo TZ eco may not be rebuilt,
modied or opened.
Warning
Never recharge batteries, do not short
circuit them, do not take them apart - Risk
of explosion! Remove dead batteries from
the device immediately.
Do not use old and new batteries together.
Clean battery and device contacts before
inserting if necessary.
Keep batteries away from children. Avoid
contact with skin, eyes and mucous mem-
branes. In case of contact with battery
acid, rinse the affected areas immediately
with plenty of water, and seek medical
attention immediately.
Inserting / replacing batteries
Remove the battery cover by simply pulling
it off. Now insert the batteries. Pay attenti-
on to the correct polarity! At a later battery
change, the conguration of your varmo TZ
eco is maintained.
Controls-/ Display elements
Lights up if mechanical tasks are
ongoing.
Displays if the varmo TZ eco is includ-
ed.
Lights up if the Display shows the
Z-Wave NodeID.
Lights up if less than 15% battery is
remaining.
Lights up if child protection is set.
Displayed if the LCD shows a setpoint
temperature.
Displayed instead of °C Icon if the
varmo TZ eco is set to direct control
mode.
Including
Set your primary Z-Wave Controller to
inclusion mode and follow the steps.
1.Inclusion mode (Inclusion) is displayed
 Press Boost-Button
2.Display shows Node-ID
Inclusion completed
3.Installation mode is displayed
 Installation at the radiator
4.After succesful installation press the
green blinking button to start the adapti-
on. Once the adaptation is completed, the
display shows the setpoint temperature.
Mounting
After succesful inclusion the display shows
and the button is green blinking (don‘t
press it yet). Follow the steps for installation.
1.Turn the manual thermostat head up com-
pletely, loosen the fastening and pull the
thermostat off of the valve.
2.Use an appropriate adapter, if required,
and push it onto the valve.
3.Now, you put varmo TZ eco on the
connector.
 
valvevarmo TZ eco valveadaptervarmo TZ eco
If you are not sure which valve you have,
please visit: www.donexon.com/service
Here you will nd a list of various valves
and adapters.
Manual operation
Button/Interaction Result/Behavior
Press once Decrease room tempera-
ture by 0,5°C.
Press and
hold Decrease Room temperature by 0,5°C and lower the Room
temperature by 0,5°C every
0,5 seconds or until the
lowest temperature is set.
Press once Increase room temperature
by 0,5°C.
Press and
hold Increase Room temperature by 0,5°C and raise the Room
temperature by 0,5°C every
0,5 seconds or until the
highest temperature is set.
Push once • Conrm action which is
displayed in the LCD
•Switch into Boost-Mode
(Quick Heat)
•Quit Boost-mode (Quick
Heat) if currently active
Hold for 3
seconds The LCD shows the Z-Wave Node ID.
Hold for 5
seconds The varmo TZ eco will react to Inclusion/Exclusion
Commands.
C
Hold while
unpowered
and insert
batteries
Allows factory reset of the
varmo TZ eco.
Hold both si-
multaneously
for 3 seconds
Sets or clears the Child
protection.
Adapters
No adapter is required for the following
valves:
Heimeier, Junkers Landys+Gyr,
MNG, Honeywell, Braukmann
(each with thread size M 30x1,5)
No adapter
neccessary
Danfoss RAV (the pin supplied must
be attached to the valve plunger)
Danfoss RA
Danfoss RAVL
Warning
Remove the connecting pieces of the
plastic adapter completely before you use
one of the supplied adapter!
Info: For additional adaptors, please visit:
www.donexon.com
Removing
Exclude the varmo TZ eco from the network
before removing. Set Z-Wave Controller in
Exclusion mode. Hold the boost button for at
least 5 seconds to exclude. When this pro-
cess is nished, is again on the display.

Unscrew the cap nut and remove varmo TZ
eco off the valve.
Help and error messages
Error Cause/Solution
Batteries do not have enough power.
Replace batteries.
Heating
element
does not
warm up.
Is the boiler water temperature O.K.?
Valve does not open, is it calcied after
the summer pause/heating pause?
Adjust the temperature of the boiler
water. Remove the varmo TZ eco,
move the valveback and forth per hand
or with a tool.
Heating
element
does
not cool
down.
Valve does not close completely. It
may be that the closing point of your
valve seat has shifted.
Adapt again (see “Adapting”) Move
the valve stem several times by hand,
it may be that adaptation is impossible
because your valve is calci ed or the
seat no longer performs its function.
Pressure
piece falls
out (This
can also
cause an
E1-error).
Due to an endless thread the pres-
surepiece, which is situated at the
bottom, can fall out if the device has
not been afxed on the valve.
Put in the pressure piece. The device
can be adapted by removing and
inserting the batteries. The endless
thread is rotating now and xes the
pressure piece again. Just install it to
the radiator and adapt it once again.
ER1-ER3 The error code can be cleared by
pressing the boost button.
ERR Inclusion failed.
Z-Wave Controller out of range.
ER1 Valve positioning not possible.
Check if the valve is jammed.
ER2 Valve not detected.
Check if the varmo TZ eco is correc-
tly mounted.
ER3 Valves closing point not detected.
Check if the varmo TZ eco is correc-
tly mounted.
LEGAL NOTICE
Environmental protection:
From the date of implementation of
European guidelines 2012/19/EU into
national law, the following applies:
Electric and electronic devices and batteries
may not be disposed of in household waste.
The consumer is obliged to return electric and
electronic devices and batteries to the public
collection points established for them or to the
point of sale. The particulars of this are regu-
lated by the applicable state laws. The symbol
on the product, operation instructions or
packaging points to these provisions.
You make an important contribution to the
protection of the environment by reusing or
recycling old equipment/batteries or making
use of them in other ways.
Declaration of conformity:
Hereby, VARIA3 GmbH declares that
the varmo TZ eco Radiator Thermost-
at is in compliance with Directive 2014/53/EU.
The full text of the EU declaration of conformity
is available at the following internet address:
https://donexon.com/service.
Z-Wave and Z-Wave Plus are registered
trademarks of Sigma Designs and it is
subsidiaries in the United States and other
countries.
Warranty:
The two-year warranty begins on the day of
purchase. Please keep the receipt as evidence
of purchase in the future. During the guarantee
period, defective radiator thermostats may be
sent to the service address below. Please en-
sure sufcient postage is paid.
A new or repaired device will then be sent to
you free of charge. Following expiry of the gua-
rantee, you may still send the defective device
to the address below for repairs. Please ensure
sufcient postage is paid. Repairs carried out
after the guarantee period are subject to a
charge. Your legal rights are not affected by
this guarantee.
There is no new warranty period starting when
repairing or replacing the device. Please note
that we only grant warranty on the function
of the device. We will not grant warranty for
the interaction between the thermostat and
the bottom part of the valve. The technical
data is only valid for the use of the following
valves: Heimeier, Junkers Landys + Gyr, MNG,
Honeywell, Braukmann (measure of thread
M30 x 1,5), Oventrop (M30 x 1,5) Danfoss RA,
RAV and RAVL.
Please see the combinations of the devices
on our website (www.donexon.com/service
Adapter list) Eurotronic does not issue a gua-
rantee when using the thermostat with valves
which are not mentioned above.
Technical specications
Device short description: varmo TZ eco
EAN: 4251660900025
Supply Voltage: 2 x 1,5V LR6/Mignon/AA
Radio Frequency: 868,42 MHz
Connection: M30 x 1,5mm
Method of operation: Type 1
Dimensions (W x H x D): 56 x 68 x 89 mm
Weight: 176g (incl. batteries)
Degree of protection: IP20
Degree of pollution: 2
Output Power: +4dBm
Technical modications are subject to change.
ENGLISH
Funktionalität zwischen dem Zusammenspiel
des Thermostats und des Ventilunterteils ge-
ben. Die anwendungsbezogenen technischen
Daten sind ausschließlich zusammen mit den
Ventilen Heimeier, Junkers Landys+Gyr, MNG,
Honeywell Braukmann Gewindemaß (M30x1,5),
Oventrop (M30x1,5) Danfoss RA, RAV und RAVL
gewährleistet. Die Gerätekombinationen kön-
nen auf unserer Webseite (www.donexon.com)
entnommen werden.
Beim Betrieb des Thermostats mit Fremdventi-
len-/adaptern, die nicht aufgeführt sind, ist die
Funktionalität durch den Anwender sicherzu-
stellen. VARIA3 GmbH erbringt in diesen Fällen
keine Garantieleistung. Nach Ablauf der Garan-
tiezeit haben Sie ebenfalls die Möglichkeit, das
defekte Gerät zwecks Reparatur ausreichend
frankiert an die angegebene Adresse zu sen-
den. Nach Ablauf der Garantiezeit anfallende
Reparaturen sind kostenpichtig. Ihre gesetz-
lichen Rechte werden durch diese Garantie
nicht eingeschränkt.
Technische Änderungen jederzeit vorbehalten.
Decrease
Temperature
Increase
Temperature
Boost / Okay
Button for Task conrmation

