Duerkopp Adler 251-140040 User manual

1.Arm bed components 1.
ᴎ໇䚼ӊ
ᑣো ӊো Description ৡ⿄ Qty
1 0251 GS0548 Bed screw stud ᑩᑻᬃ󰵦 4
2 0251 GK239 Side plate ৢにᵓ 1
3 0251 GR3340 Gasket ৢにᵓൿ 1
4 0251 GS053 Screw 3/16-28 L=9 ৢにᵓ㶎䩝3/16-28 L=9 8
5 0251 GR6245 Face plate arm 䴶ᵓ 1
6 0251 GR6162 Gasket 䴶ᵓൿ 1
7 0251 GS5198 Scew 3/16-28 L=12 䴶ᵓ㶎䩝3/16-28 L=12 3
8 0251 GR6163 Rubber plug 䴶ᵓ䇗㡖㶎ᄨา 2
9 0251 GR6164 Rubber plug 䩜ᴚ᳆ᶘ㶎ᄨา 1
10 0251 GR6165 Rubber plug ᣥ㒓䖲ᴚ䫔㶎ᄨา 1
11 0251 GR6168 Rubber plug Ꮉ㡎ᄨา 1
12 0251 GR6166 Rubber plug 䗕᭭䇗㡖㶎ᄨา 2
13 0251 GR6167 Rubber plug ϟ䕈Ⳇᄨา 1
14 0251 GR5791 Scale base plate 󰵼ሎᑻ 1
15 0251 GS5054 Scew 11/64-40 L=5 󰵼ሎᑻ㶎䩝11/64-40 L=5 2
16 0251 GR6250V17 Bobbin winder asm 㒩㒓఼˄䚼ӊ˅ 1
17 0251 GRD1172 Bobbin winder cushion washer 㒩㒓఼ᆚᇕൿ 1
18 0251 GR6204V5 Thread tension comp 㒩㒓ᓴ࡯䚼ӊ 1
19 0251 GR6205V2 Thread tension shaft comp 㒩㒓ᓴ࡯䕈䚼ӊ (1)
20 0251 GZ1152 Thread tension shaft 㒩㒓ᓴ࡯䕈 ((1))
21 0251 GR5013 Threading plate 㒩㒓ᓴ࡯䖛㒓ᵓ ((1))
22 0251 GL1040 Nut 㒩㒓ᓴ࡯ᮟ䪂㶎↡ (1)
23 0251 GW1107 Spring 㒩㒓ᓴ࡯ᔍㇻ (1)
24 0251 GR6284 Thread tension disk 㒩㒓఼ᓴ࡯།㒓Ⲭ (2)
25 0251 GS04 Screw 15/64-28 L=10.5 㒩㒓ᓴ࡯఼㋻೎㶎䩝15/64-28 L=10.5 1
26 0251 GS5187 Screw 11/64-40 L=6 㒩㒓఼ᅝ㺙㶎䩝 11/64-40 L=6 3
27 0251 GW1106 Spring 㒩㒓䕈ᑻᔍㇻ (1)
28 0251 GW1104 Spring ࡼ԰ᵓ໡ԡᔍㇻ (1)
29 0251 GR6257 Bobbin Supper ẁᖗᑻ (1)
30 0251 GR6261 O-ring 㒩㒓䕂‵㛊೜ (1)
31 0251 GR6201 Thread trimmer ࡆ㒓ߔ 1
32 0251 GS5188 Screw 9/64-40 L=4 ࡆ㒓ߔ㶎䩝 9/64-40 L=4 2
33 0251 GW1105 Spring 㒩㒓䕈ᔍㇻ (1)
ˉ2ˉ

-3-
2.Main shaft & thread take-up components

2.Main shaft & thread take-up components 2.
