jbc DPM-A User manual

INSTRUCTION MANUAL
Solder Paste Hand Dispenser
Ref. DPM-A

2
Packing List
The following items are included:
Solder Paste Hand Dispenser ..................................................................................................... 1 unit
Ref. DPM-A

Solder Paste Hand Dispenser
Ref. DPM-A
INSTRUCTION MANUAL
www.jbctools.com
www.jbctools.com
3
Manual ................................................................................................................................................ 1 unit
Ref. 0023415
3cc Syringe Barrel ........................................................................................................................... 2 units
Ref. SB03CC

4
How to use
4. Place the needle in the syringe barrel.
1. DPM use 3CC syringes. Ask your solder
paste supplier for this format or fill in the
syringe barrel with solder past.
2. Place the piston into the syringe barrel.
3. Insert the plunger rod in the syringe barrel to
eliminate air and press the solder past.

www.jbctools.com
5
5. Lift the toggle
7. Lower the toggle
6. Insert the plunger with the syringe in the
housing, fit the syringe fins in
8. Operate the lever until the paste comes out

6.5
32
STYLE Ref. COLOR SOLDER
PASTE GAUGE ØID (mm) ØID (in) ØOD (mm) ØOD (in) LENGTH (mm)
LENGTH
(in)
TOTAL
LENGTH
(mm)
TOTAL
LENGTH
(in)
QTY
Stainless
Steel
Needles
ND18S6 Green Type 2 18 0.84 0.050 1.27 0.033 6.5 0.25 24 0.25 10
ND20S6 Pink Typ e 3 20 0.61 0.036 0.90 0.024 6.5 0.25 24 0.25 10
ND21S6 Purple Type 3 21 0.51 0.032 0.82 0.020 6.5 0.25 24 0.25 10
ND22S6 Blue Ty pe 3 22 0.41 0.028 0.72 0.016 6.5 0.25 24 0.25 10
ND23S6 Orange Type 3 23 0.31 0.025 0.63 0.013 6.5 0.25 24 0.25 10
ND25S6 Plan Red Type 4 25 0.25 0.020 0.50 0.010 6.5 0.25 24 0.25 10
ND27S6 Clear Type 5 27 0.2 0.016 0.40 0.008 6.5 0.25 24 0.25 10
ND30S6 Lavender Type 6 30 0.15 0.012 0.31 0.006 6.5 0.25 24 0.25 10
STYLE Ref. COLOR SOLDER
PASTE GAUGE ØID (mm) ØID (in) ØOD (mm) ØOD (in) LENGTH (mm)
LENGTH
(in)
TOTAL
LENGTH
(mm)
TOTAL
LENGTH
(in)
QTY
Tapered
Tips
ND18P Green Type 2 18 0.84 0.033 1.27 0.050 - - 32 1.26 10
ND20P Pink Type 3 20 0.64 0.024 1.20 0.048 - - 32 1.26 10
ND22P Blue Type 3 22 0.41 0.016 0.72 0.028 - - 32 1.26 10
ND25P Red Type 4 25 0.25 0.010 0.50 0.020 - - 32 1.26 10
ND27P Clear Typ e 5 27 0.2 0.008 0.40 0.016 - - 32 1.26 10
6
Nozzles Range
STAINLESS STEEL NEEDLES
TAPERED TIPS
More Info at www.jbctools.com

STYLE Ref. COLOR SOLDER
PASTE GAUGE ØID (mm) ØID (in) ØOD (mm) ØOD (in) LENGTH (mm)
LENGTH
(in)
TOTAL
LENGTH
(mm)
TOTAL
LENGTH
(in)
QTY
Stainless
Steel
Needles
ND18S6 Green Type 2 18 0.84 0.050 1.27 0.033 6.5 0.25 24 0.25 10
ND20S6 Pink Typ e 3 20 0.61 0.036 0.90 0.024 6.5 0.25 24 0.25 10
ND21S6 Purple Type 3 21 0.51 0.032 0.82 0.020 6.5 0.25 24 0.25 10
ND22S6 Blue Ty pe 3 22 0.41 0.028 0.72 0.016 6.5 0.25 24 0.25 10
ND23S6 Orange Type 3 23 0.31 0.025 0.63 0.013 6.5 0.25 24 0.25 10
ND25S6 Plan Red Type 4 25 0.25 0.020 0.50 0.010 6.5 0.25 24 0.25 10
ND27S6 Clear Type 5 27 0.2 0.016 0.40 0.008 6.5 0.25 24 0.25 10
ND30S6 Lavender Type 6 30 0.15 0.012 0.31 0.006 6.5 0.25 24 0.25 10
STYLE Ref. COLOR SOLDER
PASTE GAUGE ØID (mm) ØID (in) ØOD (mm) ØOD (in) LENGTH (mm)
LENGTH
(in)
TOTAL
LENGTH
(mm)
TOTAL
LENGTH
(in)
QTY
Tapered
Tips
ND18P Green Type 2 18 0.84 0.033 1.27 0.050 - - 32 1.26 10
ND20P Pink Type 3 20 0.64 0.024 1.20 0.048 - - 32 1.26 10
ND22P Blue Type 3 22 0.41 0.016 0.72 0.028 - - 32 1.26 10
ND25P Red Type 4 25 0.25 0.010 0.50 0.020 - - 32 1.26 10
ND27P Clear Typ e 5 27 0.2 0.008 0.40 0.016 - - 32 1.26 10
www.jbctools.com
7

Specifications
0023415-0521
- Dimensions: 130x66x16mm / 0.05kg
5.12x 2.6 0 x 0.6 3 i n / 0.11l b
- Package Dimensions: 155x55x45mm / 0.007kg
6 .10 x 2.17 x1.7 7i n / 0.16 l b
Complies with CE standards
ESD Safe
This product should not be thrown in the garbage.
In accordance with the European directive 2012/19/EU, electronic equipment at the end of its life must
be collected and returned to an authorized recycling facility.
Warranty
JBC’s 2 year warranty covers this equipment against
all manufacturing defects, including the replacement
of defective parts and labour.
Warranty does not cover product wear or misuse.
In order for the warranty to be valid, equipment must
be returned, postage paid, to the dealer where it was
purchased.
