DUALphone 3058 User manual

4INSTALLATION GUIDE
ENGLISH
INSTALLATION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Connecting the base station and power plug . . . . . . . . . . . . . . . . . . . . . . 5
Getting Started . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Installing and charging the batteries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Installing software (from CD). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
USING THE HANDSET. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Basic operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Power on/off operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Selecting language . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Making landline external calls (PSTN). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Making Skype calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Taking calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Redialling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Dialling from the phone book . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Muting the microphone and ringer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Call hold/transfer. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Party conference . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Call waiting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Changing the earpiece and ring volume . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Paging the handset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Handset speaker phone. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Key lock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Warning signals, confirmation signals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Short key definition. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Call log . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Browsing, deleting, saving. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Missed calls, answered calls, dialled calls . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Deleting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
CE DECLARATION OF CONFORMITY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
In this guide
CONTENTS

5
ENGLISH
■Connecting the base station and power plug
This is how you connect the plugs to the corresponding sockets in the base station
– please note that they cannot be connected incorrectly because the sockets and plugs
are designed to prevent reverse poling:
1) Plug the telephone line in the telephone connection socket.
2) Connect the power supply to the base and into a socket outlet.
3) Plug the USB cable into the USB port on your PC.
The base station in now ready to operate.
Note:
• Only use the connection cable supplied.
INSTALLATION
CAUTION:
Plug the adapter into a socket outlet that is close to the equipment and easily
accessible. Use only the power supply supplied with the unit. The use of any
other power supply may damage the unit.
,
USB Cable
AC Power Input Phone Jack
Installation

6
ENGLISH
INSTALLATION
■Getting Started
Installing and charging the batteries
1) Insert two rechargeable AAA size batteries in the compartment, ensuring correct polarity.
2) Close the compartment.
3) Place the handset in the base station to charge for 14 hours prior to first use.
Note:
• If you do not charge your DUALphone properly, the battery performance will be
compromised.
Warning: The handset will not work and will be damaged if the wrong batteries are used.
7

7
ENGLISH
INSTALLATION
Installing software (from CD)
If the installation CD included in the package does not run automatically when inserted into
the CD ROM drive of your computer, please open your CD-ROM drive and double-click on
setup.exe to open the main screen.
For further information please see: www.dualphone.net
7

8
ENGLISH
Using the handset
■Basic Operation
Power on/off operation
1) The handset is powered on by plugging in the battery or by pressing
for two
seconds.
2) Topower off the handset, press for two seconds.
Note:
• If the handset is in the base station, only and are functional.
Selecting language
Different languages are available for the handset. To select a language:
1) Press to enter the main menu.
2) Press or to select Handset Settings, then to enter.
3) Press or to scroll through the menu until Language appears.
4) Press to enter language selection.
5) Press or to select language.
6) When English is selected, press to confirm without additional input language, or
press to add an additional input language, then press or to select the
additional language and press to confirm.
7) Press to confirm the selection when selecting another language than English.
Making landline external calls (PSTN)
Post-dialling
1) Press or and wait for a dialling tone.
2) Dial the telephone number.
3) Press to end the call.
Pre-dialling
1) Dial the telephone number (up to 24 digits); delete any incorrect entries by
pressing .
2) Press or , and the number entered is dialled.
3) Press to end the call.
Note:
• If call barring is enabled and the number dialled matches with the barring conditions,
you will be prompted that the call is barred. During the conversation you can use
or to adjust the speaking volume (five levels).
USING THE HANDSET 8

