DROPSA Minisumo II User manual

2
Minisumo II Pump
Use and maintenance manual
Original instructions
Manual drafted in compliance
with directive 2006/42 C2280IE - WK 40/20
DropsA products can be purchased at DropsA branches and authorised distributors,
go to www.dropsa.com/contact or write to [email protected]

3
Index
1. INTRODUCTION............................................................2
1.1 GENERAL INFORMATION.......................................2
1.2 MANUFACTURER DATA.........................................2
1.3 Identification label ................................................2
1.4 How to use ............................................................2
1.5 Personnel qualification .........................................3
1.6 Personal protective equipment ............................3
2. Safety ...........................................................................4
2.1 General warnings ..................................................4
2.2 Residual risks.........................................................4
2.3 Pictograms.............................................................5
3. Machine description.....................................................6
3.1 Intended use and prohibited use..........................6
3.1.1 Intended use ......................................................6
3.2 Sound emissions....................................................7
3.3 Technical specifications.........................................8
3.4 Dimensions............................................................9
3.5 Standard pump components.. Errore. Il segnalibro
non è definito.
3.5.1 Inverters ...........................................................10
3.5.2 Fixed fixed flow rate pump elements ..............10
3.5.3 Minimum and maximum level indicators for
grease/oil ..................................................................11
3.5.3.1 Laser for grease minimum level (optional) ...11
3.5.3.2 Floating switch minimum/maximum level
sensor for oil .............................................................11
3.5.3.3 Floating switch visual maximum level for
grease/oil ..................................................................11
3.5.4 Grease and oil stirring paddle (standard
execution) .................................................................11
3.6 Electrical equipment ................................................11
4. Installation .................................................................12
4.1 Receipt and checking the content.......................12
4.2 Packaging ............................................................12
4.3 Transport and handling.......................................12
4.4 Storage ................................................................13
4.5 Environmental conditions ...................................13
4.6 Installation ..........................................................13
4.7 Electrical connection ...........................................14
5. Operating instructions ...............................................15
5.1 Preliminary procedures.......................................15
5.1.1 Filling the reservoir with grease.......................15
5.2 .............................................................................15
5.3 Starting the pump ...............................................16
5.4 Stopping the pump .............................................16
6. Adjustments...............................................................17
6.1 Adjustment/calibration of the level probe .........17
6.1.1 Calibration of the laser Level probe 0295131,
24Vdc Out NO and NC (1 threshold).........................17
6.1.2 Laser probe calibration thresholds 0295130,
24Vdc Out 4~20mA/2 NO (4 thresholds) ..................18
6.1.3 REED floating switch connection
0295150/0295160.....................................................18
7. Maintenance..............................................................19
7.1 General warnings ................................................19
7.2 Maintenance operations table............................20
7.2.1 Piping joints check ...........................................20
7.2.2 General cleaning of the pump .........................20
7.2.4 Replacing pumping elements...........................21
8. Troubleshooting....................................................22
8.1 Problems, causes and solutions ..........................22
9. Ordering information.................................................23
9.1 Standard versions ...............................................23
9.2 Optional equipment............................................24
9.3 Spare parts .........................................................24
10. Additional information.............................................25
10.1 Waste disposal ..................................................25
10.2 Toxic-harmful waste..........................................25
10.2.1 Provisional storage.........................................25
10.2.2 Characteristics of the containers ...................25
10.2.3 Registration obligations .................................26
10.3 Scrapping the machine .....................................26
10.4 Dismantling of the electronic components (WEEE
directive) ...................................................................26
11 Attachments .............................................................27
11.1 Hydraulic diagrams ...........................................27