User manual and Guarantee
Please read this User Manual carefully be-
fore installing the varmo TZ eco thermostat
and store this manual for documentation.
Scope of delivery
1 varmo TZ eco energy saving controller
1 Operating instructions (part of the product)
1 Screw for adapter
3 adapter (Danfoss RA, RAV, RAVL)
2 batteries LR6 AA 1,5 V
Safety Instructions
• varmo TZ eco is designed for use in
buildings.
• Operate varmo TZ eco only as de-
scribed in the user manual.
• varmo TZ eco should only be put to use
in a dry and dust-free place, away from
direct sunlight.
• Do not keep using the device when
there is obvious damage.
• varmo TZ eco may not be rebuilt,
modied or opened.
Warning
Never recharge batteries, do not short
circuit them, do not take them apart - Risk
of explosion! Remove dead batteries from
the device immediately.
Do not use old and new batteries together.
Clean battery and device contacts before
inserting if necessary.
Keep batteries away from children. Avoid
contact with skin, eyes and mucous mem-
branes. In case of contact with battery
acid, rinse the affected areas immediately
with plenty of water, and seek medical
attention immediately.
Inserting / replacing batteries
Remove the battery cover by simply pulling
it off. Now insert the batteries. Pay attenti-
on to the correct polarity! At a later battery
change, the conguration of your varmo TZ
eco is maintained.
Controls-/ Display elements
Lights up if mechanical tasks are
ongoing.
Displays if the varmo TZ eco is includ-
ed.
Lights up if the Display shows the
Z-Wave NodeID.
Lights up if less than 15% battery is
remaining.
Lights up if child protection is set.
Displayed if the LCD shows a setpoint
temperature.
Displayed instead of °C Icon if the
varmo TZ eco is set to direct control
mode.
Including
Set your primary Z-Wave Controller to
inclusion mode and follow the steps.
1.Inclusion mode (Inclusion) is displayed
 Press Boost-Button
2.Display shows Node-ID
Inclusion completed
3.Installation mode is displayed
 Installation at the radiator
4.After succesful installation press the
green blinking button to start the adapti-
on. Once the adaptation is completed, the
display shows the setpoint temperature.
Mounting
After succesful inclusion the display shows
and the button is green blinking (don‘t
press it yet). Follow the steps for installation.
1.Turn the manual thermostat head up com-
pletely, loosen the fastening and pull the
thermostat off of the valve.
2.Use an appropriate adapter, if required,
and push it onto the valve.
3.Now, you put varmo TZ eco on the
connector.
 
valvevarmo TZ eco valveadaptervarmo TZ eco
If you are not sure which valve you have,
please visit: www.donexon.com/service
Here you will nd a list of various valves
and adapters.
Manual operation
Button/Interaction Result/Behavior
Press once Decrease room tempera-
ture by 0,5°C.
Press and
hold Decrease Room temperature by 0,5°C and lower the Room
temperature by 0,5°C every
0,5 seconds or until the
lowest temperature is set.
Press once Increase room temperature
by 0,5°C.
Press and
hold Increase Room temperature by 0,5°C and raise the Room
temperature by 0,5°C every
0,5 seconds or until the
highest temperature is set.
Push once • Conrm action which is
displayed in the LCD
•Switch into Boost-Mode
(Quick Heat)
•Quit Boost-mode (Quick
Heat) if currently active
Hold for 3
seconds The LCD shows the Z-Wave Node ID.
Hold for 5
seconds The varmo TZ eco will react to Inclusion/Exclusion
Commands.
C
Hold while
unpowered
and insert
batteries
Allows factory reset of the
varmo TZ eco.
Hold both si-
multaneously
for 3 seconds
Sets or clears the Child
protection.
Adapters
No adapter is required for the following
valves:
Heimeier, Junkers Landys+Gyr,
MNG, Honeywell, Braukmann
(each with thread size M 30x1,5)
No adapter
neccessary
Danfoss RAV (the pin supplied must
be attached to the valve plunger)
Danfoss RA
Danfoss RAVL
Warning
Remove the connecting pieces of the
plastic adapter completely before you use
one of the supplied adapter!
Info: For additional adaptors, please visit:
www.donexon.com
Removing
Exclude the varmo TZ eco from the network
before removing. Set Z-Wave Controller in
Exclusion mode. Hold the boost button for at
least 5 seconds to exclude. When this pro-
cess is nished, is again on the display.

