DTS Zappiti Player 4K Mini User manual

English ● Français
Quick Start Guide
Guide de démarrage rapide
Manufactured under license from Dolby Laboratories.
Dolby and the double-D symbol are trademarks of Dolby Laboratories.
DTS, the Symbol, & DTS and the Symbol together are registered trademarks & DTS 2.0+Digital Out
is a trademark of DTS, Inc. Product includes software. © DTS, Inc. All Rights Reserved.

2
Dune HD TV-303D Quick Start Guide

3
English
3
Table of Contents
Table of Contents Table des matières
English
Quick Start Guide
• Introduction
• Key Features
• Extra Functions
• Package Contents
• Exterior
• Remote Control
• Getting Started
• Connect to PlayStore
• Set your personal home page
• Connecting USB Drives
• Using external HDD
• Using SD Memory Cards
• Using USB 3.0 Host Function
• Zappiti Explorer
• Switching the Player On and Off
• NAS (Network Attached Storage)
• Wi-Fi
• Limitations
• Updating Your Player and Getting More Information
Français
Guide de démarrage rapide
• Introduction
• Fonctions clés
• Autre fonctionnalités
• Contenu de la boîte
• Vues extérieures
• Télécommande
• Démarrage
• Connexion au PlayStore
• Personnalisation de la page d’accueil
• Connexion USB
• Utilisation d’un disque dur externe
• Utilisation de cartes mémoire SD
• Utilisation du port USB Host 3.0
• Zappiti Explorer
• Allumage et extinction
• NAS (Network Attached Storage)
• Wi-Fi
• Restrictions
• Mise à jour et informations complémentaires
4 16

4
Zappiti Player 4K Mini. Quick Start Guide
Introduction
Zappiti Player 4k is an all-in-one solution for video playback with upscaling (up to 4K) and 3D video playback.
Key Features
Android: Android Apps friendly. Easy access with streaming contents providers, VOD/SVOD, catch up TV, musical
playback, social networks, news, weather info, trailers, games, internet radio and more…
Up-Scaling 4K: Display your videos with an ultra high quality upscaling Ultra HD 4K (3840x2160 and 4096x2160).
3D video friendly: Supports most of the 3D video formats such as BD ISO 3D, MVC, SBS, and Top/Bottom.
Network Player: Connect your player on a local network and enjoy your content from a PC, a MAC or a NAS via SMB.
MKV Player: Playback HD and SD video in MKV containers and other modern video file formats, including top quality
HD video with very high bit-rates > 120 Mbp/s.
SATA connector: Easily and quickly connect external SATA HDD (up to 6 TB pre formated HDD) to the Zappiti Player
4K Mini with fast connexion (up to 6 Gbit/s in SATA III).
USB Ports: Conveniently connect HDDs, USB flash drives, USB card readers and other USB storage devices.
USB Port 3.0: Read or copy your files in high speed.
Full Range of A/V Connectors: S/PDIF Optical Audio outputs, AV analogue output via an adaptor, HDMI CEC output.
Multichannel home cinema audio: Bitstream, downmix stereo.
High-Quality Music Playback: Plays very high-quality (up to 192 kHz / 24-bit) music files in various formats.
Video Output Flexibility: Output video in any resolution and format from SD to 1080p (1920x1080, 24p/PAL/NTSC),
Ultra HD (3840x2160, 24p/25p/30p) and 4K (4096x2160, 24p).
Playback memory: Resume playback from the last position.
Computer Mouse Friendly: Connect a computer mouse (air or not) to control the player and Android Apps.
Advanced File Browser: Convenient file browser with powerful file management (copy, move, delete, rename).
Open GUI: Add your own Android Apps, customize the Home Page of the player, add any widgets (weather, news...).
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●

5
English
Zappiti Media Center V4 friendly
● Zappiti Media Center interface: Cover arts exploration system for your Movies, TV Shows and musical files with
presenting informations (subtitles, actors, director, release date, ...). Powerfull automatic indexation of Movies and TV
Shows by category directly to the player without any use of a computer.
● Search Engine: Easy access to your movies or TV Shows thanks to Zappiti powerful search engine combined with
smart filters (actors, director, length, ratings, release date, ...).
● Zappiti edit functions: Edit or delete the movie covers directly via the remote control.
Change the posters, edit the groups, edit the synopsis, change the genre of the movie, etc….
● Zappiti on startup: Enable/disable startup for Zappiti Media Center from system boot by Zappiti setting.
● Multiple video collections: Create and manage one collection by each family member or one collection by HDD
and switch collection easily.

