01 Introduction
The DucoBox Reno, the most compact ventilation unit in Europe, performs two functions in a DUCO Demand-Controlled Natural
Ventilation System.
On the one hand, it is the master, or brain of the system. It receives and interprets signals from slave components (measurements
from sensors or manual input), on the basis of which it controls the ventilation system.
On the other hand, it is the extractor fan that exhausts stale air with excessive CO2content or humidity.
CO2levels are measured via optional CO2sensors; the humidity level is measured via a standard RH sensor integrated in the box
itself.
DUCO advises against connecting the DucoBox (via a duct or directly) to an extractor hood, regardless of the type. This usually
causes excessive fouling in the DucoBox, which affects its operation or has a more direct effect on output.
Master
Slave 1
Figure 1: with standard integrated RH sensor

4
ENGLISH
L2003342 Installation guide for DucoBox Reno (Revision A | 17.05.2023)
02 Mounting
02.A Position
figure 2: Against a wall, you can position the Box in any possible direction. Figure 3: You can also mount the box vertically or horizontally.
If you place the DucoBox Reno in a damp room with a water connection, avoid placing it on the floor.
02.B Mounting
Figure 4: Mounting: adapt the mounting material to the surface

5
ENGLISH
L2003342 Installation guide for DucoBox Reno (Revision A | 17.05.2023)
02.C Air duct connections
Limit the resistance. A non-return flap is required when discharging into a manifold.
Be sure to take note of the ‘10 unmissable tips’ as well when mounting the DucoBox. Avoiding excessive use of bends, especially
angles greater than 90° and adhering to the diameter guidelines for the ductwork will ensure that the ventilation box is able to
do its job satisfactorily. Failure to take account of this recommendation may result in a highly energy and maintenance intensive
system that gives rise to excessive noise nuisance frequently.
Select a roof pass-through
with low resistance.
0,5 à 1 m
Duct leading to the roof pass-through: use a
reducer 125mm– 160mm. Never use flexible
connections. Avoid curves in this part of the
canalization. If the DucoBox is not mounted in a
protected (insulated) volume, this duct needs to be
thermally insulated.
Use an
acoustic
silencer of
minimum
0.5 to 1 m.
This in every
connection
which leads
to a different
room.
Keep the box airtight. Close
the cover tightly and place
a cap onto any unused
opening.
Avoid as much as
possible the use of
curves. Avoid sharp
angles.
Avoid bumps and dirt in the ducts.
> 90°
160
mm
125 mm → ≥ 30 m³/h
100 mm → < 30 m³/h
< 90°
Reduce the transmission of
vibrations:
• Use silent blocks when fixing the
DucoBox to the wall.
• Use duct suspension clamps with
rubber.
Do not place an
exhaust air valve
directly on the box.
Use a 90° bend
between the DucoBox
and the valve. Use
valves with an as low
as possible back-
pressure and follow
the instructions as
given in the manual
regarding the opening
of the valves.
Assure an airtight
connection by using
tape, clamping strips
or tie-wrap. Do not
use screws.
Diameter of the ducts:
125mm upward from 30m³/h
100mm less than 30m³/h
Or an equivalent based on a specific duct calculation
(p.e. for ducts placed in floor screed). Make sure that
the total counter pressure in the ducts is as low as
possible (preferably ≤150Pa) and that the airspeed in
every duct does not exceed 3m/s.
installation-tips-duct-system-DucoBox-Silent-Focus-(en)
1
7
8
9
10
2
3
4
5
6
DISCLAIMER: no rights can be derived from this document.
All tips are only advisory. All those carrying out
the work can, depending on the project at
hand, determine for themselves which
tips are feasible and/or useful.
The smooth running of your Duco ventilation system is totally dependent
on the choice and the quality of implementation of the duct system!
10 UNMISSABLE TIPS
Has the duct system been optimized? Ask
professional advice from your duct supplier. It
saves you time, ensures quality and provides
energetic advantage for the end user!
L1025000-C 05.05.2023