Ϟ䕈 ᣥ㒓䚼ӊ
ᑣো ӊো Description ৡ⿄ Qty
1 0251 GP1030 Hand wheel Ϟ䕂 1
2 0251 GS03 Screw 15/64-28 L=15 Ϟ䕂㶎䩝15/64-28 L=15 2
3 0251 GZ431 Main shaft Ϟ䕈 1
4 0251 GR6005 Oil seal Ϟ䕈⊍ᇕ 1
5 0251 GO1137 Main shaft bushing, rear Ϟ䕈ৢ䕈༫ 1
6 0251 GR1469 Thrust collar asm. Ϟ䕈ᣵ೜ 1
7 0251 GS39 Screw 1/4-40 L=6 Ϟ䕈ᣵ೜㶎䩝1/4-40 L=6 2
8 0251 GO1138 Bushing , intermediats Ϟ䕈Ё䕈༫ 1
9 0251 GS0549 Screw 15/64 L=9 Ϟ䕈Ё䕈༫㶎䩝 15/64 L=9 1
10 0251 GO1139 Main shaft bushing, fornt Ϟ䕈ࠡ䕈༫ 1
11 0251 GR1470 Oil seal ᳆ᶘ⊍䞣䰤ࠊ↵ 1
12 0251 GX334 Oil amount adjusting pin asm. ᳆ᶘ⊍䞣䇗㡖䫔 1
13 0251 GO269 Rubber pushing ᳆ᶘ⊍䞣䇗㡖䫔༫ 1
14 0251 GR1471 Rubber ring ᳆ᶘ⊍䞣䇗㡖䫔Oᔶ೜ 1
15 0251 GH1123 Counterweight 䩜ᴚ᳆ᶘ 1
16 0251 GS06 Screw 9/32-28 L=16 䩜ᴚ᳆ᶘᅮԡ㶎䩝9/32-28 L=16 1
17 0251 GR1472 Rubber ring ᅮԡ㶎䩝Oᔶ೜ 1
18 0251 GS0550 Screw 9/32-28 L=16 䩜ᴚ᳆ᶘ㋻೎㶎䩝9/32-28 L=16 1
19 0251 GH563 Needle bar crank asm. ᣥ㒓᳆ᶘ䚼ӊ (1)
20 0251 GS39 Screw 1/4-40 L=6 ᣥ㒓᳆ᶘᅮԡ㶎䩝 1/4-40 L=6 2
21 0251 GH566 Thread take-up crank ᣥ㒓䖲ᴚ (1)
22 0251 GR3349 Rubber ᣥ㒓ᴚ䰆⊍༫ (1)
23 0251 GO270 Needle bearing ᣥ㒓ᴚ⒮䩜䕈ᡓ (1)
24 0251 GX1129 Thread take-up crank shaft ᣥ㒓䖲ᴚ䫔 1
25 0251 GR3350 Oil wick ᣥ㒓䖲ᴚ䫔⊍㒓 1
26 0251 GS04 Screw 15/64-28 L=10.5 ᣥ㒓䖲ᴚ䫔㶎䩝15/64-28 L=10.5 1
27 0251 GS09 Screw (left twist) 9/64-40 L=4.8 ᣥ㒓᳆ᶘᎺᮟ㶎䩝9/64-40 L=4.8 (1)
28 0251 GK1050 Thread take-up lever cover ᣥ㒓ᴚᡸ㔽 1
29 0251 GS5186 Screw 3/16-28 L=6 ᣥ㒓ᴚᡸ㔽㶎䩝3/16-28 L=6 1
30 0251 GH564V4 Thread take-up lever asm. ᣥ㒓ᴚߚ䚼ӊ (1)
31 0251 GP1024 Bobbin winder driving wheel 㒩㒓偅ࡼ䕂 1
32 0251 GS0155 Screw 15/64-28 L=9 㒩㒓偅ࡼ䕂㶎䩝15/64-28 L=9 2
33 0251 GH1131V8 Thread take-up asm. ᣥ㒓ᴚ䚼ӊ 1
34 0251 GH334 Needle bar crank rod 䩜ᴚ䖲ᴚ (1)
35 0251 GO270 Needle bearing 䩜ᴚ䖲ᴚ⒮䩜䕈ᡓ (1)
ˉ4ˉ

ো
3.Needle bar & thread tension components 3.
