Dremel 3Z Laser Measurer Assembly instructions

Operating/Safety Instructions
Consignes de fonctionnement/sécurité
Instrucciones de funcionamiento y
seguridad
1-800-4-DREMEL (1-800-437-3635) www.dremel.com
Call oll Free for Consumer Information and Service Locations
Pour obtenir des informations et les adresses de nos centres de
service après-vente, appelez ce numéro gratuit
Llame gratis para obtener información para el consumidor y
ubicaciones de servicio
IMPORTANT
Read Before Using
●
IMPORTANT
ire avant usage
●
IMPORTANTE
eer antes de usar
For English Version
See page 3
●
Version française
Voir page 23
●
Versión en español
Ver la página 45
3Z Laser Measurer
3Z Digital aser
Measurer
2610067140 3Z Laser Measurer 02-21.qxp_La out 1 2/24/21 8:01 AM Page 1

2
Safety Symbols
The definitions below describe the level of severity
for each signal word. Please read the manual and pay
attention to these symbols.
This is the safety alert symbol. It is used to
alert you to potential personal injury
hazards. Obey all safety messages that follow
this symbol to avoid possible injury or death.
DANGER indicates a hazardous situation which, if not
avoided, will result in death or serious injury.
WARNING indicates a hazardous situation which, if not
avoided, could result in death or serious injury.
CA TION indicates a hazardous situation which, if not
avoided, could result in minor or moderate injury.
General Safety Rules
Read all instructions. Failure to ollow
all instructions listed below may re-
sult in hazardous radiation exposure, electric shock, ire
and/or serious injury.
The term “laser measure” in the warnings listed below
refers to your battery-operated (cordless) laser measuring
tool.
SAVE ALL WARNINGS AND INSTRUCTIONS FOR
FUTURE REFERENCE
2610067140 3Z Laser Measurer 02-21.qxp_La out 1 2/24/21 8:01 AM Page 2

3
The ollowing label is on your laser measure or your
sa ety. ALWAYS BE AWARE o its location when using
the laser measure.
Do not direct the laser beam at persons or
animals and do not stare into the laser beam
yoursel . This tool produces laser class 2 laser
radiation and complies with 21 CFR 1040.10
and 1040.11 except for conformance with IEC
60825-1 Ed. 3., as described in Laser Notice No. 56, dated
May 8, 2019. This can lead to persons being blinded.
DO NOT stare directly at the laser beam or project the
laser beam directly into the eyes o others. Serious eye
injury could result.
DO NOT place the laser measure in a position that may
cause anyone to stare into the laser beam intentionally
or unintentionally. Serious eye injury could result.
DO NOT operate the laser measure around children or
allow children to operate the laser measure. Serious eye
injury could result.
ALWAYS: Make sure that any bystanders in the vicinity
o use are made aware o the dangers o looking directly
into the laser measure.
Never aim the beam at a workpiece with a re lective sur-
ace. Bright shiny re lective sheet steel or similar re lec-
tive sur aces are not recommended or laser use.
Reflective surfaces could direct the beam back towards
the operator.
Use o controls or adjustments or per ormance o pro-
cedures other than those speci ied herein may result in
hazardous radiation exposure.
LASER RADIATION. DO NOT STARE INTO BEAM.
CLASS 2 LASER PRODUCT.
RADIACIÓN LÁSER. NO MIRE AL RAYO.
PRODUCTO LÁSER DE CLASE 2.
RAYONNEMENT LASER. NE REGARDEZ PAS
DIRECTEMENT DANS LE FAISCEAU. PRODUIT
LASER DE CLASSE 2.
2
2610067140 3Z Laser Measurer 02-21.qxp_La out 1 2/24/21 8:01 AM Page 3

4
DO NOT use any optical tools such as, but not limited to,
telescopes or transits to view the laser beam. Serious
eye injury could result.
DO NOT leave the laser measure “ON” unattended in any
operation mode. ALWAYS turn the laser measure “OFF”
when not in use. Leaving the laser measure “ON” in-
creases the risk of someone inadvertently staring into the
laser beam.
DO NOT operate the laser measure in combustible areas
such as in the presence o lammable liquids, gases or
dust.
Do not use the laser viewing glasses as sa ety goggles.
The laser viewing glasses are used for improved visualiza-
tion of the laser beam, but they do not protect against
laser radiation.
Do not use the laser viewing glasses as sun glasses or in
tra ic. The laser viewing glasses do not afford complete
V protection and reduce color perception.
ALWAYS position the laser measure securely. Damage to
the laser measure and/or serious injury to the user could
result if the laser measure falls.
Take care to recognize the accuracy and range o the
laser measure. Measurement may not be accurate if used
beyond the rated range of the laser measure.
DO NOT remove or de ace any warning or caution labels.
Removing labels increases the risk of exposure to laser ra-
diation.
Electrical sa ety
Batteries can explode or leak, cause injury or ire. To re-
duce this risk, always ollow all instructions and warn-
ings on the battery label and package.
DO NOT short any battery terminals.
DO NOT charge alkaline batteries.
DO NOT mix old and new batteries. Replace all o them
at the same time with new batteries o the same brand
and type.
DO NOT mix battery chemistries.
Dispose o or recycle batteries per local code.
2610067140 3Z Laser Measurer 02-21.qxp_La out 1 2/24/21 8:01 AM Page 4