Unscrew the cap nut and remove varmo TZ
eco off the valve.
Help and error messages
Error Cause/Solution
Batteries do not have enough power.
Replace batteries.
Heating
element
does not
warm up.
Is the boiler water temperature O.K.?
Valve does not open, is it calcied after
the summer pause/heating pause?
Adjust the temperature of the boiler
water. Remove the varmo TZ eco,
move the valveback and forth per hand
or with a tool.
Heating
element
does
not cool
down.
Valve does not close completely. It
may be that the closing point of your
valve seat has shifted.
Adapt again (see “Adapting”) Move
the valve stem several times by hand,
it may be that adaptation is impossible
because your valve is calci ed or the
seat no longer performs its function.
Pressure
piece falls
out (This
can also
cause an
E1-error).
Due to an endless thread the pres-
surepiece, which is situated at the
bottom, can fall out if the device has
not been afxed on the valve.
Put in the pressure piece. The device
can be adapted by removing and
inserting the batteries. The endless
thread is rotating now and xes the
pressure piece again. Just install it to
the radiator and adapt it once again.
ER1-ER3 The error code can be cleared by
pressing the boost button.
ERR Inclusion failed.
Z-Wave Controller out of range.
ER1 Valve positioning not possible.
Check if the valve is jammed.
ER2 Valve not detected.
Check if the varmo TZ eco is correc-
tly mounted.
ER3 Valves closing point not detected.
Check if the varmo TZ eco is correc-
tly mounted.
LEGAL NOTICE
Environmental protection:
From the date of implementation of
European guidelines 2012/19/EU into
national law, the following applies:
Electric and electronic devices and batteries
may not be disposed of in household waste.
The consumer is obliged to return electric and
electronic devices and batteries to the public
collection points established for them or to the
point of sale. The particulars of this are regu-
lated by the applicable state laws. The symbol
on the product, operation instructions or
packaging points to these provisions.
You make an important contribution to the
protection of the environment by reusing or
recycling old equipment/batteries or making
use of them in other ways.
Declaration of conformity:
Hereby, VARIA3 GmbH declares that
the varmo TZ eco Radiator Thermost-
at is in compliance with Directive 2014/53/EU.
The full text of the EU declaration of conformity
is available at the following internet address:
https://donexon.com/service.
Z-Wave and Z-Wave Plus are registered
trademarks of Sigma Designs and it is
subsidiaries in the United States and other
countries.
Warranty:
The two-year warranty begins on the day of
purchase. Please keep the receipt as evidence
of purchase in the future. During the guarantee
period, defective radiator thermostats may be
sent to the service address below. Please en-
sure sufcient postage is paid.
A new or repaired device will then be sent to
you free of charge. Following expiry of the gua-
rantee, you may still send the defective device
to the address below for repairs. Please ensure
sufcient postage is paid. Repairs carried out
after the guarantee period are subject to a
charge. Your legal rights are not affected by
this guarantee.
There is no new warranty period starting when
repairing or replacing the device. Please note
that we only grant warranty on the function
of the device. We will not grant warranty for
the interaction between the thermostat and
the bottom part of the valve. The technical
data is only valid for the use of the following
valves: Heimeier, Junkers Landys + Gyr, MNG,
Honeywell, Braukmann (measure of thread
M30 x 1,5), Oventrop (M30 x 1,5) Danfoss RA,
RAV and RAVL.
Please see the combinations of the devices
on our website (www.donexon.com/service
Adapter list) Eurotronic does not issue a gua-
rantee when using the thermostat with valves
which are not mentioned above.
Technical specications
Device short description: varmo TZ eco
EAN: 4251660900025
Supply Voltage: 2 x 1,5V LR6/Mignon/AA
Radio Frequency: 868,42 MHz
Connection: M30 x 1,5mm
Method of operation: Type 1
Dimensions (W x H x D): 56 x 68 x 89 mm
Weight: 176g (incl. batteries)
Degree of protection: IP20
Degree of pollution: 2
Output Power: +4dBm
Technical modications are subject to change.
ENGLISH
Funktionalität zwischen dem Zusammenspiel
des Thermostats und des Ventilunterteils ge-
ben. Die anwendungsbezogenen technischen
Daten sind ausschließlich zusammen mit den
Ventilen Heimeier, Junkers Landys+Gyr, MNG,
Honeywell Braukmann Gewindemaß (M30x1,5),
Oventrop (M30x1,5) Danfoss RA, RAV und RAVL
gewährleistet. Die Gerätekombinationen kön-
nen auf unserer Webseite (www.donexon.com)
entnommen werden.
Beim Betrieb des Thermostats mit Fremdventi-
len-/adaptern, die nicht aufgeführt sind, ist die
Funktionalität durch den Anwender sicherzu-
stellen. VARIA3 GmbH erbringt in diesen Fällen
keine Garantieleistung. Nach Ablauf der Garan-
tiezeit haben Sie ebenfalls die Möglichkeit, das
defekte Gerät zwecks Reparatur ausreichend
frankiert an die angegebene Adresse zu sen-
den. Nach Ablauf der Garantiezeit anfallende
Reparaturen sind kostenpichtig. Ihre gesetz-
lichen Rechte werden durch diese Garantie
nicht eingeschränkt.
Technische Änderungen jederzeit vorbehalten.
Decrease
Temperature
Increase
Temperature
Boost / Okay
Button for Task conrmation

User manual and Guarantee
Please read this User Manual carefully be-
fore installing the varmo TZ eco thermostat
and store this manual for documentation.
Scope of delivery
1 varmo TZ eco energy saving controller
1 Operating instructions (part of the product)
1 Screw for adapter
3 adapter (Danfoss RA, RAV, RAVL)
2 batteries LR6 AA 1,5 V
Safety Instructions
• varmo TZ eco is designed for use in
buildings.
• Operate varmo TZ eco only as de-
scribed in the user manual.
• varmo TZ eco should only be put to use
in a dry and dust-free place, away from
direct sunlight.
• Do not keep using the device when
there is obvious damage.
• varmo TZ eco may not be rebuilt,
modied or opened.
Warning
Never recharge batteries, do not short
circuit them, do not take them apart - Risk
of explosion! Remove dead batteries from
the device immediately.
Do not use old and new batteries together.
Clean battery and device contacts before
inserting if necessary.
Keep batteries away from children. Avoid
contact with skin, eyes and mucous mem-
branes. In case of contact with battery
acid, rinse the affected areas immediately
with plenty of water, and seek medical
attention immediately.
Inserting / replacing batteries
Remove the battery cover by simply pulling
it off. Now insert the batteries. Pay attenti-
on to the correct polarity! At a later battery
change, the conguration of your varmo TZ
eco is maintained.
Controls-/ Display elements
Lights up if mechanical tasks are
ongoing.
Displays if the varmo TZ eco is includ-
ed.
Lights up if the Display shows the
Z-Wave NodeID.
Lights up if less than 15% battery is
remaining.
Lights up if child protection is set.
Displayed if the LCD shows a setpoint
temperature.
Displayed instead of °C Icon if the
varmo TZ eco is set to direct control
mode.
Including
Set your primary Z-Wave Controller to
inclusion mode and follow the steps.
1.Inclusion mode (Inclusion) is displayed
 Press Boost-Button
2.Display shows Node-ID
Inclusion completed
3.Installation mode is displayed
 Installation at the radiator
4.After succesful installation press the
green blinking button to start the adapti-
on. Once the adaptation is completed, the
display shows the setpoint temperature.
Mounting
After succesful inclusion the display shows
and the button is green blinking (don‘t
press it yet). Follow the steps for installation.
1.Turn the manual thermostat head up com-
pletely, loosen the fastening and pull the
thermostat off of the valve.
2.Use an appropriate adapter, if required,
and push it onto the valve.
3.Now, you put varmo TZ eco on the
connector.
 
