Dramastic Audio Obsidian User manual

0
I
0
4
8
12
16
20
dB
COMPRESSION
THRESHOLD RATIO ATTACK - mS RELEASE - S MAKEUP COMPRESSOR EXTERNAL
SIDE-CHAIN POWER
+12
6
0.5
Lo-Fi
Auto
1.2
.6
.3
.1
30
10
31
.3
.1
12
10
8
4
2
+15
0
-15
USER’S MANUAL
Dramastic Audio®
Dramastic Audio®
Obsidian™
Obsidian™
Obsidian™
Obsidian™

Obsidian User’s Manual Warning
The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of
uninsulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of
electric shock to persons.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
TO REDUCE THE RISK OF ELECTRIC SHOCK DO NOT REMOVE COVER. NO USER SERVICEABLE PARTS
INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating
and maintenance (servicing) instructions in the literature accompanying the appliance.
WARNING:
TO PREVENT FIRE OR SHOCK HAZARDS, DO NOT EXPOSE
THIS PRODUCT TO RAIN OR MOISTURE.
BEFORE OPERATING THIS UNIT, CAREFULLY READ THE
OPERATING INSTRUCTIONS AND SAFETY PRECAUTIONS IN
THIS MANUALAS WELLAS ON THE UNIT ITSELF.
THIS APPARATUS MUST BE EARTHED.
WARNING:
3

www.DramasticAudio.com
Copyright ©2006, Dramastic Audio Corp.
All Rights Reserved.
Part No. 07-0007
Obsidian User’s Manual Safety
4
1. POWER SOURCES – The unit should be connected to a power supply only of the type described in the operating instructions, or as marked on the
unit. Please check to make sure the voltage selector switch on the back of the unit is set for the proper voltage in your area (either 100-120v or
200-240v 50/60Hz) before connecting to the AC. For best noise performance always use a grounded 3 core / 3 pin AC cord.
2. POWER CORD PROTECTION – AC power cords should be routed so that they are not likely to be walked on or pinched by items placed upon or
against them. Never take hold of the plug or cord if your hand is wet. Always grasp the plug body when connecting or disconnecting it.
3. GROUNDING OF THE PLUG – This unit is equipped with a 3-wire grounding type plug. This plug will only fit into a grounding-type power inlet.
This is a safety feature. Do not defeat the purpose of the grounding-type plug. If you are unable to insert the plug into the outlet, contact your
electrician to replace your obsolete outlet.
4. HEAT – The unit should not be located near heat sources, or other units that produce heat.
5. VENTILATION – When installing this unit in a rack or any other location, be sure there is adequate ventilation. Improper ventilation will cause
overheating, and damage to the unit.
6. WATER AND MOISTURE – Do not use the unit near any source of water or in excessively moist environments. Care should be taken so that
liquids are not spilled on or near the unit.
7. CLEANING – First disconnect the unit from AC power. The unit should only be cleaned with a damp lint free cloth. Do not use solvents or
abrasives to clean the unit, as this will damage the finish. Please make sure the unit is completely dry before reconnecting to AC power.
8. DAMAGE REQUIRING SERVICE – The unit should be serviced by authorized service personnel when:
a) TheAC power supply cord or plug has been damaged.
b) Objects have fallen or liquids have spilled into the unit.
c) The unit has been exposed to rain.
d) The unit does not operate normally or exhibits a marked change in performance.
e) The unit has been dropped, or the enclosure damaged.
9. SERVICING – The user should not attempt to service the unit. There are no user serviceable parts inside. Servicing only to be performed by
authorized personnel.
WARRANTY VOID IF CASE IS OPENED.

Obsidian User’s Manual Table Of Contents
5
Warnings 3
Safety 4
Introduction 6
Installation 9
Rear Panel View 10
Connections 12
Front Panel View 14
Front Panel Controls 16
Limited Warranty 19
Technical Specifications 20
