Owner’s manual ENGLISH
1

This manual forms an integral part of the motorcycle and must be kept with it for its whole service life.
If the motorcycle is resold, the manual must always be handed over to the new owner.
This manual must be preserved with care. If it is lost or becomes damaged, contact a Ducati Dealer or
authorised Service Centre without delay to obtain a new copy of the manual.
The quality standards and safety of Ducati motorcycles are steadily improved as new design solutions,
equipment and accessories are developed. While the information contained in this manual is current at the
time of going to print, Ducati Motor Holding S.p.A. reserves the right to make changes at any time without
notice and without any obligations. For this reason, the illustrations in this manual might differ from your
motorcycle.
Any and all reproduction or spreading of the contents herein in whole or in part is forbidden. All rights reserved
to Ducati Motor Holding S.p.A. Any request for written authorisation shall be addressed to this company,
specifying the reasons for request.
Enjoy your ride!
2

Table of contents
Introduction 7
Safety guidelines 7
Warning symbols used in the manual 8
Intended use 9
Rider's obligations 10
Rider's training 11
Apparel 12
Safety "Best Practices" 13
Refuelling 15
Carrying the maximum load allowed 16
Information about carrying capacity 16
Dangerous products - warnings 17
Vehicle identification number 19
Engine identification number 20
Option kits / Customisations 21
Instrument panel (Dashboard) 30
Instrument panel 30
Acronyms and abbreviations used in the
Manual 35
Technological Dictionary 35
Function buttons 38
Parameter setting/displaying 40
Main functions 47
Engine rpm indication (RPM) 49
Motorcycle speed 51
Riding Mode 53
DTC 57
ABS 64
DWC 71
Gear 78
Fuel level 79
Engine Coolant temperature 81
Menu Functions 83
Odometer (TOT) 85
Trip meter 1 (TRIP 1) 87
Trip meter 2 (TRIP 2) 89
Residual range (RANGE) 90
Trip time (TRIP TIME) 91
Clock 93
Average fuel consumption 94
Instantaneous fuel consumption 96
3

Average speed 98
Ambient air temperature 100
Auxiliary functions 101
Infotainment 104
Cruise Control 116
Service indication (SERVICE) 119
OIL SERVICE zero warning 120
OIL SERVICE or SERVICE DATE or DESMO SERVICE
countdown indication 121
OIL SERVICE or SERVICE DATE or DESMO SERVICE
indication 122
Warnings/Alarms 123
Error warnings 129
Side stand warning 130
Fog lights 131
Setting MENU 132
Customising the Riding Mode 134
Customising the Riding Mode: Parameter
storage 138
Customising the Riding Mode: Engine
setting 140
Customising the Riding Mode: DTC level
setting 142
Customising the Riding Mode: DWC level
setting 145
Customising the Riding Mode: ABS setting 148
Customising the Riding Mode: Reset to default
settings (DEFAULT) 151
Customising the Riding Mode: Reset to default
settings (ALL DEFAULT) 153
Pin Code 154
Changing the PIN CODE 158
Date setting 164
Clock setting 169
Backlighting setting 171
Setting the units of measurement 173
Bluetooth device setting 182
Light control 197
Immobilizer system 204
Keys 205
Replacing the battery in the active key 208
Duplicate keys 212
Restoring motorcycle operation via the PIN
CODE 213
Controls 216
Position of motorcycle controls 216
"Hands free" system 217
Left-hand switch 230
Clutch lever 234
Right-hand switch 235
4

Throttle twistgrip 237
Front brake lever 238
Rear brake pedal 239
Gear change pedal 240
Adjusting the position of the gearchange pedal and
rear brake pedal 241
Main components and devices 243
Position on the vehicle 243
Tank filler plug 244
Seat lock 246
Seat height adjustment 249
Side stand 252
Bluetooth control unit 254
Power outlet 256
Centre stand 258
Assembling the Ducati side panniers 260
Using the side panniers 265
USB connection 269
Adjusting windscreen height 270
Adjusting the front fork 271
Adjusting the rear shock absorber 273
Riding the motorcycle 275
Running-in recommendations 275
Pre-ride checks 277
ABS device 279
Engine start/stop 280
Moving off 283
Braking 284
Stopping the motorcycle 286
Parking 287
Refuelling 289
Tool kit and accessories 290
Front mudguard half kit 291
Main use and maintenance
operations 295
Checking coolant level and topping up, if
necessary 295
Checking brake and clutch fluid level 297
Checking brake pads for wear 299
Charging the battery 300
Checking drive chain tension 304
Lubricating the drive chain 306
Using the supplied chain tension gauge 307
Replacing the high and low beam bulbs 309
Rear turn indicators 311
Number plate light 312
5

