Double Intelligence Technology SIENNA Multimedia Interface User manual

Contents
1. Multimedia Interface
Cables' connection
2. Main cable 3. NAVI RGB cable
4. F/R-CCD cable 5. AV cable
6. Inner Board 7. SIENNA-LVDS cable
8. FPC28-S cable 9. FPC28-O cable
10. FPC30-O cable
12. IB-T cover
Multimedia Interface
1 2 3 4 5 7
Main DTV DVR DVD
LVDS
Switch
Main cable
To DTV
NAVI RGB cable
F/R-CCD cable
To DVR
To DVD
To GPS Navigator
To CCD To Power
Supply
Inner Board
IB Box
(IB-B cover &
IB-T cover)
FPC28-O/FPC28-S/
FPC30-O cables
SIENNA-LVDS cable
1. Multimedia Interface x1
2. Main cable x1
3. NAVI RGB cable x1
4. F/R-CCD cable x1
5. AV cable x3
6. Inner Board x1
7. SIENNA-LVDS cable x1
8. FPC28-S cable x1
9. FPC28-O cable x1
10. FPC30-O cable x2
11. IB-B cover x1
12. IB-T cover x1
13. IB screw(M3x5) x8
Infotainment System
SIENNA
123456
ON
P1 P2
11. IB-B cover
13. IB screw
Infotainment System
SIENNA
SIENNA
V1.1
M u l t i m e d i a I n t e r f a c e
for
Double
Intelligence
Technology
http://www.navi-tuner.com
Interface
Installation
Guide
6
RGB
Input
F/R
CCD
Please study SIENNA V1,1
Unit Installation Guide

Original page
Switch Setting
Multimedia Interface Setup
123456
ON
No. Position & Function
1
2
3
4
5
6
Reserve
ON:Ext. DIT89 Android Box
OFF:Ext. QROI NAVI Box
Reserve
Reserve
Reserve
Reserve
NAVI сhannel
CODE page
SETTING page
Step 1: Switch to NAVI-TUNER mode
Step 3: Select & enable the added devices
P4P3 P5
Step 2: Enter the code page.
1.Click the “ ”(Setting) icon to enter the code
page.
2.Input " " of number code to enter the 8888
SETTING page.
Front Camera
1.Front camera always been set up as enabled
after reversing done.
2.The 5"/10"/15" means auto switching to Front
Camera channel while out the “R” gear, then
after 5 or 10 or 15 seconds, auto back to the
previous frame page before reversing. The
default value is 5 seconds.
Rear Camera
1.Rear camera always set up to been triggered by
12V. Please link the Rear Camera +12V signal
(ex. reversing lamp of +12V) to the Main cable
of CCD 12V wire.
2.Select the "A.M. Rear Camera" or “Original
Camera” item. No select means no rear camera
been installed.
NAVI
Select to enable the NAVI(RGB input) channel of
the added NAVI device.
Added devices
1.TV
2.DVR
3.DVD
If the added device has been selected properly,
the pane in front of the device name should be
changed from " " to " ".
Installation is completed
Final test
1.Power off the vehicle.
2.Power on the vehicle.
3.Power on the infotainment system.
4.Press the "HOME" key on unit for , 2 seconds
display should switch from original mode to
NAVI channel page.
5.Press the "HOME" key on unit for , 6 seconds
display should switch from original mode to
NAVI-TUNER mode of Main page.
6.Click icon to check if the corresponding added
device works properly.
7.For switching to another channel, press
"HOME" key on unit for , display 2 seconds
should switch to NAVI-TUNER mode of Main
page, then which channel you click the icon
want to switch to, display should switch to the
corresponding channel.
8.Short press "HOME" key on unit, display should
switch to original mode of home page.
9.a-Anytime, in "R" gear, display should switch to
Rear Camera channel. Out "R" gear, display
should automatically switch back to the pre-
vious frame before reversing.
b-If Front Camera has been set and selected,
out "R" gear, display should switch to Front
Camera channel and stand for the time has
been selected, then automatically switch back
to the previous frame before reversing.
10.If the test was NG, please go step2~3 again.
11.If the test was still NG after done item 10,
please check if all the power & signal cables
have been connected properly, then go step1~3
again.
12.If the test was still NG after done item 11,
maybe the device or interface is NG, please
change a good device or interface, then go the
whole installation again.
P5
Congratulations, the installation is completed.
HOME key on unit
MAIN page
MAIN page
1.Power on the infotainment
system.
2.Press "HOME" key on info-
tainment unit for 2 seconds
to switch the display from
original mode to NAVI(RGB
input) channel.
3.Press "HOME" key for 6
seconds to switch the display from original mode to
NAVI-TUNER mode of MAIN page.
NAVI сhannel MAIN page
