Ducati Scrambler User manual

This manual is an integral part of the motorcycle and must remain with it for its entire life.
The manual must accompany the motorcycle if it is sold or transferred to a new owner.
Please store this manual in a safe a place. In case of damage or loss, request a new copy by contacting:
Ducati North America, Inc.
10443 Bandley Drive
Cupertino, California, 95014
Tel: [phone]
Fax: [phone]
E-mail: cu[email protected]
Web site: www.ducatiusa.com
Quality and safety standards of Ducati motorcycles are constantly being updated consequent to the
development of new design solutions, equipment and accessories. Although the manual includes fully
updated information at the time of print, Ducati Motor Holding S.p.A. therefore reserves the right to make
changes without prior notification or without incurring obligations. For this reason, you may note
discrepancies when comparing some illustrations with your motorcycle.
Any and all reproduction or dissemination of the contents in whole or in part is strictly prohibited. All rights
are reserved by Ducati Motor Holding S.p.A. Requests for authorizations shall be made in writing to this
company with specification of the reason.

Owner's manual US/CANADA
1

We'd like to welcome you among Ducati enthusiasts and congratulate you on your excellent choice of
motorcycle. We imagine you'll be riding your Ducati motorcycle for long trips as well as short daily excursions.
Ducati Motor Holding S.p.A. wishes you smooth and enjoyable riding.
Your motorcycle is the result of constant research and development by Ducati Motor Holding S.p.A., so it's
important that the standard of quality is upheld through careful observance of the scheduled maintenance
chart and the use of original spare parts. In the Owner's Manual you'll find instructions for performing small
maintenance procedures. The most important servicing and maintenance procedures are contained in the
Service Manual available at Authorized Service Centers of Ducati Motor Holding S.p.A..
In your own interest and safety, and in order to guarantee product reliability, we strongly recommend that
you go to an Authorized Dealer or Service Center for any servicing included on the scheduled maintenance
chart, see page 175.
Our highly skilled staff has access to the special tools and equipment needed to perform any servicing
procedure with expertise. They use only Ducati original spare parts as the best guarantee for full
interchangeability, smooth running and long life.
All Ducati motorcycles come with a Warranty Booklet. The Warranty does not extend to motorcycles used
in competitions or competitive trials. Any tampering or even partial modification of the components will result
in automatic invalidation of Warranty rights. Incorrect or insufficient servicing procedures, use of non-original
spare parts or parts not explicitly approved by Ducati may lead to the invalidation of the Warranty, besides
potential damage and reduced performance.
Enjoy your ride!
2

Table of Contents
Introduction 7
Safety guidelines 7
Warning symbols used in the manual 7
Intended use 7
Rider's obligations 8
Reporting of safety defects 10
Rider's training 10
Apparel 10
Safety "Best Practices" 11
Refueling 13
Carrying the maximum load allowed 14
Information about carrying capacity 14
Dangerous products - warnings 15
Vehicle identification number 16
Engine identification number 18
Customizations 19
Plate position 28
Noise and exhaust emission control system
information 32
California emission control warranty
statement 32
Your warranty rights and obligations 32
Manufacturer’s warranty coverage 33
Owner's warranty responsibilities 33
California evaporation emission system 34
Ducati limited warranty on emission control
system 35
Instrument panel (Dashboard) 38
Instrument panel 38
Acronyms and abbreviations used in the
Manual 42
Technological Dictionary 43
Function push-buttons 44
Parameter setting/displaying 45
Main functions 50
Motorcycle speed 52
Engine rpm indication (RPM) 53
Menu 1 functions 55
Odometer (TOT) 56
Trip meter 1 (TRIP 1) 57
Trip meter 2 (TRIP 2) 58
3