䩜ᴚǃ།㒓䚼ӊ
ᑣӊো Description ৡ⿄ Qty
1 0251 GR1478 Needle bar connection asm 䩜ᴚ䖲᥹󰵦 1
2 0251 GS042 Screw 9/64-40 L=7.5 䩜ᴚ䖲᥹󰵦㶎䩝 9/64-40 L=7.5 1
3 0251 GU168 Slide block 䩜ᴚ䖲᥹󰵦⒥ഫ 1
4 0251 GO1092 Needle bar bushing,upper 䩜ᴚϞ䕈༫ 1
5 0251 GR6174 Cap 䩜ᴚϞ䕈༫ᄨา 1
6 0251 GO1093 Needle bar bushing,lower 䩜ᴚϟ䕈༫ 1
7 0251 GR3351 Needle bar thread guide 䩜ᴚϟ䕈༫㒓䩽 1
8* 0251 GZ1150 Needle bar(DBX1) 䩜ᴚ(DBX1) 1
8** 0251 GZ1174 Needle bar(134 ) 䩜ᴚ(134 ) 1
9 0251 GR3352 Needle bar thread guide 䩜ᴚ㒓䩽 1
10 0251 GS071 Screw 1/8-44 L=4.5 ᬃ䩜㶎䩝1/8-44 L=4.5 1
11* 0251 GV15 Needle (DBX1# 14) ᴎ䩜 (DBX1# 14) 1
11*
*
0251 GV1006 Needle(134 Nm90) ᴎ䩜(134 Nm90) 1
12 0251 GR6175 Two-hole thread eyelet Ѡⴐ㒓䩽 1
13 0251 GS5186 Screw 3/16-28 L=6 Ѡⴐ㒓䩽㶎䩝3/16-28 L=6 1
14 0251 GR3354 Frame thread guide , right ে㒓䩽 1
15 0251 GS0552 Screw 11/64-40 L=6 ে㒓䩽㶎䩝 11/64-40 L=6 1
16 0251 GR3355 Frame thread guide,left Ꮊ㒓䩽 1
17 0251 GS0552 Screw 11/64-40 L=6 Ꮊ㒓䩽㶎䩝 11/64-40 L=6 1
18 0251 GR1635 Tension post socket ᣥ㒓ㇻ䇗㡖ᑻ (1)
19 0251 GW1109 Take-up spring ᣥ㒓ㇻ (1)
20 0251 GS015 Screw །㒓㶎䩝 (1)
21 0251 GS016 Set screw 9/64-40 L=5.5 །㒓㶎䩝㋻೎㶎䩝9/64-40 L=5.5 (1)
22 0251 GX567 Thread release pin ᵒ㒓䩝 1
23 0251 GR1488 Tension disc །㒓ᵓ (2)
24 0251 GR1489 Tension disc holder ᵒ㒓ᵓ (1)
25 0251 GW1110 Tension spring །㒓ㇻ (1)
26 0251 GR1490 Tension disc stopper །㒓ࠊࡼᵓ (1)
27 0251 GL1037 Tension nut །㒓㶎↡ (1)
28 0251 GS48 Screw 15/64-28 L=7 །㒓఼㶎䩝15/64-28 L=7 1
29 0251 GX568 Tension release supporting pin ᵒ㒓䕙䩝 1
30 0251 GR1717 Snap ring ᵒ㒓䕙䩝ᣵ೜ 1
31 0251 GR3357 Washer plate ᵒ㒓䕙䩝ൿ⠛ 1
32 0251 GW432 Tension release supporting spring ᵒ㒓䕙䩝ᔍㇻ 1
33 0251 GR6179 Needle thread guide ᇐ㒓ᵓ 1
34 0251 GS5186 Tension disc 3/16-28 L=6 ᇐ㒓ᵓ㶎䩝 3/16-28 L=6 2
35 0251 GR6298V10 Thread tension asm. །㒓఼䚼ӊ 1
* FOR ASIA 䫔ᕔѮ⌆
** FOR EUROPE 䫔ᕔ󱂜⌆
ˉ6ˉ

4.Presser bar components 4.
᭭䚼ӊ
ᑣো ӊ ো Description ৡ⿄ Qty
1 0251 GS0553 Presser spring regulator 䇗㶎䩝 1
2 0251 GL0114 Nut 1/2-28 䇗㶎↡ 1/2-28 1
3 0251 GR1494 Presser guide bar 䇗ᇐᴚ 1
4 0251 GW253 Presser spring 䇗ㇻ 1
5 0251 GZ275 Presser bar ᴚ 1
6 0251 GR3358 Needle bar guide bracket ᴚᇐᶊ 1
7 0251 GS033 Screw 1/4-40 L=8 ᴚᇐᶊ㶎䩝1/4-40 L=8 1
8 0251 GR3359 Presser bar thread guide 㓧㒓䇗㡖࣒ 1
9 0251 GS0100 Screw 9/64-40 L=8.5 㓧㒓䇗㡖࣒㶎䩝9/64-40 L=8.5 2
10 0251 GO1135 Presser bar bushing , lower ᴚ㹀༫ 1
11 0251 GM1077V5 Presser foot asm. ⌏㛮䚼ӊ 1
12 0251 GS020 Screw 9/64-40 L=10.5 ⌏㛮㶎䩝 9/64-40 L=10.5 1
13 0251 GR3360 Hand lifter 㛮ᡇ᠟ 1
