“Output pin connection”
Red : Upper left / Right Channel (+)
Green :Bottom left / Right Channel (-)
White : Upper right / Left channel (+)
Blue : Bottom right / Left channel (-)
Stylus Replacement
Stylus replacement is available at DS-Audio. Please consult our authorized dealer for its
cost and time.
Equalizer & Optical Cartridge
Descriptions of Parts and Controls
RL
RED
GREEN Blue
White
Power Switch
L / R channel lines of your turn table player are connected to those terminals.
Make sure that each channel is connected to the same channel, while Optical
cartridge is taking power out from those lines, Misconnection may damage the cartridge.
Power On / Off button
Power inlet terminal
INPUT
Connect to the power outlet with the suppiled AC power cable.
Low cutoff switch
You can select the cutoff of the low frequency range below 30Hz or below 50Hz.
Refer to the graph below for the low-frequency roll-off graph when each is selected. ※Do not connect MM/MC cartridge to this Equalizer. It may break MM/MC cartridge.
Power indicator LED
LED indicates power being on when it is lit. When Equalizer is turned on, yet LED
is not lit,check the Cartridge connection and Equalizer connection
Cantilever / Stylus
Adjust the Stylus pressure carefully as to the recommended pressure range.
Do not remove the film on the bottom as it is a dust prevention film.
Output pins
Connect Output pins as described in “Output pin connection”.
GND
Connect the ground line of your turn table player
* Connect outputs 1 to 3 to line level input terminals such as AUX terminals.
* You can select from a total of 6 types of patterns so that you can select the output that
best matches your system. These 6 types of outputs differ only in the low cutoff curve.
RCA output and XLR output (balanced output 2nd hot)
a, 30Hz switch selected OUT PUT1 output
(LINE output)
It is equipped with a cutoff analog filter from 30Hz to 6dB/oct.
b, 30Hz switch selected OUT PUT2 output
(LINE output)
Equipped with a cutoff analog filter from 30Hz to 6dB/oct and
25Hz to 12dB/oct.
c, 30Hz switch selected OUT PUT3 output
(LINE output)
The analog filter of the cutoff of 35Hz to 12dB/oct, 30Hz to
6dB/oct, and 25Hz to 12dB/oct is installed.Please use when
you do not want to move the woofer or when there is a lot of
warp in the record.
d, 50Hz switch selected OUT PUT1 output
(LINE output)
It is equipped with a cutoff analog filter from 50Hz to 6db/oct.
e, 50Hz switch selected OUT PUT2 output
(LINE output)
Equipped with a cutoff analog filter from 50Hz to 6dB/oct
and 25Hz to 12dB/oct.
f,50Hz switch selected OUT PUT3 output
(LINE output)
The analog filter of the cutoff of 35Hz to 12dB/oct, 50Hz to
6dB/oct, and 25Hz to 12d/oct is installed.Please use when
you do not want to move the woofer or when there is a lot of
warp in the record.