Partial fuel reserve counter (TRIP FUEL) 59
Ambient air temperature (AIR) 61
Errors 62
Error warnings 63
Displayed errors description 64
Clock 68
High engine temperature 69
Service warning (SERVICE) 70
OIL SERVICE zero warning 71
DESMO SERVICE countdown warning 72
DESMO SERVICE warning 73
Setting menu 74
ABS control unit enabling/disabling 77
Battery voltage 80
Instrument panel back-lighting setting
(B.LIGHT) 82
Clock setting function (CLOCK) 84
Pin Code 87
Changing the PIN CODE 91
Setting the unit of measurement 96
Light control 103
Immobilizer system 106
Keys 107
Operation 108
Duplicate keys 109
Entering PIN CODE function for overriding
purposes 110
Controls 114
Position of motorcycle controls 114
Key-operated ignition switch and steering
lock 115
Left-hand switch 116
Clutch lever 117
Right-hand switch 120
Throttle twistgrip 121
Front brake lever 122
Rear brake pedal 123
Gear change pedal 124
Adjusting the position of the gearchange pedal and
rear brake pedal 125
Main components and devices 127
Position on the vehicle 127
Fuel tank plug 128
Seat lock 129
Side stand 130
USB connection 131
Adjusting the rear shock absorber 132
4

Riding the motorcycle 134
Running-in recommendations 134
Pre-ride checks 136
ABS 138
Starting the engine 139
Moving off 141
Braking 142
Stopping the motorcycle 144
Parking 145
Refueling 146
Tool kit and accessories 147
Main maintenance operations 148
Check brake fluid level 148
Changing the air filter 149
Checking brake pads for wear 150
Charging the battery 151
Lubricating cables and joints 155
Adjusting the throttle cable 156
Checking drive chain tension 157
Lubricating the drive chain 159
Replacing the headlight bulbs 160
Changing the turn indicator bulbs 163
Aligning the headlight 164
Adjusting the rear-view mirrors 166
Tubeless tires 167
Check engine oil level 169
Cleaning and replacing the spark plugs 171
Cleaning the motorcycle 172
Storing the motorcycle 174
Important notes 174
Scheduled maintenance chart 175
Scheduled maintenance chart: operations to be
carried out by the dealer 175
Scheduled maintenance chart: operations to be
carried out by the customer 179
Technical data 180
Weights 180
Overall dimensions 181
Top-ups 183
Engine 184
Timing system 185
Performance 186
Spark plugs 186
Fuel system 186
Brakes 186
Transmission 187
5

Frame 188
Wheels 188
Tires 188
Suspensions 188
Exhaust system 189
Available colors 189
Electric system 191
Routine maintenance record 196
Routine maintenance record 196
6

Introduction
Safety guidelines
Your safety and that of others are very important.
Ducati Motor Holding S.p.A. urges you to ride your
motorcycle responsibly.
Before using your motorcycle for the first time,
please read this manual carefully from start to finish
and closely follow the guidelines. This will allow you
to obtain all information regarding a correct use and
maintenance. If you have any doubts or questions,
consult a Dealer or Authorized Service Center.
Warning symbols used in the manual
Different forms of information regarding potential
hazards that may affect you or others have been
used. These include:
- Safety stickers on the motorcycle;
- Safety warnings preceded by a warning symbol
and by one or the two words CAUTION or
IMPORTANT.
Attention
Failure to observe these instructions may lead
to a hazardous situation and cause severe injury to
the rider or others, or even death.
Important
Possibility of damaging the motorcycle and/or
its components.
Note
Additional information regarding the job being
performed.
The terms RIGHT and LEFT are referred to the
motorcycle viewed from the riding position.
Intended use
Attention
This motorcycle is designed for on-road use,
may be used occasionally on dirt trail. Usage in
conditions for which it was not designed (e.g. heavy
off-road use) can lead to loss of control of the
motorcycle, increasing the risk of a crash.
7

