DoorBird A1061 Series User manual

VERSION ., MIN. HW .
Page 2-17
Installation Manual
IP Door Chime
A1061x Series
Seite 18-34
Installationsanleitung
IP Türgong
A1061x Serie
A1061X
Page 35-50
Manuel d‘installation
Carillon IP DoorBird
Série A1061x

22
INSTALLATION MANUAL
Read these instructions carefully before starting to use any components.
Keep the manual so you can refer to it at a later date if required. If you hand
over the device to other persons for use, please hand over the operating
manual as well.
To make things easier we use the term “device” for the product “DoorBird IP
Door Chime” and “mobile device” for a smartphone or tablet. You can always find
the most up-to-date version of the installation manual on www.doorbird.com/
support
Liability
Every care has been taken in the preparation of this document.
Please inform Bird Home Automation GmbH of any inaccuracies or omissions.
Bird Home Automation GmbH cannot be held responsible for any technical
or typographical errors and reserves the right to make changes to the product
and manuals without prior notice. Bird Home Automation GmbH makes no
warranty of any kind with regard to the content of this document, including,
but not limited to, the implied warranties of merchantability and fitness for
a particular purpose. Bird Home Automation GmbH shall neither be liable
nor responsible for incidental or consequential damages in connection with
the furnishing, performance or use of this material. This product is only to
be used for its intended purpose.
Equipment Modifications
This equipment must be installed and used in strict accordance with the
instructions given in the user documentation. This equipment contains no
components that require service by the user. Unauthorized equipment
changes or modifications will invalidate all applicable regulatory certifications
and approvals.
Symbols used
Caution: Indicates a hazardous situation which, if not avoided,
could result in minor or moderate injury.
Danger: Indicates a hazardous situation which, if not avoided,
will result in death or serious injury.
Warning: Indicates a hazardous situation which, if not avoided,
could result in death or serious injury.

33
ENGLISHENGLISH
Notice: Indicates a situation which, if not avoided, could result
in damage to property.
Note: Indicates useful information which helps in getting the
most out of the product.
NOTICE
Hazard information
• Mounting, installation and servicing work on electrical devices may
only be performed by a qualified eletrician. Failure to observe this
regulation could result in the risk of serious damage to health or fatal
injury due to electric shocks.
• Devices with 110-240 V connection: The device may only be connected
to an easily accessible power socket outlet. The mains adapter must
be pulled out if a hazard occurs.
• For power supply, only use the original plug-in mains adapter
delivered with the device or a recommended PoE-Switch/PoE-Injector
as specified in this manual.
• Because of electrostatic charging, direct contact with the circuit board
can result in destruction of the device. Direct contact with the circuit
board must therefore be avoided at any time.
• Observe the EN 60065 resp. EN 60950 resp. EN 62368 standard.
• Do not use the device if there are signs of damage to the housing,
control elements or connecting sockets, for example, or if it
demonstrates a malfunction. If you have any doubts, please have
the device checked by an authorized expert.
• Do not open the device. This voids the warranty of the device. The
device does not contain any parts that can be maintained by the
user. In the event of an error, please have the device checked by an
authorized expert.
• For safety, approval and licensing reasons (CE/FCC/IC etc.),
unauthorized change and/or modification of the device is not
permitted.
• The device is not a toy; do not allow children to play with it. Do not
WARNING
Important: Indicates significant information which is essential
for the product to function correctly.

44
leave packaging material lying around. Plastic films/bags, pieces of
polystyrene, etc. can be dangerous in the hands of a child.
• Always lay cables in such a way that they do not become a risk to
people and domestic animals.
• Voltage is applied to parts within the equipment. Do not touch any
parts that are not associated with the installation, wiring, or connection.
Electric shock could result.
• On devices which are not marked as weather-proof: Keep the device
away from water or any other liquid.
• Do not install or make any wire terminations while power supply is
plugged in. It can cause eletric shock or damage to the device.
• Before turning on power, make sure wires are not crossed or shorted. If
not, fire or eletric shock could result.
• High voltage may be present internally. Do not open the device.
Electric shock could result.
• The device is not of explosion-proof. Do not install or use near gases or
flammable materials. Fire or explosion could result.
• Do not install two power supplies in parallel to a single input. Fire or
damage to the device could result. Be sure to connect a single power
supply to the device.
• Do not connect any terminal on the device to an AC power line. Fire or
electric shock could result.
• Keep AC cord from being marred or crushed. If the AC cord is fractured,
fire or electric shock could result.
• Do not plug or unplug with wet hands. Electric shock could result.
• Do not put any metal or flammable material into the device. Fire,
electric shock, or device trouble could result.
• Existing wiring may contain high voltage AC electricity. Damage to the
device or electric shock could result. Wiring and installation must be
done by a qualified eletrician.
•When mounting the device on a wall or ceiling, install the device in a
convenient location, but not where it could be jarred or bumped. Injury
could result.
• On devices with ground terminals, connect to an earth ground.
Otherwise fire or malfunction could result.
• On devices with plastic or real glass, do not put high pressure on the
glass. If fractured, injury could result.
WARNING