valvevarmo TZ eco valveadaptervarmo TZ eco
If you are not sure which valve you have,
please visit: www.donexon.com/service
Here you will nd a list of various valves
and adapters.
Manual operation
Button/Interaction Result/Behavior
Press once Decrease room tempera-
ture by 0,5°C.
Press and
hold Decrease Room temperature by 0,5°C and lower the Room
temperature by 0,5°C every
0,5 seconds or until the
lowest temperature is set.
Press once Increase room temperature
by 0,5°C.
Press and
hold Increase Room temperature by 0,5°C and raise the Room
temperature by 0,5°C every
0,5 seconds or until the
highest temperature is set.
Push once • Conrm action which is
displayed in the LCD
•Switch into Boost-Mode
(Quick Heat)
•Quit Boost-mode (Quick
Heat) if currently active
Hold for 3
seconds The LCD shows the Z-Wave Node ID.
Hold for 5
seconds The varmo TZ eco will react to Inclusion/Exclusion
Commands.
C
Hold while
unpowered
and insert
batteries
Allows factory reset of the
varmo TZ eco.
Hold both si-
multaneously
for 3 seconds
Sets or clears the Child
protection.
Adapters
No adapter is required for the following
valves:
Heimeier, Junkers Landys+Gyr,
MNG, Honeywell, Braukmann
(each with thread size M 30x1,5)
No adapter
neccessary
Danfoss RAV (the pin supplied must
be attached to the valve plunger)
Danfoss RA
Danfoss RAVL
Warning
Remove the connecting pieces of the
plastic adapter completely before you use
one of the supplied adapter!
Info: For additional adaptors, please visit:
www.donexon.com
Removing
Exclude the varmo TZ eco from the network
before removing. Set Z-Wave Controller in
Exclusion mode. Hold the boost button for at
least 5 seconds to exclude. When this pro-
cess is nished, is again on the display.

Unscrew the cap nut and remove varmo TZ
eco off the valve.
Help and error messages
Error Cause/Solution
Batteries do not have enough power.
Replace batteries.
Heating
element
does not
warm up.
Is the boiler water temperature O.K.?
Valve does not open, is it calcied after
the summer pause/heating pause?
Adjust the temperature of the boiler
water. Remove the varmo TZ eco,
move the valveback and forth per hand
or with a tool.
Heating
element
does
not cool
down.
Valve does not close completely. It
may be that the closing point of your
valve seat has shifted.
Adapt again (see “Adapting”) Move
the valve stem several times by hand,
it may be that adaptation is impossible
because your valve is calci ed or the
seat no longer performs its function.
Pressure
piece falls
out (This
can also
cause an
E1-error).
Due to an endless thread the pres-
surepiece, which is situated at the
bottom, can fall out if the device has
not been afxed on the valve.
Put in the pressure piece. The device
can be adapted by removing and
inserting the batteries. The endless
thread is rotating now and xes the
pressure piece again. Just install it to
the radiator and adapt it once again.
ER1-ER3 The error code can be cleared by
pressing the boost button.
ERR Inclusion failed.
Z-Wave Controller out of range.
ER1 Valve positioning not possible.
Check if the valve is jammed.
ER2 Valve not detected.
Check if the varmo TZ eco is correc-
tly mounted.
ER3 Valves closing point not detected.
Check if the varmo TZ eco is correc-
tly mounted.
LEGAL NOTICE
Environmental protection:
From the date of implementation of
European guidelines 2012/19/EU into
national law, the following applies:
Electric and electronic devices and batteries
may not be disposed of in household waste.
The consumer is obliged to return electric and
electronic devices and batteries to the public
collection points established for them or to the
point of sale. The particulars of this are regu-
lated by the applicable state laws. The symbol
on the product, operation instructions or
packaging points to these provisions.
You make an important contribution to the
protection of the environment by reusing or
recycling old equipment/batteries or making
use of them in other ways.
Declaration of conformity:
Hereby, VARIA3 GmbH declares that
the varmo TZ eco Radiator Thermost-
at is in compliance with Directive 2014/53/EU.
The full text of the EU declaration of conformity
is available at the following internet address:
https://donexon.com/service.
Z-Wave and Z-Wave Plus are registered
trademarks of Sigma Designs and it is
subsidiaries in the United States and other
countries.
Warranty:
The two-year warranty begins on the day of
purchase. Please keep the receipt as evidence
of purchase in the future. During the guarantee
period, defective radiator thermostats may be
sent to the service address below. Please en-
sure sufcient postage is paid.
A new or repaired device will then be sent to
you free of charge. Following expiry of the gua-
rantee, you may still send the defective device
to the address below for repairs. Please ensure
sufcient postage is paid. Repairs carried out
after the guarantee period are subject to a
charge. Your legal rights are not affected by
this guarantee.
There is no new warranty period starting when
repairing or replacing the device. Please note
that we only grant warranty on the function
of the device. We will not grant warranty for
the interaction between the thermostat and
the bottom part of the valve. The technical
data is only valid for the use of the following
valves: Heimeier, Junkers Landys + Gyr, MNG,
Honeywell, Braukmann (measure of thread
M30 x 1,5), Oventrop (M30 x 1,5) Danfoss RA,
RAV and RAVL.
Please see the combinations of the devices
on our website (www.donexon.com/service
Adapter list) Eurotronic does not issue a gua-
rantee when using the thermostat with valves
which are not mentioned above.
Technical specications
Device short description: varmo TZ eco
EAN: 4251660900025
Supply Voltage: 2 x 1,5V LR6/Mignon/AA
Radio Frequency: 868,42 MHz
Connection: M30 x 1,5mm
Method of operation: Type 1
Dimensions (W x H x D): 56 x 68 x 89 mm
Weight: 176g (incl. batteries)
Degree of protection: IP20
Degree of pollution: 2
Output Power: +4dBm
Technical modications are subject to change.
ENGLISH
Funktionalität zwischen dem Zusammenspiel
des Thermostats und des Ventilunterteils ge-
ben. Die anwendungsbezogenen technischen
Daten sind ausschließlich zusammen mit den
Ventilen Heimeier, Junkers Landys+Gyr, MNG,
Honeywell Braukmann Gewindemaß (M30x1,5),
Oventrop (M30x1,5) Danfoss RA, RAV und RAVL
gewährleistet. Die Gerätekombinationen kön-
nen auf unserer Webseite (www.donexon.com)
entnommen werden.
Beim Betrieb des Thermostats mit Fremdventi-
len-/adaptern, die nicht aufgeführt sind, ist die
Funktionalität durch den Anwender sicherzu-
stellen. VARIA3 GmbH erbringt in diesen Fällen
keine Garantieleistung. Nach Ablauf der Garan-
tiezeit haben Sie ebenfalls die Möglichkeit, das
defekte Gerät zwecks Reparatur ausreichend
frankiert an die angegebene Adresse zu sen-
den. Nach Ablauf der Garantiezeit anfallende
Reparaturen sind kostenpichtig. Ihre gesetz-
lichen Rechte werden durch diese Garantie
nicht eingeschränkt.
Technische Änderungen jederzeit vorbehalten.
Decrease
Temperature
Increase
Temperature
Boost / Okay
Button for Task conrmation