Attention
This motorcycle must not be used for towing or
for the addition of a sidecar, since this may cause a
loss or control and consequent accident.
This motorcycle carries the rider and can carry a
passenger.
Attention
The total weight of the motorcycle in running
order with rider, passenger, baggage and additional
accessories must not exceed 805lb/ 365kg.
Rider's obligations
All riders must hold a driver's license.
Attention
Riding without a license is illegal and punishable
by law. Make sure you always have your license on
you when setting out on the motorcycle. Do not allow
inexpert riders or those not in possession of an
authorized driver's license to ride the motorcycle.
Do not ride the motorcycle when under the influence
of alcohol or drugs.
Attention
Riding under the influence of alcohol or drugs is
illegal and punishable by law.
Avoid taking medication before riding the motorcycle
if you have not consulted your doctor about potential
side effects.
Attention
Some medications may induce sleepiness or
other effects that impair reflexes and the ability of the
rider to control the motorcycle, which may lead to
accident.
Some countries require mandatory insurance
coverage.
Attention
Check the laws applicable to your country. Take
out an insurance policy and keep the policy in a safe
place along with the other motorcycle documents.
To protect the safety of the rider and/or passenger,
some countries have made it a law to wear a
homologated helmet.
8

Attention
Check the laws applicable to your country.
Riding without a helmet may be punishable by a fine.
Attention
Failure to be wearing a helmet in case of
accident increases the chance of serious injury and
even death.
Attention
Make sure that the helmet complies with safety
specifications, provides excellent visibility, is the
correct size for the head, and has the certification
label affixed to the helmet surface conforming to the
standards in force in your state. Road traffic laws
differ from state to state. Check the laws in force in
your country before riding the motorcycle and pay
strict adherence to them .
Attention
Tampering with Noise Control System
Prohibited. Federal Law prohibits the following acts
or causing thereof:
1) the removal or rendering inoperative by any
person, other than for purposes of maintenance,
repair, or replacement, of any device or element
of design incorporated into any new vehicle for
the purpose of noise control prior to its sale or
delivery to the ultimate purchaser or while it is in
use; or
2) the use of the vehicle after such device or
element of design has been removed or
rendered inoperative by any person.
Among the acts presumed to constitute tampering
are those listed below:
1) Removal of, or puncturing the muffler, baffles,
header pipes or any other component that
conducts exhaust gases.
2) Removal or puncturing of any part of the intake
system.
3) Lack of proper maintenance.
4) Replacing any moving part of the vehicle, or parts
of the exhaust or intake system, with parts other
than those specified by the manufacturer.
This product should be checked for repair or
replacement if the motorcycle noise has increased
9

significantly through use. Otherwise, the owner may
become subject to penalties under state and local
ordinances.
Reporting of safety defects
If you believe your vehicle has a defect that could
cause a crash or cause injury or death, you should
immediately inform the National Highway Traffic
Safety Administration (NHTSA), in addition to
notifying Ducati North America, 10443 Bandley Drive
Cupertino, California, 95014, Tel.: [phone],
Fax: [phone]. If NHTSA receives similar
complaints, it may open an investigation, and if it
finds that a safety defect exists in a group of vehicles,
it may order a recall and remedy campaign. However,
NHTSA cannot become involved in individual
problems between you, your dealer, or Ducati North
America. To contact NHTSA, you may either call the
Auto Safety Hotline toll-free at 1-800-424-9393 (or
366-0123 in Washington, D.C. area) or write to:
NHTSA, 1200 New Jersey Avenue SE W43-488,
Washington, D.C. 20590. You can also obtain other
information about motor vehicle safety from the
Hotline.
Rider's training
Accidents are frequently due to inexperience. Riding,
maneuvering and or braking are carried out differently
from other vehicles.
Attention
A rider's lack of preparation or an inappropriate
use of the vehicle may result in a loss of control, death
or serious damage.
Check your knowledge of current "TRAFFIC LAWS";
read carefully and familiarize yourself with the
contents of the M.O.M (Motorcycle Operator
Manual) pertinent to your state available at the M.S.F.
(Motocycle Safety Fundation) (www.msf-usa.org)
website.
You are strongly recommended to take a riding
course approved by the M.S.F. (Motocycle Safety
Fundation).
Apparel
Clothing in the use of the motorcycle plays an
important role in safety, as the motorcycle provides
a person no protection from impact in the same way
as an automobile.
10