2
1. INTRODUCTION
1.1 GENERAL INFORMATION
With this manual, we wish to provide you with all the important information for the safety of installation, operation and
maintenance personnel and for the decommissioning of the MINISUMO II pump.
The most recent version can be obtained by requesting it from the Sales Technical Office or online at
http://www.dropsa.com.
This manual, drafted originally in the ITALIAN language, constitutes an integral part of the pump and must be carefully
kept for the entire life of the same.
In the event that the pump is sold, rented or lent for use, it must be delivered to the new user together with the EC
Conformity Declaration.
Carrying out any operation on the pump without first having carefully read and comprehended all the instructions
contained in this manual is prohibited.
The images contained in this manual are purely illustrative and are not binding for the Manufacturer who reserves the
right to make changes to components and/or parts for improvement or other reasons without updating this manual if
these changes have not altered the operation and safety of the pump.
1.2 MANUFACTURER DATA
DropsA S.p.A.
Via Benedetto Croce, 1
20090 – Vimodrone (MI) – ITALY
Ph. [phone]
Fx. [phone]
E-mail: [email protected]
Web: http://www.dropsa.com
1.3 Identification label
A yellow is located on the front part of the pump reservoir that indicates the product code and the
basic characteristics.
ATTENTION
Removing or tampering with the identification label is strictly prohibited.
1.4 How to use
For a better understanding of the information provided in this manual, the warnings or instructions
that are considered to be critical or dangerous are highlighted with the following symbols:
DANGER
For instructions that, if not followed, may cause danger.
ATTENTION
For instructions which, if not followed, may cause damage to the pump.

3
1.5 Personnel qualification
To ensure that all the operations carried out on the pump take place in safe conditions, the operators in charge
must possess the qualifications and prerequisites required to carry out the relative operations.
The operators are classified as follows:
FIRST LEVEL OPERATOR:
unqualified personnel, in other words, without specific skills, capable of carrying out only simple tasks.
MECHANICAL MAINTENANCE SPECIALIST:
qualified technicians that are capable of performing adjustments, maintenance and repair operations
upon the machine's mechanical components. This person is not qualified to work on live electrical
systems.
ELECTRICAL MAINTENANCE SPECIALIST:
qualified technician responsible for all electrical operations. This person is capable of operating on the
machinery even with live electrical cabinets and junction boxes.
1.6 Personal protective equipment
This operating manual presumes that the pump has been installed in a workplace where all of the compulsory
safety requirements are observed. Specifically, personnel must be provided with personal protection
equipment in relation to the operations that they must fulfil.
PROTECTIVE GLOVES
These must be suitable for the hand of the operator who must wear them and they must be long
enough to cover the operator's elasticised garment at the wrist. They must guarantee a secure and
quick grip, as well as high resistance to the product being handled. They must also guarantee
protection and comfort against low and high temperatures and good absorption of perspiration.
Protective gloves must be used in the event of work and maintenance operations on the pump.
EYE PROTECTION
These must be of suitable dimensions for the operator’s face, they must provide maximum visual
field and comfort and be suitable for prolonged use. They must provide maximum safety against
possible infiltrations and they must protect from drops and sprays.
Eye protection must be used each time work or cleaning instruments are used that imply the projection of solid
particles, even very small ones.
PROTECTIVE FOOTWEAR
The footwear must have an anatomic, anti-stress insole, allow proper breathability of the foot for
the comfort of the foot and the upper part must be impenetrable to contact with the product
being used. They must completely cover the ankle, overlapping with the trousers and they must be
the type that allow rapid removal of the foot in the event that this should be necessary.
They must have a steel toe for protection against impact and crushing.
Protective footwear must be used throughout the entire period that work and maintenance is carried out on
the pump.