5
DO NOT dispose o batteries in ire.
Keep batteries out o reach o children.
Remove batteries i the device will not be used or sev-
eral months.
Maintenance
DO NOT disassemble the laser measure. There are no
user serviceable parts inside. Disassembling the laser
will void all warranties on the product. Do not modi y
the product in any way. Modifying the laser measure may
result in hazardous laser radiation exposure.
ALWAYS remove the batteries when cleaning the laser
light aperture to laser lens.
DO NOT use this laser measure or any purpose other
than those outlined in this manual. This could result in
serious injury.
ALWAYS use only the accessories that are recommended
by the manu acturer o your laser measure. se of acces-
sories that have been designed for use with other laser
measures could result in serious injury.
Repair and servicing must always be per ormed by a
quali ied repair acility. Repairs performed by unqualified
personnel could result in serious injury.
2610067140 3Z Laser Measurer 02-21.qxp_La out 1 2/24/21 8:01 AM Page 5

6
Symbols
Important: Some of the following symbols may be used on your tool.
Please study them and learn their meaning. Proper interpretation of these
symbols will allow you to operate the tool better and safer.
Symbol Designation / Explanation
V Volts (voltage)
Arrow (action in the direction of arrow)
This is the safety alert symbol. It is used to alert you to
potential personal injury hazards. Obey all safety
messages that follow this symbol to avoid possible injury
or death.
Alerts user to read manual
Laser radiation. Do not stare into beam.
2610067140 3Z Laser Measurer 02-21.qxp_La out 1 2/24/21 8:01 AM Page 6

7
Functional Description and Specifications
3Z Digital Laser Measure
(f) (h)(g)
(d)
(b)
(c)
(a)
(2)
(1)
(3)
(4)
(e)
ft2
ft2
'
'
''
''
(5)
(6)
3ZLaserMeasurer
(8)
(7)
2610067140 3Z Laser Measurer 02-21.qxp_La out 1 2/24/21 8:01 AM Page 7

8
1Measuring button
2Display
3Battery compartment
cover
4Locking mechanism
of the battery
compartment cover
5Serial number
6Laser warning label
7Reception lens
8Laser beam output
9Release buttons for
adapter
Display elements
aCurrent measured
value
bPrevious measured
value
cReference level: rear
edge
dLaser switched on
eFitted adapter
fArea measurement
gTemperature warning
hBattery warning
Tape adapter
10 Tape
11 Inner edge of
hook
12 Outer edge of
hook
Wheel adapter
13 Wheel
(9)
(10)
(9)
(12)
(11)
(9)
(9)
(13)
Tape adapter
Wheel adapter
2610067140 3Z Laser Measurer 02-21.qxp_La out 1 2/24/21 8:01 AM Page 8

9
Digital laser measure
Article Number F013LM0100
Measuring rangeA) 0.5 - 65.0 ft
(0.15 – 20.00 m)
Measuring accuracyB) ± 1/8 inch (± 3 mm)
Smallest display unit 1/16 inch
Operating temperature 14 °F … 104 °F
(– 10 °C ... +40 °C)
Storage temperature -4 °F ... 158 °F
(– 20 °C ... +70 °C)
Altitudes up to 6560 ft (2000 m)
Max. relative humidity 90 %
Degree of pollutionC) 2
Laser class 2
Laser type 635 nm, <1 mW
Laser beam divergence (at 77°F (25°C)) < 1.5 mrad
Batteries 2 x 1.5 V LR03 (AAA)
Battery life during measuring operation approx. 5h
Weight according to EPTA-Procedure 01:2014 0.18 lbs (0.08 kg)
Dimensions 4.13 x 1.49 x 0.87 inch
(105 x 38 x 22.3 mm)
Adapter - general specifications
Operating temperature 14 °F … 104 °F
(– 10 °C ... +40 °C)
Storage temperature -4 °F ... 158 °F
(– 20 °C ... +70 °C)
Max. relative humidity 90 %
Degree of pollutionC) 2
Tape adapter
Article Number 1619PB6583
Measuring accuracy ±1/16 inch/5 ft
(±1 mm/m)
2610067140 3Z Laser Measurer 02-21.qxp_La out 1 2/24/21 8:01 AM Page 9