14 0251 GS0554 Screw 9/64-40 L=8.7 㛮ᡇ᠟㶎䩝 9/64-40 L=8.7 1
15 0251 GR3361V2 Hand lifter cam asm. 㛮ᡇ᠟ߌ䕂䚼ӊ 1
16 0251 GR1503 Rubber ring 㛮ᡇ᠟䕈Oᔶ೜ 1
17 0251 GR3363 Lifting lever 㛮䰡ᵓ 1
18 0251 GR3364V3 Hand lifter link asm. ᢀ㛮ࠡᴴᴚ䚼ӊ 1
19 0251 GS0161 Link shaft ࠡᴴᴚ㶎㒍䫔 2
20 0251 GR1510 Snap ring 㶎㒍䫔ᓔষᣵ೜ 3
21 0251 GR3366 Lifting lever ring 䰡ᵓ䖲᥹⡍ࠊᓔষᣵ೜ 1
22 0251 GR3367 Tension release plate ᵒ㒓乊ᵓ 1
23 0251 GS0162 Tension release shaft ᵒ㒓乊ᵓ㶎㒍䫔 1
24 0251 GR1510 Snap ring 㶎㒍䫔ᓔষᣵ೜ 2
25 0251 GW433 Tension release return spring ᵒ㒓乊ᵓ໡ԡㇻ 1
26 0251 GR3368 Lifting lever connecting rod ᢀ㛮ᢝᴚ 1
27 0251 GR1510 Snap ring ᢝᴚᓔষᣵ೜ 1
28 0251 GR3369 Lifting lever link ᢀ㛮ৢᴴᴚ 1
29 0251 GS0557 Hinge screw ৢᴴᴚ䕈ԡ㶎䩝 1
30 0251 GS0558 Hinge screw ᢀ㛮ᢝᴚ㶎䩝 1
31 0251 GR3370 Connecting rod vertical ᢀ㛮乊ᴚ 1
32 0251 GR6242 Finger guard ֱ䩜ᶊ (1)
33 0251 GR6180 Thread trimmer ߛ㒓ߔ 1
34 0251 GK1051 Oil protecting bushing ᴚ䰆⊍༫ 1
35 0251 GR2035 Gasket 㶎㒍䫔ൿ೜ 1
36 0251 GM1084V4 Presser foot branch asm. ⌏㛮ߚ䚼ӊ (1)
ˉ8ˉ

-9-
5.Hook driving shaft components

n
5.Hook driving shaft components 5.
࣒㒓䚼ӊ
ᑣো ӊো Description ৡ⿄ Qty
1* 0251 GN161 Hook asm ᮟẁ 1
1** 0251 GN1033 Hook asm ᮟẁ 1
2* 0251 GN162 Bobbin case asm ẁᄤ 1
2** 0251 GN1034 Bobbin case asm ẁᄤ (1)
3 0251 GN163 Bobbin ẁᖗ 1
4 0251 GS029 Screw SM4.46×40 L=4.7 ᮟẁ㋻೎㶎䩝SM4.46×40 L=4.7 2
5 0251 GR3371 Positioning finger ᮟẁᅮԡ䩽 1
6 0251 GS030 Screw 11/64-40 L=9.5 ᮟẁᅮԡ䩽㶎䩝11/64-40 L=9.5 1
7 0251 GZ434 Hook driving shaft ϟ䕈 1
8 0251 GS031 Oil seal screw ϟ䕈䰤⊍㶎䩝 1
9 0251 GR1515 Oil wick ϟ䕈䰤⊍㢃 1
10 0251 GO1148 Lower shaft bushing asm. Fro ϟ䕈ࠡ䕈༫䚼ӊ 1
11 0251 GS0559 Screw 15/64-28 L=4. ϟ䕈ࠡ䕈༫㶎䩝 15/64-28 L=4. 1
12 0251 GO470 Bushing , rear ϟ䕈ৢ䕈༫ 1
13 0251 GS053 Screw 3/16-28 L=9 ϟ䕈ৢ䕈༫㶎䩝3/16-28 L=9 2
14 0251 GR1519 Thrust collar ϟ䕈ᣵ೜ 1
15 0251 GS082 Screw 11/64-40 L=4.8 ϟ䕈ᣵ೜㶎䩝11/64-40 L=4.8 8
16 0251 GC165 Lower shaft gear,Small ϟ䕈Ӳ啓䕂˄ᇣ˅ 1
17 0251 GS033 Screw 1/4-40 L=8 Ӳ啓䕂㶎䩝 1/4-40 L=8 1
18 0251 GC166 Upright shaft gear, Large オ䕈ϟӲ啓䕂˄໻˅ 1
19 0251 GO471 Upright shaft bushing, lower オ䕈ϟ䕈༫ 1
20 0251 GO472 Upright shaft bushing, upper オ䕈Ϟ䕈༫ 1
21 0251 GS053 Screw 12/64-28 L=9 オ䕈Ϟ䕈༫㶎䩝12/64-28 L=9 1
22 0251 GZ435 Upright shaft オ䕈 1
23 0251 GC167 Upright shaft gear, Small オ䕈ϞӲ啓䕂˄ᇣ˅ 1
24 0251 GC168 Main shaft gear,Large Ϟ䕈Ӳ啓䕂˄໻˅ 1
25 0251 GR6238 Oil seal ϟ䕈⊍ᇕ 1
26 0251 GR6181 O-ring ϟ䕈䰤⊍㶎䩝Oᔶ೜ 1
* FOR ASIA 䫔ᕔѮ⌆
** FOR EUROPE 䫔ᕔ󱂜⌆
ˉ10ˉ

-11-
6.Feed mechanism components

6.Feed mechanism components 6.
