Dsoon H8WIFI User manual

User Manual
WiFi Trail Camera
Model: H8WIFI
www.dsoonhunt.com

Table of Contents
TABLE OF CONTENTS
English
Français
Deutsch
Italiano
Español 9 9 -12 2
75-98
51-74
27-50
2-26
1
En
De
Fr
It
Es

2
Important Note
IMPORTANT NOTE
Congratulations on your purchase of one of the best trail cameras
on the market! We appreciate your business and want to earn your
trust. Please refer to the instructions in this manual to ensure that
you are completely satisfied with this product.
We will offer QUICK REPLACEMENT or FULL REFUND referring
to any issues.
US Dsoon Customer Service:
Email: [e-mail]
Web:www.dsoonhunt.com
Facebook messenger
Use Guide WiFi connection video
WhatsApp

Table of Contents
Camera Overview 5
Quick Start 6
Parameter Settings 10
3
Trouble Shooting/FAQ
Using the Wall Bracket 16
Wifi Feature 17
APP Function Settings 21
Camera Operation 9
Reviewing Your Photos/Videos 22
23
26
FCC Compliance Statement
Package Includes 4
Installation 7
TABLE OF CONTENTS

Trail Camera
32GB Micro SD Card Fixed Bracket Mounting Strap
Allen Wrench Screw Plug Kit USB Cable
User Manual
4
Package Includes

Camera Overview
5

6
Quick Start

Installation
7
1.Open the two latches on the right side of the camera,
and then open the battery protection cover. For maxi-
mum battery life, you should install 8 new 1.5V AA
Alkaline batteries into the battery slots.(Removing the
battery will reset the camera time and date)
2.Recommends using new batteries. Choose the type of
battery you use when you turn it on. Anytime you load or
unload batteries, make sure that the camera is OFF.
3.Using an external power source: you can connect an
external 6V DC power source with at least 1.5A to the DC
Port at the bottom of the camera. The power connector is
a 3.5x1.35 mm coaxial DC power plug with positive tip
(inside pin) polarity. Leave internal batteries in the camera
during use.
Loading Batteries
Tips：Use the hook next to the DC
port to fix the external power cord
Work with
1.5V AA Alkaline Batteries

8
Installation
1.The camera uses a Micro SD card(TF card) to save your
photos (.jpg format) or videos (.avi format).
Micro SD/SDHC/SDXC class 6 or higher speed cards, up
to a maximum 512GB are supported.
2.Formatting the micro SD card before using it for the first
time. This can be done in “Format memory card” in the
camera menu. Make sure you have backed up (saved to your
computer) any files you want to keep on a previously used
card, as formatting erases all files.
3.Insert the micro SD card into the card slot with its label
side upwards. A “click” sound indicates that the card is
installed successfully.
4.To take out the micro SD card, just gently push in the card.
The card is released from the slot and ready to be removed
when you hear the click.
Inserting the Micro SD Card
Micro/Mini SD Card
(TF Card)
Work with

Camera Operation
9
The OFF mode is the safe mode when any actions
need to be taken (e.g. Replacing the micro SD card
or batteries, or transporting the device).
OFF
mode
ON
mode
TEST
mode
The camera will take photos or videos automatically
(with its current settings) when it is triggered by the
PIR sensor’s detection of activity in the area it monitors.
In the TEST mode, you can check and change the settings
of the camera by using its built-in LCD screen. You can
also take photos, record videos and play files manually.
●Press the UP key, then press the SHOT to take a video.
Press the SHOT button again to stop recording.
●Press the DOWN key, then press the SHOT to take photo.
●Press the MENU key, the setup options will be showing
on the LCD screen.
●Press the UP/DOWN key, scroll to the next or previous
parameter.
●Press the RIGHT/LEFT key to change the setting.
●Press the OK key to save the new setting.
●Press the MENU key to exit the setup menu.
●Press the PLAY key to enter image review mode.
*After setting the parameters to your preferences, be sure to move
the switch to ON mode to begin actually taking photos or videos.
*Please remove the protective foil from the camera before use for
not affecting the camera effect.
Operation in TEST Mode
Three basic operation modes
NOTE