10
Measuring range 1/4 inch - 5 ft
(0.005 m - 1.5 m)
Weight according to EPTA-Procedure 01:2014 0.066 lbs (0.03 kg)
Dimensions 1.49 x 1.32 x 0.88 inch
(38 x 33.5 x 22.3 mm)
Wheel Adapter
Article Number 1619PB6582
Measuring accuracy ±1/16 inch/1 ft
(±5 mm/m)
Measuring range (max.) 65.0 ft (20 m)
Weight according to EPTA-Procedure 01:2014 0.045 lbs (0.02 kg)
Dimensions 1.49 x 1.89 x 0.88 inch
(38 x 48 x 22.3 mm)
A) For measurements from the rear edge of the tool. In unfavorable conditions,
e.g. with extremely bright interior lighting or a poorly reflecting surface, the
measuring range may be reduced.
B) In unfavorable conditions, e.g. with extremely bright interior lighting, a
poorly reflecting surface or a room temperature that deviates significantly
from 77 °F (25 °C), the deviation can be a maximum of ±5/16 inch at a dis-
tance of 65 ft. In favorable conditions, an additional deviation of ±0.038
inch / 65 ft needs to be taken into account.
C) Non-conductive pollution only, whereby occasional temporary conduc-
tivity caused by condensation is expected.
2610067140 3Z Laser Measurer 02-21.qxp_La out 1 2/24/21 8:01 AM Page 1

11
Intended Use
Assembly
Inserting/changing the batteries
It is recommended that you use alkaline batteries to operate the measuring
tool.
– Insert the batteries (see figure 1). When inserting the batteries, ensure that
the polarity is correct according to the illustration on the inside of the bat-
tery compartment.
The battery warning (h) is shown on the display when the battery voltage
is weakening.
When the battery symbol first appears on the display, measurements can
be made for approx. another 15 minutes.
When the battery symbol flashes, you have to replace the batteries because
measurements are no longer possible.
Always replace all batteries at the same time. Only use batteries from
one brand and with identical capacity.
Remove the batteries from the laser measure when not using it for ex-
tended periods.When storing for extended periods, the batteries can cor-
rode and discharge themselves.
uDo not use lithium-ion batteries. This may result in damage to the
measuring tool.
Digital laser measure: The measuring tool is intended for measuring dis-
tances, lengths, heights and clearances, and for calculating areas. The
measuring tool is suitable for measuring indoors.
Tape adapter: The tape adapter is intended for use in combination with
the 3Z Laser Measurer for measuring circumferences (e.g. of vases, pipes,
etc.) and lengths of freestanding objects (e.g. televisions, shelves, etc.) in
interior areas.
Wheel adapter: The wheel adapter is intended for use in combination with
the 3Z Laser Measurer for measuring distances between two points (e.g.
lengths of material) in interior areas.
2610067140 3Z Laser Measurer 02-21.qxp_La out 1 2/24/21 8:01 AM Page 1

12
Do not leave the switched-on laser measure un-
attended and switch the laser measure off after
use. Other persons could be blinded by the laser beam.
Protect the laser measure against moisture and direct sun light.
Do not subject the laser measure to extreme temperatures or varia-
tions in temperature. As an example, do not leave it in vehicles for a long
time. In case of large variations in temperature, allow the laser measure to
adjust to the ambient temperature before putting it into operation. In case
of extreme temperatures or variations in temperature, the accuracy of the
laser measure can be impaired.
Avoid heavy impact to or falling down of the laser measure.After severe
exterior effects to the laser measure, it is recommended to carry out an ac-
curacy check (see “Accuracy Check of the Distance Measurement”, page
15) each time before continuing to work.
Switching the aser Measure on/off
– To switch on the measuring tool, briefly press the measuring button (1).
When the measuring tool is switched on, the laser beam is switched on.
The indicator (d) flashes on the display.
– To switch off the measuring tool, hold down the measuring button (1).
Do not point the laser beam at persons or ani-
mals and do not look into the laser beam your-
self, not even from a large distance.
Measuring Process
A continuous measurement is performed after the measuring tool has been
switched on. The current measured value (a) is shown on the bottom line
of the display (see figure 2).
Operation - Laser Measure
2610067140 3Z Laser Measurer 02-21.qxp_La out 1 2/24/21 8:01 AM Page 1