䗕᭭ߚ䚼ӊ
ᑣো ӊো Description ৡ⿄ Qty
10251 GR6247V6 Feed drive eccentric cam asm. 䗕᭭أᖗ䕂䚼ӊ 1
20251 GT198 Feed drive eccentric cam 䗕᭭أᖗ䕂
(
1
)
30251 GS034 Screw 1/4-40 L=11 䗕᭭أᖗ䕂㶎䩝 1/4-40 L=11
(
2
)
40251 GR3373 Thrust collar 䗕᭭أᖗ䕂Ⲫᵓ
(
1
)
50251 GS011 Screw 9/64-40 L=6 أᖗ䕂Ⲫᵓ㶎䩝 9/64-40 L=6
(
2
)
60251 GH568 Rocker shaft connectin
g
rod 䗕᭭䖲ᴚ 1
70251 GX1029 Walkin
g
foot
p
in 䗕᭭䖲ᴚ䫔 1
80251 GS0560 Screw 9/64-40 L=6 䗕᭭䖲ᴚ䫔㶎䩝 9/64-40 L=6 1
90251 GR5254 Walkin
g
foot link 䗕᭭䭓ᨚࡼᵓ 2
10 0251 GR5255 Connectin
g
lin
k
䗕᭭ⷁᨚࡼᵓ 2
11 0251 GX1030 Walkin
g
foot
p
in ⷁᨚࡼᵓ䖲᥹䫔 2
12 0251 GS0560 Screw 9/64-40 L=6 䖲᥹䫔㶎䩝 9/64-40 L=6 2
13 0251 GR3376V2 Walkin
g
foot ad
j
ustin
g
link 䗕᭭ᨚࡼᵓᑻ䚼ӊ 1
14 0251 GX573
A
d
j
ustin
g
link fulcrum shaft 䗕᭭ᨚࡼᵓᑻᎺ䫔 1
15 0251 GS48 Screw 15/64-28 L=7 Ꮊ䫔㶎䩝15/64-28 L=7 1
16 0251 GX573
Aj
ustin
g
link fulcrum shaft 䗕᭭ᨚࡼᵓᑻে䫔 1
17 0251 GS48 Screw 15/64-28 L=7 ে䫔㶎䩝15/64-28 L=7 1
18 0251 GH569 Feed rocker shaft crank asm 䗕᭭᳆ᶘ 1
19 0251 GX1031 Walkin
g
foot
p
in 䗕᭭᳆ᶘ䫔 1
20 0251 GS0560 Screw 9/64-40 L=6 ᳆ᶘ䫔㶎䩝9/64-40 L=6 1
21 0251 GS0561 Screw 3/16-28 L=14 䗕᭭᳆ᶘ㶎䩝 3/16-28 L=14 1
22 0251 GZ436 Feed rocker shaft 䗕᭭䕈 1
23 0251 GR1524 Retainin
g
rin
g
䗕᭭䕈䕈⫼ᣵ೜ 1
24 0251 GR1469 Thrust collar asm. 䗕᭭䕈ᣵ೜ 1
25 0251 GS39 Screw rocker shaft bushin
g
1/4-40 L=6 䗕᭭䕈ᣵ೜㶎䩝1/4-40 L=6 2
26 0251 GO473 Feed rocker shaft boshin
g
䗕᭭䕈ࠡ䕈༫ 1
27 0251 GR6283/8 Feed do
g
asm. 䗕᭭⠭ᇣ㒘ӊ 1
