ENGLISH
Welcome to Donner
We are very grateful to have you purchasing our product.
Please take a few minutes to read the instructions for operating
this product,which will show you how to use it and explain the
function and operation of the device,ensuring a trouble-free
installation.
Please keep these operating instructions properly for future
reference.
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS EQUIPMENT
TO RAIN OR MOISTURE.
TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK AND ANNOYING INTERFERENCE, PLEASE
USE ONLY THE RECOMMENDED ACCESSORIES FOR UNINTERRUPTED SERVICE OF THIS
DEVICE!
*DESIGN AND SPECIFICATIONS MAY CHANGE WITHOUT NOTICE.
Warning:
WARNING
ELECTRIC SHOCK HAZARD
DO NOT OPEN
01 02 03 04 05 06 07
08 09 10 11 12 13 14 15
16 17 18
19 20 21 22 23 24 25
26 27 28 29 30 31 32 33
34 35 36
37 38 39 40 41 42 43
44 45 46 47 48 49 50 51
52 53 54
55 56 57 58 59 60 61
62 63 64 65 66 67 68 69
70 71 72
73 74 75 76 77 78 79
80 81 82 83 84 85 86 87
88 89 90
91 92 93 94 95 96 97
98 99 100 101 102 103 104 105
106 107 108 109

MAIN OUT: 1/4" TS mono output connector that outputs overall signal and is controlled by Master
knob.
MIDI IN: MIDI input connector that inputs MIDI messages and can support the use of external
MIDI devices.
MIDI OUT: MIDI output connector that allows you to output the MIDI signal from this unit to control
other MIDI devices.
USB-C : Type-C connector that connects to the host computer for firmware updates and USB MIDI
data transmission.
POWER INPUT: DC9V power input
POWER SWITCH: Power on/off.
AUX IN connector: 1/8" TS audio signal connector that used for connecting other audio signals and
outputting mixed signal with the sound of B1 through MAIN OUT jack and PHONES jack.
Headphone output interface: 1/8" audio signal interface that used for connecting the headphones
output. Turn Master knob can control the volume.
Sync In interface: connecting an external clock to start or stop signal.
Sync Out interface: connect and send internal clock to external device.
Wave switch : shifting between saw wave and square wave on the currently used oscillator.
Pitch knob: potentiometer with a detent at the center that controls oscillator frequency, with a range
of fifth intervals lower on the left half and fifth intervals higher on the right half.
Cutoff knob: controlling the cutoff frequency of low-pass VCF filter, the larger the value of the knob
the higher the cutoff frequency.
Resonance knob: controlling the signal amplitude at the cutoff frequency point, the larger the knob
value the stronger the gain.
PANEL INTRODUCTION
2
1
3
4
5
6
2
1
3
4
5
7
8
6
123456
01 02 03 04 05 06 07
08 09 10 11 12 13 14 15
16 17 18
19 20 21 22 23 24 25
26 27 28 29 30 31 32 33
34 35 36
37 38 39 40 41 42 43
44 45 46 47 48 49 50 51
52 53 54
55 56 57 58 59 60 61
62 63 64 65 66 67 68 69
70 71 72
73 74 75 76 77 78 79
80 81 82 83 84 85 86 87
88 89 90
91 92 93 94 95 96 97
98 99 100 101 102 103 104 105
106 107 108 109

Press OCT to enter octave adjustment mode. The OCT button indicator flashes and the display shows
the current octave value.
Press ▲ or ▼to adjust the octave value, the screen will display the upper and lower octaves value.
The octave adjustment mode is automatically exited when no operation is performed for an extended
period of time, and the octave adjustment mode can be exited by pressing OCT again.
SETTING OCTAVE
SETTING TEMPO
Press the TEMPO TAP button once to enter tempo adjustment mode, the TEMPO TAP button
indicator flashes and the display shows the currently set speed.
Press ▲ or ▼ to adjust the Tempo value, which ranges from 40 BPM to 240 BPM.
If you press and hold ▲ or ▼, the Tempo value will change rapidly in succession.
The Tempo adjustment mode is automatically exited when no operation is performed for an extended
period of time, and the Tempo adjustment mode can be exited by pressing and hold TEMPO TAP for
approximately 2 seconds.
10
11
12
13
14
15
16
17
18
19
9Depth knob: controlling the modulation depth applied by the envelope to the VCF cutoff frequency,
the larger the knob value the greater the depth.
Decay knob: controlling the amount of time of the envelope to decay from the current signal level to
the minimum level, the larger the knob value the longer the time.
Accent knob: adjusting the amount of Accent effect, the larger the value of the knob the more
obvious the Accent effect. (Only have an effect when notes programmed with an accent.)
Saturation switch: controlling the distortion effect.
Drive knob: controlling the level of distortion gain, the larger the value of the knob the greater the
gain.
Tone knob: controlling the brightness of the distortion tone, the larger the value of the knob the
brighter the tone.
Delay switch: controlling the delay effect.
Level knob: controlling the volume of the delay effect sound, the higher the value of the knob the
higher the volume of the effect sound.
Time knob: controlling the delay time of the delay effect, the larger the knob value the longer the
delay time.
Feedback knob: controlling the number of feedback of delay effect, the feedback number is 1 when
the knob value is minimum, the greater the knob value the greater the number of feedbacks.
Master knob: controlling the total output volume of the unit, the higher the value of the knob the
louder the volume.
In octave setting mode, adjust the higher and lower octaves of the range.
There are two ways to adjust the Tempo value.
- The first way is Tap Tempo. You can change the Tempo by pressing the TEMPO TAP button 2 to 4
times in a row.
- If you need to adjust the Tempo value precisely, please refer to the second way below.
KEYBOARD MODE
- In the keyboard mode (default mode), you can directly press the keys on the keyboard to play.
- Follow the steps below can set equipment parameters.
