Dudley 50416 User manual

Installaon and User Guide
Manual Soaps and Hand Saniser
Dispensers
Applicable to product groups:
50416 Classic 1L Foam Soap Dispenser
50412 Classic 1L Liquid Soap Dispenser
50417 Classic 1L Hand Saniser Dispenser
50440 Plasma 1L Soap Dispenser
50004/6 Planum 375ml Soap Dispenser
50012/14/15/18 Planum 1L Soap Dispenser
50012/18 Planum Shower Gel Dispenser
Version 1.1

Thank you for choosing a Dudley Industries Soap or Hand Saniser Dispenser.
This dispenser is designed and manufactured by our team at our facilies based in Lancashire, UK.
All our products are designed to withstand constant use in busy environments. Our Manual Soap
Dispensers and Hand Sanisers are supported by a 10 year warranty provided they are installed and
maintained correctly and not subject to any vandalism. Products must not be modied in any way as
this will invalidate the warranty.
Please follow these instrucons for safe installaon and pass this document to the user for safe
keeping.
Installaon and User Guide
Manual Soaps and Hand Saniser Dispensers
Safety Informaon
Please read these instrucons thoroughly before installaon and retain for future reference.
Remove all packaging and check contents for any damage prior to commencing installaon. If there
are any issues please contact our Customer Services Team on [phone].
Before commencing installaon and drilling into walls check that there are no hidden electrical
cables or water pipes.
When using power tools always ensure you wear the correct PPE and operate following the
manufacturer’s instrucons.
This dispenser should only be used for the type of soap specied i.e. Liquid, Foam or Hand Saniser.
Check outer box for details.
Page 2

Installaon and User Guide
Manual Soaps and Hand Saniser Dispensers
Page 3
Product Features
Brushed and lacquered dispensers are manufactured from Stainless Steel.
White units are constructed from steel and powder coated.
Internal mechanisms are constructed from mixed materials.
All units (see product groups) are bulk ll/top up and suitable for your choice of formulaon but
always ensure the correct type is used i.e. liquid, foam or hand saniser.
All units are lockable to protect the contents and spare keys are available from Customer Services.
Soap dispensers are operated by pushing a buon or the cover to dispense the soap, this is to
reduce the pressure on wall xings to ensure they remain safe and secure.
Fixing kits are included with all units.
Installaon
Following the guide for xing; measure and mark the posion of the xing holes on the wall
ensuring that they are level.
Drill holes in the wall using the appropriate size drill bit. Drill to the depth of the wall plug. If the
surface is led, drill into the grout lines whenever possible. Insert the wall plugs supplied.
Open the dispenser, remove the reservoir if necessary and posion the dispenser xing holes over
the wall holes made.
Insert the screws provided and ghten to secure the dispenser. We always recommend that you use
all xing holes available for strength and security.
Replace any internal mechanisms and close the cover.
Press the cover mulple mes to ensure operaon before lling with consumable.
70
46
50
150.6
178
5.8
4
5.5
4
Example:

Installaon and User Guide
Manual Soaps and Hand Saniser Dispensers
Page 4
Filling and relling
Unlock the cover and hinge open.
Li the lid of the reservoir and ll with your choice of consumable ensuring it is correct for the type
of pump supplied i.e. liquid, foam or hand saniser soluons.
Replace the reservoir lid and close the cover ensuring the lock is engaged.
If new or empty, prime the dispenser by pressing the buon or cover mulple mes to ensure the
formulaon reaches the nozzle ready for dispensing.
General Maintenance & Cleaning
Brushed Stainless Steel Units:
Clean with warm water and a so cloth, wipe in the same direcon as the brushed grain. Dry
thoroughly. DO NOT use soap, chemical cleaning detergents or abrasive cleaners.
Powder Coated & Lacquered Units:
Clean with a mild detergent and so cloth. Ensure any detergent is fully rinsed o prior to drying
thoroughly.
End of Life Disposal
All Dudley Industries units are manufactured to ensure longevity and a reliable life span. When a
dispenser has reached its end of life it should be disposed of in a safe manner. Most components
can be re-cycled in accordance with your local authority waste management policy.

Installaon and User Guide
Manual Soaps and Hand Saniser Dispensers
Page 5
Troubleshoong
Soap not dispensing:
Check the reservoir to ensure soap is available.
Clean the nozzle with a so warm cloth (NEVER INSERT ANYTHING INTO THE NOZZLE).
Fill the reservoir with a small amount of warm water and depress the nozzle to try and clear
any soap build up.
Cover/Buon won’t depress:
Open the cover and check that there is no debris blocking operaon.
Check to see if there is any damage which may be causing the fault.
Check to see if installaon is correct, i.e the dispenser is not skewed.
Lost Key:
Spare keys can be purchased from our Customer Services Team call [phone].
Correct Pump Guidance:
Dierent consumable formulaons require dierent pumps
Always check that you are using the correct consumable for the pump in the dispenser.
• Foam soaps require a foam pump
• Liquid Soap and Gel Hand Sanisers require a liquid / gel pump
• Liquid Hand Sanisers (not gel) and toilet seat cleaners require a spray pump
If unsure please call our customer services team on [phone] who can advise.

Installaon and User Guide
Manual Soaps and Hand Saniser Dispensers
INSTALLATION HEIGHT GUIDE
Accessible Washrooms:
Above Counter:
General Washrooms:
