DOSCH&AMAND Products DA1270 User manual

-1-
DA1270 DECT Repeater
Manual
page
2 Start-up with DECT GAP Basisstation
2 Operational Place of Repeater
3 Start Configuration
4 Cascading (Daisy Chain)
5 ex-works-setting (Reset)
Connectors, LED, USB, Button
6 Software Upgrade
Question and Answers (FAQ)
7 Security Advices
8 Warranty
9 Recycling
10 CE Conformity

-2-
Start-Up with Standard DECT Base
1. switch-on DA1270 near Base Station
2. switch-on Repeater Mode of DECT Base Station
(see Manual of DECT Base Station)
3. press „Registration“ at DECT Base Station
4. wait till DA1270 is in operational mode
Operational Place of Repeater
For best selection of operational place follow below rules a-c
adivide in half the distance between DECT handset and DECT base
b distance of Repeater to Base shall not be smaller than 10 Meter
cLED2 green

-3-
Star Configuration in REP Mode
Up to 5 Repeater can be configured in a star around the DECT Base.
Follow chapter „SET-UP with
DECT Base Station“ and set
sequentially all DA1270
Repeater in operation. Please
assure that all Repeaters are
close together at DECT Base and
switched-on during the whole
process.
After registration place the Repeaters at their individual operational place
and assure that the DECT Link quality (LED2 green) of each Repeater
with respect to the Base station.
In case a single Repeater must be exchanged, all other Repeaters must
be taken back to the Base Station and switched on, prior to start the
registration of the new Repeater.

-4-
Cascading in REP Mode
Max 2 Repeater can be cascaded. The configuration as Cascade or Star
is done automatically.
DA1270 is analysing
the DECT radio link
and in case the link
quality to the Base is
insufficient, the Repeater establish a cascade to the neighbouring
Repeater.
If you change the operational position of Repeater, the configuration can
be automatically changed as cascade or star.
Follow chapter „SET-UP with DECT Base Station“ and set sequentially
all DA1270 Repeater in operation. After registration place the
Repeaters at their individual operational place
Cascades are not always supported by DECT Base
Stations (hop=0). Contact the manufacturer of the DECT Base to get
more information.

-5-
ex-works-setting (RESET)
Press Side Key for 5 seconds to activate the RESET function of the
product. All settings are reset to ex-works conditions
After RESET the DA1270 Repeater is automatically
starting the SEARCH Mode for DECT Base Station.
Connectors, LED, side key
Nr
Element
1
LED1 power supply (on/off)
2
LED2 DECT Link Quality (3 colors)
3
LED3 active call in REP (on/off)
4
side key(Reset, special for multicall HS)
5
USB connector (SW Upgrade)

-6-
Software Upgrade
Software Upgrades for DA1270 can be downloaded via USB connector
and USB cable to PC. Please search your Supplier’s website to get
information about such Software Upgrades
FAQ Questions and Answers
Please contact the respective Websites of manufacturer and/or
Supplier. Here you can find Technical Support and FAQs.

-7-
Security Advices
Make sure your DA1270 is not exposed to heat and interference from
electrical devices e.g. motors and transformers.
DA1270 shall be not be placed close to metallic walls.
Place DA1270 in wall sockets only with LEDs on top.
Protect your DA1270 from wet conditions, dust and aggressive liquids
and acrid fumes.
Use soft and wet wipes for cleaning the product. Never use
detergents.
Only qualified and authorised service personal are allowed to open
and repair the product.
If you hand the product to further person, do not forget to hand this
manual with the product

-8-
Warranty
Your dealer warrants for 2 years for material and manufacturing
quality of the product. Appointed date is the date of Buyer‘s receipt.
The Buyer has the right for repair or replacement.
Returned and replaced products will pass its property to the Seller. In
case of defects Buyer has to immediately inform the Seller about such
defects.
Warranty claims must be made evident via original receipt.
Any defect caused by incorrect handling, usage and caused by
physical stress or other incorrect environmental conditions are not
subject to warranty claims.

-9-
Recycling
Please contact your Seller regarding Recycling of your
product. In no case get disposed of your product via
household garbage.
Manual for DA1270 DECT Repeater
English Version 2.0 Edition 01
January 2017
Editor
DOSCH&AMAND Products GmbH München

-10-
CE Conformity
This product fulfills the requirements of EU rules 2004/108/EG (Richtlinie
des Europäischen Parlaments und des Rates zur Angleichung der
Rechtsvorschriften der Mitgliedstaaten über die elektromagnetische
Verträglichkeit und zur Aufhebung der Richtlinie 89/336/EWG), and
2006/95/EG (Richtlinie des Europäischen Parlaments und des Rates zur
Angleichung der Rechtsvorschriften der Mitgliedstaaten betreffend
elektrische Betriebsmittel zur Verwendung innerhalb bestimmter
Spannungsgrenzen). The conformity with a.m. rules is confirmed by the
CE sign. The CE Conformity Declaration and Manufacturer’s Declaration
can be viewed under following address :
DOSCH&AMAND Products GmbH, Neumarkterstr. 18, 81673 München
Technical Support
More technical support can be supplied via Service Number of your Dealer
Please consult the Dealer’s website for respective Tel Number.