4
2. Safety
2.1 General warnings
Before carrying out any operation on the pump, it is important to read this manual. Always observe the safety regulations
of the nation in which the pump is installed and the need to use specialised personnel in the various operations of
maintenance, operation, installation, etc. required during the life of the pump.
The main rules of conduct to be observed to work at a good safety level are the following:
The operations of installation, operation, maintenance, etc. must always be carried out by qualified and trained
personnel.
It is good practice to always wear the foreseen personal protection equipment without exception.
Always carry out all of the cleaning, adjustment and maintenance operations ensuring that the power supplies are
disconnected.
Never direct jets of water toward the electrical parts, even if they are protected by housings.
Never smoke during operation or maintenance, especially in the event that flammable solvents or materials are
used.
Do not damage the labels, signs and pictograms applied to the pump. In the event that they are damaged
inadvertently, replace them immediately with identical ones.
Checking the chemical compatibility of the pump construction materials with the fluid that you intend to pump. An
incorrect choice could cause, in addition to damage to the pumps and the lines, serious risk to personnel (leaking of
products that are irritants and harmful to the health) and to the environment.
Never exceed the maximum permitted operating pressure value for the pump and the components connected to it.
If in doubt, see the data on the machine's label.
Use only original spare parts.
If you must replace components with others, ensure that they are suitable to function at the pump's maximum
operating pressure.
DropsA S.p.A. will not be held liable for damage to people or objects stemming from improper use of the pump, tampering
with its safety devices or failing to observe occupational health and safety regulations.
ATTENTION
Never try to stop or deviate any leaks with your hands or other parts of the body.
ATTENTION
The warnings on risks using a lubricant pump implies must be carefully read. The user must be familiar with
operation through the Operation and Maintenance Manual.
2.2 Residual risks
DANGER
The pump was designed in such a way so as to reduce residual risk for personnel to a minimum. Nevertheless, we urge caution and
attention in carrying out maintenance operations. Unfortunately, the familiarity achieved through frequent contact with the pump often
leads to forgetting or underestimating any risks.
The hazards that have not been entirely eliminated, but that have been deemed acceptable, are listed
below:
Contact with lubricant during maintenance or filling the reservoir
During the maintenance phase, low pressure spurts of lubricant are possible. (For this reason,
maintenance operations must be carried out using suitable PPE, in accordance with the prevailing
regulations).
Protection from direct or indirect contact with the lubricant must be ensured by the machine user.

5
Use of unsuitable lubricant.
The characteristics of the lubricant are indicated both on the pump and in this Operation and
maintenance manual (in the event of any doubt, contact the Dropsa S.p.A. Technical Office):
Electrical current
No operations must be carried out on the machine before disconnecting it from the electrical power
supply and ascertaining that no-one can reconnect it during the operation. All of the installed
equipment (electrical and electronic), reservoirs and base structures must be connected to the
ground line.
Electrocution
This can occur only in the event of serious negligence by the user who, however, is qualified.
Flammability
The lubricant used in the lubrication circuits is a fluid that is not normally flammable. In any case, all
possible measures must be taken to prevent it coming into contact with very hot parts or naked
flames.
Pressure
Before any operation, check for the absence of any residual pressure in all branches of the lubricant
circuit, that could cause spurts of oil or grease in the event that fittings or components are
disassembled. After long periods of inactivity, check the seal on all the parts subject to pressure. Do
not subject the fittings, pipes and the parts under pressure to violent impact. A damaged hose or
fitting is DANGEROUS. Replace it.
We recommend using only original spare parts.
2.3 Pictograms
Some pictograms are applied on the pump with warning and safety symbols for the operators.
Carefully read and familiarise yourself with the symbols and their message before using the pump.
ELECTRICAL HAZARD
You are close to electrical connections (protected) but accidental contact with them may cause electrocution and even death.
LASER RADIATION HAZARD
DropsA S.p.A. will not be liable for damage to people or things dues to the failure to observe the
regulations indicated by the pictograms or their imperfect preservation.

6
3. Machine description
The MINISUMO II range of lubrication pumps are particularly suited for dual-line and progressive systems and can adapt to
many needs without mechanical modifications, even after installation. In fact, be choosing a set of components that are
perfectly compatible with one another and easy to assemble, you can vary the pressure, the quantity of lubricant
distributed, the type of lubricant or the type of distribution.
This construction technique is based essentially on the following modules:
Motor
Pump body
Two pumping elements
Reservoir
Valves and output assemblies (inverter, pressure adjustment valve, etc.).
The bearing structure is the same for any version. The dual pumping element constitutes the essential module.
The pumping element normally has only one outlet, but the version with separate outlets can be requested.
Two types of grease and oil reservoirs with different volumes (10 or 30 kg~22 or 66 lbs) can be arranged on the pump
body with stirring paddle and electric level indicator.
The MINISUMO II electric pump is fully protected against the external environment and can operate without difficulty
even in the most severe environmental conditions.
3.1 Intended use and prohibited use
3.1.1 Intended use
The MINISUMO II pump is the ideal electric DropsA pump for use with single and dual line systems.
Lubrication systems engineered with the Dual Line System are generally used on large scale machinery and in harsh
operating conditions to lubricate multiple points on large machines.
NOTE: The pump is designed to work with maximum NLGI 2 grade lubricants.
Use NBR gasket compatible lubricants.
Any residual lubricant inside that was used for assembly and testing is NLGI 2 grease.
A table is shown that compares the NLGI (National Lubricating Grease
Institute) and ASTM (American Society for Testing and Materials)
categories for greases, limitedly to the values that involve the pump.
For further information on the technical characteristics and the safety
measures to adopt, see the Product Safety Data Sheet (Directive
93/112/EEC) related to the type of lubricant selected and supplied by
the manufacturer.
GREASES
NLGI ASTM
000 445 – 475
00 400 – 430
0 355 – 385
1 310 – 340
2 265 – 295