Aligning the headlight 313
Adjusting the rear-view mirrors 315
Tubeless tyres 316
Check engine oil level 319
Cleaning and replacing the spark plugs 321
Cleaning the motorcycle 322
Storing the motorcycle 324
Important notes 324
Scheduled maintenance chart 325
Scheduled maintenance chart: operations to be
carried out by the dealer 325
Scheduled maintenance chart: operations to be
carried out by the Customer 329
Technical data 330
Weights 330
Dimensions 331
Fuel, lubricants and other fluids 332
Engine 334
Desmodromic timing system with variable timing
(DVT) 335
Performance data 336
Spark plugs 336
Fuel system 336
Brakes 336
Transmission 337
Frame 338
Wheels 338
Tyres 338
Suspension 338
Exhaust system 339
Available colours 339
Electric system 340
Routine maintenance record 347
Routine maintenance record 347
6

Introduction
Safety guidelines
We would like to welcome you among Ducati
enthusiasts, and congratulate you on your excellent
choice of motorcycle. We think you will ride your
Ducati motorcycle for long journeys as well as short
daily trips. Ducati Motor Holding S.p.A. wishes you
smooth and enjoyable riding.
Your motorcycle is the result of Ducati Motor Holding
S.p.A.'s on-going research and development efforts.
It is important that you preserve its quality standard
by strictly observing the maintenance plan and using
genuine spare parts. This manual provides
instructions on minor maintenance operations. Major
maintenance operations are described in the
Workshop Manual available to Ducati Authorised
Service Centres.
In your own interest, for your safety and in order to
guarantee product reliability, you are strongly advised
to refer to our authorised Dealers and Service Centres
for any operations listed in the scheduled
maintenance chart, see page 325.
Our highly skilled staff have access to special
implements and appropriate equipment required to
perform any servicing job at best, and use Ducati
original spare parts only as the best guarantee for full
interchangeability, smooth running and long life.
All Ducati motorcycles come with a Warranty Card.
The warranty does not apply to motorcycles used in
racing competitions.
Tampering with or altering any components, even
partially, will make the warranty null and void
effective immediately. Improper or poor
maintenance, using other than original spare parts or
parts not expressly approved by Ducati may invalidate
your warranty rights and lead to damage or loss of
performance.
Your safety and that of other road users are very
important. Ducati Motor Holding S.p.A. recommends
that you ride responsibly.
Before using your motorcycle for the first time, read
this entire manual carefully and closely follow the
guidelines outlined in it. The manual provides full
information on proper motorcycle operation and
7

maintenance. In case of any doubts, please contact a
Dealer or Authorised Service Centre.
Warning symbols used in the manual
Several kinds of warnings are used as an alert of the
possible hazards for you or other persons such as:
- Safety labels on the motorcycle;
-Safety messages preceded by a warning symbol
and either WARNING or IMPORTANT.
Warning
Failure to comply with these instructions may
put you at risk, and could lead to severe injury or even
death of the rider or other persons.
Important
Possibility of damaging the motorcycle and/or
its components.
Note
Additional information about the current
operation.
The terms RIGHT and LEFT are referred to the
motorcycle viewed from the riding position.
8

Intended use
Warning
This motorcycle was designed for both road use
and for light off-road and dirt road use. Heavy duty off-
road use is not advised and can result in the rider
losing control of the vehicle, thereby increasing the
risk of accidents.
Warning
This motorcycle may not be used to tow any
trailers or with a side-car attached; this can lead to
loss of control and result in an accident.
This motorcycle carries the rider and can carry a
passenger.
Warning
The total weight of the motorcycle in running
order including rider, passenger, luggage and
additional accessories should not exceed 450kg/
992lb.
Warning
The maximum weight permitted for the side
panniers, top case and the tank bag must never
exceed 30 kg (66 lb), divided as follows:
10 kg (22lb) max. per side pannier;
5 kg (11 lb) max. for the top case;
5 kg (11 lb) max. for the tank bag.
9