6
ENGLISH
L2003342 Installation guide for DucoBox Reno (Revision A | 17.05.2023)
03 Communication
03.A Connection & buttons
7
Figure 5: Remove the cover plate of the lid with
a screwdriver to gain access to the adjustment
buttons.
Figure 6: You now have access to the adjustment
buttons.
Figure 7: The circuit board is located under the lid.
UP
LED INDICATOR
‘HIGH’
LED INDICATOR
INST / CALIB
PERILEX
CO2BOXSENSOR
FAN
POWER
24 VDC
CALIBRATE
INST / ENTER
DOWN
DUCO NETWORK TOOL
Figure 8: Connections and buttons on the circuit board of the DucoBox Reno

7
ENGLISH
L2003342 Installation guide for DucoBox Reno (Revision A | 17.05.2023)
Wireless communication
The DucoBox Reno is able to communicate with DUCO slave components via a wireless (RF) connection.
RF obstacle-free zone
Do not place any obstacles causing RF interference or other
devices with an RF connection within a radius of at least 30 cm
around the RF component. We take these to include items such
as washing machines, tumble dryers, ironing boards, etc.
Remote control
RF230 VAC RF230 VAC
Switch Sensor
RF230 VAC
Max. of 25 RF components
230 VAC
≥ 30 cm RF
DucoBox
Reno
Figure 9: Communication via RF
RF components have a maximum free-field range of 350 metres. This distance will be much less in a building because of obstacles.
Therefore, you will need to take objects such as walls, concrete and metal into account. All slave components (except those which
are battery powered) also act as repeaters. Signals from components that are unable to make a (strong) connection with the master
component are forwarded automatically via no more than one other non-battery-powered component (= hop). Please refer to
information sheet RF communication (L8000018) at www.duco.eu for further information.
DUCO RF
Power supply 230 VAC
Wiring 1,5 mmm2
Frequency 868 Mhz
Maximum distance 350 m, free field (less through obstacles)
Maximum number of components Up to 25 wireless components in a single system

8
ENGLISH
L2003342 Installation guide for DucoBox Reno (Revision A | 17.05.2023)
04 Additional control option
04.A 3-position switch (only in the Netherlands)1through Perilex2
The last action on any remote control is always leading. The ventilation position on the 3-position switch can therefore be overruled
by another remote control, such that an incorrect ventilation position will be visible on the 3-position switch.
Please refer to the manual with the DUCO Perilex plug for more information.
high setting
medium setting
low setting
Figure 10: Perilex switch
04.B CO2Box sensor
A CO2Box sensor can be integrated into a duct port of the DucoBox Reno and provide measurement in an air duct. A DucoBox Reno
can contain a maximum of one CO2Box sensor.
CO2BOX SENSOR MOUNTING + CONNECTING
1. Disconnect the DucoBox Reno from the mains and remove the lid of the DucoBox Reno. To do this, first remove the screw
located behind the cover plate. (Figure 11: Remove the cover plate and unscrew the lid).
2. Disconnect the motor plate by unclipping the 4 clamps. To do this, slide a flat screwdriver behind the clamp and tilt it back
slightly (approx. 5mm) so that the clamp is released from the opening in the casing (see Figure 11: open the casing and Figure
12: remove the motor plate).
3. Secure the CO2Box sensor from the outside in the desired duct port by clicking it into place on the rib closest to the motor
plate (Figure 13: Clicking the CO2Box sensor into the duct port). To do this, make a tilting movement by first tightening the
lower and then the upper clamp.
4. Pass the cable of the CO2Box sensor through the opening on the inside of the casing at the level of the corresponding duct
port. Then pass the cable of the CO2Box sensor through the relevant opening (marked with 'sensor cable') of the motor plate
according to the diagram shown below in Figure 14: four options for wiring a maximum of 1 CO2Box sensor to the circuit board.
5. Attach the motor plate to the casing. The motor plate is fixed when the 4 clamps are engaged in the casing. Make sure that the
strain relief of the power cable is pushed into the opening provided for this purpose. The power cable can be attached to the
outside of the casing by using the cable clips.
6. Connect the CO2Box sensor to the connector (CO2) on the DucoBox Reno PCB (03.A).
7. Mount the lid correctly on the unit. Make sure the notch in the lid is over the power cable opening (Figure 15: Note the notch in
the lid). Screw the lid back on and close with the cover plate.
1 This is not a DUCO component.
2 Only in the Netherlands.

