Ducati Superbike 848evo Corse User manual

cod 913.7.205.1H

1
US/CANADA
Owner's Manual

2
Introduction
We'd like to welcome you among Ducati enthusiasts
and congratulate you on your excellent choice of
motorcycle. We imagine you'll be riding your Ducati
motorcycle for long trips as well as short daily
excursions. Ducati Motor Holding S.p.A. wishes you
smooth and enjoyable riding.
Your motorcycle is the result of constant research
and development by Ducati Motor Holding S.p.A., so
it's important that the standard of quality is upheld
through careful observance of the scheduled
maintenance chart and the use of original spare parts.
In the Owner's Manual you'll find instructions for
performing small maintenance procedures.
The most important servicing and maintenance
procedures are contained in the Service Manual
available at Authorized Service Centers of Ducati
Motor Holding S.p.A..
In your own interest, for your safety and in order to
guarantee product reliability, we strongly
recommend that you go to an Authorized Dealer or
Service Center for any servicing included on the
scheduled maintenance chart (see page 134)
Our highly skilled staff has access to the special tools
and equipment needed to perform any servicing
procedure with expertise. They use only Ducati
original spare parts as the best guarantee for full
interchangeability, smooth running and long life.
All Ducati motorcycles come with a Warranty
Booklet.
The Warranty does not extend to motorcycles used
in competitions or competitive trials.
Any tampering or even partial modification of the
components will result in automatic invalidation of
Warranty rights.
Incorrect or insufficient servicing procedures, use of
non-original spare parts or parts not explicitly
approved by Ducati may lead to the invalidation of the
Warranty, besides potential damage and reduced
performance.

3
Table of contents
Introduction 2
Safety guidelines 6
Warning symbols used in the manual. 6
Permitted use 7
Rider's obligation 7
Reporting safety defects 9
Rider education 10
Clothing 10
“Best Practices” for safety 11
Refueling 13
Carrying the maximum load allowed 15
Dangerous products - warnings 16
Vehicle ID number 18
Engine ID number 19
Plate positioning 20
Noise and exhaust emission control system
information 26
California emission control warranty statement
Your warranty rights and obligations 27
Manufacturer’s warranty coverage 27
Owner's warranty responsibilities: 27
California evaporation emission system 28
Ducati limited warranty on emission control
system 28
Instrument Panel (Dashboard) 31
Dashboard 31
LCD unit functions 34
LCD – How to set/display parameters 36
Total distance covered indicator: “Odometer“ 39
Air temperature indicator 40
Vehicle speed indication 41
Engine coolant temperature indicator 42
Partial trip meter “TRIP A” 43
Partial trip meter “TRIP B“ 44
Distance traveled on fuel reserve: “TRIP FUEL“ 45
Maintenance indicator (SERV) 46
Battery voltage indicator (BATT). 47
Engine idle RPM setting (RPM) 48
LAP timer 49
Stored data display (LAP Memory) 51
DDA data acquisition 53
Erase DDA 54
Function for activation/deactivation of DTC (Ducati
Traction Control) 55
Description of the system 55
Activation of the system 56
The functions of the system 56
Routine maintenance 56
DTC (Ducati Traction Control) setting function 57
Tips on how to select the sensitivity level 60
Tips for use on the track 61
Tips for use on the road 61

4
Quick Shift (DQS ON/OFF) enable / disable
function 62
Clock setting function 63
Dashboard diagnosis 65
Instrument panel backlighting 71
Headlight “smart” auto-off 71
Headlight “smart” switch-on 72
The Immobilizer system 73
Keys 73
Code card 74
Immobilizer override procedure 75
Operation 77
Duplicate keys 77
Service menu - unit of measurement (UNIT SET) 78
Controls 80
Position of motorcycle controls 80
Key-operated ignition switch and steering lock 81
LH switch 82
Clutch lever. 83
RH switch 84
Throttle twistgrip 84
Front brake lever 85
Rear brake pedal 86
Gear change pedal 86
Setting the gear change and rear brake pedals 87
Main components and devices 89
Position on the vehicle 89
Fuel tank plug 90
Seat lock 91
Side stand 92
Steering damper 93
Front fork adjusters 94
Rear shock absorber adjusters 96
Riding the motorcycle 98
Break-in recommendations 98
Pre-ride checks 100
Starting the engine 101
Moving off 103
Braking 104
Stopping the motorcycle 105
Parking 105
Refueling 106
Tool kit and accessories 107
Main maintenance operations 108
Removing the fairing 108
Changing the air filter 112
Checking and topping up coolant level 113
Checking brake and clutch fluid level 114
Checking brake pads for wear 116
Lubricating cables and joints 117