Rider's obligations
All riders must hold a valid licence.
Warning
Riding without a licence is illegal and is
prosecuted by law. Always make sure you have your
licence with you when riding. Do not let
inexperienced riders or persons without a valid
licence use your motorcycle.
Do not ride under the influence of alcohol and/or
drugs.
Warning
Riding under the influence of alcohol and/or
drugs is illegal and is prosecuted by law.
Do not take prescription or other drugs before riding
unless you have consulted your doctor about their
side effects.
Warning
Some medications and drugs may cause
drowsiness or other effects that slow down reaction
time and the rider's ability to control the motorcycle,
possibly leading to an accident.
Some states require vehicle insurance.
Warning
Check your state laws. Obtain insurance
coverage and keep your insurance document secure
with the other motorcycle documents.
To protect rider and passenger safety, some states
mandate the use of a certified helmet.
Warning
Check your state laws. Riding without a helmet
may be punishable by law.
Warning
Riders without helmets are more likely to suffer
severe bodily injury or die if they are in an accident.
10

Warning
Check that your helmet complies with safety
specifications, permits good vision, is the right size
for your head, and carries a certification label
indicating that it conforms to the standards in force in
your state. Road traffic laws differ from state to state.
Learn about traffic laws in your state before riding and
always obey them.
Rider's training
Accidents are frequently due to inexperience. Riding,
manoeuvres and braking must be performed in a
different way than on the other vehicles.
Warning
Untrained riders or a wrong use of the vehicle
may lead to loss of control, serous injuries or even
death.
11

Apparel
Riding gear is very important for safety. Unlike cars,
a motorcycle offers no impact protection in an
accident.
Proper riding gear includes helmet, eye protection,
gloves, boots, long sleeve jacket and long trousers.
- The helmet must meet the requirements listed
at page 10; if your helmet does not have a visor,
use suitable eye wear;
- Use five-finger gloves made from leather or
abrasion-resistant material;
- Riding boots or shoes must have non-slip soles
and offer ankle protection;
-Jacket, trousers or riding suit must be made from
leather or abrasion-resistant material and have
high-visibility colours and inserts.
Important
Never wear loose clothing, items or accessories
that may become tangled in motorcycle parts.
Important
For your safety, always wear suitable protective
gear, regardless of season and weather.
Important
Have your passenger wear proper protective
clothing.
12

Safety "Best Practices"
These few simple operations are critical to people
safety and to preserving the full performance of your
motorcycle. Never forget to perform them before,
while and after riding.
Important
Closely follow the indications provided at
chapter "Riding the motorcycle" during the running-in
period.
Failure to follow these instructions releases Ducati
Motor Holding S.p.A. from any liability whatsoever for
any engine damage or shorter engine life.
Warning
Before riding your motorcycle, become familiar
with the controls you will need to use when riding.
Perform the checks recommended in this manual
before each ride (see page 283).
Warning
Failure to carry out these checks before riding
may lead to motorcycle damage and injury to rider
and/or passenger.
Warning
Start the engine outdoors or in a well ventilated
area. The engine should never be started or run
indoors.
Exhaust gases are poisonous and may lead to loss of
consciousness or even death within a short time.
Use proper body position while riding and ensure your
passenger does the same.
Important
Rider must hold the handlebar with both hands
at ALL TIMES while riding.
Important
Both rider and passenger should keep their feet
on the footpegs when the motorcycle is in motion.
Important
The passenger should always hold on to the
grab handles under the seat with both hands.
13

Important
Be very careful when tackling road junctions, or
when riding in areas near exits from private grounds,
car parks or on slip roads to access motorways.
Important
Be sure you are clearly visible and do not ride
within the blind spot of vehicles ahead.
Important
ALWAYS signal your intention to turn or pull to
the next lane in good time using the suitable turn
indicators.
Important
Park your motorcycle where no one is likely to
knock against it, and use the side stand. Never park
on uneven or soft ground, or your motorcycle may fall
over.
Important
Visually inspect the tyres at regular intervals for
detecting cracks and cuts, especially on the side
walls, bulges or large spots that are indicative of
internal damage. Replace them if badly damaged.
Remove any stones or other foreign bodies caught in
the tread.
Warning
Engine, exhaust pipes and silencers stay hot
long after the engine is switched off; pay particular
attention not to touch the exhaust system with any
body part and do not park the vehicle next to
flammable material (wood, leaves etc.).
14