9
ENGLISH
8
• The call timer will start counting when the call is connected; the call timer format is
HH:MM:SS. After the connection is established, you can view the Phone Book by
pressing
.
Making Skype calls
Making a SkypeOut call
SkypeOut allows you to use your Internet connection to call ordinary telephones and
mobile telephones worldwide.
There are two ways to make a SkypeOut call:
Direct dialling
1) Dial the number using the format “00/011 + country code + telephone number”.
2) Press to dial out the number.
3) Press to end the call.
Dialling from Skype contacts list
1) Press , and the first entry in the Skype contacts list appears.
2) Press or to select the required subscriber from the list. Alternatively, enter the
fi r st letter of the name required.
3) Press or to dial out the selected SkypeOut number.
4) Press to end the call.
Note:
• If one call is ended, pressing can terminate the other call.
USING THE HANDSET
ENGLISH

10
ENGLISH
Taking calls
When an external landline call is received, the telephone number of the caller may
appear (depending on configuration and network). If the caller has been entered in
your phone book, the name may appear.
When a Skype call is received, the incoming Skype username or SkypeIn number will be
shown on the screen.
When receiving a landline or Skype call, the handset will ring, and the green LED on
the base station will flash.
Handset is in the base station
1) Take the handset from the base station, and the connection is automatically
established (provided the AUTO ANS function is active). Otherwise, press
,
, or
INT
.
2) Carry out the conversation.
3) Press to end the call.
Handset is not in the base station
1) Press , , or
INT
to carry out the conversation.
2) Press to end the call.
Note:
• You can reject a call by simply pressing .
Redialling
Your DUALphone stores up to 20 last dialled landline numbers in the Landline Dialled
Log and an unlimited number of dialled Skype usernames or SkypeOut numbers in the
Skype Dialled Log.
Press to view the dialled calls or use the user menu (see Call Log for details).
Note:
• If there are no records in the Dialled Call Log, there will be no information on the
display, and you will automatically be returned to the main menu.
1) Press or to select the desired type of dialled call.
2) Press to confirm your selection.
3) Press or to select the desired record.
4) Press or to redial the desired record. If Skype Dialled is selected, is
also available.
5) Press to end the call.
USING THE HANDSET

11
ENGLISH
Dialling from the Phone Book
1) Press
, and the first entry in the Phone Book appears (alternatively the text No
Records if you have no entries) – or access the Phone Book through the user menu
(see Phone Book for details).
2) Press or to view the name list or enter the first letter of the name to quick
search an entry.
3) Press to view the details.
4) Press or to select the required number.
5) Press or to dial the number.
6) Press to end the call.
Muting the microphone and ringer
• Press to switch the microphone on or off during a call.
• Press to switch the ringer on or off during ringing.
Call hold/transfer
If your DUALphone is connected to a PABX network, it is possible to put external
landline calls on hold and transfer them to other extensions.
1) Press to put the call on hold.
2) Enter the extension number you want, and the extension called will ring.
3) Press again if you would like to take back the call, or to transfer the call.
Party conference
Skype conference call
1) Press to enter the Skype contacts list.
2) Press or to view the contacts, and press to select participants one by one
(up to four Skype users can be chosen to join the conference). Press again to
cancel a selected party from the conference group.
3) Press to start the conference call.
4) Press to disconnect from the conference call, allowing the others to continue
with the external call.
Call waiting
During an ongoing call you can always start a new call by pressing the corresponding
button.
Note:
• You can press to terminate the ongoing Skype call and turn to the landline
call or press to release the landline call and turn to the Skype call. If one call
is ended, pressing can terminate the other call.
USING THE HANDSET

12
ENGLISH
USING THE HANDSET
Changing the earpiece and ringer volume
Press
or as often as necessary to change the earpiece and ringer volume during a
call.
Paging the handset
If the handset has been misplaced, it is possible to call it by pressing on the base
station. Pressing any key will stop the handset page ring.
Handset speaker phone
Press to activate or deactivate the handset speaker.
Key lock
Lock/unlock the handset keypad by pressing and holding for two seconds.
Note:
• Incoming calls can still be received and the alarm can be turned off by pressing any
key. Only and are functional when the keypad is locked.
Warning signals, confirmation signals
Key tone Acoustic signal when a key is pressed. Can be switched off
(see Handset Settings).
Low battery
charge
If a low battery condition is detected, the handset will beep
every 30 seconds, and the empty battery icon will be
displayed on the screen.
Out of range When the handset is too far away from the base station, the
text Out of Range will be displayed on the screen.
PC Not Available When Skype cannot be accessed successfully, the PC Not
Available icon will be displayed and activate an error tone.
Short-key definition
There are six short-keys: , , ,
INT
, and :
In standby mode, press to enter the Answered Call log.
In standby mode, press to enter the Missed Call log.
In standby mode, press , to access the Skype Contacts list.
In standby mode, press
INT
, to access the intercom menu.
In standby mode, press to access the Dialled Call log.
In standby mode, press to access the landline Phone Book.