9
ENGLISH
L2003342 Installation guide for DucoBox Reno (Revision A | 17.05.2023)
(Figure 11: remove the cover plate and unscrew the lid) Figure 12: detaching the motor plate
Figure 13: removing the motor plate Figure 14: snap the CO2box sensor into the duct port
Figure 15: Four options for cabling up to one CO2Box sensor to circuit board
!
Figure 16: Note the recess in the lid

10
ENGLISH
L2003342 Installation guide for DucoBox Reno (Revision A | 17.05.2023)
05 Electronical installation
05.A Change settings
Most of the factory settings for the network and components will be satisfactory as they are, however, depending on the situation, it
may be desirable to change some parameters, such as the CO2setpoint. This can be done using the DUCO Network Tool. 3. This us-
er-friendly software also enables problems in the system to be pinpointed. The DUCO Network Tool is issued to every installer after
attending a free training course at the DUCO Academy4. Please refer to our website or your DUCO dealer for further information.
05.B Installer / User mode
To add, remove or replace components to the network, the system should be put in ‘Installer mode’. The LED on each component
indicates the component's active mode (see table at 05.C in the next section).
Installer mode can be activated by pressing the INST button of the DucoBox Reno (see drawing in chapter "03.A Connection & but-
tons"). When the LED on the master unit starts flashing green, Installer mode is active. Press ‘INST’ again to return to ‘User mode’
(LED fully on or off). The system reverts automatically to ‘User mode’ after 15 minutes of inactivity.
05.C LED indications
RED (blinking slowly)
Not in network
RED (blinking rapidly)
Busy pairing
GREEN (blinking slowly)
In network
GREEN (blinking rapidly)
In network, waiting for associated components
YELLOW (clignotement rapide)
Transitional phase (please wait)
YELLOW (on)
Initialising (system configuration in progress)
WHITE or OFF
Normal
BLUE
Component is displayed if changes are being put through via the master.
ORANGE
The system is not working correctly because the DucoBox has not been calibrated. Restart the
DucoBox. Follow the guidelines in ‘10 essential tips’ if the problem recurs continually.
3 Only in Belgium and the Netherlands
4 Only in Belgium and the Netherlands

11
ENGLISH
L2003342 Installation guide for DucoBox Reno (Revision A | 17.05.2023)
05.D Pairing components
Never pair more than one system with RF components at the same time. If you do so, a component in the wrong network could be
paired, e.g. in the neighbours’ DucoBox.
PAIRING COMPONENTS ON THE DUCOBOX RENO
1. Activate ‘Installer mode’ by tapping ‘INST’ on the DucoBox. The LED will flash green rapidly.
2. Add control components by tapping once on the component to be paired. The LED will flash red briefly and then start to flash
green rapidly. Repeat this step until all remaining components in the current zone have been paired. With RF components:
start with the component closest to the master. If the first pairing is unsuccessful, another component may be tried first, which
can then act as a hop for components that are unable to make an RF connection with the DucoBox.
3. Once all components have been paired, ‘Installer mode’ can be deactivated by tapping ‘INST’ on the DucoBox Reno. The LEDs
on all components will stop flashing.
Example of a pairing sequence
2 3
1 4
Figure 17: Xindicates the order in which to press a component button