28 0251 GR3378 Oil wick 䗕᭭䕈⊍㒓
(
1
)
29 0251 GR2425 Feed rocker asm. ⠭ᶊᑻ
(
1
)
30 0251 GS69 Scerw 3/16-28 L=14 ⠭ᶊᑻ㶎䩝3/16-28 L=14
(
1
)
31 0251 GR1528 Washer ⠭ᶊᑻ㶎䩝ൿ೜
(
1
)
32 0251 GR6003V4 Feed bar asm ⠭ᶊ䚼ӊ
(
1
)
33 0251 GX418 Feed bar shaft ⠭ᶊ䫔
(
1
)
34 0251 GS092 Screw 11/64-40 L=7 ⠭ᶊ䫔㶎䩝 11/64-40 L=7
(
1
)
35 0251 GM1086 Feed do
g
䗕᭭⠭ 1
36 0251 GS072 Screw 1/8-44 L=6 䗕᭭⠭㶎䩝1/8-44 L=6 2
37 0251 GM1068 Throat
p
late 䩜ᵓ 1
38 0251 GS044 Screw 11/64-40 L=6.8 䩜ᵓ㶎䩝 11/64-40 L=6.8 2
39 0251 GM1073V3 Bed slide asm. ᥼ᵓ䚼ӊ 1
40 0251 GM204 Slide
p
late ᥼ᵓ
(
1
)
41 0251 GW1096 Bed slide s
p
rin
g
᥼ᵓㇻ
(
1
)
42 0251 GS045 Screw 3/32-56 L=1.9 ᥼ᵓㇻ㶎䩝 3/32-56 L=1.9
(
2
)
43 0251 GH570 Drivin
g
shaft crank asm.front ᢀ⠭ঝᔶ᳆ᶘ 1
44 0251 GS037 Screw 11/64-40 L=10.5 ᢀ⠭ঝᔶ᳆ᶘ㶎䩝11/64-40 L=10.5 1
45 0251 GZ437 Liftin
g
shaft ᢀ⠭䕈 1
46 0251 GR1524 Retainin
g
rin
g
ᢀ⠭䕈䕈⫼ᣵ೜ 1
47 0251 GO473 Feed rocker shaft bushin
g
ᢀ⠭䕈ࠡ䕈༫ 1
48 0251 GH571 Rear crank asm. ᢀ⠭ৢ᳆ᶘ 1
49 0251 GS049 Screw 3/16-28 L=12 ᢀ⠭ৢ᳆ᶘ㶎䩝3/16-28 L=12 1
50 0251 GH572 Connectin
g
rod ᢀ⠭䖲ᴚ 1
51 0251 GS0562 Hin
g
e screw ᢀ⠭䖲ᴚ䕈ԡ㶎䩝 1
52 0251 GL7 Nut 9/32-28 ᢀ⠭䖲ᴚ䕈ԡ㶎↡ 9/32-28 1
53 0251 GR1535 Sna
p
rin
g
ᢀ⠭䖲ᴚ䕈⫼ᣵ೜ 1
54 0251 GR1469 Thrust collar asm. ᢀ⠭䕈ᣵ೜ 1
55 0251 GS39 Screw 1/4-40 L=6 ᢀ⠭䕈ᣵ೜㶎䩝 1/4-40 L=6 2
56 0251 GR6182 Oil
p
rotectin
g
rubbe
r
䗕᭭䕈䰆⊍༫ 2
57 0251 GRD1087 Washer ⠭ᶊᑻൿ೜
(
1
)
ˉ12ˉ

7.Feed regulating components 7.
