DS18 12XL1500-8 User manual

ENGLISH | ESPAÑOL
12" MID-RANGE LOUDSPEAKER
ALTAVOZ DE RANGO MEDIO DE 12"
OWNER’S MANUAL
MANUAL DEL USUARIO
12XL1500-8

SPECIFICATIONS / ESPECIFICACIONES:
Nominal Diameter / Diámetro Nominal.............................................................................................. 12" / 305mm
Nominal Impedance / Impedancia Nominal .................................................................................................. 8 ohms
RMS Power Handling / Manejo de Potencia RMS...................................................................................750 watts
MAX Power Handling / Manejo de Potencia MAX.................................................................................1500 watts
Sensitivity (1w/1m) / Sensibilidad (1w /1m) ...............................................................................................98.7 dB
Frequency Response / Respuesta de Frecuencia.............................................................................. 45Hz-6.5KHz
Recommended Hi Pass Crossover / Corte Paso Alto Recomendado.............................................................60Hz
Sold as Pair or Single / Vendido en Par o Unidad ........................................................................... Single / Unidad
MOTOR / MOTOR:
Voice Coil Diameter / Diámetro de la Bobina de Voz...........................................................................3.5" / 89mm
VC Former Material / Material Interior de Bobina de Voz............................................................................ Kapton
Winding Material / Material del Embobinado ..........................
CCAW (2 Layers IN/OUT) (2 Capas Adentro/Afuera)
Cone Material / Material del Cono ....................................................... Non-Pressed Paper / Papel No Prensado
Dust Cap Material / Material de la Tapa Antipolvo............................................................................ Paper / Papel
Surround Material / Material de la Suspensión .....................................................................................Cloth / Tela
Basket Material / Material de la Canasta...............................................................................Aluminum / Aluminio
Basket Color/Finish / Color/Acabado de la Canasta ...............................................Satin Black / Negro Satinado
Magnet Material / Material del Imán ...............................................................................................Ferrite / Ferrita
Magnet Weight / Peso del Imán ........................................................................................................................ 93 Oz
Displacement Volume / Volumen de Desplazamiento .....................................................................2.2L / 0.09ft3
THIELE & SMALL PARAMETERS / PARÁMETROS T/S:
Equivalent Volume / Volumen Equivalente..........................Vas.................................................... 62.7L / 2.21ft3
Excursion / Excursión ..............................................................Xmax ...............................................................4.5mm
Free Air Resonance / Resonancia al Aire Libre.....................Fs .......................................................................54Hz
Mechanical Factor / Factor Mecánico ...................................Qms ..................................................................... 6.98
Electrical Factor / Factor Eléctrico.........................................Qes ...................................................................... 0.41
Total Factor / Factor Total ......................................................Qts ....................................................................... 0.38
Mechanical Mass / Masa Mecánica.......................................Mms .................................................................. 56.4g
Mechanical Compliance / Cumplimiento Mecánico.............Cms ..........................................................0.16mm/N
BL Factor / Factor Bl ...............................................................Bl........................................................................16.92
Voice Coil Inductance / Inductancia de Bobina de Voz........Le ...................................................................0.12mH
Cone Area / Área del Cono ......................................................Sd.............................................................. 526.85cm²
DC Resistance / Resistencia DC .............................................Re...................................................................5.8 ohm
Mechanical Mass w/o air / Mechanical Mass w/o air.........Mmd..................................................................... 57g
MEASUREMENTS / MEDIDAS:
Overall Diameter / Diámetro Total ...................................................................................................12.3" / 312mm
Overall Depth / Profundidad Total.................................................................................................5.76" / 146.2mm
Front Mount Baffle Cutout
/ Corte del Orificio de Montaje...........................................................10.9" / 278mm
Mounting Depth / Profundidad de Montaje ....................................................................................5.23" / 133mm
Motor Diameter / Diámetro del Motor.............................................................................................7.48" / 190mm
12XL1500-8