12
ENGLISH
L2003342 Installation guide for DucoBox Reno (Revision A | 17.05.2023)
05.E Removing / replacing components
Removing paired components from the network or replacing is only possible within 30 minutes after the component is paired in
or is restarted. Restarting can be done by disconnecting the power for a moment. After a time-span of 30 minutes, remove and
replace operations are ignored.
Removing a component
1
Activate ‘Installer mode’ by long-
pressing 2diagonal buttons on a
paired control. The LED will flash
green rapidly. 5 sec
2
Press once and hold a button on
the component to be removed
in order to remove it from the
network.
ATTENTION: any underlying
components will also be removed
from the network.
5 sec
3
Deactivate ‘Installer mode’ by
pressing the 4buttons on a paired
control simultaneously (or using
the palm of your hand on a control
featuring touch buttons). The LED
will turn white.
Replacing a component
1
Activate ‘Installer mode’ by long-
pressing 2diagonal buttons on a
paired control. The LED will flash
green rapidly. 5 sec
2Press briefly twice on the button
of the component to be replaced.
2x
OLD
3
Tap once on the button for the new
component. The latter will take on
all settings / connections in the
network. 1x
NEW
3
Deactivate ‘Installer mode’ by
pressing the 4buttons on a paired
control simultaneously (or using
the palm of your hand on a control
featuring touch buttons). The LED
will turn white.
05.F Tips
Remove all components from the network (e.g. in case of problems):
Activate Installer mode and long press INST until the LED starts flashing red. The DucoBox will reboot (around 15 seconds) and the
LED will stop flashing.
Restore factory settings of the DucoBox and all registered components:
Long press INST + + when not in Installer mode. The network will be preserved.
Use the DUCO Network Tool to read out information from components.

13
ENGLISH
L2003342 Installation guide for DucoBox Reno (Revision A | 17.05.2023)
06 Air calibration
The system needs to be configured for it to work correctly. This will ensure its operation is as quiet as possible and energy-efficient.
See under the Tools heading at www.duco.eu for information about determining ventilation flow rates.
06.A Air calibration procedure for DucoBox Reno
The air calibration procedure must be carried out on a calm day (no more than wind force 2: leaves rustling, feel-
ing the wind in one’s face).
Calibrating the DucoBox Reno
1
Set all exhaust vents so they match the desired flow rate in
accordance with the table below. Proper pre-setting makes for rapid
and correct calibration.
Flow
rate
DucoVent
Design
DucoVent Basic
and other vents
75m³/h 100% open
50m³/h 50% open
25m³/h 25% open
When using DucoVent Design exhaust vents always leave the outer
ring in place for acoustic effect. Figure 18: example situation for calibration
2
Before activating air calibration mode:
• Close all windows and doors.
• Ensure that all duct openings in the DucoBox are fully closed and that the
DucoBox lid is closed!
• Avoid air leaks in the ventilation ducts.
• Set all window ventilators to the open position
OPEN
3
Ensure that the lid of the DucoBox is properly closed. Remove the front cover with a screwdriver.
Figure 19: Remove the front cover of the lid with
a screwdriver to gain access to the adjustment
buttons.
Figure 20: Removing the front cover