䗕᭭䇗㡖䚼ӊ
ᑣো ӊ ো Description ৡ⿄ Qty
10251 GR6183 Feed dial 䗕᭭䎱ᮟ䪂 1
20251 GS0563 Screw 3/16-28 L=18 䗕᭭䎱ᮟ䪂㶎䩝 3/16-28 L=18 1
30251 GS0564 Feed regulator screw 䗕᭭䇗㡖㶎󰵦 1
40251 GR3383 Rubber ring 䗕᭭䇗㡖㶎󰵦Oൟ೜ 1
50251 GX576 Pin 䗕᭭䎱䫕ড়䫔 1
60251 GW257 Spring 䗕᭭䎱䫕ড়ㇻ 1
70251 GR3384 Feed regulator 䗕᭭䇗㡖఼ 1
80251 GO474 Feed regulator bushing 䗕᭭䇗㡖఼䕈༫ 1
90251 GS0565 Screw 3/16-28 L=7 䗕᭭䇗㡖఼䕈ッ㶎䩝3/16-28 L=7 1
10 0251 GX577 Feed regulator pin צ䗕᭭䖲ᴚ䫔 1
11 0251 GS011 Screw 9/64-40 L=6 䖲ᴚ䫔㶎䩝 9/64-40 L=6 2
12 0251 GH1101 Feed regulator connecting rod צ䗕᭭䖲ᴚ 1
13 0251 GR1510 Snap ring צ䗕᭭䖲ᴚᣵ೜ 2
14 0251 GZ1027 Feed reverse shaft צ䗕᭭䕈 1
15 0251 GR3385 Rubber ring צ䗕᭭䕈Oൟ೜ 1
16 0251 GO1094 Feed reverse shaft boshing צ䗕᭭䕈䕈༫ 1
17 0251 GR6185 Reverse feed control lever צ䗕᭭ᡇ᠟ 1
18 0251 GS050 Screw 1/4-40 L=10 צ䗕᭭ᡇ᠟ᅮԡ㶎䩝 1/4-40 L=10 1
19 0251 GS033 Screw 1/4-40 L=8 צ䗕᭭ᡇ᠟㶎䩝1/4-40 L=8 1
20 0251 GH574V2 Feed reverse arm asm. צ䗕᭭᳆ᶘ䚼ӊ 1
21 0251 GS0566 Feed reverse arm screw צ䗕᭭᳆ᶘ㶎䩝 1
22 0251 GW435 Feed reverse spring צ䗕᭭ᢝㇻ 1
23 0251 GR3387 Feed spring hook ᢝㇻ೎ᅮᡇ 1
24 0251 GR3388 Adjusting link spring guide ᨚࡼᵓᑻ໡ԡᵓ 1
25 0251 GS0567 Screw 11/64-40 L=5 ໡ԡᵓ㶎䩝 11/64-40 L=5 2
26 0251 GW436 Spring ᨚࡼᵓᑻ໡ԡㇻ 1
27 0251 GR6186 Reverse feed lever rubber צ䗕᭭ᡇ᠟ൿ 1
ˉ14ˉ

8.Lubrication components 8.
⍺⒥䚼ӊ
ᑣো ӊো Description ৡ⿄ Qty
1 0251 GR3389V12 Lubrication oil pump asm. ⊍⋉䚼ӊ 1
2 0251 GR3390 Oil pump installing base ⊍⋉ᅝ㺙ᵓ (1)
3 0251 GS062 Screw 15/64-28 L=9 ⊍⋉ᅝ㺙㶎䩝 15/64-28 L=9 1
4 0251 GR3391 Oil pump ⊍⋉ԧ (1)
5 0251 GO476 Oil pump bushing ⊍⋉ԧ㹀༫ (1)
6 0251 GR3392 Oil pump impeller ⊍⋉৊䕂 (1)
7 0251 GR3393 Oil pump impeller cover ⊍⋉৊䕂ᠬᵓ (1)
8 0251 GR3394 Lubricating oil pump cover ⊍⋉Ⲫ (1)
9 0251 GS554 Screw M3 L=10 ⊍⋉Ⲫ㶎䩝 M3 L=10 (3)
10 0251 GR3395 Hook driving shaft oil tube ϟ䕈կ⊍ㅵ (1)
11 0251 GR3396 Plunger ಲ⊍󰵦า (1)
12 0251 GW437 Plunger spring 󰵦าㇻ (1)
13 0251 GS0569 Plunger screw M7X0.75 L=5 󰵦า㶎䩝 M7X0.75 L=5 (1)
14 0251 GS0568 Screw M3 L=8 ⊍⋉㶎䩝 M3 L=8 (3)
15 0251 GS0570 Oil pump support ⊍⋉䖲᥹㶎󰵦 1
16 0251 GS030 Screw 11/64-40 L=9.5 䖲᥹㶎󰵦㶎䩝 11/64-40 L=9.5 1
17 0251 GR3397 Rubber joint կ⊍ㅵ᥹༈ 1