TL video
resolution
Set the resolution of time lapse video.
Options:[5200x3900P]/[4608x3456P]/
[4416x3312P]/[4000x3000P]/
[3648x2736P]/[3264x2448P]/
[3072x2304P]/[2592x1944P]/[2048x1536P].
10
Parameter Settings
Options:
[Photo]: Capture photos with motion detection.
[Video]: Capture videos with motion detection.
[Photo & Video]: Capture both photos and
videos with motion detection.
Mode
Set resolution for still photos. The higher resolution,
the better image quality, but takes more power and
storage space.
Options:[32MP:6480x4860P]/[20MP:5200x3900P]/
[16MP:4608x3456P]/[12MP:4000x3000P]/
[8MP:3264x2448P]/[5MP:2592x1944P]/
[3MP:2048x1536P]/[1MP:1280x960P].
resolution
Set the video resolution.
Options:[3840x2160P/10fps]/[2688x1520P/20fps]/
[1920x1080P/30fps]/[1280x720P/60fps]/
[1280x720P/30fps]/[848x480P]/
[720x480P/30fps]/[640x480P/30fps]/
[320x240P/30fps].
Video
resolution
Selects how many photos will be taken in sequence
per trigger.(Burst Images)
Options:[1 photo]/[2 photos]/[3 photos]/[10 photos].
series
Parameter Settings

The default setting is ON. The two side
PIR sensors provide wider sensing angle
and enhance response time.
Options:[On]/[Off].
Side
motion
sensors
Parameter Settings
11
Set the length of each video clip recorded
each time when motion is detected.
Options:3-59 seconds or 1-2 minutes.
Video
length
1.The Shot lag is referring to is the time delay
between one shot and the next. It is different
from the trigger speed of a trail camera(the
trigger speed is the amount of time it takes for
the trail camera to take and record the photo
once the camera detects an animal).
2.For example, if you set your Shot lag time on
your camera to a 5 second, when the camera
captures the action and finishesshooting, it will
wait 5 seconds before subsequent detection. You
would collect 12 sets of photos every minute.
Options:5-59 seconds or 1-60 minutes.
Shot lag
Opening this function, you'll be able to record
sound while recording a video.
Options:[On]/[Off].
Audio
recording

12
Parameter Settings
This refers to how sensitive the camera is to
objects that pass in front of it. For interior areas
and environments with little interference, select
High. Select Middle for exterior areas and
environments with a normal amount of interference,
and select Low for environments with a high level of
interference (Please note that the temperature may
also affect the sensitivity). The High setting is
suitable for warm ambient temperatures, whereas
Low should be selected for cold environments.If
you are looking for larger animals, such as deer or
bear, the sensitivity can be turned down quite
liberally, as larger animals are obviously easier to
detect. However, if you are after getting photos of
a rare song bird that is nesting near by, the High
sensitivity might be your best option.
Options:[Low]/[Middle]/[High].
Sensitivity
motion
sensors
You can set the camera to start recording at a
specific clock time(Make sure you set the date
and time of the camera accurately before using
this setting). Select ON and set the Start and End
time for the active phase. The settings made here
apply to every day monitoring. The camera will
not record any images outside of the active phase.
For example, you may only be interested in nocturnal
animals, so you schedule your camera to only
work at night.
Options:[Low]/[Middle]/[High].
Target
recording
time

Parameter Settings
13
When Time lapse model is turned on, the PIR
sensor is not available, which means that the
camera will not detect. Instead, it takes photos
or records video clips automatically at your
choice of intervals regardless of if there is
anything in front of camera or not.
[Normal]: Set the interval for taking photos or videos
regularly(According to the "mode/resolution/photo s
eries" you set). For example, set the interval time to
1 hour, the camera will take a photo every hour. If
you want to observe that a plant blooms, the camera
will take 24 photos in 24 hours to record the whole
process of blooming.
[TL Video]: Set up to take a picture at regular intervals.
Unlike Normal mode, these sequence of images can
then be joined together into a video, effectively speeding
up whatever sequence of events has been recorded
[Off]: Turn off the time lapse mode.
●Interval Options: The default is 30-seconds, but
can be set anywhere from 3-seconds to 24-hour.
Options:
Time lapse
Set the language display on screen.
recording a video.
Options:
[English]/[German]/[Danish]/[Finnish]/
[Swedish]/[Spanish]/[French]/[Italian]/
[Dutch]/[Portuguese]/[Simplified Chinese]/
[Traditional Chinese]/[Japanese].
Language