5
Adjusting throttle control free play 118
Charging the battery 119
Checking drive chain tension 120
Chain lubrication 121
Replacing the high and low beam bulbs 122
Replacing the parking light bulb 124
Rear turn indicators 125
Number plate light 125
Beam setting 126
Rear view mirror adjustment 127
Tubeless tires 128
Checking engine oil level 130
Cleaning and replacing the spark plugs 131
Cleaning the motorcycle 132
Storing the motorcycle 133
Important notes 133
Maintenance 134
Scheduled maintenance chart: operations to be
performed by the Dealer 134
Scheduled maintenance chart: operations to be
performed by the customer 137
Technical data 138
Overall dimensions (mm) 138
Weights 138
Engine 140
Timing system 140
Performance data 141
Spark plugs 141
Fuel system 141
Brakes 142
Transmission 143
Frame 144
Wheels 144
Tires 144
Suspensions 145
Exhaust system 146
Available colors 146
Electrical system 146
Routine maintenance record 152

6
Safety guidelines
Your safety and that of others are very important.
Ducati Motor Holding S.p.A. urges you to ride your
motorcycle responsibly.
Before using your motorcycle for the first time,
please read this manual carefully from start to finish
and closely follow the guidelines. This will allow you
to obtain all information regarding a correct use and
maintenance.
If you have any doubts or questions, consult a Dealer
or Authorized Service Center.
Warning symbols used in the manual.
Different forms of information regarding potential
hazards that may affect you or others have been
used. These include:
- Safety stickers on the motorcycle;
- Safety warnings preceded by a warning symbol
and by one or the two words Caution or
Important.
Warning
Failure to observe these instructions may lead
to a hazardous situation and cause severe injury to
the rider or others, or even death.
Important
Possibility of damaging the motorcycle and/or
its components.
Note
Additional information regarding the job being
performed.
The terms RIGHT and LEFT are referred to the
motorcycle viewed from the riding position.

7
Permitted use
This motorcycle must be used only on road surfaces
with asphalt or flat and even pavement.
This motorcycle may not be used on dirt roads or for
off-road riding.
Warning
Using the bike off-road may cause the rider to
lose control, which in turn may lead to vehicle
damage, injury or death.
Warning
This motorcycle must not be used for towing or
for the addition of a sidecar, since this may cause a
loss or control and consequent accident.
Warning
The total weight of the motorcycle in running
order with rider, passenger, baggage and additional
accessories must not exceed 882 lb (400kg).
Rider's obligation
All riders must hold a driver's license.
Warning
Riding without a license is illegal and punishable
by law. Make sure you always have your license on
you when setting out on the motorcycle. Do not
allow inexpert riders or those not in possession of an
authorized driver's license to ride the motorcycle.
Do not ride the motorcycle when under the influence
of alcohol or drugs.
Warning
Riding under the influence of alcohol or drugs is
illegal and punishable by law.
Avoid taking medication before riding the motorcycle
if you have not consulted your doctor about potential
side effects.
Warning
Some medications may induce sleepiness or
other effects that impair reflexes and the ability of the
rider to control the motorcycle, which may lead to
accident.

8
Some countries require mandatory insurance
coverage.
Warning
Check the laws applicable to your country. Take
out an insurance policy and keep the policy in a safe
place along with the other motorcycle documents.
To protect the safety of the rider and/or passenger,
some countries have made it a law to wear a
homologated helmet.
Warning
Check the laws applicable to your country.
Riding without a helmet may be punishable by a fine.
Warning
Failure to be wearing a helmet in case of
accident increases the chance of serious injury and
even death.
Warning
Make sure that the helmet is in compliance with
safety specifications, provides excellent visibility, is
the correct size for the head, and has the DOT
(Department of Transportation) label affixed to the
helmet surface.
Laws regulating traffic vary from country to country.
Check the laws in force in your country before riding
the motorcycle and pay strict adherence to them .
Warning
Tampering with Noise Control System
Prohibited. Federal Law prohibits the following acts
or causing thereof:
1) the removal or rendering inoperative by any
person, other than for purposes of maintenance,
repair, or replacement, of any device or element
of design incorporated into any new vehicle for
the purpose of noise control prior to its sale or
delivery to the ultimate purchaser or while it is in
use; or
2) the use of the vehicle after such device or
element of design has been removed or
rendered inoperative by any person.
Among the acts presumed to constitute tampering
are those listed below:
1) Removal of, or puncturing the muffler, baffles,
header pipes or any other component that
conducts exhaust gases.
2) Removal or puncturing of any part of the intake
system.
3) Lack of proper maintenance.

