DTK Computer Apex 386/40 User manual

KEEN-3336/4030
Personal Computer
User’s Manual
Edition 1.1
The following does not apply to any country where such provisions are inconsistent
withlocallaw:
We make no warranties with respect to this documentation either express or implied
and provide it "as is". This includes but is not limited to any implied warranties of
merchantability and fitness for a particular purpose. The information in this document
is subject to change without notice. We assume no responsibility for any errors that
may appear in this document.
IBM PC, IBM PC/XT and IBM PC/AT are registered trademarks of International
Business Machines Corporation. MS-DOS is a registered trademark of Microsoft
Corporation. Intel is a registered trademark of the Intel Corporation.
All other brand names are registered trademarks of their respective companies.
Documentation design and writing by: Hazel Chen, Nena Tsai, Patty Lee, and Alan
Patterson.
© 1992 Datatech Enterprises Co., Ltd.
i

Federal Communications Commission (FCC) Statement
Radio Frequency Interference Statement
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This equip-
ment generates, uses and can radiate radio frequency energy and it not installed and used
in accordance with the instructions, may cause harmful interference to radio communica-
tions. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Any special accessories needed for compliance must be specified in the instruction manual.
Warning: A shielded-type power cord is required in order to meet FCC emission limits and
also to prevent interference to nearby radii and t&vision reception. It is essential that only
the attached power cord be used.
Use only shielded cables to connect I/O devices to this computer.
You am cautioned that changes or modifications not expressly approved by the party
responsible for compliance could void your authority to operate the equipment.
This digital apparatus does not exceed the Class B limits for radio noise emissions from
digital apparautus as set out in the radii interference regulations of the Canadian
Department of Communication.
Le Présent appareil numérique n'émet pas de bruits radioélectriques dépassant les limites
applicables aux apparels numériques de Class B preescrites dans le réglement sur le
brouillage radiélectrique édicté parte Ministére des Communications du Canada.
ii

Warning
• Your warranty be voided if you open your system unit case
up to reconfigure the system.
• If you wish to reconfigure the computer at any time, ensure that
the power is turned OFF before changing any hardware set-
tings, such as DIP switches or jumpers.
III

About This Manual
What’s Inside
Here’s what you’ll find in this manual:
Chapter 1—
“System Overview”, gets you acquainted with the basic
concepts of your system.
Chapter 2 —
"Setting Up Your System”, shows you how to set up or
upgrade your system.
Chapter 3 — ‘Operating Your System: shows you the basics of the
MS-DOS functions and the BIOS setup program.
Chapter 4 —
"Keyboard”, explains the keyboards features, layout
and basic functions.
Chapter 5 — “Troubleshooting”, covers simple troubleshooting pro-
cedures and provides directions for additional help.
Chapter 6 —
“Appendix”, provides some technical specifications for
your system and shows you how to install disk drives.
Chapter 7 — "Glossary": explains some microcomputer terms.
iv

How to use this manual
For the advanced user
If you are an experienced PC user and do not want to upgrade your
system now and you want to start using your personal computer as
quickly as possible, refer to the Quick Start section at the beginning
of chapter one.
Quick Start will provide you all the information you need to set up the
hardware.
For the beginner
Chapter 1 gives you the basic information you need to use this
system. Chapter 2 provides greater detail on the hardware and on
how to upgrade your system. Your system is quite simple to set up.
However if you are unsure of yourself, find an experienced PC hand
to help out.
V

