Draper VMS/KD User manual

■STOCK No. 64600 ■PART No.VMS/KD
•INSTRUCTIONS•
03/2001
IMPORTANT: PLEASE READ THESE INSTRUCTIONS
THOROUGHLY BEFORE USE.
UNDERSTANDING HOW THIS MACHINE WORKS AND SETTING IT
CORRECTLY IS FUNDAMENTAL TO OBTAINING
A SATISFACTORY RESULT.
MITRE SAW

MITRE SAW TECHNICAL DATA
COMPONENT PARTS
1. Vice clamp assembly.
2. Length stop assembly.
3. Cut depth stop.
4. Cut depth stop screws.
5. Two plastic feet with screw holes
for bench mounting.
6. Base socket head screws.
7. Pre-set angle arm.
8. Pivot pin.
9. Plated cursor screw.
10. Cursor.
11. Blade tensioning nut.
12. Pivot screw.
13. Saw table.
14. Saw frame handle.
15. Saw frame guide bar carriers.
16. Saw blade.
17. Saw frame carriers.
18. Saw frame assembly.
Specification:
Max. cutting width clamped at 45°............110mm
Max. cutting width clamped at 90°............160mm
Max. cutting height ...................................120mm
Blade length..............................................550mm
Blade width.................................................45mm
Table length ..............................................400mm
Max. reach of adjustable stop............... 450mm
Weight......................................................3.1kg

PRE-SET ANGLES
ASSEMBLY OF ACCESSORIES
The vice clamp ✕✌ can be mounted on the left or right hand side of the saw table front
for holding workpieces securely.
The adjustable length stop ✖✌ can be mounted at either end of the saw table and set
for the required length of cut.
90˚
45˚ 36˚
30˚ 22.5˚
✕✌
✖✌

IMPORTANT WARNING
To get the best from your saw and ensure it is correctly set ensure the following is
correct:
(a) The saw blade is tensioned sufficiently to avoid ‘whip’ which will cause the blade to
deviate from a true cut.
(b) The blade is ‘in line’ and central to the frame.
(c) The workpiece is square and true to the base casting.
(d) Tension is always released after use.
(e) The correct type of blade for the application is used.
(f) After assembly and setting has been carefully carried out, always test your mitre
saw and the angles with some scrap timber to ensure the machine is assembled
correclty and cutting true.
SPARE BLADES
Spare blades are available for this Mitre Saw. Draper Stock No. 60506 ..............14tpi
60507 ..............18tpi
60508 ..............24tpi