User manual and Guarantee
Please read this User Manual carefully be-
fore installing the varmo TZ eco thermostat
and store this manual for documentation.
Scope of delivery
1 varmo TZ eco energy saving controller
1 Operating instructions (part of the product)
1 Screw for adapter
3 adapter (Danfoss RA, RAV, RAVL)
2 batteries LR6 AA 1,5 V
Safety Instructions
• varmo TZ eco is designed for use in
buildings.
• Operate varmo TZ eco only as de-
scribed in the user manual.
• varmo TZ eco should only be put to use
in a dry and dust-free place, away from
direct sunlight.
• Do not keep using the device when
there is obvious damage.
• varmo TZ eco may not be rebuilt,
modied or opened.
Warning
Never recharge batteries, do not short
circuit them, do not take them apart - Risk
of explosion! Remove dead batteries from
the device immediately.
Do not use old and new batteries together.
Clean battery and device contacts before
inserting if necessary.
Keep batteries away from children. Avoid
contact with skin, eyes and mucous mem-
branes. In case of contact with battery
acid, rinse the affected areas immediately
with plenty of water, and seek medical
attention immediately.
Inserting / replacing batteries
Remove the battery cover by simply pulling
it off. Now insert the batteries. Pay attenti-
on to the correct polarity! At a later battery
change, the conguration of your varmo TZ
eco is maintained.
Controls-/ Display elements
Lights up if mechanical tasks are
ongoing.
Displays if the varmo TZ eco is includ-
ed.
Lights up if the Display shows the
Z-Wave NodeID.
Lights up if less than 15% battery is
remaining.
Lights up if child protection is set.
Displayed if the LCD shows a setpoint
temperature.
Displayed instead of °C Icon if the
varmo TZ eco is set to direct control
mode.
Including
Set your primary Z-Wave Controller to
inclusion mode and follow the steps.
1.Inclusion mode (Inclusion) is displayed
 Press Boost-Button
2.Display shows Node-ID
Inclusion completed
3.Installation mode is displayed
 Installation at the radiator
4.After succesful installation press the
green blinking button to start the adapti-
on. Once the adaptation is completed, the
display shows the setpoint temperature.
Mounting
After succesful inclusion the display shows
and the button is green blinking (don‘t
press it yet). Follow the steps for installation.
1.Turn the manual thermostat head up com-
pletely, loosen the fastening and pull the
thermostat off of the valve.
2.Use an appropriate adapter, if required,
and push it onto the valve.
3.Now, you put varmo TZ eco on the
connector.
 
valvevarmo TZ eco valveadaptervarmo TZ eco
If you are not sure which valve you have,
please visit: www.donexon.com/service
Here you will nd a list of various valves
and adapters.
Manual operation
Button/Interaction Result/Behavior
Press once Decrease room tempera-
ture by 0,5°C.
Press and
hold Decrease Room temperature by 0,5°C and lower the Room
temperature by 0,5°C every
0,5 seconds or until the
lowest temperature is set.
Press once Increase room temperature
by 0,5°C.
Press and
hold Increase Room temperature by 0,5°C and raise the Room
temperature by 0,5°C every
0,5 seconds or until the
highest temperature is set.
Push once • Conrm action which is
displayed in the LCD
•Switch into Boost-Mode
(Quick Heat)
•Quit Boost-mode (Quick
Heat) if currently active
Hold for 3
seconds The LCD shows the Z-Wave Node ID.
Hold for 5
seconds The varmo TZ eco will react to Inclusion/Exclusion
Commands.
C
Hold while
unpowered
and insert
batteries
Allows factory reset of the
varmo TZ eco.
Hold both si-
multaneously
for 3 seconds
Sets or clears the Child
protection.
Adapters
No adapter is required for the following
valves:
Heimeier, Junkers Landys+Gyr,
MNG, Honeywell, Braukmann
(each with thread size M 30x1,5)
No adapter
neccessary
Danfoss RAV (the pin supplied must
be attached to the valve plunger)
Danfoss RA
Danfoss RAVL
Warning
Remove the connecting pieces of the
plastic adapter completely before you use
one of the supplied adapter!
Info: For additional adaptors, please visit:
www.donexon.com
Removing
Exclude the varmo TZ eco from the network
before removing. Set Z-Wave Controller in
Exclusion mode. Hold the boost button for at
least 5 seconds to exclude. When this pro-
cess is nished, is again on the display.

Unscrew the cap nut and remove varmo TZ
eco off the valve.
Help and error messages
Error Cause/Solution
Batteries do not have enough power.
Replace batteries.
Heating
element
does not
warm up.
Is the boiler water temperature O.K.?
Valve does not open, is it calcied after
the summer pause/heating pause?
Adjust the temperature of the boiler
water. Remove the varmo TZ eco,
move the valveback and forth per hand
or with a tool.
Heating
element
does
not cool
down.
Valve does not close completely. It
may be that the closing point of your
valve seat has shifted.
Adapt again (see “Adapting”) Move
the valve stem several times by hand,
it may be that adaptation is impossible
because your valve is calci ed or the
seat no longer performs its function.
Pressure
piece falls
out (This
can also
cause an
E1-error).
Due to an endless thread the pres-
surepiece, which is situated at the
bottom, can fall out if the device has
not been afxed on the valve.
Put in the pressure piece. The device
can be adapted by removing and
inserting the batteries. The endless
thread is rotating now and xes the
pressure piece again. Just install it to
the radiator and adapt it once again.
ER1-ER3 The error code can be cleared by
pressing the boost button.
ERR Inclusion failed.
Z-Wave Controller out of range.
ER1 Valve positioning not possible.
Check if the valve is jammed.
ER2 Valve not detected.
Check if the varmo TZ eco is correc-
tly mounted.
ER3 Valves closing point not detected.
Check if the varmo TZ eco is correc-
tly mounted.
LEGAL NOTICE
Environmental protection:
From the date of implementation of
European guidelines 2012/19/EU into
national law, the following applies:
Electric and electronic devices and batteries
may not be disposed of in household waste.
The consumer is obliged to return electric and
electronic devices and batteries to the public
collection points established for them or to the
point of sale. The particulars of this are regu-
lated by the applicable state laws. The symbol
on the product, operation instructions or
packaging points to these provisions.
You make an important contribution to the
protection of the environment by reusing or
recycling old equipment/batteries or making
use of them in other ways.
Declaration of conformity:
Hereby, VARIA3 GmbH declares that
the varmo TZ eco Radiator Thermost-
at is in compliance with Directive 2014/53/EU.
The full text of the EU declaration of conformity
is available at the following internet address:
https://donexon.com/service.
Z-Wave and Z-Wave Plus are registered
trademarks of Sigma Designs and it is
subsidiaries in the United States and other
countries.
Warranty:
The two-year warranty begins on the day of
purchase. Please keep the receipt as evidence
of purchase in the future. During the guarantee
period, defective radiator thermostats may be
sent to the service address below. Please en-
sure sufcient postage is paid.
A new or repaired device will then be sent to
you free of charge. Following expiry of the gua-
rantee, you may still send the defective device
to the address below for repairs. Please ensure
sufcient postage is paid. Repairs carried out
after the guarantee period are subject to a
charge. Your legal rights are not affected by
this guarantee.
There is no new warranty period starting when
repairing or replacing the device. Please note
that we only grant warranty on the function
of the device. We will not grant warranty for
the interaction between the thermostat and
the bottom part of the valve. The technical
data is only valid for the use of the following
valves: Heimeier, Junkers Landys + Gyr, MNG,
Honeywell, Braukmann (measure of thread
M30 x 1,5), Oventrop (M30 x 1,5) Danfoss RA,
RAV and RAVL.
Please see the combinations of the devices
on our website (www.donexon.com/service
Adapter list) Eurotronic does not issue a gua-
rantee when using the thermostat with valves
which are not mentioned above.
Technical specications
Device short description: varmo TZ eco
EAN: 4251660900025
Supply Voltage: 2 x 1,5V LR6/Mignon/AA
Radio Frequency: 868,42 MHz
Connection: M30 x 1,5mm
Method of operation: Type 1
Dimensions (W x H x D): 56 x 68 x 89 mm
Weight: 176g (incl. batteries)
Degree of protection: IP20
Degree of pollution: 2
Output Power: +4dBm
Technical modications are subject to change.
ENGLISH
Funktionalität zwischen dem Zusammenspiel
des Thermostats und des Ventilunterteils ge-
ben. Die anwendungsbezogenen technischen
Daten sind ausschließlich zusammen mit den
Ventilen Heimeier, Junkers Landys+Gyr, MNG,
Honeywell Braukmann Gewindemaß (M30x1,5),
Oventrop (M30x1,5) Danfoss RA, RAV und RAVL
gewährleistet. Die Gerätekombinationen kön-
nen auf unserer Webseite (www.donexon.com)
entnommen werden.
Beim Betrieb des Thermostats mit Fremdventi-
len-/adaptern, die nicht aufgeführt sind, ist die
Funktionalität durch den Anwender sicherzu-
stellen. VARIA3 GmbH erbringt in diesen Fällen
keine Garantieleistung. Nach Ablauf der Garan-
tiezeit haben Sie ebenfalls die Möglichkeit, das
defekte Gerät zwecks Reparatur ausreichend
frankiert an die angegebene Adresse zu sen-
den. Nach Ablauf der Garantiezeit anfallende
Reparaturen sind kostenpichtig. Ihre gesetz-
lichen Rechte werden durch diese Garantie
nicht eingeschränkt.
Technische Änderungen jederzeit vorbehalten.
Decrease
Temperature
Increase
Temperature
Boost / Okay
Button for Task conrmation