6
Zappiti Player 4K Mini. Quick Start Guide
NOTE:
1. Zappiti Player 4K Mini
2. IR remote control
3. 2.4G air mouse / keyboard
4. AV cable
5. SATA cable (can be optional)
6. HDMI 4K cable
7. Power adaptor
8. Quick Install Guide
9. IR Cable
Additional items (optional) may be included into the package, depending on player configuration, region, and
distributor.
1
6
2
8 97
3 4 5
Package Contents

7
English
1. Wi-Fi antenna
2. Power switch
3. DC power 12V
4. IR Outpout
5. Digital Outpout SPDIF
6. 3.5 mm AV out
7. HDMI OUT
8. HDMI IN
9. LAN 10/100/1000
Rear view
Front view Side view (right)
Exterior
1. SATA 2. USB 2.0
1. USB 3.0 host
2. SD/MMC card reader
1. LED indicator
Side view (left)
11
2
11 2 3 4 5 6 7 8 9 2

8
Zappiti Player 4K Mini. Quick Start Guide
Remote Control
1. POWER — Toggle power OFF and ON.
2. Z — Toggle Front LED OFF and ON.
3. SUBTITLE — Change subtitle language.
4. INFO — Show / Hide the pop-up info.
5. AUDIO — Change audio language or channel.
6. MUTE — Mute audio.
7. PAGE UP/PAGE DOWN — Scroll up and down
in various lists — Next / Previous chapter.
8. VOLUME +/- — Increase / Decrease volume.
9. PLAY/PAUSE — Start playback / Pause playback.
10. HOME — Go to Home Menu to select application.
11. RETURN — Stop Playback / Return to the previous menu or mode.
12. DOWN/UP — Fast reverse / Fast forward play.
13. LEFT/RIGHT — Jump to 1 min backward/forward.
ARROW and OK Buttons — Navigate menu selection.
14. MENU — Show/hide the pop-up menu.
15. MOUSE — Switch to the virtual mouse mode.
16. NUMBER Buttons — Enter numeric values ;
1-9 : direct access from 10 to 90% of the timeline or total pages.
0 : reset the playback position to the beginning.
17. ZOOM — Zoom in / Zoom out.
18. DELETE — Delete the previous character/item.
1
8
10
13
14
16
17
2
4
6
3
5
9
7
11
12
15
18

9
English
NOTES:
● Use alkaline AAA batteries.
● Observe polarity when inserting batteries.
● Direct the remote control to the player. There must be no obstacles between the RC and the player.
● If RC functions only at short distances or stops functioning, make sure to replace the batteries.
● Some RC buttons may have several functions depending on the current player mode.
● Some RC buttons may be available only in certain player modes or only during playback of a certain content.

10
Zappiti Player 4K Mini. Quick Start Guide
Getting Started
Ensure there is enough space around the player for proper cooling. The space at each side should be not less than
10 cm. Ensure the RC has batteries installed.
Connect the player to your TV and to other A/V equipment in an appropriate way. Use HDMI connection to get the
Make sure to use HDMI OUT (not HDMI IN) connection to link your ZAPPITI PLAYER 4K Mini to your TV.
best possible quality of video and audio. Make sure to switch off the player and all relevant A/V equipment before
connecting them. Ensure your TV and other A/V equipment are configured to use proper inputs.
Switch on the player. The player will perform its initial loading procedure, which may take up to about 1 minute. During
the loading procedure, “ZAPPITI PLAYER” logo is shown on the TV.
●If you do not see “ZAPPITI PLAYER” logo on the TV when you switch on the player, it may mean some problem
with the connection between the player and the TV or that a wrong video input is chosen in the TV or A/V
receiver/switch. In such a case, recheck the cables and the settings of the TV or A/V receiver/switch, or try to use
different cables or a different way of connecting the player to the TV.
Finally, you should see the main screen of the player menu. The main screen shows items allowing to use different
applications and access all storage devices and network drives connected to the player.
Adjust the player settings as needed using “SETUP” item on the main screen of the player menu. In particular, you may
want to adjust video settings, audio settings, and network settings.
WARNING: after firmware update and restart, please restart again the Zappiti Player 4K Mini.
To choose the language of the player menu, use “Settings / Personal / Language & input” setting.