14
Parameter Settings
If you turned ON, cameras will automatically
delete the oldest datas once the SD card is full,
and recording continues as expected. If you
turned OFF, cameras will stop saving new data
to your SD card once it is full.
Options:[On]/[Off].
Endless
Capture
Options:
[Set time&date]: Use LEFT/RIGHT buttons to move
to next field. Use UP/DOWN buttons to change the
setting, pressing the OK button to save the changes.
[Time format]:24h, 12h.
[Date format]:dd/mm/yyyy, yyyy/mm/dd,
mm/dd/yyyy.
Time & date
Offer the stamp with info such as date, time,
moon phase and temperature the moment the
photo was taken.
Options:
[Time&date]:stamped time, date, moon phase
and temperature.
[Date]:stamped time, moon phase and temperature.
[Off]:no stamp.
stamp
Set password of the trail camera. From "0-9" and
"A-Z". If you forget password:Press and hold the
UP button and the OK button, and then move the
switch to the TEST mode to turn on the camera,
after about 5 seconds the camera reset finished.
Options:[On]/[Off].
Password
protection

Parameter Settings
15
Set and change the WIFI name of the trail camera.
From "0-9", "A-Z", "a-z" and "_", Up to 16 character.
WIFI SSID
Set and change the WIFI password of the trail
camera. From "0-9", "A-Z", "a-z" and "_", Up to
8 character.
WIFI
Password
Open/close the button sound.
Options:[On]/[Off].
Beep sound
Formatting memory card will completely erase
all photos on the memory card.
Options:[Yes]/[No].
Format
memory
card
Set the unique serial number for the camera.
From "0-9" and "A-Z", Up to 4 character.
Options:[On]/[Off].
Serial NO.
Restore all camera settings to the factory
default settings except time and date.
Options:[Yes]/[No].
Reset
settings
Look up the firmware information of the camera.
Version

16
2.Use a drill with a 6 mm drill bit to drill the required
holes and insert the plugs and insert the wall plugs
flush with the wall.
1.Mark the drill holes by holding the foot of the wall
bracket at the desired mounting location and marking
the hole positions.
3.Screw the wall bracket to the
wall using the supplied screws .
4.Mount the camera on the
tripod screw and screw the
camera a little way on (about
three turns).
5.Turn the camera in the
desired direction and lock
it with the lock nut .
6.To move the camera into its final position, undo the two
pivot bolts a little, position the camera and fix the position
by tightening the two pivot bolts.
Using the Wall Bracket
Using the Wall Bracket
Note:
Ensure that there are no electric lines, water or heating pipes
installed at the proposed drilling location.
The supplied wall plugs are only suitable for mounting on concrete
and stone. Before starting the installation, please check your
installation location carefully for its suitability for the plugs.

Wifi Feature
17
●APP Compatibility: Requires IOS11.0 or later, Android 8.0 or
later. Compatible with iOS/Android/iPad/Tablet.
●When connected with Wi-Fi, make sure to keep the cell
phone and the camera as closer as possible. The stronger
and more stable the Wi-Fi signal is, the faster the download
speed will be. The control distance is up to 80 feet, but it is
recommended to connect within 10 feet.
●After the phone is connected to the camera WiFi, the
phone will disconnect from the private WiFi. Accessing the
camera or downloading pictures through the APP does not
consume data.
●First time you open "Dsoon" app, please allow app to
access your Photos to make sure the photos and videos
taken by the camera can be downloaded in your phone
album. And please allow app to use your Bluetooth to make
sure you can pair with the camera's Bluetooth in the "Dsoon"
app. You can turn off or turn on "Allow access" in the phone
settings.(see below)
Wifi Feature
NOTE

18
1.Make sure that the micro SD card and battery are properly
installed in the trail camera. And the camera switch is in "ON"
mode. (If adjust from "TEST" mode to "ON" mode, you need to
wait for the end of the 15-second countdown on the screen.)
2.Download "Dsoon" APP from App Store or Google play,
or scan the QR code in the user manual. Then turn on the
Bluetooth and WiFi on the phone.
Wifi Feature
WiFi Connected Steps