9
4) Replacing any moving part of the vehicle, or parts
of the exhaust or intake system, with parts other
than those specified by the manufacturer.
This product should be checked for repair or
replacement if the motorcycle noise has increased
significantly through use. Otherwise, the owner may
become subject to penalties under state and local
ordinances.
Reporting safety defects
If you believe your vehicle has a defect that could
cause a crash or cause injury or death, you should
immediately inform the National Highway Traffic
Safety Administration (NHTSA), in addition to
notifying Ducati North America, 10443 Bandley Drive
Cupertino, California, 95014, Tel: [phone],
Fax: [phone]. If NHTSA receives similar
complaints, it may open an investigation, and if it
finds that a safety defect exists in a group of vehicles,
it may order a recall and remedy campaign. However,
NHTSA cannot become involved in individual
problems between you, your dealer, or Ducati North
America. To contact NHTSA, you may either call the
Auto Safety Hotline toll-free at 1-800-424-9393 (or
366-0123 in Washington, D.C. area) or write to:
NHTSA, 1200 New Jersey Avenue SE W43-488,
Washington, D.C. 20590. You can also obtain other
information about motor vehicle safety from the
Hotline.

10
Rider education
Accidents are frequently due to inexperience. Riding,
maneuvering and or braking are carried out differently
from other vehicles.
Warning
A rider's lack of preparation or an inappropriate
use of the vehicle may result in a loss of control,
death or serious damage.
Be sure you know the “RULES OF THE ROAD“,
carefully read and familiarize with the contents of the
M.O.M. (Motorcycle Operator Manual) for
information on your State and which can be viewed
on the M.S.F. (Motorcycle Safety Foundation)
website (www.msf-usa.org).
You are strongly recommended to take a riding
course approved by the M.S.F. (Motorcycle Safety
Foundation).
Clothing
Clothing in the use of the motorcycle plays an
important role in safety, as the motorcycle provides a
person no protection from impact in the same way as
an automobile.
Suitable clothing includes: helmet, eye protection,
gloves, boots, long-sleeved jacket and long pants.
- The helmet must have the requisites as listed on
page 8, if the helmet model has no visor, use
suitable goggles;
- Gloves must have five fingers and be made of
leather or other abrasion-resistant material;
- Boots or shoes used for riding must have non-slip
soles and ankle protection;
- Jacket and pants, or even riding suits, must be
made of leather or abrasion-resistant material and
in a color with inserts that are very visible.
Important
In any case, avoid wearing loose or floppy
clothing that can become stuck in the motorcycle
parts.

11
Important
For your safety this type of clothing must be
used in both summer and winter.
Important
For the safety of the passenger, make sure that
he or she also wears appropriate clothing.
“Best Practices” for safety
Before, during and after use, remember to follow
some simple rules that are extremely important for
safety and for maintaining the motorcycle at top
efficiency.
Important
During the break-in period, carefully observe the
instructions contained on page 98. Failure to follow
these instructions releases Ducati Motor Holding
S.p.A. from any liability whatsoever for any engine
damage or shorter engine life.
Warning
Do not ride the motorcycle unless you are well
familiarized with the controls to be used during the
ride.
Before starting the motorcycle, always performs the
checks detailed in this manual (see page 100).
Warning
Failure to perform checks may cause damage to
the vehicle and serious injury to the rider and/or
passenger.

12
Warning
Start the engine when outdoors or in a well
ventilated place. Never start the engine in a closed
environment.
Exhaust gases are poisonous and may lead to loss of
consciousness or even death within a short time.
During the ride, assume a correct body position and
make sure the passenger does the same.
Important
The rider should ALWAYS keep both hands on
the handlebar.
Important
Both rider and passenger should keep their feet
on the footpegs when the motorcycle is in motion.
Important
The passenger should always hold on to the
strap on passenger seat with both hands.
Important
Be very careful when maneuvering
intersections or when riding in areas near exits from
private grounds, parking lots or access roads to
highways.
Important
Be sure you are clearly visible and do not ride in
the blind spot of the vehicles ahead.
Important
ALWAYS signal your intention to turn or pull
over to the next lane with due warning using the turn
indicators.
Important
Park your motorcycle where no one is likely to
hit it, and use the side stand.
Never park on uneven or soft ground or your
motorcycle may fall over.