55
ENGLISHENGLISH
• On devices with LCD, if LCD is punctured, do not allow contact with the
liquid crystal inside. Injury could result. If necessary, gargle your mouth
and clean your eyes or skin with clear water for at least 15 minutes and
consult your doctor.
• Do not put anything on the device or cover the device with cloth,
silicone, glue, coating, separate covering etc. Fire or device issues could
result.
• Do not install the device in any of the following locations. Fire, electric
shock, or device trouble could result.
 Places under direct sunlight or places near heating equipment that
varies in temperature.
 Places subject to dust, oil, chemicals, hydrogen sulfide (hot spring).
 Places subject to moisture and humidity extremes, such as bathrooms,
cellars, greenhouses, etc.
 Places where the temperature is very low, such as inside a refrigerated
area or in front of an air conditioner.
 Places subject to steam or smoke (e.g. near heating or cooking surfaces).
 Where noise generating devices such as dimmer switches or inverter
electrical appliances are closeby.
 Locations subject to frequent vibration or impact.
• On devices with intercom, be sure to perform a call test with low audio
volume on both intercom devices. A sudden call etc. may arrive causing
for example damage to your ear.
• If the device does not operate properly, unplug the power supply.
• All devices which are not marked as weather-proof are designed for
indoor use only. Do not use outdoor.
• On devices which are marked weather-proof: Do not spray with high-
pressure water. Device issues could result.
• We do not assume any liability for damage to property or personal injury
caused by improper use or the failure to observe the
• hazard information. In such cases, any claim under warranty ceases. For
consequential damages, we assume no liability!

66
Safety instructions
• The device shall be used in compliance with local laws and regulations.
• Store the device in a dry and ventilated environment.
• Avoid exposing the device to shocks or heavy pressure.
• Do not install the device on unstable brackets, surfaces or walls. Make
sure the material is strong enough to support the weight of the device.
• Use only applicable tools when installing the device. Using excessive
force with tools could cause damage to the device.
• Do not use chemicals, caustic agents, or aerosol cleaners.
• Use a clean dry cloth for cleaning.
• Use only accessories that comply with technical specification of the
device. These can be provided by Bird Home Automation GmbH.
• Use only spare parts provided by or recommended by Bird Home
Automation GmbH.
• Do not attempt to repair the device by yourself. Contact Bird Home
Automation GmbH for service matters.
• Keep the device more than 1 m (3.3‘) away from microwave, radio, TV,
wireless router and any other wireless devices.
• On devices with intercom or built-in speaker or built-in microphone or
signal transmission functions, keep the wires more than 30 cm (12‘‘)
away from AC 100-240 V wiring. AC induced noise and/or device
malfunction could result.
• Install the device in an area that will be accessible for future inspections,
repairs and maintenance.
• If the device is used close to a cellular phone, the device may malfunction.
• The device can be damaged if dropped. Handle with care.
• The device turns inoperative during power failure.
• On devices with intercom or built-in speaker or built-in microphone,
in areas where cellular or Radio / TV broadcasting station antennas are
closeby, the device may be affected by radio frequency interference.
• On devices with LCD screen, it must be noted in advance that the LCD
panel, though manufactured with very high precision techniques,
inevitably will have a very small portion of its picture elements always lit
or not lit at all. This is not considered a device malfunction.
• On devices with intercom, due to the environmental sound around
NOTICE

