Dorel Home Products 4643039MK User manual

B344643039MK00-067846-C
DateofPurchase


 
LotNumber(TAKENFROMCARTON)
ThankyouforpurchasingfromDHP!
THISINSTRUCTIONBOOKLETCONTAINSIMPORTANTSAFETY
INFORMATION.PLEASEREADANDKEEPFORFUTUREREFERENCE.
1
      
Questions,concerns,missingparts?
CONTACTOURCUSTOMERSERVICEDEPARTMENT
BEFORERETURNINGPRODUCTTOTHERETAILER.

Ifpartsaremissingordamaged,wewillgladlyshipyour
replacementpartsfreeofcharge.

Visitwww.dhpfurniture.com/eng/replacement-parts
orcallToll-Free1-800-267-1739.
Youcanalsochatwithusatwww.dhpfurniture.com
2023Dorel Home Products All Rights Reserved
Weight Limit: 1000 Lb / 454 Kg

 4643039MK(Black), 4643 13 9MK(White)
MetalBed
Queen
C.W. - 2023/8/ 25

2
Workinaspaciousareaandnearwheretheunitwillbeused,preferablyona
carpet,oruseapieceofthecardboardpackagingtoprotectyourfloorandproduct.
Makesureallpartsareincluded.Mostpartsarelabeledorstampedontheraw
edge.
Readeachstepcarefully.Itisveryimportantthateachstepoftheinstructionsis
performedinthecorrectorder.Ifthesestepsarenotfollowedinsequence,
assemblydifficultieswilloccur.
Thisproductmaycontainsmallcomponents.Pleaseensurethattheyarekept
awayfromsmallchildren.
Thisproductisdesignedforhomeuseandisnotintendedforcommercialuse.
Forhelpwithassembly,identifyingparts,productinformationortoorderparts,
pleasecontactus:
Limited1yearWarranty



DHPwarrantsthisproducttobefreefromdefectsinmaterialandworkmanship
andagreestoremedyanysuchdefect.Thiswarrantycoversoneyearfromthe
dateoforiginalpurchasefromauthorizedretailers.Thisissolelylimitedtothe
repairorreplacementofdefectivepartsandassemblylaborisnotincluded.

Thiswarrantydoesnotapplytoanyproductwhichhasbeenimproperly
assembled,subjectedtomisuseorabuseorwhichhasbeenalteredorrepairedin
anyway.Thewarrantydoesnotcoverwearing,tearing,fadingorsplittingofthe
fabric(whereapplicable).Liabilityforconsequentialdamagesisexcludedtothe
extentexclusionispermittedbylaw.Thiswarrantygivesyouspecificlegalrights
andyoumayalsohaveotherrightswhichvaryfromstatetostateorprovinceto
province.

Toobtainwarrantyservice,purchasermustpresentoriginalbillofsale.
Componentsrepairedorreplacedarewarrantedthroughtheremainderofthe
originalwarrantyperiodonly.Thedefectivecomponentswillberepairedor
replacedwithoutcharge,subjecttothetermsandconditionsdescribedabove.

Thetermsandconditionsofthelimitedwarrantyaresubjecttochangewithout
notice.Forthelatestwarrantypolicy,pleasevisitwww.dhpfurniture.com.
ContactUs!

ReadBeforeBeginningAssembly




�
1hour
DoNOTuse
powertools
Thisproductisshippedin
1carton
1-800-267-1739
DHP Consumer Services
12345AlbertHudon,Suite100, 
Montreal,QuebecH1G3L1
[e-mail]
Chat
withus! www.dhpfurniture.com
1 hour

3
PARTS
A
B
C
D
H
E
E
F
F
K
G
YI
O
1
M

4

Eachparthasauniquepartnumber.Please
referencetheappropriatepartnumberwhen
contactingcustomerserviceforreplacement
parts.

Beforethrowinganypackaging,please
verifyallcontentsandmakesureyouhave
receivedallthepartslistedabove!
    
    
    
SideRail
2PCS
SideRail
2PCS
Footboard
1PC
Headboard
1PC
Post
1PC
Brace
1PC
Brace
2PCS
Brace
2PCS
Bracket
1PC
A B D EF
G H I K

PARTSLIST
C
Post
1PC

PARTNUMBERS
PART
LABELS
4643039MK
(Black)
A 
B 
C
D 
E 
F 
G 
H 
I 
K
T950660
T950670
T937990
T938000
T938010
T937 950
4643 13 9MK
(White)
T1031940
T1031950
T1031900
T1031910
T1031920
T1031930
T1031980
T1031990
T1031960
T1031970
T1031860
T1031870
T1031880
T1031890

5

Eachparthasauniquepartnumber.Please
referencetheappropriatepartnumberwhen
contactingcustomerserviceforreplacement
parts.

Beforethrowinganypackaging,please
verifyallcontentsandmakesureyouhave
receivedallthepartslistedabove!
PARTSLIST


PlasticPlug
28PCS
Slats
14PCS
Leg
3PCS
Y
MO
1
PARTNUMBERS
PART
LABELS
4643039MK
(Black)
M 
O1 
Y
T1017830
T938020
T392590
T392590
4643 13 9MK
(White)
T1032000
T1032010

6
Pleasedonotcompletelytightenallthehardware,
untiltheentireassemblyiscomplete,unless
otherwiseindicatedinthestep-by-stepinstructions.
Thescrew(s),bolt(s)tobeusedateachstepare
showninactualsizeinthelowerrightcornerofthe
page.
HardwarePack
HARDWARELIST
1 2 3 4 5
7
6
4mm
L-AllenKey
1PC
Wrench
1PC
1/4"X7/8"
Bolt
8PCS
5/16"X7/8"
Bolt
8PCS
1/4"
Nut
4PCS
8
1/4"X11/16"
Bolt
12PCS

  
  
4643039MK (Black)
1/4"X1 1 / 2 "
Bolt
4PCS
4643139MK (W hite)
HP # : T4643039MK-00
HP # : T4643139MK-00
1/4"X7/8"
Bolt
4PCS

7

�
C
C

Step1
Removetheplasticplugsfrom headboardC.

8

X8
4

A
A
B
C
C
Step
2
InsertpostA/BintoheadboardC .  and
attach withbolts 
.


9
Step3

InsertsiderailFX2intosiderailEX2and
attachwithbolts

.
X4
4
E
E
E
F
F
F
Ensure h oles
onthe topside.

10


X4
6
H
G
H
E
F
E
F
E
G
F
F
H
6
3
X 4
3
Step4
4.1 AttachbraceHX2tosub-assembly
siderailE/FX2frompreviousstepwith
bolts

.
4.2 AttachbraceGto siderail EX2with
bolts

.
4.1 4.2