11
English
Add your own applications
The Zappiti Player 4K Mini is compatible with GooglePlay. So you can install your own Android applications.
Set your personal home page
The home page of the Zappiti Player 4K can be modified. To delete an application form the home page, click on it for
a few seconds with the Air Mouse. Then, drag and drop it on the red cross. To move an application to a new location,
you just have to drag and drop it to a new location. To add a new application previously installed, click on the Applica-
tions icon (second icon from the left). Then, click the selected application for a few seconds. The Home Page will
appear. Drag and drop the application on the wanted location. You can also drag and drop associed widgets.
Connect to PlayStore
Before to start using your Zappiti Player, you need to update Android apps:
1. On the home page, please click the GooglePlay button.
2. Please fill your Google email and password. If you don’t have any Google email, please create an account on
Google from any computer connected to the Internet.
3. By using the AirMouse, please click on the left of the scren and drag to the right. The, click on My Application and
click the button « Update all ».
Use the RC buttons UP, DOWN, LEFT, RIGHT, OK, RETURN to navigate through the player menu. Use the MENU
RC button to show the list of available commands. Use the INFO RC button to show the INFO pannel.
NOTE: To stop the process of an application in use, go to “Settings / Apps”, click on the application you want to
stop, then click “Force Stop” on the application settings. To uninstall, please click on the Uninstall button located on
the same application settings page.

12
Zappiti Player 4K Mini. Quick Start Guide
Connecting USB Drives
USB drive. Power provided by the USB ports of the player may not be enough for correct functioning of the USB drive.
Do not disconnect or switch off the USB drive when some write operation is in progress.
Using external HDD
Using SD Memory Cards
To explore your video files, please click the « Z » icon, then select « Explorer » and click on « Zappiti Player 4K » icon.
The player will recognize the USB drives, and will show an item corresponding to the USB drive on the local source.
The Zappiti Player 4K Mini feature a SATA connector to connect external 3.5” SATA HDD. Please use the included
SATA cable (may be not provided, depends of your local reseller). To explore your video files, please click the « Z »
icon, then select « Explorer » and click on « Zappiti Player 4K » icon. The player will recognize the USB drives, and
will show an item corresponding to the USB drive on the local source.
The Zappiti Player 4K Mini is not able to format HDD. To format an HDD, please use dedicated format software on
your computer. The Zappiti Player 4K Mini is compatible with pre formated HDDs up to 6 TB (NTFS, FAT16, FAT32,
HFS, EXT2/3).
To use a memory card, insert it in the memory card slot located on the left side of the media player. The Zappiti Player
4K Mini will recognize the memory card, and will show an item corresponding to the memory card on the local source
list in ES Explorer. Some SD memory cards may not be recognized by the player or may work incorrectly; in such a
case, use other models of memory cards.
Do not eject the SD memory card when some write operation is in progress.

13
English
Using USB 3.0 Host Function
ES Explorer
The Zappiti Player 4K Mini feature a USB 3.0 port. This port can be used to transfer files from an HDD to another one
with very high speed.
ES Explorer feature Samba client which explores the pictures, musics, videos, documents and other files on your
server NAS or your computers. With ES Explorer you can manage your files like you do on your desktop or laptop
using Multiple Select, Cut/Copy/Paste, Move, Create, Delete, Rename, Search, Share, Send, Hide, Create Shortcut,
and Bookmark.
Zappiti Explorer, the fast and easy way to play video content
To explore and play your video files fastly and easily, we strongly advise you to use Zappiti Explorer who is optimized
to play specific video contents such as BDMV (Blu-ray folders), VIDEO_TS (DVD folders) and BD ISO. DVD menus
are supported. For additional features (to manage your share folders and files) please use MENU button of the RC.
If your shared folder is not discovered, you can add it manually by using the dedicated option. To explore connected
HDDs, Flash memories or SD Cards, please click on “Zappiti Player 4K” option. Please use “1-9” buttons for “10-90%”
of total files contained in a folder. “0” button go to the top of the list.
NOTE: To explore BDMV and VIDEO_TS folders, please use RIGHT button. To play the included video content,
please use ENTER.
ATTENTION: AirMouse is not supported in Zappiti Explorer. Please use IR RC. Keyboard is supported.