77
ENGLISHENGLISH
the device, it may hinder smooth communication, but this is not a
malfunction.
• On devices with Username/Password, the Username/Password to
access the device is the customer‘s responsibility. Make sure to use
a password that cannot be easily guessed by a third party. We
recommend that you change the Password on a regular basis.
• We will, under no circumstances, be liable for damage that occurs due
to failures in power supply, network equipment or terminal devices;
failures due to Internet providers and cellular network providers;
failures such as disconnected lines and other losses in communication,
which makes it impossible to provide this service as well as in any way
delay this service due to any other causes outside of our responsibility;
or if an error or missing data occurs during transmission.
Warranty Information
For information about the device warranty, see www.doorbird.com/warranty
Transportation
When transporting the device, use the original packaging or equiva-
lent to prevent damage to the device.
NOTICE

88
Device
COMPONENTS
Contents
 1x Device
 1x Power supply unit
(mains adaptor) with four
country-specific adaptors
 1x RJ45 network cable (300 cm)
 3x Phillips countersunk
head screws
Loudspeaker
Large-sized broadband speaker.
Cable inlet
To feed the cable into the device, if the
cables are surface-mounted.
Diagnostic-LED
To visualize the current status of the device.
Mounting points
To mount the device on a wall or ceiling
using countersunk head screws.
Connection terminal
Power supply (15 V DC -; 15 V DC +),
Storey-call button (STC),
Setup button (SET), LAN/PoE.
Cable clamp
Front
Back
1
4
2
3
5
6
 3x Dowels
 3x Crimp connectors
 1x Installation manual
 1x Drilling template
 1x Quickstart Guide with Digital
Passport

99
ENGLISHENGLISH
VIDEOS
Need help with the installation? Be sure to watch our installation videos
which can be found on http://www.doorbird.com/support
Each individual step of the installation is clearly documented in the videos.
INSTALLATION
All steps below should be carried out carefully by a competent adult, taking
into consideration any applicable safety regulations. Should you have any
questions, please contact us or a competent specialist directly. Please ensure
that all wires used for the installation are undamaged along their entire
length and approved for this type of use.
Network speed and network components
Please ensure that the upload speed of your Internet connection is at least
0.5 Mbps. You can also carry out a speed test at any time via the DoorBird App.
The user experience is only as good as your network speed, network stability
and quality of your network components, such as your Internet router and
WiFi access points or WiFi repeaters. Please also make sure that your network
components are no more than two years old, have been manufactured by a
well-known manufacturer, and have the latest firmware installed.
Should these requirements not be fulfilled, it may happen, i.e. that the
performance of audio and video is poor or push notifications are delayed or
do not arrive on your smartphone or tablet at all.
High-speed Internet (via landline): DSL, cable or optical fibre
Network: 802.11b/g/n 2.4 GHz or Ethernet, with DHCP

1010
STEP : SWITCHING OFF POWER
Switch off the power to all wires leading to the assembly location, i.e.
the door chime, electric door opener, power supply unit, PoE-Switch/
PoE-Injector etc.
STEP : DISMANTLING THE EXISTING DOOR CHIME
Should there already be a door chime on the wall, please do not hesitate to
remove it.
STEP : DETERMINING THE ASSEMBLY LOCATION
The device is designed for indoor-use only.
Press the drilling template of the device against the wall or ceiling at the
desired installation site and mark the boreholes with a pencil. Remove the
drilling template again. Ensure that no cables are to be found in the wall or
ceiling behind the boreholes.
STEP : DOWELS AND SCREWS
If the wall of the house is not made of wood, you should drill dowel holes 5 mm
in diameter in the wall according to the drilling template and then place
the dowels provided into the boreholes.
If you must drill holes in a wall, insert screws into a wall or lever up a
wall, ensure that no cables or mains (gas, water, etc.) are to be found
in the wall.
If the wall of the house is made of wood, dowels are not normally required.
There are special dowels for assembling the device on an insulating wall, e.g.
Fischer insulating dowels.
Please check with your insulating material manufacturer regarding which
dowels they recommend. Use the Phillips countersunk head screws provided
to position it in the dowels or on the wall, so that the countersunk head
screws protrude a few millimeters above the wall.
STEP : PREPARING THE POWER SUPPLY
The device can be powered by two simple doorbell wires using the power-
supply unit (mains adaptor) supplied with it or via PoE (Power over Ethernet)
using a network cable. The device can alternatively also be supplied with a
DIN-rail power supply unit that you can obtain from us directly. The device
does not use battery power.