Refuelling
Refuel outdoors with engine off.
Do not smoke or use open flames while refuelling.
Be careful not to spill fuel on engine or exhaust pipe.
Never completely fill the tank when refuelling. Fuel
should never be touching the rim of filler recess.
When refuelling, avoid breathing the fuel vapours and
prevent fuel from reaching your eyes, skin or clothes.
Warning
The motorcycle is only compatible with fuel
having a maximum content of ethanol of 10% (E10).
Using fuel with ethanol content over 10% is
forbidden. Using it could result in severe damage of
the engine and motorcycle components. Using fuel
with ethanol content over 10% will make the
warranty null and void.
Warning
In case of indisposition caused by breathing fuel
vapours for a long time, stay in the open air and
contact your doctor. In case of contact with eyes,
thoroughly flush with water; in case of contact with
skin, immediately clean with water and soap.
Warning
Fuel is highly flammable, in case of accidental
spillage of fuel on your clothes it is necessary to
change into clean clothes.
15

Carrying the maximum load allowed
Your motorcycle is designed for long-distance riding,
carrying the maximum load allowed in full safety.
Even weight distribution is critical to preserving these
safety features and avoiding trouble when
performing sudden manoeuvres or riding on bumpy
roads.
Warning
The maximum speed permitted with the side
panniers, the top case and the tank bag fitted must
not exceed 180 km/h (112 mph) and at any rate it
must comply with the applicable statutory speed
limits.
Warning
Do not exceed the total permitted weight for the
motorcycle and pay attention to information provided
below regarding load capacity.
Information about carrying capacity
Important
Arrange your luggage or heavy accessories in
the lowest possible position and close to motorcycle
centre.
Important
Never fix bulky or heavy objects to the
handlebar or to the front mudguard as this would
affect stability and cause danger.
Important
Be sure to secure the luggage to the supports
provided on the motorcycle as firmly as possible.
Improperly secured luggage may affect stability.
Important
Do not insert any objects you may need to carry
into the gaps of the frame as these may foul moving
parts.
Warning
Make sure the tyres are inflated to the proper
pressure and that they are in good condition.
16

Refer to paragraph "Tyres" on page 316.
Important
If you install the side panniers (available on
request from Ducati Parts service), sort out luggage
and accessories according to their weight and
arrange them in the side panniers to evenly distribute
the weight. Close the side panniers with the relevant
key locks.
Dangerous products - warnings
Used engine oil
Warning
Prolonged or repeated contact with used engine
oil may cause skin cancer. If working with engine oil
on a daily basis, we recommend washing your hands
thoroughly with soap immediately afterwards. Keep
away from children.
Brake dust
Never clean the brake assembly using compressed
air or a dry brush.
Brake fluid
Warning
Spilling brake fluid onto plastic, rubber or
painted parts of the motorcycle may cause damages.
Protect these parts with a clean shop cloth before
proceeding to service the system. Keep away from
children.
Warning
The fluid used in the brake system is corrosive.
In the event of accidental contact with eyes or skin,
wash the affected area with abundant running water.
Coolant
Engine coolant contains ethylene glycol, which may
ignite under particular conditions, producing invisible
flames. Although the flames from burning ethylene
glycol are not visible, they are still capable of causing
severe burns.
Warning
Take care not to spill engine coolant on the
exhaust system or engine parts.
17

These parts may be hot and ignite the coolant,
which will subsequently burn with invisible flames.
Coolant (ethylene glycol) is irritant and poisonous
when ingested. Keep away from children. Never
remove the radiator cap when the engine is hot. The
coolant is under pressure and will cause severe
burns.
The cooling fan operates automatically: keep hands
well clear and make sure your clothing does not snag
on the fan.
Battery
Warning
The battery gives off explosive gases; never
cause sparks or allow naked flames and cigarettes
near the battery. When charging the battery, ensure
that the working area is properly ventilated.
18

Vehicle identification number
Note
These numbers identify the motorcycle model
and should always be indicated when ordering spare
parts.
It is recommended to record the frame number of
your motorcycle in the space below.
Frame number
Fig. 1
19