User manual and Guarantee
Please read this User Manual carefully be-
fore installing the varmo TZ eco thermostat
and store this manual for documentation.
Scope of delivery
1 varmo TZ eco energy saving controller
1 Operating instructions (part of the product)
1 Screw for adapter
3 adapter (Danfoss RA, RAV, RAVL)
2 batteries LR6 AA 1,5 V
Safety Instructions
• varmo TZ eco is designed for use in
buildings.
• Operate varmo TZ eco only as de-
scribed in the user manual.
• varmo TZ eco should only be put to use
in a dry and dust-free place, away from
direct sunlight.
• Do not keep using the device when
there is obvious damage.
• varmo TZ eco may not be rebuilt,
modied or opened.
Warning
Never recharge batteries, do not short
circuit them, do not take them apart - Risk
of explosion! Remove dead batteries from
the device immediately.
Do not use old and new batteries together.
Clean battery and device contacts before
inserting if necessary.
Keep batteries away from children. Avoid
contact with skin, eyes and mucous mem-
branes. In case of contact with battery
acid, rinse the affected areas immediately
with plenty of water, and seek medical
attention immediately.
Inserting / replacing batteries
Remove the battery cover by simply pulling
it off. Now insert the batteries. Pay attenti-
on to the correct polarity! At a later battery
change, the conguration of your varmo TZ
eco is maintained.
Controls-/ Display elements
Lights up if mechanical tasks are
ongoing.
Displays if the varmo TZ eco is includ-
ed.
Lights up if the Display shows the
Z-Wave NodeID.
Lights up if less than 15% battery is
remaining.
Lights up if child protection is set.
Displayed if the LCD shows a setpoint
temperature.
Displayed instead of °C Icon if the
varmo TZ eco is set to direct control
mode.
Including
Set your primary Z-Wave Controller to
inclusion mode and follow the steps.
1.Inclusion mode (Inclusion) is displayed
 Press Boost-Button
2.Display shows Node-ID
Inclusion completed
3.Installation mode is displayed
 Installation at the radiator
4.After succesful installation press the
green blinking button to start the adapti-
on. Once the adaptation is completed, the
display shows the setpoint temperature.
Mounting
After succesful inclusion the display shows
and the button is green blinking (don‘t
press it yet). Follow the steps for installation.
1.Turn the manual thermostat head up com-
pletely, loosen the fastening and pull the
thermostat off of the valve.
2.Use an appropriate adapter, if required,
and push it onto the valve.
3.Now, you put varmo TZ eco on the
connector.
 
valvevarmo TZ eco valveadaptervarmo TZ eco
If you are not sure which valve you have,
please visit: www.donexon.com/service
Here you will nd a list of various valves
and adapters.
Manual operation
Button/Interaction Result/Behavior
Press once Decrease room tempera-
ture by 0,5°C.
Press and
hold Decrease Room temperature by 0,5°C and lower the Room
temperature by 0,5°C every
0,5 seconds or until the
lowest temperature is set.
Press once Increase room temperature
by 0,5°C.
Press and
hold Increase Room temperature by 0,5°C and raise the Room
temperature by 0,5°C every
0,5 seconds or until the
highest temperature is set.
Push once • Conrm action which is
displayed in the LCD
•Switch into Boost-Mode
(Quick Heat)
•Quit Boost-mode (Quick
Heat) if currently active
Hold for 3
seconds The LCD shows the Z-Wave Node ID.
Hold for 5
seconds The varmo TZ eco will react to Inclusion/Exclusion
Commands.
C
Hold while
unpowered
and insert
batteries
Allows factory reset of the
varmo TZ eco.
Hold both si-
multaneously
for 3 seconds
Sets or clears the Child
protection.
Adapters
No adapter is required for the following
valves:
Heimeier, Junkers Landys+Gyr,
MNG, Honeywell, Braukmann
(each with thread size M 30x1,5)
No adapter
neccessary
Danfoss RAV (the pin supplied must
be attached to the valve plunger)
Danfoss RA
Danfoss RAVL
Warning
Remove the connecting pieces of the
plastic adapter completely before you use
one of the supplied adapter!
Info: For additional adaptors, please visit:
www.donexon.com
Removing
Exclude the varmo TZ eco from the network
before removing. Set Z-Wave Controller in
Exclusion mode. Hold the boost button for at
least 5 seconds to exclude. When this pro-
cess is nished, is again on the display.