Suitable clothing includes: helmet, eye protection,
gloves, boots, long-sleeved jacket and long pants.
-The helmet must have the requisites as listed on
page 8, if the helmet model has no visor, use
suitable goggles;
- Gloves must have five fingers and be made of
leather or other abrasion-resistant material;
-Boots or shoes used for riding must have non-slip
soles and ankle protection;
- Jacket and pants, or even riding suits, must be
made of leather or abrasion-resistant material
and in a color with inserts that are very visible.
Important
In any case, avoid wearing loose or floppy
clothing that can become stuck in the motorcycle
parts.
Important
For your safety this type of clothing must be
used in both summer and winter.
Important
For the safety of the passenger, make sure that
he or she also wears appropriate clothing.
Safety "Best Practices"
Before, during and after use, remember to follow
some simple rules that are extremely important for
safety and for maintaining the motorcycle at top
efficiency.
Important
During the break-in period, carefully observe the
instructions contained in section "Riding the
motorcycle" of this Manual.
Failure to follow these instructions releases Ducati
Motor Holding S.p.A. from any liability whatsoever for
any engine damage or shorter engine life.
Attention
Do not ride the motorcycle unless you are well
familiarized with the controls to be used during the
ride.
Before starting the motorcycle, always perform the
checks detailed in this manual (see page 139).
11

Attention
Failure to perform checks may cause damage to
the vehicle and serious injury to the rider and/or
passenger.
Attention
Start the engine when outdoors or in a well
ventilated place. Never start the engine in a closed
environment.
Exhaust gases are poisonous and may lead to loss of
consciousness or even death within a short time.
During the ride, assume a correct body position and
make sure the passenger does the same.
Important
The rider should ALWAYS keep both hands on
the handlebar.
Important
Both rider and passenger should keep their feet
on the footpegs when the motorcycle is in motion.
Important
The passenger should always hold on to the
grab handles under the seat with both hands.
Important
Be very careful when maneuvering
intersections or when riding in areas near exits from
private grounds, parking lots or access roads to
highways.
Important
Be sure you are clearly visible and do not ride in
the blind spot of the vehicles ahead.
Important
ALWAYS signal your intention to turn or pull
over to the next lane with due warning using the turn
indicators.
Important
Park your motorcycle where no one is likely to
hit it, and use the side stand. Never park on uneven
or soft ground or your motorcycle may fall over.
12

Important
Visually inspect the tires at regular intervals for
cracks and cuts, especially on sidewalls, bulges or
large spots which are indicative of internal damage.
Replace them if badly damaged.
Remove any stones or other foreign bodies caught in
the tread.
Attention
The engine, exhaust pipes and mufflers stay hot
for a long time after the engine has been turned off.
Be especially careful not to touch the exhaust system
with any part of the body and never park the
motorcycle near flammable materials (wood, leaves,
etc.).
Attention
When you leave the motorcycle unattended,
always remove the ignition key and make sure it is
inaccessible to anyone unsuitable to ride the
motorcycle.
Refueling
Refuel the motorcycle in an open area and with the
engine switched off.
Do not smoke or ever use flames during refueling.
Be careful never to drop fuel on the engine or exhaust
pipe.
When refueling, do not fill the tank completely: fuel
should never be touching the rim of filler recess.
When refueling, avoid inhaling fuel vapors and take
care that they do not come in contact with eyes, skin
or clothing.
Attention
The vehicle is compatible only with fuel having
a maximum ethanol content of 10% (E10).
Using fuel with ethanol content over 10% is
prohibited. Using it could result in severe damage of
the engine and motorcycle components. Using fuel
with ethanol content over 10% will render the
Warranty null and void.
Attention
In case of malaise caused by prolonged
inhalation of fuel vapors, stay outdoors and consult a
physician. In case of contact with eyes, rinse eyes
thoroughly with water. In case of contact with skin,
wash the area immediately with soap and water.
13