13
During continuous measurement, the measuring tool can be moved relative
to the target and the current measured value (a) will be updated approx.
every 0.5 seconds on the bottom line of the display (see figure 3).
The indicator (d) flashes on the display.
The rear edge of the measuring tool is the reference level for the measure-
ment ( ). (See figure 4)
1
'
6
''
' ''
Fig. 2
1
'
6
''
8
'5''
Fig. 3
1
'
6
''
Fig. 4
2610067140 3Z Laser Measurer 02-21.qxp_La out 1 2/24/21 8:01 AM Page 1

14
Measuring ength
– Press the measuring button (1) to stop the measuring process. The laser
beam is switched off and the current measured value (a) is displayed.
– Press the measuring button (1) again to switch the laser back on and
continue measuring. The current measured value (a) is shown on the
bottom line of the display, while the previous measured value (b) is dis-
played above it.
Area Measurement
– Press the measuring button (1) twice in quick succession to multiply the
last two measurements together (see figure 5). The indicator (f) ap-
pears on the display and the area measurement is shown.
Press the measuring button (1) twice in quick succession again to dis-
play the last two measurements.
If measuring tool remains idle for 5 minutes, the measuring tool with auto-
matically switch itself off to preserve battery life.
uDo not direct the laser beam at persons or animals and do not stare
into the laser beam yourself (even from a distance).
General Advice
The reception lens (7) and the laser beam output (8) must not be covered
during the measuring process.
ft2
ft2
ft
2
ft2
Fig. 5
2610067140 3Z Laser Measurer 02-21.qxp_La out 1 2/24/21 8:01 AM Page 1

15
The measurements are taken at the center of the laser beam, even when
the laser is pointed at surfaces diagonally.
In order to get an accurate measurement, the laser measure must not be
moved while taking a measurement. Therefore, place the laser measure,
as much as possible, against or on a firm stop or supporting surface. To
record the current measurement value on the display, press the measuring
button (1) (see also "Measuring Length" on page 14).
Effects to the Measuring Range
The measuring range depends on the light conditions and the reflection
properties of the target surface.
Effects to the Measuring Result
Due to physical effects, faulty measurements cannot be excluded when
measuring on different surfaces which include:
– Transparent surfaces (e.g., glass, water),
– Reflecting surfaces (e.g., polished metal, glass),
– Porous surfaces (e.g. insulation materials),
– Structured surfaces (e.g., roughcast, natural stone).
Also, air layers with varying temperatures or indirectly received reflections
can affect the measured value.
Accuracy Check of the Distance Measurement
The accuracy of the distance measurement can be checked as follows:
– Select a permanent measuring section with a length of approx. 3 ft to
33 ft (1 m to 10 m); its length must be precisely known (e.g. the width
of a room or a door opening). The measuring distance must be indoors;
the target surface for the measurement must be smooth and reflect well.
– Measure the distance 10 times after another.
The deviation of the individual measurements from the mean value must
not exceed ±1/8” (±3.0mm). Log the measurements, so that you can com-
pare their accuracy at a later point of time.
To Attach Adapter (see figure 1): Attach the adapter to the laser measure
so that it clicks into place.
To Remove Adapter:Press the release buttons (9) and take off the adapter.
Operation - Fitting the Adapter
2610067140 3Z Laser Measurer 02-21.qxp_La out 1 2/24/21 8:01 AM Page 1

16
– Switch on the measuring tool (see "Switching the laser measure on/off",
page 12).
uOnly use the tape adapter on clean and dust-free surfaces to avoid
measurement inaccuracies.
Measuring length (see figures 6−7)
After the measuring tool has been switched on, the tape extension is meas-
ured continuously. The current measured value (a) is shown on the bottom
line of the display. During continuous measurement, the length of the tape
can be adjusted, and the current measured value (a) is updated on the bot-
tom line of the display.
The measuring process is indicated by a blinking arrow on the display.
There are two possibilities to measure distances: using the outer edge or
using the hook function (inner edge) for measurements.
Outer edge measurement:
– Pull the tape (10) out of the adapter by the contact edge (11) and place
the tape with the outer edge (12) (marked in blue) against the object to
be measured (Fig. 6).
The visible length of tape (between the blue marking on the outer edge
of the contact edge and the marking on the exit of the tape on the
adapter housing) corresponds to the measurement length (in inch).
3ZLaserMeasurer
''
Fig. 6
Operation - ape Adapter
2610067140 3Z Laser Measurer 02-21.qxp_La out 1 2/24/21 8:01 AM Page 1