7
Prohibited Use
Any use other than that for which the pump was built is an abnormal condition and therefore may
cause damage to the pump itself and constitute grave danger for the operator.
A series of operations relative to improper use of the pump which are prohibited under any circumstances are listed
below.
Use the pump only in industrial installations. Different use of the machine is prohibited;
Do not use the pump in conditions other than those indicated in this operation and maintenance manual;
Do not use the pump in an explosive or aggressive atmosphere. or in an atmosphere. with a high concentration of
airborne dust or oily substances;
Do not make changes, transformations, carry out repair or maintenance operations on the pump of your own
initiative. Maintenance work may be carried out only in compliance with the indications in this manual.
Do not use non-original replacement parts or parts not foreseen by the Manufacturer;
Do not use the pump to pump substances other than those permitted. Use of prohibited materials may damage the
pump, deteriorate its performance or reduce its useful life;
Do not expose the pump to rain, steam, excessive humidity or direct sunlight;
Do not install the pump in locations subject to flooding;
Do not place or store near flammable or combustible materials or substances;
Do not open the oil filler or drainage caps during operation of the pump.
PROHIBITED FLUIDS
FLUIDS
HAZARDS
Lubricants with abrasive additives
Wear of pump internal components
Lubricants with silicon additives
Seizing of the pump
Petrol – solvents – flammable liquids
Fire – explosion – damage to the gaskets
Corrosive products
Corrosion of the pump – damage to personnel
Water
Oxidation of the pump
Food substances
Contamination of the same
For more detailed information on the compatibility of the product with particular fluids, contact the DropsA S.p.A.
Technical Office.
ATTENTION
Using the pump submerged in fluids or in a particularly aggressive or explosive/flammable environment is
prohibited unless it has been prepared ahead of time by the supplier for this purpose.
ATTENTION
DO NOT use lubricants that are aggressive to NBR gaskets. If you are unsure, contact the DropsA SpA technical
office for a detailed list of recommended oils.
3.2 Sound emissions
In normal operating conditions, the noise emission does not exceed the value of 70 dB “A” at a distance of 1 metre (39.3
inches) from the pump.

8
3.3 Technical specifications
GENERAL SPECIFICATIONS
Empty weight (10 Kg reservoir)
40 Kg - 88 lbs
Empty weight (30 Kg reservoir)
45 Kg - 99 lbs
Empty weight (100 Kg reservoir)
60 Kg - 132 lbs
ELECTRICAL SPECIFICATIONS
Motor power supply
230-400V - ±5% 50Hz
280-480V - ±5% 60Hz
24V cc
Insulation class F
Motor power rating
0.37 Kw
Motor protection degree
IP 54
Minimum level
Laser (grease) – Float (oil)
Maximum level
Float (grease/oil)
HYDRAULIC SPECIFICATIONS
Pumping system
Piston
Flow rate (2 pumping elements)
110 cc/min
Maximum operating pressures
380 bar (5511 psi) - (1)300 bar (4351 psi)
Outlet connection
G3/8” BSP
Reservoir capacity
10-30-100 Kg (22-66-220 lbs)
Filling filter
Filtering grade 300 µ
By-pass valve
Adjustable 0~380 bar (0~5511 psi) – precalibrated 300 bar
(4350 psi) -
(1)
250 bar (3625 psi)
Operating temperature
- 10 ÷+ 50 °C (+14~122F)
Operating humidity
90% R.H.
Permitted lubricants (1)
Mineral oil lubricant, min. 32 cSt; max. grease NLGI2
Storage temperature
-40 ÷+65 °C (-40~149F)
Continuous sound pressure level
< 70 dB(A)
Note: The specifications refer to an operating temperature of + +20°C (+ +68°F)
(1) With 24V cc motor
(2)If a different product is used, you must ask DropsA S.p.A. if it is suitable for use