Unscrew the cap nut and remove varmo TZ
eco off the valve.
Help and error messages
Error Cause/Solution
Batteries do not have enough power.
Replace batteries.
Heating
element
does not
warm up.
Is the boiler water temperature O.K.?
Valve does not open, is it calcied after
the summer pause/heating pause?
Adjust the temperature of the boiler
water. Remove the varmo TZ eco,
move the valveback and forth per hand
or with a tool.
Heating
element
does
not cool
down.
Valve does not close completely. It
may be that the closing point of your
valve seat has shifted.
Adapt again (see “Adapting”) Move
the valve stem several times by hand,
it may be that adaptation is impossible
because your valve is calci ed or the
seat no longer performs its function.
Pressure
piece falls
out (This
can also
cause an
E1-error).
Due to an endless thread the pres-
surepiece, which is situated at the
bottom, can fall out if the device has
not been afxed on the valve.
Put in the pressure piece. The device
can be adapted by removing and
inserting the batteries. The endless
thread is rotating now and xes the
pressure piece again. Just install it to
the radiator and adapt it once again.
ER1-ER3 The error code can be cleared by
pressing the boost button.
ERR Inclusion failed.
Z-Wave Controller out of range.
ER1 Valve positioning not possible.
Check if the valve is jammed.
ER2 Valve not detected.
Check if the varmo TZ eco is correc-
tly mounted.
ER3 Valves closing point not detected.
Check if the varmo TZ eco is correc-
tly mounted.
LEGAL NOTICE
Environmental protection:
From the date of implementation of
European guidelines 2012/19/EU into
national law, the following applies:
Electric and electronic devices and batteries
may not be disposed of in household waste.
The consumer is obliged to return electric and
electronic devices and batteries to the public
collection points established for them or to the
point of sale. The particulars of this are regu-
lated by the applicable state laws. The symbol
on the product, operation instructions or
packaging points to these provisions.
You make an important contribution to the
protection of the environment by reusing or
recycling old equipment/batteries or making
use of them in other ways.
Declaration of conformity:
Hereby, VARIA3 GmbH declares that
the varmo TZ eco Radiator Thermost-
at is in compliance with Directive 2014/53/EU.
The full text of the EU declaration of conformity
is available at the following internet address:
https://donexon.com/service.
Z-Wave and Z-Wave Plus are registered
trademarks of Sigma Designs and it is
subsidiaries in the United States and other
countries.
Warranty:
The two-year warranty begins on the day of
purchase. Please keep the receipt as evidence
of purchase in the future. During the guarantee
period, defective radiator thermostats may be
sent to the service address below. Please en-
sure sufcient postage is paid.
A new or repaired device will then be sent to
you free of charge. Following expiry of the gua-
rantee, you may still send the defective device
to the address below for repairs. Please ensure
sufcient postage is paid. Repairs carried out
after the guarantee period are subject to a
charge. Your legal rights are not affected by
this guarantee.
There is no new warranty period starting when
repairing or replacing the device. Please note
that we only grant warranty on the function
of the device. We will not grant warranty for
the interaction between the thermostat and
the bottom part of the valve. The technical
data is only valid for the use of the following
valves: Heimeier, Junkers Landys + Gyr, MNG,
Honeywell, Braukmann (measure of thread
M30 x 1,5), Oventrop (M30 x 1,5) Danfoss RA,
RAV and RAVL.
Please see the combinations of the devices
on our website (www.donexon.com/service
Adapter list) Eurotronic does not issue a gua-
rantee when using the thermostat with valves
which are not mentioned above.
Technical specications
Device short description: varmo TZ eco
EAN: 4251660900025
Supply Voltage: 2 x 1,5V LR6/Mignon/AA
Radio Frequency: 868,42 MHz
Connection: M30 x 1,5mm
Method of operation: Type 1
Dimensions (W x H x D): 56 x 68 x 89 mm
Weight: 176g (incl. batteries)
Degree of protection: IP20
Degree of pollution: 2
Output Power: +4dBm
Technical modications are subject to change.
ENGLISH
Funktionalität zwischen dem Zusammenspiel
des Thermostats und des Ventilunterteils ge-
ben. Die anwendungsbezogenen technischen
Daten sind ausschließlich zusammen mit den
Ventilen Heimeier, Junkers Landys+Gyr, MNG,
Honeywell Braukmann Gewindemaß (M30x1,5),
Oventrop (M30x1,5) Danfoss RA, RAV und RAVL
gewährleistet. Die Gerätekombinationen kön-
nen auf unserer Webseite (www.donexon.com)
entnommen werden.
Beim Betrieb des Thermostats mit Fremdventi-
len-/adaptern, die nicht aufgeführt sind, ist die
Funktionalität durch den Anwender sicherzu-
stellen. VARIA3 GmbH erbringt in diesen Fällen
keine Garantieleistung. Nach Ablauf der Garan-
tiezeit haben Sie ebenfalls die Möglichkeit, das
defekte Gerät zwecks Reparatur ausreichend
frankiert an die angegebene Adresse zu sen-
den. Nach Ablauf der Garantiezeit anfallende
Reparaturen sind kostenpichtig. Ihre gesetz-
lichen Rechte werden durch diese Garantie
nicht eingeschränkt.
Technische Änderungen jederzeit vorbehalten.
Decrease
Temperature
Increase
Temperature
Boost / Okay
Button for Task conrmation

User manual and Guarantee
Please read this User Manual carefully be-
fore installing the varmo TZ eco thermostat
and store this manual for documentation.
Scope of delivery
1 varmo TZ eco energy saving controller
1 Operating instructions (part of the product)
1 Screw for adapter
3 adapter (Danfoss RA, RAV, RAVL)
2 batteries LR6 AA 1,5 V
Safety Instructions
• varmo TZ eco is designed for use in
buildings.
• Operate varmo TZ eco only as de-
scribed in the user manual.
• varmo TZ eco should only be put to use
in a dry and dust-free place, away from
direct sunlight.
• Do not keep using the device when
there is obvious damage.
• varmo TZ eco may not be rebuilt,
modied or opened.
Warning
Never recharge batteries, do not short
circuit them, do not take them apart - Risk
of explosion! Remove dead batteries from
the device immediately.
Do not use old and new batteries together.
Clean battery and device contacts before
inserting if necessary.
Keep batteries away from children. Avoid
contact with skin, eyes and mucous mem-
branes. In case of contact with battery
acid, rinse the affected areas immediately
with plenty of water, and seek medical
attention immediately.
Inserting / replacing batteries
Remove the battery cover by simply pulling
it off. Now insert the batteries. Pay attenti-
on to the correct polarity! At a later battery
change, the conguration of your varmo TZ
eco is maintained.
Controls-/ Display elements
Lights up if mechanical tasks are
ongoing.
Displays if the varmo TZ eco is includ-
ed.
Lights up if the Display shows the
Z-Wave NodeID.
Lights up if less than 15% battery is
remaining.
Lights up if child protection is set.
Displayed if the LCD shows a setpoint
temperature.
Displayed instead of °C Icon if the
varmo TZ eco is set to direct control
mode.
Including
Set your primary Z-Wave Controller to
inclusion mode and follow the steps.
1.Inclusion mode (Inclusion) is displayed
 Press Boost-Button
2.Display shows Node-ID
Inclusion completed
3.Installation mode is displayed
 Installation at the radiator
4.After succesful installation press the
green blinking button to start the adapti-
on. Once the adaptation is completed, the
display shows the setpoint temperature.
Mounting
After succesful inclusion the display shows
and the button is green blinking (don‘t
press it yet). Follow the steps for installation.
1.Turn the manual thermostat head up com-
pletely, loosen the fastening and pull the
thermostat off of the valve.
2.Use an appropriate adapter, if required,
and push it onto the valve.
3.Now, you put varmo TZ eco on the
connector.
 