Contents
Chapter 1
System Overview
.....................................
1
1-1 Introduction ..............................
2
Operating System
..............................
2
1-2 QuickStart ...............................
3
1-3 Features ................................
4
1-4 Specifications .............................
5
1-5 Example of a System Configuration ..................
6
1-6 SystemUnit ..............................
7
1-7 Control Panel ...................................
..............................
Reset Button
8
8
Turbo Button
.................................
8
Indicator Lights
................................
8
Keylock
....................................
8
System Power Switch
............................
9
1-8 Rear Panel ..............................
10
Keyboard Connector
............................
11
Power Cord Connector
...........................
12
Display Port
.................................
13
Power Voltage Setting
...........................
14
1-9 Other Peripherals ..........................
16
1-10 Disk Drives ............................. 17
Floppy Disk Drives
.............................
18
Copy Protection
.............................. 19
Hard Disks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 0
1-11 Keyboard ..............................
21
1-12 Maintaining Your Equipment ....................
22
vi

Chapter 2
Setting Up Your System
................................
1
2-1 Unpacking Your Main System ........................
2
2-2 Configuration ........................................
3
Restrictions
.....................................................
3
BoardLayout........................................4
lnstallling Processor
........................................
5
Installing Numeric Coprocessor .......................
5
ROM Installation
...............................
6
Main Memory Configuration
.........................
7
Total 32-bit Memory Switch Settings
6
Video Selection
........................................
..............................
19
2-3 Jumper Options and Connectors
Functions of Connectors and Jumpers ........................
........................
10
11
Jumpers for Cache and Main Memory Configuration
...........
14
2-4 Factory Default Settings .........................
15
2-5 Connection to Power Supply .........................
16
vii

Chapter 3
Operating Your System
................................
1
3-1 An Introduction to DOS ........................
2
Loading DOS
.................................
2
System Messages
.............................. 2
3-2 DOS Operations ............................
3
Starting MS-DOS
...............................
3
Formatting Disks
............................... 3
Banking up Your Diskettes and Files
..................... 4
Deleting your Diskettes and Files
......................
5
Finding Out What Is on a Disk
........................
5
3-3 Hard Disk Drive Format ........................ 6
Step 1 — Prefomatting
...........................
6
Step 2 —
Partitioning
.............................
6
Step3 — Format
...............................
7
3-4 Helpful Hints ..............................
8
3-5 BIOS Utility and Setup .........................
9
3-6 System BIOS .............................
9
Hard Disk Preformat
............................ 10
System Utilities
.............................. 10
Password
.................................. 10
User-defined Hard Disk Type
.........................
11
Shadow RAM
................................
11
3-7 Setup Program ............................
12
Entering the Setup Program
........................
12
Running the Setup Program
........................
14
Shadow RAM
................................
17
Exiting the Program
............................ 17
3-8 System BIOS Error Messages ....................
18
VIII

Chapter 4
Keyboard
.............................................
1
4-1 Keyboard Layout ............................
2
4-2 Getting Acquainted with Your Keyboard ................3
Function Keys
................................ 3
Numeric Keypad
............................... 3
Mode Indicator Lights
Special Keys
...............................5
............................... 6
QWERTY Keys
................................7
Cursor Keys
.................................
6
Key Combinations
..............................
6
4-3 Keyboard Tilt Adjustment ....................... 9
Chapter 5
Troubleshooting ......................................
1
5-1 Troubleshooting Procedures ......................
2
5-2 System Error Messages ........................ 7
5-3 Examples of System Error Messages .................
8
Chapter 6
Appendix
............................................
1
6-1 Disk Drives ...............................
2
Floppy Disk Drives
..............................
2
Hard Disk Drives
...............................
6
6-2 Technical Information .........................
9
386 Microprocessor
.............................
9
Math Coprocessor
..............................
9
Memory Subsystem
............................
10
6-3 Shadow RAM ............................ 11
6-4 Entering 33/40MHz Cache Mode ..................
13
6-5 Quick Reference for Jumper Settings ................
14
6-6 Hard Disk Types Supported ..................... 15
Chapter 7
Glossary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1
ix