13
ENGLISH
■Call Log
Browsing, deleting, saving
IMPORTANT: To use the Call Log function, you must subscribe to your network
operator’s Caller Line Identification (CLI) service.
Missed calls, answered calls, dialled calls
There are six types of call logs: Landline missed, Landline answered and Landline
dialled, Skype missed, Skype Answered and Skype dialled. Each landline log can contain
up to 20 records while the Skype logs are unlimited.
1) Press
to enter the main menu.
2) Press or to select Call Log, then press to enter the log.
Note:
• If there are no records in the call log, there will be no information on the display,
and you will automatically be returned to the main menu.
1) Press or to select the desired call log type, then press to confirm.
2) Press or to find the desired record.
3) Press to view detailed information (date/time).
4) Press .
The Landline Call logs operate as follows:
1) Press or to select Save or Delete.
2) Press to confirm, or press to back up.
If you select Save:
1) Press or to select a location in which to store the number, then press to
confirm.
2) Press to switch input method.
3) Press to confirm.
4) Press or to select a group, then press to confirm.
If you select Delete:
1) Simply press key to confirm.
Note:
• Short-keys are available in standby mode: Press to access the Missed Call log,
press to access the Received Call log, and press to access the Dialled Call
log. In the Skype call logs, just press to delete the selected entry.
USING THE HANDSET

14
ENGLISH
Deleting
1) Press
or to select Delete through the submenu Call Log, then press .
2) Press or to select one type of calls or all calls.
3) Press to delete the desired records, or pres to go back.
Note:
• When viewing the records, press , and the highlighted record will be recalled
immediately.
USING THE HANDSET

15
ENGLISH
CE DECLARATION OF CONFORMITY
CE DECLARATION OF CONFORMITY
This product is manufactured for RTX Products A/S. Please also refer to the introduction
in the Quick Guide, guarantee and safety & warranty information sheet.
The DUALphone 3058 comply with the requirements of EC directives:
99/5/EC Directive for radio facilities and telecommunication terminals
The presumption of conformity with essential requirements regarding Council Directive
99/05/EC is assured according to:
R&TTE Directive 99/05/EC Standard: EN301406 V 1.5.1
The DUALphone 3058 is in conformity with the below mentioned directives:
EMC Directive 89/336/EC Standard: EN301489 – 1 V 1.5.1
Standard: EN301489 – 6 V 1.2.1
Safety Directive 2006/95/EC Standard: EN60950 – 1:2001
(1st edition)
SAR Recommendation 99/519/EC Standard: EN50360, EN50385
Due to existing differences between public telecommunication networks in different
states, this authentication does not constitute in itself an unconditional guarantee for
successful operation of these units on every network terminal point.
Intended use:
The DUALphone 3058 is designed to switch onto the analogue telephone network via
the normal telephone socket and USB interface on a PC connected to a broadband
connection. Any other use is deemed as not intended use. The company does not
accept claims resulting from unauthorised alterations or modifications not described in
this user manual.
Denmark, Noerresundby, 26-01-2007
Klaus Ahlbeck
RTX Products A/S
Stroemmen 6
9400 Noerresundby
Denmark
Telephone: +45 96322300
Fax: +45 96322310
Table of contents
Other DUALphone IP Phone manuals