1111
ENGLISHENGLISH
Option 1: Power supply using the power-supply unit (mains adaptor)
Two insulated wires are required to power the device by connecting it to the
power-supply unit (mains adaptor) supplied with it. These wires are normally
already there and are freely accessible once you have removed the previous
door chime. You can also connect the power supply without any additional
wires to the door chime, the power supply has a 300cm long cable with two
insulated wires. If you need longer wiring, connect the wires of the power
supply using the supplied crimp connectors with the two wires that you want
to use for the power supply.
Do not plug the power supply unit into the wall socket yet.
Only use the power supply unit provided along with the device, or a
DIN-rail power supply unit that you can obtain from us separately,
since this has been specially stabilized electrically and is equipped
with an integrated audio interference reduction device. Other power
supply units may destroy the device or cause poor transmission quality.
The warranty automatically expires if you use a different power supply
unit. The power supply unit is plugged into a wall socket inside your
house, usually where the two wires from your previous door chime
comes out of the wall in the interior of the house.
Option 2: Power supply via PoE (as an alternative)
To power the device via a PoE-Switch (e.g. D-Link DGS-1008P) or PoE-Injector
(e.g. DoorBird Gigabit PoE Injector) in accordance with the PoE standard IEEE
802.3af Mode A, the four wires bearing the numbers 1, 2, 3 and 6 of a Cat.5
cable or better are to be used. A Cat.5 cable or better must be used as network
signals can only be transmitted over completely insulated, shielded and
twisted cables. If you use PoE as a source of power, the WiFi interface of the
device is automatically inactive, and the four wires for PoE then simultaneously
form the data link. The device won’t start if your PoE Switch or PoE injector
does not support the PoE Standard IEEE 802.3af Mode A (see Diagnostic-LED
and Diagnostic-Sounds).
1. Disconnect the PoE-Switch or PoE-Injector from the power grid.
2. Place the network cable in the installation site of the device.
Do not combine the power supply from the power supply unit
(mains adaptor) with the power supply via PoE. You can find further
information about PoE here: http://www.doorbird.com/poe
STEP : FURTHER CONNECTIONS (OPTIONAL)
If desired, connect additional wires to the installation site of the device.
The wires or connection options mentioned in this section are optional.
NOTICE
NOTICE

1212
Be sure to use
four insulated,
shielded and
twisted wires of
a network cable
in accordance
with the Cat.5
standard or
better. Only four
wires of the
network cable
will be used.
Connecting the unit to a network
You can connect the device to your existing network
via WiFi, or alternatively use a network cable (Ethernet).
For reasons of network stability, we principally recom-
mend using a network cable, as WiFi is sensitive to
interference (range, house walls acting as shields, relia-
bility of performance, third party WiFi networks, wireless
transmitters causing interference in the area, etc.).
The device can be powered by PoE or using the power
supply unit provided. If you use PoE as a source of power,
the WiFi interface of the device remains inactive.
Use only a network cable with RJ45 plug that meets the
Cat.5 standard or a better one.
Connect the network cable to your PoE-Switch or
PoE-Injector that is connected to your Internet router.
Then connect it to the device.
Conventional Storey-call button
You can connect a conventional button to the device
to realize a separate storey-call. A Storey-call button is
typically used if you have more than one door, e.g. street
door and apartment door. Please make sure to add no
voltage on that contact.
Please make sure to add no voltage on these ports. Extra voltage
may destroy the device immediately.
STEP : PREPARING THE WIRES
Remove about 5 mm of insulation material at the end of the wires that you
would like to connect to the device (Power supply, Storey-call button).
STEP : CONNECTING THE WIRES
It is possible to connect the cables and wires to the device conveniently and
safely via a connection terminal on the reverse of the device. The individual
contacts on the connection terminal are labelled on the casing. You can
connect all necessary cables and wires to the device using the connection
terminal now. Please remove any cables and wires on the connection
terminal that you do not need. Remove about 5 mm of insulation material at
the end of the wires that you would like to connect to the screw connection
terminal of the device.
Two insulated
wires.
6 (R-)
3 (R+)
2 (T-)
1 (T+)
NOTICE