9
3.4 Dimensions
10 Kg
30 Kg
100 Kg
A
344 [13.5]
533
983
B
841 [33.1]
1030
1480
C
731 [27.7]
920
1370
D
616 [24.2]
805
1255

10
3.5 Standard pump components
STANDARD PUMP COMPONENTS
1
Laser minimum level
7
Pumping system
2
Maximum level
8
Bypass
3
Reservoir
9
Pressure gauge
4
Ratio motor
10
Filling (for grease pump)
5
Delivery line 1
11
Reservoir minimum level (for oil pump)
6
Delivery line 2
12
Lubricant filler cap (for oil pump)
3.5.1 Inverters
For the inverter technical specifications and the methods of use, see the specific product manuals attached to the pump.
3.5.2 Fixed fixed flow rate pump elements
The pump is configured with one or two fixed flow rate pumping elements (110 cm^3/ min for each pumping element).
The seal between piston and pumping body is a dry type since it has no gasket in between.
The pumping element check valve is the tapered seal type. This solution allows an outstanding seal of the system to be
guaranteed at high operating pressures (max pressure of 400 bar – 5800 psi).
The pumping elements are mounted on the pump body without the need to disconnect the piping of the line with a
threaded connection, which makes it easy to assemble/disassemble.
9
8
1
2
4
5
3
10
7
12
11
Return Delivery
Detail without
inverter

11
3.5.3 Minimum and maximum level indicators for grease/oil
3.5.3.1 Laser for grease minimum level (optional)
The minimum level is achieved by a laser probe. The probe is normally closed when there is grease.
When the minimum level is reached, the probe signals the lack of lubricant.
For connections and setting see Par. 6.1.1 and 6.1.2.
3.5.3.2 Floating switch minimum/maximum level sensor for oil
A dipstick probe with dual floating switch mounted on the pump cover allows the minimum oil level
(reserve) and the maximum level (that allows the interruption of automatic reservoir filling) to be
read.
For connections, see Par. 6.1.3.
3.5.3.3 Floating switch visual maximum level for grease/oil
The filling phase of the lubricant in the reservoir is carried out by the operator with an appropriate
pump.
Once the maximum level of lubricant is reached, the rod that indicates that the reservoir is full
intervenes.
3.5.4 Grease and oil stirring paddle (standard execution)
Two reservoirs have been provided with capacity of 10, 30 and 100 kg. (22-66 – 220 lbs).
As standard, the reservoirs have the stirring paddle and the scraper that do not need to be
disassembled in the event of disassembly and replacement of the same. As standard equipment,
under the stirring paddle there is an electrogalvanized steel mesh with 0.5 mm (0.02 in.) holes. There
pump is thereby protected from any foreign objects that could be inadvertently present during the
reservoir filling phase.
3.6 Electrical equipment
“DROPSA” electrical equipment is designed for the purpose of providing a system complete with all
the controls needed for operation of centralized lubrication systems that is automatic and controlled
by safety signals. The primary supply voltage is 400 Vac and 50 Hz. Other voltages are available on
request. For more information on the available version, contact the DropsA sales engineers.
*For control equipment with 4/3 inverter, contact the DropsA technical sales office.
**For other primary power supply and inverter voltages, contact the DropsA technical sales office.
Type of probe Type of inverter*
Supply
voltage
V **
Code Electrical
equipment VIP5 PRO
Code Electrical equipment
VIP5 PLUS
Code Electrical
equipment with PLC
LASER PROBE
24Vdc
(standard)
Out NO and NC
(1 threshold)
or Floating switch
Electromagnetic
Valve 4/2
or hydraulic
24 VDC
1639211 1639210
1637008
Electro-pneumatic
Valve 4/2
or hydraulic
24 VDC 1637011
LASER PROBE
24Vdc Out
4~20mA/2 NO (4
thresholds)
Electromagnetic
Valve 4/2
or hydraulic
24 VDC
1639211 1639210
1637001
Electro-pneumatic
Valve 4/2
or hydraulic
24 VDC 1637005

