How to read the spare parts list :
- The list is grouped according to construction modules. A module is a group of parts fulfilling in the machine a concrete
function. The abbreviated module designation is given in the left top corner both of the drawing and of the text. The complete
module designation (as given in the delivery note) is related to the abbreviated designation as follows:
Abbreviated omplete
M XXX = S980 000XXX
Items in the order are presented under complete code (ten-digit number)
- This catalogue is common for a number of machine models whose type designation agrees with the first five digits printed
on the catalogue cover. The complete type designation of the machine is then used for identifying the modules (lists
of parts)mounted on the machine in question.
The complete type designation has the following structure:
XXXX - XXX - XXX
lass Subclass Sewing category
The contents is divided into sections corresponding to this structure. A table situated at the head of each section gives
information on which modules are applied to a particular machine model. The machine class and subclass are printed on the
label situated on the machine bed plate and visible with tilted machine head. The sewing category is indicated on the tag
supplied together with the machine.
- All items, the complete code (ten-digit number) of which are presented in the tables there is possible to order as spare parts.
- The symbol shows that the part is to be lubricated by grease (used for the machine assembly).
- The symbol shows that the part is glued (used for the machine assembly).
Parts marked in the drawings with the symbol * and with the remark * SPARE PARTS SUPPLIED WITH THE MA HINE
are attached with head of machine.
CONTENTS :
Modules of machine head and of enclosed accessories
Abbreviated Ordering (complete) Denomination Table No.
module No. module No.
Class (modules identical for all subclasses)
M 501 Machine arm 1
M 502 Bed plate 2
M 512 Post-bed 3
M 513 Needle and thread mechanism 4
M 517 Thread tensioner plate 5
M 503 Post-bed for sewing hook 6
M 508 Needel feeding 7
M 516 S980 000516 Feed carrier 48
M 500 Top roller drive 8
M 511 S980 000511 overs of post 9
M 509 Bootom feed 10
M 514 Lubrication 11
Subclass
- Table of subclasses 12
M 820 Sewing hook 13
M 518 S980 000518 Electromagnetically controlled top roller lifting 14
M 504 S980 000504 Thread trimmer 15
M 519 S980 000519 Thread trimmer drive 16
M 249 S980 000249 Electromagnetically controlled backtacking 17
M 521 S980 000521 Push-button panel 18
M 008 S980 000008 Electrical switch board 19
M 520 S980 000520 Parts for machine without trimming 48
