DSPPA Mini40 User manual

Features
l Arc-shaped design
Rounded frame, elegant and moderate, conform to modern beauty
l Precision processing
Processed by precision frosting technology, with oxidable surface, never rust.
l High-quality aluminum
Produced by high performance aluminum, impact resistant, never out of shape
l Powerful functions
Pushed by Bluetooth mode or line mode. Wide range for transmitting and
radiating
l Beautiful sound
Two channel of stereo line output, 2×25W
Power Input Amplifier
Output
Indicator Line Input
Bluetooth Power Amplifier
Mini40
Operation Instructions
Welcome to use the public address system manufactured by DSPPA Company. For the
better application of this equipment, please read the operation instruction carefully prior
to use.
Guangzhou DSPPA Audio Co., Ltd.
http：//www.dsppatech.com
Mini40
Installment instructions: (Please be familiar with the following parts)
Power Input Amplifier Indicator Line Input
Output
A. Horizontal Installment
1. 4 screws are installed in the needed place.
Amplifier
Output
Indicator Line Input
80 m m
90 m m
A.Horizontal Installment
1.4 screws are installed in the needed place.
12
Features
l Arc-shaped design
Rounded frame, elegant and moderate, conform to modern beauty
l Precision processing
Processed by precision frosting technology, with oxidable surface, never rust.
l High-quality aluminum
Produced by high performance aluminum, impact resistant, never out of shape
l Powerful functions
Pushed by Bluetooth mode or line mode. Wide range for transmitting and
radiating
l Beautiful sound
Two channel of stereo line output, 2×25W
Power Input Amplifier
Output
Indicator Line Input
Bluetooth Power Amplifier
Mini40
Operation Instructions
Welcome to use the public address system manufactured by DSPPA Company. For the
better application of this equipment, please read the operation instruction carefully prior
to use.
Guangzhou DSPPA Audio Co., Ltd.
http：//www.dsppatech.com
Mini40
Installment instructions: (Please be familiar with the following parts)
Power Input Amplifier Indicator Line Input
Output
A. Horizontal Installment
1. 4 screws are installed in the needed place.
Amplifier
Output
Indicator Line Input
80 m m
90 m m
A.Horizontal Installment
1.4 screws are installed in the needed place.
12

B.Vertical Installment
1. 4 screws are installed in the needed place.
C.Put on the ceiling
1. Connect the lines of power input and amplifier input.
2. According to the need to connect the input lines.
3. Be sure that the installment is secure or not.
Attention:
Mini40 has two pushing ways.
When the power connects and line input, the indicator
flashes in red.
When the Bluetooth connects, the indicator lights in red.
Specification
Rated Power 2×25W
Maximum power 2×40W
Frequency Response 20Hz~20kHz
Harmonic Distortion ＜0.1%
S/N Ratio 82dB
Static power consumption 0.24W
Impedance 4-16Ω
Input Level 0dbV(0.775V)
Input Impedance ＞10kΩ
Bluetooth Distance 10m
Bluetooth Standard BT2.1+EDR
Power 100-240V
Gross Weight 0.33kg
Net Weight 0.35kg
External Dimension (mm) 125mm×100mm×35mm
Packing Size(mm) 135mm×110mm×45mm
34
B.Vertical Installment
1. 4 screws are installed in the needed place.
C.Put on the ceiling
1. Connect the lines of power input and amplifier input.
2. According to the need to connect the input lines.
3. Be sure that the installment is secure or not.
Attention:
Mini40 has two pushing ways.
When the power connects and line input, the indicator
flashes in red.
When the Bluetooth connects, the indicator lights in red.
Specification
Rated Power 2×25W
Maximum power 2×40W
Frequency Response 20Hz~20kHz
Harmonic Distortion ＜0.1%
S/N Ratio 82dB
Static power consumption 0.24W
Impedance 4-16Ω
Input Level 0dbV(0.775V)
Input Impedance ＞10kΩ
Bluetooth Distance 10m
Bluetooth Standard BT2.1+EDR
Power 100-240V
Gross Weight 0.33kg
Net Weight 0.35kg
External Dimension (mm) 125mm×100mm×35mm
Packing Size(mm) 135mm×110mm×45mm
34

Warning Statement
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and (2)
this device must accept any interference received, including interference that may cause
undesired operation.
Any Changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
Note: This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installation.
This equipment generates uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or more of the
following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help.
This equipment complies with FCC radiation exposure limits set forth for an
uncontrolled environment. This equipment should be installed and operated with
minimum distance 20cm between the radiator & your body.

