Dudley Classic 1L Auto Soap Dispenser 50310 User manual

Installaon and User Guide
Automac Soap Dispensers
Applicable to product groups:
50310 Classic 1L Auto Soap Dispenser
Version 1.1

Thank you for choosing a Dudley Industries Soap Dispenser.
This dispenser is designed and manufactured by our team at our facilies based in Lancashire, UK.
All our products are designed to withstand constant use in busy environments. Our Automac
Soap Dispensers are supported by a 10 year warranty provided they are installed and maintained
correctly and not subject to any vandalism. Products must not be modied in any way as this will
invalidate the warranty.
Please follow these instrucons for safe installaon and pass this document to the user for safe
keeping.
Installaon and User Guide
Automac Soap Dispensers
Safety Informaon
Please read these instrucons thoroughly before installaon and retain for future reference.
Remove all packaging and check contents for any damage prior to commencing installaon. If there
are any issues please contact our Customer Services Team on [phone].
Before commencing installaon and drilling into walls check that there are no hidden electrical
cables or water pipes.
When using power tools always ensure you wear the correct PPE and operate following the
manufacturer’s instrucons.
This dispenser should only be used for the type of soap specied, check outer box for details.
Page 2

Installaon and User Guide
Automac Soap Dispensers
Page 3
Product Features
Brushed dispensers are manufactured from Stainless Steel.
White units are constructed from steel and powder coated.
Internal mechanisms are constructed from mixed materials.
All units (see product groups) are bulk ll/top up and suitable for your choice of formulaon but
always ensure the correct type is used i.e. liquid, foam or hand saniser.
All units are lockable to protect the contents and spare keys are available from Customer Services.
Automac soap dispensers are operated by placing a hand underneath the unit which is detected by
the infrared technology which then triggers the pump.
Fixing kits are included with all units.
Installaon
Following the guide for xing; measure and mark the posion of the xing holes on the wall
ensuring that they are level.
Drill holes in the wall using the appropriate size drill bit. Drill to the depth of the wall plug. If the
surface is led, drill into the grout lines whenever possible. Insert the wall plugs supplied.
Open the dispenser, remove the reservoir if necessary and posion the dispenser xing holes over
the wall holes made.
Insert the screws provided and ghten to secure the dispenser. We always recommend that you use
all xing holes available for strength and security.
Insert the baeries ensuring the correct posioning.
Replace any internal mechanisms and close the cover.
Trigger the infrared sensor mulple mes and listen for the mechanism to work to ensure operaon
before lling with consumable.
Example:
67.9
77.4
192.9
202.4
227.9
235.4
52.4
72.5
80
105
87.5
50
108.6
72.5
90

Installaon and User Guide
Automac Soap Dispensers
Page 4
Filling and relling
Unlock the cover and hinge open.
Li the lid of the reservoir and ll with your choice of consumable ensuring it is correct for the type
of pump supplied i.e. liquid, foam or hand saniser soluons.
Replace reservoir lid and close the cover ensuring the lock is engaged.
If new or empty, prime the dispenser by triggering the infrared sensor mulple mes to ensure the
formulaon reaches the nozzle ready for dispensing.
General Maintenance & Cleaning
Brushed Stainless Steel Units:
Clean with warm water and a so cloth, wipe in the same direcon as the brushed grain. Dry
thoroughly. DO NOT use soap, chemical cleaning detergents or abrasive cleaners.
Powder Coated Units:
Clean with a mild detergent and so cloth. Ensure any detergent is fully rinsed o prior to drying
thoroughly.
Fing and replacing the baeries
The unit uses 4 x C Cell Alkaline Baeries, these are housed in the pump
secon of the dispenser.
Remove the reservoir and li the pump out.
Remove the back cover to gain access to the baery compartment. Fit
the baeries as per the image ensuring they are placed with posive
and negave ends in the correct place.

Installaon and User Guide
Automac Soap Dispensers
Page 5
Troubleshoong
Soap not dispensing:
Check the reservoir to ensure soap is available.
Check that the baeries are operaonal.
Clean the nozzle with a so warm cloth. (NEVER INSERT ANYTHING INTO THE NOZZLE)
Fill the reservoir with a small amount of warm water and trigger the pump to try and clear
any soap build up.
Pump motor not acvang
Firstly replace the baeries.
Ensure the sensor is clean and nothing is obstrucng it’s range.
Soap is dispensed randomly without being triggered
Somemes reecve surfaces can trigger the sensor, for example highly polished counter
tops or mirrors. Also high visibility clothing can trigger the sensor.
Lost Key:
Spare keys can be purchased from our Customer Services Team call [phone]
End of Life Disposal
All Dudley Industries units are manufactured to ensure longevity and a reliable life span. When a
dispenser has reached its end of life it should be disposed of in a safe manner. Most components
can be re-cycled in accordance with your local authority waste management policy.
Baery Disposal
Baeries should not be disposed of in general waste. Please contact your local authority or waste
contractor to ask about recycling opons and disposal.

Installaon and User Guide
Automac Soap Dispensers
INSTALLATION HEIGHT GUIDE
Accessible Washrooms:
Above Counter:
General Washrooms:
