Dual MGH30BT Operating instructions

MGH30BT
INSTALLATION/OWNER'S MANUAL
AM/FM Gauge Hole Receiver

2
MGH30BT OPERATION
Mounting & Wiring
Please read entire manual before installation.
Before You Start
• Disconnect negative battery terminal. Consult a qualified technician for instructions.
• Avoid installing the unit where it would be subject to high temperatures, such as from
direct sunlight, or where it would be subject to dust, dirt or excessive vibration.
Getting Started
• Once a suitable location has been determined, drill the hole and secure the stereo
using the metal mounting bracket. If the bracket needs to be shortened, remove the
appropriate number of breakaway segments using a pair of pliers.
Fuse:
When replacing the fuse, make sure
new fuse is the correct type and
amperage. Using an incorrect fuse
could damage the radio.
Tip:
When a suitable ground wire is
not present in the vehicle wiring
harness, connect the black ground
wire to the vehicle chassis.
Break Lines
Color Connection
Red 12V Ignition / Accessory
Black Ground
Blue Remote Turn-on B (+)
Grey Right Front (+)
Grey/Black Right Front (-)
White Left Front (+)
White/Black Left Front (-)
Violet Right Rear (+)
Violet/Black Right Rear (-)
Green Left Rear (+)
Green/Black Left Rear (-)

3
MGH30BT OPERATION
Installation
Mounting the Radio
1. Choose a mounting location on the dash board or instrument panel that will
allow room behind to run radio cables to the power source. Consider how you will use
the AUX IN, LINE OUT and USB connectors and route the appropriate extension cables
to an accessible area.
2. Cut a hole in the dash board using the template provided in the back of this manual. At
least 3 3/4” depth is needed to mount the radio.
IMPORTANT! Do not mount this unit where it can be submerged in water.
3. Slide the included spring washers (B) over the screw posts (A) and attach the screw
posts to the back of the radio.
4. Place the radio in front of the dashboard opening so the wiring can be brought through
the opening.
5. After completing the wiring connections, turn the radio on to confirm operation (vehicle
accessory switch must be on). If the radio does not operate, recheck all wiring until the
problem is corrected. Once proper operation is achieved, turn the accessory switch off
and proceed with final mounting of the radio. Refer to the “Wiring Diagram” on page 5.
NOTE: Before final installation, test the wiring connections to make sure the unit is con-
nected properly and the system works.
6. Insert the radio into the mounting hole.
7. Place the “U” bracket (C) over the screw posts and secure the radio to the dash using
the included hex nuts (D). If necessary, cut the score marks (E) on either side of the
mounting bracket to custom fit the bracket length for your application. See Figure A.
Installation
A
C
D
E
B
3 Inch Hole

4
MGH30BT OPERATION
Control Locations - Receiver
4
6
1
2
3
5
7
8
9
10
11
Select / Thumbs Up
Volume Up
Volume Down
Mode / Thumbs Down
Audio / Menu
1
2
3
4
5
6
7
8
9
10
11
Power
Mute
Band / Go Back
Tune Down
Tune Up
Play / Pause

5
MGH30BT OPERATION
Control Locations - Remote
12
4
3
5
6
7
8
9
10
11
Preset 6 / Folder Up
Display
Mute
Preset 5 / Folder Down
Preset 4 / Play / Pause
Preset 1 / Repeat
Band / Go Back
Tune / Track Down
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
Mode
Volume Up
Power
Select
Tune / Track Up
Volume Down
Audio / Menu
Preset 3 / Intro
Preset 2 / Random
15
13
14
16
17
12

6
MGH30BT OPERATION
Press or any other button to turn the unit on. Press and
hold to turn the unit off.
Press MODE to enter the Mode Menu, then press MODE
to select between Tuner, Aux, USB, iPod, Bluetooth and
Pandora modes. Modes of operation are shown in the
display.
The MGH30BT offers rear RCA auxiliary input ports for
connecting an audio device, MP3 player, etc. Press MODE to
select auxiliary input mode.
Adjust volume using volume keys.
Press DISP to toggle between ID3 tag and file/folder name
for MP3/WMA files being played from CDs or USB devices.
If abnormal operation occurs, press MENU and TUNE
nn
for three seconds to reset the unit to the default factory
settings.
Power On/Off
Mode
Auxiliary Input
Volume
Display
Reset
General Operation

