DSPPA DSP8064B User manual

confer[email protected] /www.dsppacs.com The specifications will be subject to change without prior notice.
Copyright © Guangzhou DSPPA Audio Co.,Ltd All rights reserved.
DSP8064B
40W Wall Mount Speaker with Power Tap
The DSP8064 is a wall mount speaker built-in 70v/100v transformer. The 70v/100v transmission is
realized in a high-voltage, low-current mode, which makes longer distance transmission and parallel
connection of multiple loudspeakers possible.
Metal grille and ABS enclosure of black color, long-term durability, never out of shape and fading; high
sensitivity, clear and sonorous sound. Easy and secure wall mount installation by hanging holes.
It is ideal choice for industrial and commercial applications in hotel, school, office and factory where
background music and paging is needed.
Input 70V/100V/8Ω
Wide Freq.Resp.:65Hz-20KHz
Max SPL:107±2dB
High sensitivity:91±2dB
Wall mount type loudspeaker
Metal grille and ABS enclosure of black color
Equipped with hanging holes for mounting convenient
Model
DSP8064
Speaker Unit
6.5"×1, 1"×1
Rated Power
40W
Input
Constant voltage
70/100V
Constant resistance
8Ω
Sensitivity(1M,1W)
91±2dB
Max SPL(1M)
107±2dB
Freq. Resp
65Hz-20kHz
Weight
4.6 kg
Dimension(H×W×D)
310×215×203mm
Specifications
Description
Features

[e-mail] /www.dsppacs.com The specifications will be subject to change without prior notice.
Copyright © Guangzhou DSPPA Audio Co.,Ltd All rights reserved.
1. Fit two Ø4mm nails on wall where it is needed to install a speaker system.
2. Connect audio broadcasting wire to the speaker according to the table below.
Constant
voltage
Constant
resistance
70V
100V
8Ω
Red--White
40W
-
40W
20W
40W
10W
20W
5W
10W
2.5W
5W
Note:
When the audio line is the constant voltage, prohibit the knob to the 8Ω.
Prohibit to adjust to“—” under state at 100V cause speaker damage!
3. Position the speaker, then adjust the direction of it and examine whether it is steady.
Installation
Hanging hole Nail For Mounting
Input Voltage
Terminal
Power

[e-mail] /www.dsppacs.com The specifications will be subject to change without prior notice.
Copyright © Guangzhou DSPPA Audio Co.,Ltd All rights reserved.
FREQ. RESPONSE DISTORTION
(dB SPL、1W、1m) (THD< 1.5% 1W、1m、200Hz~12kHz)
DSP 8064
Horizontal directivity pattern
DSP80 64
Vertical directivity pattern

[e-mail] /www.dsppacs.com The specifications will be subject to change without prior notice.
Copyright © Guangzhou DSPPA Audio Co.,Ltd All rights reserved.
DSP8064 Power adjustment knob
Audio line interface
Audio line interface
Power Adjustment Knob
Power Voltage
Terminal
Constant voltage
Constant resistance
70V
100V
8Ω
Red---white
40W
—
40W
20W
40W
10W
20W
5W
10W
2.5W
5W
Notification:
When the audio line is the constant voltage, prohibit the knob to the 8Ω. Prohibit to adjust to“—” under
state at 100V cause speaker damage!
Installation Diagram
Power adjust