1313
ENGLISHENGLISH
Please take care when connecting the cables and wires. Connecting
the cables and wires the wrong way may destroy the device.
STEP : FINAL ASSEMBLY
Mount the device on the Phillips countersunk head screws you already
positioned in step 3 and 4.
STC LAN/POEVDC
CONNECTOR DESCRIPTION
15 V DC -
15 V DC Power supply, negative pole (-)
Do not power the device simultaneously via the
power supply from the power supply unit (mains
adaptor) and the power supply via PoE.
15 V DC +
15 V DC Power supply, positive pole (+)
Do not power the device simultaneously via the
power supply from the power supply unit (mains
adaptor) and the power supply via PoE.
STC Storey-call button, 0 V DC/V AC, 0 A
LAN/POE
Ethernet Network cable with RJ45 plug, supports PoE
Do not power the device simultaneously via the
power supply from the power supply unit (mains
adaptor) and the power supply via PoE.
V+V-
NOTICE
NOTICE
NOTICE
NOTICE

1414
STEP : ACTIVATING THE DEVICE
Switch on the power leading to the assembly location again. If you use PoE,
make sure to switch on power of the PoE-Switch or PoE-Injector you have
connected the device to.
Do not power the device simultaneously via the power supply
from the power supply unit (mains adaptor) and the power
supply via PoE.
You can see if the device is powered by checking the Diagnostic-LED, which
lights up after about 30 to 60 seconds after the power is connected. The
device is ready for operation (booting up process, any software updates, etc.)
once it has emitted a short diagnosis sound from the integrated loudspeaker.
This may last for up to 5 minutes. Should you not hear a sound, please check
the power supply. Please also check whether you have used a wall-plug pow-
er supply and not PoE and whether you have connected the positive pole and
negative pole to the device correctly.
STEP : DOWNLOADING AND INSTALLING THE APP
Download the “DoorBird” App by Bird Home Automation onto your mobile
device from the Apple App Store or Google Play Store. You can always find
the most up-to-date version of the App manual on www.doorbird.com/support.
If you use WiFi for connecting the device to your Internet router, first go to
the DoorBird App “Settings →WiFi Setup” and follow the instructions.
If you have finished the WiFi setup or have connected the device to your
Internet router by means of a network cable, go to the DoorBird App
“Settings →Administration” and login to the video door station you would
like to pair the device with. To add the device there, go to “Peripherals →
Settings →Add”.
If you have problems adding the device to the App please check if the device
is online ( www.doorbird.com/checkonline ). If the device is not online, please
check the WiFi or network cable connection again.
DIAGNOSTIC-LED
You can see if the device is powered by checking the Diagnostic-LED,
which lights up after about 30 to 60 seconds after the power is connected.
The Diagnostic-LED automatically turns off after about 5 minutes.
DIAGNOSTIC-SOUNDS
After around one to five minutes, the device emits brief diagnostic sounds
after it has been connected to the power grid.
NOTICE

1515
ENGLISHENGLISH
TECHNICAL SPECIFICATIONS
Dimensions:
125 x 119 x 26 mm (H x W x D)
4,92 x 4,68 x 1,02 in (H x W x D)
Power Supply:
15 V DC or Power over Ethernet
(PoE 802.3af Mode-A)
Operating conditions:
0 to +55°C / 32 to 131°F
Relative Humidity
10% to 85% (non condensing)
Connectors:
1 x RJ45, 4 x Screw terminal
Loudspeaker:
102 dB
WiFi:
2.4 GHz, 802.11 b/g/n, internal
antenna
PoE:
IEEE 802.3 af/at
Housing:
Polycarbonate, UV-resistant
System requirements:
Mobile Device: Newest iOS on
iPhone/iPad, newest Android on
Smartphone/Tablet
Internet: High-Speed Landline
Broadband Internet connection, DSL,
cable or fiber optic, no socks or proxy
server
Network: 802.11b/g/n 2.4 GHz
or Ethernet Network, with DHCP
Compatible with all DoorBird IP
Video Door Stations.
Scope of delivery:
1 x IP Door Chime
1 x Network Cable
1 x Power supply unit (mains
adaptor) with four country-specific
adaptors (110 - 240 V AC to 15 V DC)
1 x Small parts
1 x Installation manual
Approvals:
CE, IC, FCC, RoHS, IP50
Weight:
200 g
Errors and omissions excepted.