Attention
Fuel is highly flammable. If it accidentally spills
onto clothes, change them.
Carrying the maximum load allowed
Your motorcycle is designed for long-distance riding
with the maximum load allowed carried in full safety.
Even weight distribution is critical to preserving these
safety features and avoiding difficulties when
performing sudden maneuvers or riding on bumpy
roads.
Attention
The maximum allowed speed with side
panniers and top-case does not have to exceed 81
mph (130 Km/h) and it must be anyway within the
limits set by the law.
Attention
Do not exceed the total permitted weight for the
motorcycle and pay attention to the information
below regarding load capacity.
Information about carrying capacity
Important
Arrange your luggage or heavy accessories in
the lowest possible position and close to motorcycle
center.
Important
Never fix bulky or heavy objects to the steering
head or front mudguard, as this would affect stability
and be dangerous.
Important
Be sure to secure the luggage to the supports
provided on the motorcycle as firmly as possible.
Improperly secured luggage may affect stability.
Important
Do not insert any objects you may need to carry
into the gaps of the frame, as these may interfere
with moving parts.
Attention
Make sure tires are inflated to the correct
pressure and that they are in good condition.
14

Please refer to paragraph "Tires" on page 167.
Dangerous products - warnings
Used engine oil
Attention
Prolonged or repeated contact with used engine
oil may cause skin cancer. If exposed to used engine
oil on a daily basis, make it a rule to wash your hands
thoroughly with soap immediately after use. Keep
away from children.
Brake lining debris
Never attempt to clean the brake assembly using
compressed air or a dry brush.
Brake fluid
Attention
Avoid spilling brake fluid onto plastic, rubber or
painted parts of the motorcycle to avoid the risk of
damage. Protect these parts with a clean shop rag
before servicing the motorcycle. Keep away from
children.
Attention
The brake fluid used in the brake system is
corrosive. In the event of accidental contact with eyes
or skin, wash the affected area with generous
quantities of running water.
Coolant
Engine coolant contains ethylene glycol, which may
ignite under particular conditions, producing invisible
flames. Although the flames from burning ethylene
glycol are not visible, they are still capable of causing
severe burns.
Attention
Take care not to spill engine coolant on the
exhaust system or engine parts.
15

Vehicle identification number
Note
These numbers identify the motorcycle model
and should always be indicated when ordering spare
parts.
We recommend that you note the frame number
(Fig 1) of your motorcycle in the space below.
Frame number
Fig 1
16

There are two types of VIN number: VIN (Fig 2) refers
to vehicles produced in the Italian factory, whereas
VIN (Fig 3) refers to vehicles produced in the Thai
factory.
ZDM X B 0 0 0 0 0 0
{
{
{
Varies-can be Ø thru 9 or X (Check digit)
DUCATI
TYPE OF
MOTORCYCLE
MODEL
YEAR
SEQUENTIAL
NUMBER
PLANT OF
MANUFACTURE
15 A N M
Fig 2
ML0 X T 0 0 0 0 0 0
{
{
{
Varies-can be Ø thru 9 or X (Check digit)
DUCATI
TYPE OF
MOTORCYCLE
MODEL
YEAR
SEQUENTIAL
NUMBER
PLANT OF
MANUFACTURE
15 A N M
Fig 3
17

Engine identification number
Note
These numbers identify the motorcycle model
and should always be indicated when ordering spare
parts.
We recommend that you note the engine number
(Fig 4) of your motorcycle in the space below.
Engine number
Fig 4
18