7
MGH30BT OPERATION
General Operation
Audio Setup Menu
Menu Function Options
Equalization
Curves
Use the VOL+ or VOL- buttons to cycle through the following equalization
curves: Flat, Pop, Jazz, Classic, Beat, Rock and User. Any manual adjustment to
the Bass or Treble settings are automatically saved as User.
Loudness Use the VOL+ or VOL- buttons to activate or deactivate the Loudness feature,
which increases bass and treble levels at low volume.
Bass Level Use the VOL+ or VOL- buttons to adjust the bass level setting
(-6 minimum / +6 maximum).
Bass Frequency Use the VOL+ or VOL- buttons to select one of the following bass frequency
settings: 60 Hz, 80 Hz, 100 Hz or 200 Hz.
Middle Level Use the VOL+ or VOL- buttons to adjust the middle level setting
(-6 minimum / +6 maximum).
Middle Frequency Use the VOL+ or VOL- buttons to select one of the following middle frequency
settings: 500 Hz, 1 kHz, 1.5 kHz or 2.5 kHz.
Treble Level Use the VOL+ or VOL- buttons to adjust the treble level setting
(-6 minimum / +6 maximum).
Treble Frequency Use the VOL+ or VOL- buttons to select one of the following treble frequency
settings: 10 KHz, 12.5 KHz, 15 KHz or 17.5 KHz.
Balance Use the VOL+ or VOL- buttons to adjust the balance setting.
(12-L to 12-R; 0 represents equal balance).
Fader Use the VOL+ or VOL- buttons to adjust the fader setting.
(12-F to 12-R; 0 represents equal balance)
Press MENU to toggle through and select one of the
following setup menus: Audio, General, Gain and Screen.
1. Once the desired menu is displayed, use the VOL+ or
VOL- buttons to scroll through the list of menu features.
2. Press SELECT to select a specific feature to adjust, then
use the VOL+ or VOL- buttons to adjust or activate
the desired feature.
3. Press SELECT to confirm and save the changes.
Setup Menu

8
MGH30BT OPERATION
General Operation
Menu Function Options Action
Tuner
Frequency
Spacing
USA Programs the unit to USA tuner spacing.
(200kHz for FM and 10kHz for AM).
S-America Programs the unit to South American tuner spacing.
(100kHz for FM and 10kHz for AM).
Europe Programs the unit to European tuner spacing.
(50kHz for FM and 9kHz for AM).
Auto Station
Store AUTO STORE Press SELECT to seek and save 6 strong stations in the
current band.
Local/Distance
Tuning
Off Activates distance tuning.
On Activates local tuning for strong station reception only.
Scrolling
Option
Off Programs the unit to not scroll any information on the
display.
Once Programs the unit to only scroll information once.
15Sec Programs unit to scroll information once every 15 seconds
(default).
On Programs unit to scroll information continuously.
iPod Control
Full Programs the head unit to advanced control of the iPod/
iPhone device.
Manual
Programs the head unit to manual control of the iPod/iPhone
device and allows music to be controlled from the iPod/
iPhone device.
Beep
Confirmation
Off Disables the confirmation beep.
On Enables the confirmation beep.
Programmable
Turn On Volume
Variable
Value
Programs unit to always turn on at a specific volume
(default is Off). A volume level of 1-30 can be selected.
General Setup Menu
Low Battery ON
Battery Voltage drops(10.8V+/-0.03V)a Beep will sound.(default)
OFF Battery Voltage drops(10.8V+/-0.03V)a Beep will not sound.

9
MGH30BT OPERATION
General Operation
Gain Setup Menu
Menu Function Options
Tuner Gain Use the VOL+ or VOL- buttons to adjust the tuner gain.
(-6 minimum / +6 maximum)
Aux Gain Use the VOL+ or VOL- buttons to adjust the gain for the front auxiliary input.
(-6 minimum / +6 maximum)
Bluetooth Gain
Use the VOL+ or VOL- buttons to adjust the gain for the Bluetooth A2DP
Playback.
(-6 minimum / +6 maximum)
USB Gain Use the VOL+ or VOL- buttons to adjust the gain for USB playback.
(-6 minimum / +6 maximum)
iPod Gain Use the VOL+ or VOL- buttons to adjust the gain for iPod playback.
(-6 minimum / +6 maximum)
Pandora Gain Use the VOL+ or VOL- buttons to adjust the gain for Pandora playback.
(-6 minimum / +6 maximum)
Screen Setup Menu
Menu Function Options
Color Use the VOL+ or VOL- buttons to adjust the color settings of the display screen
from 0 to 50.
Contrast Use the VOL+ or VOL- buttons to adjust the contrast settings of the display
screen from 0 to 50.
Brightness Use the VOL+ or VOL- buttons to adjust the brightness settings of the display
screen from 0 to 50.
Demo Use the VOL+ or VOL- buttons to to enable (ON) or disable (OFF) the
demonstration mode.

10
MGH30BT OPERATION
Manual Tuning
Seek Tuning
Band
Manually Storing
Preset Stations
Automatically Store
Preset Stations
Recalling
Preset Stations
Press TUNE
nn
or TUNE
ll
momentarily to change
radio frequency up or down one step at a time. Press and
hold to advance quickly.
Press TUNE
nn
or TUNE
ll
for more than two seconds
(then release) to automatically seek and tune to the next
strong station.
Press BAND to select between FM1, FM2, FM3, AM1 and
AM2 bands.
Up to 18 FM stations and 12 AM stations can be stored.
To manually store a station, select the desired band and
station. Press and hold Play/Pause for more than two
seconds, then press Volume Up to step through preset
numbers one through six. When the desired preset number
is reached, press SELECT to save the selection.
Press MENU twice, then press Volume Up to select Auto
Station Store. Press SELECT to confirm. The unit will
automatically scan and store the six strongest stations in
the current band as presets.
Once stations have been saved, press Play/Pause to step
through each preset station.
AM/FM Tuner Operation