1616
LEGAL NOTES
General remarks
1. DoorBird is a registered trademark of Bird
Home Automation GmbH.
2. Apple, the Apple logo, Mac, Mac OS,
Macintosh, iPad, Multi-Touch, iOS, iPhone
and iPod touch are trademarks of Apple Inc.
3. Google, Android and Google Play are
trademarks of Google, Inc.
4. The Bluetooth® word mark and logos are
registered trademarks of Bluetooth SIG, Inc.
5. All other company and product names may
be trademarks of the respective companies
with which they are associated.
6. We reserve the right to make changes to
our products in the interests of technical
advancement. The products shown may also
look different from the products supplied
based on ongoing enhancement.
7. Reproducing or using texts, illustrations and
photos from this instruction manual in any
media – even if only in the form of excerpts
– shall only be permitted with our express
written consent.
8. The design of this manual is subject to
copyright protection. We do not accept
any liability for any errors or any erroneous
content or printing errors (even in the case
of technical specifications or within graphics
and technical sketches).
9. Our products are in compliance with
all technical guidelines, electrical and
telecommunications regulations applicable
in Germany, the EU and the USA.
10. Our products and also the components
contained therein (ICs, software, etc.)
may only be used for civilian non-military
purposes.
Data privacy and data security
1. For maximum security, the device uses the
same encryption technologies as are used
in online banking. For your security, no port
forwarding or DynDNS is used either.
2. The data centre location for remote access
over the Internet by means of an App is
obligatory in the EU if the determined
Internet IP-Address location of the device is
within the EU. The data centre is operated
in line with the most stringent security
standards.
3. Video, audio and any other surveillance
methods can be regulated by laws that vary
from country to country. Check the laws in
your local region before installing and using
this device for surveillance purposes.
If the device is a door-, indoor station or camera:
• In many countries video and voice signal may
only be transmitted once a visitor has rung the
bell (data privacy, configurable in the App).
• Please carry out the mounting in such a
way that the detection range of the camera
limits the device exclusively to the immediate
entrance area.
• The device may come with a visitor history and
motion sensor. You can activate/deactivate
this function if required.
If necessary, indicate the presence of the device
in a suitable place and in a suitable form.
Please observe any relevant country-specific
statutory regulations concerning the use of
surveillance components and surveillance
cameras applicable at the installation site.
Check with the property owner and your house
community if you are allowed to install and use
this product. Bird Home Automation GmbH
cannot be held responsible for any miss-use or
miss-configuration of this product, including
the unauthorized opening of a door.
Bird Home Automation cannot be held
responsible for damages caused by improper
existing installations or improper installation.
Software and operating system’s updates
(so-called “firmware updates”) are generally
automatically installed on the products of
Bird Home Automation GmbH via Internet,
if technically possible. Automatic firmware
updates keep the products‘ software up to
date so that they always work reliably, safely
and efficiently. Through further development,
features can be added, extended or slightly
changed. Major changes or limitations to
existing features will generally occur if Bird
Home Automation GmbH deems it necessary
(e.g. for data protection, data security or
stability reasons, or to keep them up to date).
When a firmware update is available, Bird
Home Automation GmbH‘s servers generally
automatically distribute it to all compatible
products connected to the Internet or Bird
Home Automation GmbH‘s servers. This process
is gradual and can take several weeks. As soon
as a product receives a firmware update, the
system will be installed and will restart by itself.
Installed firmware updates cannot be undone.
Since the products and software of Bird Home
Automation GmbH are not explicitly customer-
specific products, a customer cannot deny an
automatic update if the product is connected
to the Internet or to the Bird Home Automation
GmbH’s server.

1717
ENGLISHENGLISH
Instructions for disposal
Do not dispose of the device with regular
domestic waste. Electronic equipment must
be disposed e.g. at local collection points for
waste electronic equipment in compliance with
the Waste Electrical and Electronic Equipment
Directive.
Publisher
Bird Home Automation GmbH
Uhlandstraße 165
10719 Berlin
Germany
Web: www.doorbird.com
Email: [email protected]
It is possible that these manual still contains
typographical errors or printing errors.The
information in this manual will be checked
regularly and corrections will be made in the
next version. We accept no liability for errors
of a technical or printing nature and their
consequences.

18