18 0251 GR6187 Main shaft oil tube Ϟ䕈կ⊍ㅵ 1
19 0251 GR6011 Oil tube ᮟẁկ⊍ㅵ 1
20 0251 GS054 Oil adjusting screw ᮟẁ⊍䞣䇗㡖㶎䩝 1
21 0251 GW259 Spring ᮟẁ⊍䞣䇗㡖ㇻ 1
22 0251 GR3400 Tube holder(lower) ᮟẁկ⊍ㅵᵓ 1
23 0251 GS062 Screw 15/64-28 L=9 ᵓ㶎䩝 15/64-28 L=9 1
24 0251 GR1561 Oil sight window ⊍に 1
25 0251 GR1562 Rubber ring ⊍にOൟ೜ 1
26 0251 GR6188V2 Oil return tube ಲ⊍ㅵ 1
27 0251 GR1566 Oil return tube holder ಲ⊍ㅵ། 1
28 0251 GS0551 Screw 3/16-28 L=6 ಲ⊍ㅵ།㶎䩝 3/16-28 L=6 1
29 0251 GR1568 Oil felt ಲ⊍↵ 1
30 0251 GR1569 Oil felt presser ಲ⊍↵། 1
31 0251 GR3402V2 Arm oil shield asm 䴶䚼䰆⊍ᵓ䚼ӊ 1
32 0251 GR3403 Arm oil shield 䴶䚼䰆⊍ᵓ (1)
33 0251 GR3404 Oil wick 䰆⊍ᵓ⊍㒓 (1)
34 0251 GS44 Screw 1/8-44 L=4 䰆⊍ᵓ㶎䩝1/8-44 L=4 1
35 0251 GR6172 Plastic seal Ϟ䕈կ⊍ㅵᆚᇕ೜ 1
ˉ16ˉ

-17-
9.Oil reservoir & knee lifter components

ো
9.Oil reservoir & knee lifter components 9.
⊍Ⲭǃ㝱ᢀ㛮䚼ӊ
ᑣӊো Description ৡ⿄ Qty
1 0251 GR6291V22 Oil reservoir asm. ⊍Ⲭ䚼ӊ 1
2 0251 GR3406 Oil reservoir ⊍Ⲭ (1)
3 0251 GR3407 Gasket ⊍Ⲭൿ (1)
4 0251 GR3408 Rubber cushion ᴎ༈ᑻൿ (4)
5 0251 GS0571 Screw 5/16-24 L=7 ᥦ⊍ᄨ㶎䩝5/16-24 L=7 (2)
6 0251 GR3409 Rubber ring ᥦ⊍ᄨ㶎䩝Oൟ೜ (2)
7 0251 GR6301 Oil reservoir magnet ⊍Ⲭ⺕䪕 1
8 0251 GR6287 Oil reservoir felt cushion ⊍Ⲭᑻൿ 2
9 0251 GR6286 Oil reservoir rubber cushion ⊍Ⲭᬃᑻ 2
10 0251 GBX108 Nail ⊍Ⲭᑻ䩝 4
11 0251 GX1130 Knee press lifter rod ᢀ㛮乊䫔 1
12 0251 GH1132 Connecting rod,vertical ᢀ㛮ঠ৥᳆ᶘ (1)
13 0251 GS0572 Screw 15/64-28 L=18 ঠ৥᳆ᶘ㶎䩝15/64-28 L=18 (1)
14 0251 GS057 Screw 15/64-28 L=30 ঠ৥᳆ᶘ䰤ԡ䇗㡖㶎䩝15/64-28 L=30 (2)
15 0251 GL21 Nut 15/64-28 ঠ৥᳆ᶘ䰤ԡ䇗㡖㶎↡ 15/64-28 (2)
16 0251 GW438 Spring ঠ৥᳆ᶘᡁㇻ (1)
17 0251 GZ439 Knee press rod ᢀ㛮䕈 (1)
18 0251 GR1583 Snap ring ᢀ㛮䕈ᓔষᣵ೜ (1)
19 0251 GR3410 Bearing bracket ᢀ㛮᪡㒉ᴚ㡖༈ (1)
20 0251 GS0573 Screw 9/32-20 L=20 ᪡㒉ᴚ㡖༈㶎䩝9/32-20 L=20 (2)
21 0251 GR3411V6 Knee press plate asm. ᪡㒉ᴚ䚼ӊ 1
22 0251 GZ440 Knee lifter plate rod ᪡㒉ᴚ (1)
23 0251 GR3412 Knee press plate ᪡㒉ᵓ (1)
24 0251 GR3958 Knee press plate cover ᪡㒉ᵓ䕃ൿ (1)
25 0251 GR3413 Rubber ᪡㒉ᴚൿ (1)
26 0251 GR3414 Knee press plate holder ᪡㒉ᴚ㡖༈ (1)
27 0251 GS584 Screw 15/64-28 L=15 㡖༈㶎䩝 15/64-28 L=15 (1)
ˉ18ˉ