17
Hook function (inner edge (11)):
– Pull the tape (10) out of the adapter by the contact edge (11) and turn
the handle by 90° to the left. Place the handle on an edge to hook the
handle on the edge (Fig. 7).
The visible length of tape (between the blue marking on the exit of the
tape on the adapter housing of the adapter and the blue marked inner
edge of the handle) corresponds to the measurement length (in inch).
Press the measuring button (1) to save the measured value. The current
measured value (a) is shown on the bottom line of the display. Press the
measuring button (1) again to start a new measurement.
The current measured value (a) is shown on the bottom line of the display,
while the previous measured value (b) is saved and shown on the top line
of the display.
Note: When switching off the measuring tool, the current measured value
(a) is reset to "0", even if the tape is still pulled out. To avoid measuring er-
rors, always retract the tape fully before taking a new measurement. Do not
press the measuring button until you have done this.
If the tape is already extended when you are fitting the adapter to the meas-
uring tool or switching on the measuring tool, the "roll in" indicator will ap-
pear on the display. Retract the tape fully and press the measuring button
before taking a new measurement.
uAlways make sure that the measuring tape does not snap back into
the adapter. Release the tape slowly back into the adapter; otherwise
it may become damaged.
''
3ZLaserMeasurer
Fig. 7
2610067140 3Z Laser Measurer 02-21.qxp_La out 1 2/24/21 8:01 AM Page 1

18
Area Measurement
– Press the measuring button (1) twice in quick succession to multiply the
last two measurements together. The indicator (f) appears on the
display and the area measurement is shown.
ft2
– Switch on the measuring tool (see "Switching the laser measure on/off",
page 12).
Measuring ength (see figures 8−10)
– Run the wheel (13) along the distance to be measured. After the meas-
uring tool has been switched on, the wheel measures continuously. The
current measured value (a) is shown on the bottom line of the display.
During continuous measurement, the wheel can be moved forwards or
backwards. The measured values will be positive in both directions. If
the direction is changed during the measurement, the value will be de-
ducted until the starting point (zero point) has been reached. Once the
starting point has been crossed, the value will become positive again.
The current measured value (a) is updated on the bottom line of the dis-
play.
– The measuring process ends once the wheel has come to a stop. The
current measured value (a) is shown.
– Press the measuring button (1) again to save the measured value, and
continue measuring. The current measured value (a) is shown on the
bottom line of the display, while the previous measured value (b) is dis-
played above it.
Note: In order to obtain an exact measurement, do not change the angle
between the measuring tool and the surface (see figure 10). Make sure that
you apply a steady amount of pressure throughout the measuring process.
The result may vary on soft substrates and/or when applying excessive
pressure. The recommended pressure for an exact measurement result is
1.1 pound-force (500 g).
Operation - Wheel Adapter
2610067140 3Z Laser Measurer 02-21.qxp_La out 1 2/24/21 8:01 AM Page 1

19
Area Measurement
– Press the measuring button (1) twice in quick succession to multiply the
last two measurements together. The indicator (f) appears on the
display and the area measurement is shown.
ft2
1
'6''
Fig. 8
Fig. 9
Fig. 10
2610067140 3Z Laser Measurer 02-21.qxp_La out 1 2/24/21 8:01 AM Page 1

20
Errors – causes and corrective measures
Cause Corrective measure
Temperature warning (g) flashing, display shows "err",
measurement not possible, measuring tool switches off
automatically after five seconds
Measuring tool is outside of
the operating temperature
range of 14 °F … 104 °F
(– 10 °C ... +40 °C).
Wait until the measuring tool has
reached operating temperature.
Then switch the measuring tool
back on.
All symbols flash, measurement not possible
Measuring tool faulty Check the batteries and replace
them if necessary.
Fitted adapter (e) flashes, display shows "err", measurement
not possible
Adapter error:
– Faulty adapter Send the adapter to the
aftersales service.
– Adapter has no connection
to the measuring tool.
Clean the contacts. If the adapter
still cannot connect to the
measuring tool after you have
done this, send the adapter to
the after-sales service.
Display shows "----" or "----" together with area measurement
indicator (f), measurement not possible
Measuring range exceeded 65 ft
(20m) or was lower than 0.5 ft
(0.15 m) or poor measuring
conditions.
Keep the measuring range < 65 ft
(20 m) or > 0.5 ft (0.15 m) and
read the notes on the measuring
range.
Area measurement smaller than
0.11 ft2(0.01 m2). Measurement
too small to be displayed.
Keep the area calculation
≥ 0.11 ft2(0.01 m2)
2610067140 3Z Laser Measurer 02-21.qxp_La out 1 2/24/21 8:01 AM Page 2