List of Figures
Chapter 1
System Overview
Figure 1-1: QuickStart ..........................
3
Figure 1-2: System Configuration ....................
6
Figure 1-3: System Unit Case ......................
7
Figure 1-4: Front Panel ..........................
8
Figure 1-5: Keylock and Two Security-lock Keys .............
9
Figure 1-6: Rear Panel ......................... 10
Figure 1-7: Connecting the Keyboard Cable ...............
11
Figure 1-8: System Power Cord ....................
12
Figure 1-9: Two Kinds of Display Connectors ............. 13
Figure 1-10: Voltage Switch ....................... 14
Figure 1-11: Power Cord Specifications .................
15
Figure 1-12: System Unit Connected to Peripherals ..........
16
Figure 1-13: Installing Floppy and Hard Disk Drives ..........
17
Figure 1-14: Floppy Disk Specifications .................
18
Figure 1-15: Copy Protection for 3.5” Floppy Disk ............
19
Figure 1-16: Copy Protection for 5.25” Floppy Disk ...........
19
Figure 1-17: Keyboard ..........................
21
Chapter 2
Setting Up Your System
..........................
1
Figure 2-1 : Unpacking Your Main System
................
2
Figure 2-2: Motherboard Layout
.....................
4
Figure 2-3:
Coprocessor Installation ...................
6
Figure 2-4:
SIMM-type DRAM ......................
7
Figure 2-5: The Four-switch DIP SW1
.................. 8
Figure 2-6:
SW1-4 Switch Settings ....................
9
Figure 2-7: An Example of Three-pin Jumper Setting..........
10
Figure 2-8:
DRAM Configurations ................... 14
Figure 2-9: Factory Defautt Settings
..................
15
Figure 2-10: Connecting to a Power Supply ............... 16
Figure 2-11: Power Supply Pinouts ................... 17
X

Chapter 3
Operating Your System
................................
1
Figure 3-1: Initial Screen ........................
13
Figure 3-2: Calculator .........................
15
Figure 3-3: Key Functions of Calculator ................
16
Chapter 4
Keyboard
Figure 4-1 : Keyboard Layout .......................
2
Figure 4-2: Function Keys ........................
3
Figure 4-3: Numeric Keypad .......................
3
Figure 4-4: Functions of Numeric Keypad Keys .............
4
Figure 4-5: Indicator Lights ........................
5
Figure 4-6: Special Keys .........................
6
Figure 4-7: Functions of Special Keys ..................
6
Figure 4-8: QWERTY Keys ........................
7
Figure 4-9: Functions of Special QWERTY Keys ............
7
Figure 4-10: Cursor Keys .........................
8
Figure 4-11: Special Functions ......................
8
Figure 4-12: Adjustment of Keyboard Angles ...............
9
Chapter 6
Appendix . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1
Figure 6-1: Fasten the Brackets on a Floppy Disk Drive .........
2
Figure 6-2: Installing the Floppy Disk Drives
...............
3
Figure 6-3: Connecting a Floppy Disk Drive
...............
4
Figure 6-4:
Connecting a Floppy Disk Drive to an FDC Card ......
4
Figure 6-5: Cables for Disk Drives
....................
5
Figure 6-6: Fasten the Brackets on a Hard Disk Drive
.......... 6
Figure 6-7: Connecting a Hard Disk Drive
................ 7
Figure 6-8:
Connecting a Hard Disk to an HDC Card ..........
7
Figure 6-9: Shadow RAM
........................ 11
Figure 6-10: Shadow RAM Control Port ................. 12
xi

Chapter 1
System Overview

System Overview
This chapter covers:
■
the basics of your system
■
the system’s features and specifications
control panel features and connectors outside the case
■
how to maintain your computer
lf you are an experienced user who wants to get to work as soon as
possible, the Quick Start section at the beginning of this chapter
provides you all the information you need to set up the hardware.
If you want to upgrade your hardware later, read Chapter 2.
If you want to gain a more thorough understanding of your computer,
read the entire manual.
Note:
You may refer to the Glossary chapter for definitions of computer
terminology.
Chapter 1: System Overview
1