14
ENGLISH
L2003342 Installation guide for DucoBox Reno (Revision A | 17.05.2023)
4
Put the DucoBox Reno into adjustment mode by pressing and together for 3 seconds until the LED next to the
INST button ( ) starts flashing. The adjustment mode is now activated for 30 minutes. There are 10 pre-programmed
calibration curves (see figure AFTER point 10 of this chapter). The LED next to flashes yellow according to a number
depending on the set control curve (from 1 to 10 times), e.g. 4 times blinking at intervals represents control curve 4 (R4).
5
Which configuration mode should I choose?
The LED next to the HIGH label lights up by default; the adjustment mode is set to
'HIGH'. Change the desired adjustment mode by pressing and briefly when
the adjustment mode is activated. The LED display next to 'HIGH' determines the
adjustment mode:
Button
Air calibration using 'HIGH'
This method is standard and has the
lowest consumption. Recommended
in the majority of homes.
Air calibration using 'LOW'
This method offers a boost mode
but may give rise to more noise
and higher consumption.
Low mode (10%) Low mode (14-33%)
Medium mode (50%) High mode (100%)
High mode (100%) Boost mode (143-333%)
LED
'HIGH' ACTIVE (green) INACTIVE (off)
The percentages in the table indicate what percentage of the flow rate configured
will be extracted.
The configuration mode chosen does not affect the operation of the AUTO mode.
HIGH
INST
CALIB
Figure 21: Selecting adjustment mode
6Select the duct with the highest flow rate and restriction.
7
Measure at the vent and adjust the DucoBox's rpm until the desired flow rate is
obtained. This can be done in two ways:
• Using the (lower) and (higher) buttons on a paired Remote control or
Room CO2/Humidity Sensor*.
• Using the ‘DOWN’ and ‘UP’ buttons on the DucoBox.
* Depending on the software version of the Remote control.
/
/
8Now measure the other vents. The flow rate from these other vents must only be
adjusted at the vents themselves.
9Repeat steps 7and 8until the desired flow rate has been obtained at each vent.
10 Exit configuration mode. To do so, press 'INST' in the DucoBox Reno.
INST

15
ENGLISH
L2003342 Installation guide for DucoBox Reno (Revision A | 17.05.2023)
1
23 4
56 7 8
8
910
50
100
150
200
2
5
0
3
00
35
0
400
0
50
100
1
5
0
200
2
5
0
3
00
35
0
Pressure (Pa)
Flow rate (m3/h)
PRESSURE/FLOW
Figure 22: overview calibration curves DucoBox Reno
06.B Option: installation of control on the DucoBox
To keep the DucoBox and controls together during delivery, the option is provided to mount the Remote control RF/Bat on the
DucoBox Reno.
Figure 23: Remove the front cover of the lid with a
screwdriver to gain access to the adjustment buttons.
Figure 24: Turn the front cover over so that the snap-
on pieces are on the outside.
Figure 25: Mount it back on the DucoBox.
Figure 26: Snap the control onto the provided snap-
on pieces of the front cover.
Figure 27: mounted control

16
ENGLISH
L2003342 Installation guide for DucoBox Reno (Revision A | 17.05.2023)
06.C Checking
The steps set out below can be used to check whether the flow rates have been set correctly.
Checking configured flow rate
1
The configured flow rate is dependent on whether the ‘HIGH’ or ‘LOW’ configura-
tion mode has been chosen.
Press for ‘HIGH’ calibration (= standard) or for ‘LOW’ calibration on a ran-
dom control to have the system run for 15 minutes at 100% of the requested flow
rate.
2Measure the flow rate at the exhaust vents.
3After the check, the system can be reset to the desired ventilation mode. If you do
not do so, the system will revert automatically to the AUTO mode after 15 minutes.

17
ENGLISH
L2003342 Installation guide for DucoBox Reno (Revision A | 17.05.2023)
07 Maintenance & service
Please refer to the maintenance instructions at www.duco.eu and view the videos on duco.tv for more information.
For service problems as a user:
Please contact your installer. Keep the serial number of your product to hand.
For service problems as an installer:
Please contact your retailer of DUCO products. Keep the serial number of your product to hand.

18
ENGLISH
L2003342 Installation guide for DucoBox Reno (Revision A | 17.05.2023)
08 Warranty
All warranty conditions concerning the DucoBox and DUCO's ventilation systems can be found on the DUCO website.
All complaints are to be reported to DUCO by the DUCO distributor with a clear description and the order/invoice number under
which the products were delivered. To do so, please fill out the complaint registration form, found on the DUCO website, mentioning
the serial number and send it to serviceduco.eu.
09 Legislation
Product card, EC declaration of conformity and energy labels can be viewed and downloaded at www.duco.eu.

19
ENGLISH
L2003342 Installation guide for DucoBox Reno (Revision A | 17.05.2023)

Installed by:
L2003342 Document last modified on 17.05.2023 (revision A)