13
Important
Visually inspect the tires at regular intervals for
cracks and cuts, especially on sidewalls, bulges or
large spots which are indicative of internal damage.
Replace them if badly damaged.
Remove any stones or other foreign bodies caught in
the tread.
Warning
The engine, exhaust pipes and mufflers stay hot
for a long time after the engine has been turned off.
Be especially careful not to touch the exhaust system
with any part of the body and never park the
motorcycle near flammable materials (wood, leaves,
etc.).
Warning
When you leave the motorcycle unattended,
always remove the ignition key and make sure it is
inaccessible to anyone unsuitable to ride the
motorcycle.
Refueling
Refuel the motorcycle in an open area and with the
engine switched off.
Do not smoke or ever use flames during refueling.
Be careful never to drop fuel on the engine or
exhaust pipe.
When refueling, do not fill the tank completely: fuel
should never be touching the rim of filler recess.
When refueling, avoid inhaling fuel vapors and take
care that they do not come in contact with eyes, skin
or clothing.

14
Warning
The vehicle is compatible only with fuel having
a maximum content of ethanol of 10% (E10). Using
fuel with ethanol content over 10% is prohibited.
Using it could result in severe damage of the engine
and motorcycle components. Using fuel with ethanol
content over 10% will render the Warranty null and
void.
Warning
In case of malaise caused by prolonged
inhalation of fuel vapors, stay outdoors and consult a
physician. In case of contact with eyes, rinse eyes
thoroughly with water. In case of contact with skin,
wash the area immediately with soap and water.
Warning
Fuel is highly flammable. If it accidentally spills
onto clothes, change them.

15
Carrying the maximum load allowed
Your motorcycle is designed for long-distance riding
with the maximum load allowed carried in full safety.
Even weight distribution is critical to preserving these
safety features and avoiding difficulties when
performing sudden maneuvers or riding on bumpy
roads.
Warning
Do not exceed the total permitted weight for
the motorcycle and pay attention to the information
below regarding load capacity.
Information about carrying capacity
Important
Arrange your luggage or heavy accessories in
the lowest possible position and close to motorcycle
center.
Important
Never fix bulky or heavy objects to the steering
head or front mudguard, as this would affect stability
and be dangerous.
Important
Be sure to secure the luggage to the supports
provided on the motorcycle as firmly as possible.
Improperly secured luggage may affect stability.
Important
Do not insert any objects you may need to carry
into the gaps of the frame, as these may interfere
with moving parts.
Warning
Make sure tires are inflated to the correct
pressure indicated at page 128 and that they are in
good condition.

16
Dangerous products - warnings
Used engine oil
Warning
Prolonged or repeated contact with used engine
oil may cause skin cancer. If exposed to used engine
oil on a daily basis, make it a rule to wash your hands
thoroughly with soap immediately after use. Keep
away from children.
Brake lining debris
Never attempt to clean the brake assembly using
compressed air or a dry brush.
Brake fluid
Warning
Avoid spilling brake fluid onto plastic, rubber or
painted parts of the motorcycle to avoid the risk of
damage. Protect these parts with a clean shop rag
before servicing the motorcycle. Keep away from
children.
Warning
The brake fluid used in the brake system is
corrosive. In the event of accidental contact with
eyes or skin, wash the affected area with generous
quantities of running water.
Coolant
Engine coolant contains ethylene glycol, which may
ignite under particular conditions, producing invisible
flames. Although the flames from burning ethylene
glycol are not visible, they are still capable of causing
severe burns.

17
Warning
Take care not to spill engine coolant on the
exhaust system or engine parts. These parts may be
hot and ignite the coolant, which will subsequently
burn with invisible flames.
Coolant (ethylene glycol) is an irritant and is
poisonous when ingested. Keep away from children.
Never remove the radiator cap when the engine is
hot. The coolant will be scalding hot and is under high
pressure.
The cooling fan operates automatically: keep hands
well clear and make sure your clothing does not get
caught in the fan.
Battery
Warning
The battery gives off explosive gases; keep it
away from any source of ignition such as sparks,
flames and cigarettes. Charge the battery in a well-
ventilated area.

18
Vehicle ID number
Note
These numbers identify the motorcycle model
and should always be indicated when ordering spare
parts.
We recommend that you note the frame number of
your motorcycle in the space below.
Frame number
DUCATI
TYPE OF
MOTORCYCLE
MODEL
YEAR
PLANT OF
MANU FACTURE
SEQUENTIAL
NUMBER
{
{
{
Varies-can be Ø thru 9 or X (Check digit)
ZDM 1 X B M V X B 0 0 0 0 0 0
fig. 1
fig. 2

19
Engine ID number
Note
These numbers identify the motorcycle model
and should always be indicated when ordering spare
parts.
We recommend that you note the engine number of
your motorcycle in the space below.
Engine number
XBG ? *000000*
ENGINE
TYPE MODEL
YEAR
SEQUENTIAL
NUMBER
fig. 3
fig. 4