1-1 Introduction
This manual will guide you through the setup of your computer and
provide the information necessary to tailor the system to fit your needs.
lf you are a novice, you will have your computer up and running with a
minimum of fuss. You will also gain valuable handson experience by
following the easy step-by-step instructions. If you are an advanced
user, you will appreciate the affordable power of this system.
The 386-based mainboard provides superlative performance and com-
plete compatibility with software written for the Intel ‘86 family of CPUs.
The system uses a cache memory subsystem providing a small
amount of fast memory (SRAM) and a large amount of slow memory
(DRAM). This system is configured to so that all system memory is fast
-fast enough to support burst cycles and to complete bus cycles with
no wait states. The cache memory provides high performance at a
cost approaching that of DRAM.
Quality, flexibility, and functionality are the key design features of your
system. This system provides optimum performance at an affordable
price.
Operating System
Your computer uses the MS-DOS
®
operating system. For more details
on this operating system, please refer to the Microsoft®MS-DOS
User’s Guide and User’s Reference. This manual is included with your
system.
2
Chapter 1: System Overview

1-2 Quick Start
If you are an experienced user anxious to start using your computer,
observe the figure below to set up your personal computer. You will still
want to use this manual later as a reference book.
Note: Save all packing materials in case you need to ship or resell your
computer in the future.
Figure 1-1: Quick Start
Chapter 1: System Overview 3

1-3 Features
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
386-33140 microprocessor with 80387-33140 or Weitek 3167
numeric coprocessor optional
Use of the DTK DA315 and DA342 chipset
Dual speed, 33/40MHz cache support in ultra-high speed.
Emulation without cache is enabled in low speed. Software
or hardware switches toggle between high and low speeds.
-
l/2/4/5/8 MB 32-bit DRAM onboard
Direct-mapped high-speed SRAM cache memory support:
64KB
Write-back cache update for O-wait state memory-write
operations
DTK, or AMI BIOS support
Shadow HAM function for BIOS and video
One 32-bit memory expansion slot for the PEI-307 32-bit
memory expansion card, expanding 32-bit memory up to
16MB
Six 16-bit AT compatible l/O slots
Two a-bit AT compatible l/O slots
AT bus speed —
KEEN-3336: 8MHz
KEEN-4030: 10MHz
DALLAS DS1287 chip to maintain system configuration and
real-time clock setting
Keyboard and speaker attachments
Seven DMA channels
16-level interrupt
Three programmable timers
4Chapter 1: System Overview

• System performance rate:
KEEN-3336
Landmark (V. 1 .14): 53.7 ~ 53.9
Power Meter MIPS (V. 1.7): 8.0MIPS
Norton SI (V. 6.0): 35.4
KEEN-4030
Landmark (V. 1.14): 65.1
Power Meter MIPS (V. 1.7): 9.4MIPS
Norton SI (V. 6.0): 42.9
1-4 Specifications
• CPU — 386 microprocessor, 33/40MHz
• RAM — Subsystem of 1 MB, 2MB, 4MB, SMB,and 8MB
• ROM — 64KB legal BIOS
• Expansion slots -Six 16-hit slots and two 8-bit slots
• Power Size — 165mm X 150mm X 150mm
• Options —
Math coprocessor 80387-33140
Weitek 3167
Chapter I: System Overview 5

1-5 Example of a System Configuration
The basic system is pictured below. You may choose peripherals and
upgrades for the system as your needs require. Even if your system is
different from the one pictured, if should operate in the same basic
manner.
Note: Figure 1-2: System Configuration
The illustrations of the system in this manual may look different from
your system; however, their main features should be the same.
6Chapter 1: System Overview

1-6 System Unit
The system unit may house a motherboard, disk drives, a power supply
and optional expansion cards.
Power Button
Reset Button
Figure 1-3: System Unit Case
Chapter I: System Overview
7