MEASUREMENTS / MEDIDAS:
Please visit our website DS18.com for more information
on our warranty policy.
We reserve the right to change products and specifications
at any time without notice.
Images may or may not include optional equipment.
Visita nuestra página web DS18.com para obtener más
información sobre nuestra garantía.
Nos reservamos el derecho de cambiar productos y
especificaciones en cualquier momento sin previo aviso. Las
imágenes pueden incluir o no equipo opcional.
WARRANTY GARANTÍA
WARNING:
Cancer and Reproductive Harm.
www.P65Warning.ca.gov
ADVERTENCIA:
Cáncer y Daño Reproductivo.
www.P65Warning.ca.gov
SPECIFICATIONS / ESPECIFICACIONES:
Nominal Diameter / Diámetro Nominal.............................................................................................. 12" / 305mm
Nominal Impedance / Impedancia Nominal .................................................................................................. 8 ohms
RMS Power Handling / Manejo de Potencia RMS................................................................................... 750 watts
MAX Power Handling / Manejo de Potencia MAX.................................................................................1500 watts
Sensitivity (1w/1m) / Sensibilidad (1w /1m) ...............................................................................................98.7 dB
Frequency Response / Respuesta de Frecuencia.............................................................................. 45Hz-6.5KHz
Recommended Hi Pass Crossover / Corte Paso Alto Recomendado.............................................................60Hz
Sold as Pair or Single / Vendido en Par o Unidad ........................................................................... Single / Unidad
MOTOR / MOTOR:
Voice Coil Diameter / Diámetro de la Bobina de Voz...........................................................................3.5" / 89mm
VC Former Material / Material Interior de Bobina de Voz............................................................................ Kapton
Winding Material / Material del Embobinado ..........................
CCAW (2 Layers IN/OUT) (2 Capas Adentro/Afuera)
Cone Material / Material del Cono ....................................................... Non-Pressed Paper / Papel No Prensado
Dust Cap Material / Material de la Tapa Antipolvo............................................................................ Paper / Papel
Surround Material / Material de la Suspensión .....................................................................................Cloth / Tela
Basket Material / Material de la Canasta...............................................................................Aluminum / Aluminio
Basket Color/Finish / Color/Acabado de la Canasta ...............................................Satin Black / Negro Satinado
Magnet Material / Material del Imán ...............................................................................................Ferrite / Ferrita
Magnet Weight / Peso del Imán ........................................................................................................................ 93 Oz
Displacement Volume / Volumen de Desplazamiento .....................................................................2.2L / 0.09ft3
THIELE & SMALL PARAMETERS / PARÁMETROS T/S:
Equivalent Volume / Volumen Equivalente..........................Vas.................................................... 62.7L / 2.21ft3
Excursion / Excursión ..............................................................Xmax ...............................................................4.5mm
Free Air Resonance / Resonancia al Aire Libre.....................Fs .......................................................................54Hz
Mechanical Factor / Factor Mecánico ...................................Qms ..................................................................... 6.98
Electrical Factor / Factor Eléctrico.........................................Qes ...................................................................... 0.41
Total Factor / Factor Total ......................................................Qts ....................................................................... 0.38
Mechanical Mass / Masa Mecánica.......................................Mms .................................................................. 56.4g
Mechanical Compliance / Cumplimiento Mecánico.............Cms ..........................................................0.16mm/N
BL Factor / Factor Bl ...............................................................Bl........................................................................16.92
Voice Coil Inductance / Inductancia de Bobina de Voz........Le ...................................................................0.12mH
Cone Area / Área del Cono ......................................................Sd.............................................................. 526.85cm²
DC Resistance / Resistencia DC .............................................Re...................................................................5.8 ohm
Mechanical Mass w/o air / Mechanical Mass w/o air.........Mmd..................................................................... 57g
MEASUREMENTS / MEDIDAS:
Overall Diameter / Diámetro Total ...................................................................................................12.3" / 312mm
Overall Depth / Profundidad Total.................................................................................................5.76" / 146.2mm
Front Mount Baffle Cutout
/ Corte del Orificio de Montaje...........................................................10.9" / 278mm
Mounting Depth / Profundidad de Montaje ....................................................................................5.23" / 133mm
Motor Diameter / Diámetro del Motor.............................................................................................7.48" / 190mm
20 Hz 50 100 200 500 1K 2K 5K 10K 20K
dBSPL
30
40
50
60
70
80
90
100
110
SPL vs Freq

V2
V1