12
4. Installation
4.1 Receipt and checking the content
Upon receiving the pump, you must ensure that the packaging is intact or whether there are clear signs of damage due to
transport or storage conditions. If everything is intact, proceed with unpacking and checking the pump.
Otherwise, if damage to the packaging is found, the transport agent and the manufacturer must be notified immediately.
The material received must always be checked to ensure that it corresponds to what is indicated on the accompanying
document.
The packaging must be opened using every precaution in order to prevent damage to people and the contents of the
package itself.
4.2 Packaging
The pump is packaged in the following way:
Secured on a metallic pallet with lateral packaging and cover in wood.
The wood can be reused or recycled in compliance with the prevailing laws in the country of installation of the pump.
Other materials such as cardboard, plastic or the protective film must be disposed of in accordance with the relevant
prevailing local regulations.
Do not burn or dispose of the package contents into the environment.
4.3 Transport and handling
DANGER
The transportation, lifting and handling operations must be carried out by expert and qualified personnel.
The pump can be lifted and handled with forklifts or pallet jacks suitable for the weight of the same, indicated on the
technical data table and in any case on the identification label. Manual handling and transport is permitted only in
compliance with the relevant prevailing local regulations.
Lift the equipment bearing in mind the direction indicated on the box.
The components of the machine can withstand temperatures during storage from -40°C to + 65°C (-
40°F~149°F). However, in order to prevent damage, start-up must take place when the machine has
reached a temperature of -10°C (+14°F).
ATTENTION
For transport, we recommend preparing the pump as indicated in the following section and emptying the
reservoir of oil.

13
4.4 Storage
Empty the pump of any oil or grease and close the intake and outlet with the specific protection. The pumps must be
stored in their own packaging and kept in covered, dry, protected places that are not exposed to direct sunlight and at a
temperature that falls within the range indicated on the technical specifications table.
4.5 Environmental conditions
The pump must be installed and used in a covered and sufficiently lit facility. The installation area
must possess all the requirements in terms of heights and air exchange, and it must comply with the
requirements set by the relevant prevailing regulation.
Temperature
The required work environment temperature values are indicated on the technical specifications
table.
Lighting
All the areas must be lit in a uniform way and sufficiently to guarantee all the operations foreseen in
the manual, preventing areas of shade, reflections, glaring or fatiguing for the vision.
4.6 Installation
No pump installation operations are required. The pump is secured to a metallic pallet which allows
safe handling with a pallet jack or a forklift. The pallet itself is designed to be able to be installed in
the system since it is equipped with 4 Ø14 mm holes suitable for floor-mounting. Provide adequate
spaces (as per the installation diagram) to prevent abnormal posture or the possibility of impact.
Subsequently, as previously described, the pump’s hydraulic connection to the machine must be
made, followed by the connection to the control panel.
DANGER
The pump connections must be made only by qualified and specifically trained personnel.

14
4.7 Electrical connection
DANGER
The connection to the ground must be made only by an electrical maintenance technician.
The pump must be installed in an industrial environment in compliance with prevailing law.
In order to prevent dangers of electrocution due to direct or indirect contact with the live parts, the
electrical power supply line must be adequately protected with a specific breaker switch with 0.03
Ampere tripping threshold and max tripping time of 1 second.
ATTENTION
Adhere to the indications on the EC identification label.
ATTENTION
A disconnect switch must be installed on the machine that hosts the pump.
ATTENTION
The switch’s disconnect power must be ≤ 10 kA and the rated current In = 6 A.
ATTENTION
All the electrical components must be connected to the ground. This is valid both for the electrical components and for controller devices.
For this purpose, ensure that the ground wire is connected directly. For safety reasons, the ground cable must be about 100 mm longer
than the phase wires. In the event of accidental disconnection of the cable, the ground terminal must be the last to disconnect.