14
Zappiti Player 4K Mini. Quick Start Guide
Switching the Player On and Off
To put the player into the standby mode, press the “POWER” RC button.
To exit the standby mode, press this button again.
To switch the player off completely, disconnect the power plug.
NOTE : After switching off the player completely, it is recommended to wait about 1 minute before switching it
on again.
Wi-Fi
Your player is equipped with a built-in wireless LAN adapter. You can use it to connect the player to the local network
via Wi-Fi.
Limitations
Compatibility of the player with a particular hardware (A/V equipment, network equipment, disk drives, etc) may
depends
of the player and the hardware, etc). If the player does not correctly work with a particular hardware, try to adjust the
-
ferent way.

15
English
Updating your Zappiti Player 4K Mini and Getting More Information
Zappiti Media Center V4
extend player
capabilities):
zappiti.com/firmwares
Please check here for more detailed and up-to-date documentation and information on player usage:
zappitiforum.com
Zappiti Player offers a “Zappiti Media Center Premium” licence. The licence number (token) is printed on the underside
of the unit. To launch Zappiti Media Center, please click the Z icon on the main page. Zappiti Media Center V4 feature
“Explorer” and “Zappiti”. Zappiti organizes automatically your media collection (Movies, TV Shows, Musics) in
categories and offers a simple, easy and stylish navigation by using cover arts or album thumbnails browsing with
synopsis and various media infos. Before you start using Zappiti, you must create two different folders:
Movies
1. Please, create a folder named "MOVIES" and copy all your movie and concert files in it.
2. Rename the movie files with the exact movie title. For example : the movie
"Metropolis" in MKV format should be named as "Metropolis.mkv".
TV Shows
1. Create a "TV Shows" folder and copy all your TV Show files in it.
2. Your episode files can be placed loose in your folder "TV Shows".
Episode files must be named as follows: "name s01e01".
"s" stands for "season" while "e" stands for "episode". For example: "Tornado s01e03.mkv".

16
Zappiti Player 4K Mini. Guide de démarrage rapide
Introduction
Caractéristiques principales
Le Zappiti Player 4K Mini est un boîtier multimédia Android compatible HEVC/H.265 équipé de connecteurs
SATA et USB 3.0, compatible Ethernet Gigabit et Wi-Fi, intégrant l’application Zappiti Media Center V4.
● Android : compatible avec les applications Android. Idéal pour accéder aux services de streaming, VOD/SVOD,
lecture musicale, réseaux sociaux, actualités, météo, bandes annonces de films, jeux, radios Internet…
● Up-Scaling 4K : affichez vos vidéos avec une mise à l’échelle haute qualité jusqu’en résolution Ultra HD 4K.
● Vidéo 3D : compatible avec une grande variété de formats vidéo 3D tels que BD ISO 3D, MVC, SBS et Top/Bottom.
● Lecteur réseau : connectez le lecteur Zappiti au réseau local et accédez au contenu d’un PC, MAC ou NAS via SMB.
● Lecteur MKV : lecture des vidéos HD et SD dans des conteneurs MKV et autres formats vidéo récents (> 120 Mbp/s).
● Connecteur SATA : connectez facilement et rapidement un disque dur informatique nu SATA (non inclus) jusqu'à 6 To
(disques durs pré-formatés uniquement) au Zappiti Player 4K Mini pour des débits ultra rapides (jusqu'à 6 Gbit/s).
● Ports USB : connectez facilement disques durs, clés USB, lecteurs de cartes USB et autres périphériques USB.
● Ports USB 3.0 : lisez ou copiez des fichiers à très haut débit.
● Une multitude de connecteurs Audio/Vidéo : SPDIF, sortie audio vidéo analogique via adaptateur, HDMI CEC.
● Audio Home Cinéma multicanal : bitstream, downmix stéréo.
● Lecture musicale de haute qualité : support des fichiers musicaux haute qualité (jusqu‘en 192 kHz /24 bits).
● Sorties vidéo et résolutions multiples : depuis la résolution SD jusqu’à Ultra HD 4K.
● Resume Playback : Mémorisation de la position de lecture.
● Télécommande IR longue portée : le lecteur Zappiti Player 4K Mini est fourni avec une télécommande infrarouge.
Compatible avec les télécommandes universelles Logitech Harmony, Pronto, Pro Control, et RTI.
● Air mouse / clavier RF longue portée : les applications Android peuvent être pilotées à l’aide d’une télécommande à
pointeur souris sans fil en radio fréquence. L’envers de la télécommande est équipée d’un clavier.
● Gestionnaire de fichiers avancé : grande facilité de gestion de contenu (copier, déplacer, effacer, renommer, trier).
● Open GUI : ajoutez vos propres applications Android, personnalisez la page d’accueil du lecteur, ajoutez des widgets.