valvevarmo TZ eco valveadaptervarmo TZ eco
If you are not sure which valve you have,
please visit: www.donexon.com/service
Here you will nd a list of various valves
and adapters.
Manual operation
Button/Interaction Result/Behavior
Press once Decrease room tempera-
ture by 0,5°C.
Press and
hold Decrease Room temperature by 0,5°C and lower the Room
temperature by 0,5°C every
0,5 seconds or until the
lowest temperature is set.
Press once Increase room temperature
by 0,5°C.
Press and
hold Increase Room temperature by 0,5°C and raise the Room
temperature by 0,5°C every
0,5 seconds or until the
highest temperature is set.
Push once • Conrm action which is
displayed in the LCD
•Switch into Boost-Mode
(Quick Heat)
•Quit Boost-mode (Quick
Heat) if currently active
Hold for 3
seconds The LCD shows the Z-Wave Node ID.
Hold for 5
seconds The varmo TZ eco will react to Inclusion/Exclusion
Commands.
C
Hold while
unpowered
and insert
batteries
Allows factory reset of the
varmo TZ eco.
Hold both si-
multaneously
for 3 seconds
Sets or clears the Child
protection.
Adapters
No adapter is required for the following
valves:
Heimeier, Junkers Landys+Gyr,
MNG, Honeywell, Braukmann
(each with thread size M 30x1,5)
No adapter
neccessary
Danfoss RAV (the pin supplied must
be attached to the valve plunger)
Danfoss RA
Danfoss RAVL
Warning
Remove the connecting pieces of the
plastic adapter completely before you use
one of the supplied adapter!
Info: For additional adaptors, please visit:
www.donexon.com
Removing
Exclude the varmo TZ eco from the network
before removing. Set Z-Wave Controller in
Exclusion mode. Hold the boost button for at
least 5 seconds to exclude. When this pro-
cess is nished, is again on the display.

Unscrew the cap nut and remove varmo TZ
eco off the valve.
Help and error messages
Error Cause/Solution
Batteries do not have enough power.
Replace batteries.
Heating
element
does not
warm up.
Is the boiler water temperature O.K.?
Valve does not open, is it calcied after
the summer pause/heating pause?
Adjust the temperature of the boiler
water. Remove the varmo TZ eco,
move the valveback and forth per hand
or with a tool.
Heating
element
does
not cool
down.
Valve does not close completely. It
may be that the closing point of your
valve seat has shifted.
Adapt again (see “Adapting”) Move
the valve stem several times by hand,
it may be that adaptation is impossible
because your valve is calci ed or the
seat no longer performs its function.
Pressure
piece falls
out (This
can also
cause an
E1-error).
Due to an endless thread the pres-
surepiece, which is situated at the
bottom, can fall out if the device has
not been afxed on the valve.
Put in the pressure piece. The device
can be adapted by removing and
inserting the batteries. The endless
thread is rotating now and xes the
pressure piece again. Just install it to
the radiator and adapt it once again.
ER1-ER3 The error code can be cleared by
pressing the boost button.
ERR Inclusion failed.
Z-Wave Controller out of range.
ER1 Valve positioning not possible.
Check if the valve is jammed.
ER2 Valve not detected.
Check if the varmo TZ eco is correc-
tly mounted.
ER3 Valves closing point not detected.
Check if the varmo TZ eco is correc-
tly mounted.
LEGAL NOTICE
Environmental protection:
From the date of implementation of
European guidelines 2012/19/EU into
national law, the following applies:
Electric and electronic devices and batteries
may not be disposed of in household waste.
The consumer is obliged to return electric and
electronic devices and batteries to the public
collection points established for them or to the
point of sale. The particulars of this are regu-
lated by the applicable state laws. The symbol
on the product, operation instructions or
packaging points to these provisions.
You make an important contribution to the
protection of the environment by reusing or
recycling old equipment/batteries or making
use of them in other ways.
Declaration of conformity:
Hereby, VARIA3 GmbH declares that
the varmo TZ eco Radiator Thermost-
at is in compliance with Directive 2014/53/EU.
The full text of the EU declaration of conformity
is available at the following internet address:
https://donexon.com/service.
Z-Wave and Z-Wave Plus are registered
trademarks of Sigma Designs and it is
subsidiaries in the United States and other
countries.
Warranty:
The two-year warranty begins on the day of
purchase. Please keep the receipt as evidence
of purchase in the future. During the guarantee
period, defective radiator thermostats may be
sent to the service address below. Please en-
sure sufcient postage is paid.
A new or repaired device will then be sent to
you free of charge. Following expiry of the gua-
rantee, you may still send the defective device
to the address below for repairs. Please ensure
sufcient postage is paid. Repairs carried out
after the guarantee period are subject to a
charge. Your legal rights are not affected by
this guarantee.
There is no new warranty period starting when
repairing or replacing the device. Please note
that we only grant warranty on the function
of the device. We will not grant warranty for
the interaction between the thermostat and
the bottom part of the valve. The technical
data is only valid for the use of the following
valves: Heimeier, Junkers Landys + Gyr, MNG,
Honeywell, Braukmann (measure of thread
M30 x 1,5), Oventrop (M30 x 1,5) Danfoss RA,
RAV and RAVL.
Please see the combinations of the devices
on our website (www.donexon.com/service
Adapter list) Eurotronic does not issue a gua-
rantee when using the thermostat with valves
which are not mentioned above.
Technical specications
Device short description: varmo TZ eco
EAN: 4251660900025
Supply Voltage: 2 x 1,5V LR6/Mignon/AA
Radio Frequency: 868,42 MHz
Connection: M30 x 1,5mm
Method of operation: Type 1
Dimensions (W x H x D): 56 x 68 x 89 mm
Weight: 176g (incl. batteries)
Degree of protection: IP20
Degree of pollution: 2
Output Power: +4dBm
Technical modications are subject to change.
ENGLISH
Funktionalität zwischen dem Zusammenspiel
des Thermostats und des Ventilunterteils ge-
ben. Die anwendungsbezogenen technischen
Daten sind ausschließlich zusammen mit den
Ventilen Heimeier, Junkers Landys+Gyr, MNG,
Honeywell Braukmann Gewindemaß (M30x1,5),
Oventrop (M30x1,5) Danfoss RA, RAV und RAVL
gewährleistet. Die Gerätekombinationen kön-
nen auf unserer Webseite (www.donexon.com)
entnommen werden.
Beim Betrieb des Thermostats mit Fremdventi-
len-/adaptern, die nicht aufgeführt sind, ist die
Funktionalität durch den Anwender sicherzu-
stellen. VARIA3 GmbH erbringt in diesen Fällen
keine Garantieleistung. Nach Ablauf der Garan-
tiezeit haben Sie ebenfalls die Möglichkeit, das
defekte Gerät zwecks Reparatur ausreichend
frankiert an die angegebene Adresse zu sen-
den. Nach Ablauf der Garantiezeit anfallende
Reparaturen sind kostenpichtig. Ihre gesetz-
lichen Rechte werden durch diese Garantie
nicht eingeschränkt.
Technische Änderungen jederzeit vorbehalten.
Decrease
Temperature
Increase
Temperature
Boost / Okay
Button for Task conrmation