15
5. Operating instructions
ATTENTION
Use gloves and eye protection as required by the oil or grease lubricant safety data sheet.
DANGER
Never ignore health hazards and always follow sanitary regulations.
Before using the MINISUMO II pump, some preliminary checks must be carried out:
Check the integrity of the pump.
Ensure that the pump is at operating temperature and that the piping is free of any air bubbles.
Ensure that the electrical connection has been carried out correctly.
With the pump started, ensure that the electric motor rotation direction matches the arrow on the motor’s
protective casing. If it turns in the opposite direction, reconnect as indicated on the electrical diagram attached to
the motor.
The unit can be opened and repaired only by specialized personnel.
5.1 Preliminary procedures
5.1.1 Filling the reservoir with grease
To fill the pump reservoir with grease, proceed as follows:
1) Unscrew the cap using an appropriate wrench;
2) Using the ½” fitting, introduce grease into the reservoir.
The reservoir must be filled until reaching the maximum level. This level is signalled by the rising of the level rod
or, if present, by the laser level probe (optional).
3) Screw the cap back on.
5.2

16
5.3 Starting the pump
1. Press the start button on the machine or system where the pump is connected.
2. Ensure that the pump starts; rotation of the motor, dispensing of the grease
and pressurised piping indicate that the pump is actually working.
3. To change the pressure valve, act on the by-pass valve adjustment screw (see
Sect. 3.5). Turn clockwise to increase or anticlockwise to decrease the pressure
(see adjacent figure);
The pump is intended to feed two lines.
See sections 3.3 and 3.4 for the pump technical data.
5.4 Stopping the pump
Stopping the pump depends directly on the system where it is installed.
+
-

17
6. Adjustments
6.1 Adjustment/calibration of the level probe
6.1.1 Calibration of the laser Level probe 0295131, 24Vdc Out NO and NC (1 threshold)
1. Reference notch.
2. Yellow LED: lights when the set value is
reached (outlet=ON).
3. Locking ring nut.
4. Setting ring nut (manually adjustable
after unlocking).
5. Green LED: indicates the correct power
supply (24Vdc).
To obtain a correct setting, take the setting ring nut to the maximum value and then descend to the
desired value.
A label is positioned on the pump with the electrical connection diagram and the settable threshold
values. The pump is normally supplied with the sensor preset at the threshold “L” (minimum level).
Whereas the other thresholds:
MM (absolute maximum level);
M (maximum level);
LL (absolute minimum level);
can be set by the user.
ATTENTION
Only one threshold at a time can be set.

18
6.1.2 Laser probe calibration thresholds 0295130, 24Vdc Out 4~20mA/2 NO (4 thresholds)
The laser probe has a display for viewing and programming mounted
on board. You can work in analogue (with signal from 4 to 20 mA) or
digital (two outputs and four intervention thresholds).
Attached is a table with the laser probe calibration parameters.
NOTE: To vary the laser probe calibration thresholds, contact DropsA personnel.
6.1.3 REED floating switch connection 0295150/0295160
LASER PROBE CALIBRATION
10 Kg reservoir 30 Kg reservoir 100Kg reservoir
Pos. Level Signal
Outlet set-up
quot
a X
[mm
]
grease
quantity [Kg]
quota X
[mm]
grease quantity
[Kg]
quota X
(mm)
grease
quantity
(Kg)
A
Absolute
maximum
level
OUT 2= Fno
nsP2 220
11 220 23 220 90
C
Minimum
level
fsP2 300 5 490 5 850 17
B
Maximum
Level
OUT 1= Fno
nsP1 250 9 250 21 250 86
D
Absolute
minimum
level
fsP1 330 3 520 3 880 14

19
7. Maintenance
7.1 General warnings
DANGER
Ensure that the electrical power supply and the hydraulic power of the system where the pump is installed are disconnected before
carrying out any maintenance operations.
DANGER
Do not carry out any type of operation, change and/or repair of any kind, except those indicated in this manual.
Only trained or authorised technical personnel possess the necessary experience for carrying out any operation with the
appropriate technique.
DANGER
Should maintenance on the pump be carried out in a way that does not comply with the instructions provided, with non-original
replacement parts or without written authorisation from the manufacturer, or in any case in such a way so as to compromise the integrity
or modify the characteristics, DropsA S.p.A. will not be held liable for personnel safety and the defective operation of the pump.
DANGER
Do not remove or tamper with the warranty seal for any reason whatsoever.