17
Français
Compatible Zappiti Media Center V4
Interface Zappiti : système d'exploration par jaquettes pour vos films, et séries TV avec présentation des informations
(sous-titres, acteurs, réalisateur, date de sortie...). Indexation automatique films / séries TV par genres.
Moteur de recherche : retrouvez facilement vos films et séries TV, grâce au puissant moteur de recherche de Zappiti
associé à de nombreux filtres et système de tris (acteurs, réalisateur, durée, note, date de sortie, …).
Édition depuis le lecteur Zappiti : éditez ou supprimez les fiches de films directement à l’aide de la télécommande.
Changez les posters, éditez les groupes, éditez les synopsis, modifiez la catégorie d’un film, etc.
Zappiti au démarrage : lancez automatiquement Zappiti Media Center au démarrage du lecteur.
Multi collections : créez une collection de films et séries TV par membre de votre famille ou par disque dur et passez
facilement de l'une à l'autre.
Téléchargement automatique de sous-titres : grâce à Zappiti, vous pouvez télécharger en un clic les sous-titres d'un
épisode de série TV ou d'un film.
Zappiti Explorer : explorez vos dossiers et lancez la lecture de vos fichiers vidéo d’une manière simple et rapide.
●
●
●
●
●
●
●

18
Zappiti Player 4K Mini. Guide de démarrage rapide
Contenu de la boîte
NOTE : des accessoires supplémentaires (optionnels) peuvent être inclus dans la boîte en fonction du pays,
du distributeur et de la configuration du lecteur.
1
6
2
87
3 4
9
5
1. Zappiti Player 4K Mini
2. Télécommande IR
3. Air mouse 2.4G / clavier
4. AV cable
5. SATA cable
(peut-être optionnel)
6. Câble HDMI 4K
7. Adaptateur secteur
8. Guide de démarrage rapide
9. Câble IR

19
Français
Vues exterieures
1. Antenne Wi-Fi
2. Bouton d’alimentation
3. Alimentation 12V
4. Sortie IR
5. Sortie audio numérique
optique SPDIF
6. Sortie AV Mini-Jack 3.5 mm
7. Sortie HDMI
8. Entrée HDMI
9. LAN 10/100/1000
Rear view
Avant Côté (droit)
1. SATA 2. USB 2.0
1. USB 3.0 host
2. Lecteur de cartes
mémoires SD/MMC
1. Indicateur LED
Côté (gauche)
11
2
11 2 3 4 5 6 7 8 9 2

20
Zappiti Player 4K Mini. Guide de démarrage rapide
Télécommande 1
8
10
13
14
16
17
2
4
6
3
5
9
7
11
12
15
18
1. POWER — Mise en veille / Démarrage de l’appareil.
2. Z — Allumage / Extinction de l’indicateur LED frontal.
3. SUBTITLE — Changer la langue de sous-titres.
4. INFO — Affichage / Désaffichage du panneau infos.
5. AUDIO — Changer la langue ou la piste audio.
6. MUTE — Désactivation / Activation du son.
7. PAGE UP/PAGE DOWN — Changement de page.
En cours de lecture : chapitre suivant/précedent.
8. VOLUME +/- — Augmentation / Diminution du volume sonore.
9. PLAY/PAUSE — Lecture / Pause.
10. HOME — Affichage de la Home Page avec les applications favorites.
11. RETURN — Retour au menu précédent / Arrêt de la lecture en cours.
12. BAS/HAUT — Retour rapide / Avance rapide.
13. GAUCHE/DROITE — Saut de 1 min en avant / arrière.
FLECHES et OK — Naviguation dans les menus et validation de la selection.
14. MENU — Affichage / Désaffichage du menu / menu contextuel.
15. MOUSE — Activation / Désactivation du mode « souris virtuelle ».
16. NUMBER Buttons — Saisie de caractères numérique ; accès directs :
1-9 : accès direct de 10 à 90% de la durée totale / total de pages.
0 : réinitialisation de la position de lecture / retour à la première page.
17. ZOOM — Zoom / Dézoom.
18. DELETE — Suppression.
