MAINTENANCE MANUAL
PROOFER OVEN
WITH TOUCH SCREEN
CONTROLS (TSC)
Models:
TSC-6/18M TSC-3/9M
IMPORTANT INFORMATION, READ BEFORE USE.
PLEASE SAVE THESE INSTRUCTIONS.
This manual is Copyright © 2013 Duke Manufacturing Company. All rights reserved.
Reproduction without written permission is prohibited. Duke is a registered
trademark of the Duke Manufacturing Company.
Duke Manufacturing Company
2305 N. Broadway
St. Louis, MO 63102
Phone: [phone]
Toll Free: 1-800-735-3853
Fax: [phone]
www.dukemfg.com
P/N 120086
REV E 6/8/2017
MAINTENANCE BY QUALIFIED,
TRAINED PERSONNEL ONLY

Maintenance Manual for DUKE TSC Proofer
Oven with Touch Screen Controls
2

3
Maintenance Manual for DUKE TSC Proofer
Oven with Touch Screen Controls
TABLE OF CONTENTS
IMPORTANT SAFETY INSTRUCTIONS ............................................................................4
OVEN/PROOFER START-UP .............................................................................................6
PROGRAMMING CONTROLS............................................................................................7
CARE AND CLEANING.......................................................................................................10
DOOR ADJUSTMENTS AND GASKET MAINTENANCE ...................................................14
TROUBLESHOOTING .......................................................................................................21
PARTS LIST AND ILLUSTRATIONS ...................................................................................22
WIRING DIAGRAM .............................................................................................................25

Maintenance Manual for DUKE TSC Proofer
Oven with Touch Screen Controls
4
IMPORTANT SAFETY INSTRUCTIONS
Throughout this manual, you will nd the following safety words and symbols that signify important
safety issues with regards to operating or maintaining the equipment.
WARNING
Indicates a hazardous situation which, if not avoided, could result
in death or serious injury.
CAUTION
Indicates a hazardous situation which, if not avoided, could result
in minor or moderate injury.
CAUTION
Indicates Important Information
Indicates electrical shock hazard which, if not avoided, could
result in death or serious injury and/or equipment damage.
Indicates hot surface which, if not avoided, could result in minor or
moderate injury. Specically, risk of burn from heating elements.
Indicates rotating fan blade hazard which, if not avoided, could
result in minor or moderate injury.
Indicates hot surface which, if not avoided, could result in minor or
moderate injury.
In addition to the warnings and cautions in this manual, use the following guidelines for safe operation
of the unit.
• Read all instructions before using equipment.
• Do not attempt to defeat the grounded connector.
• Install or locate the equipment only for its intended use as described in this manual.
• Do not use corrosive chemicals, water jet equipment, or other pressurized liquid spraying
equipment to clean this unit.
• This equipment should be serviced by qualied personnel only. Contact the nearest Duke
authorized service facility for adjustment or repair.
• Do not block any openings on the unit.
• A minimum clearance of 6″ (152.4 mm) from the top of the unit to the ceiling must be provided.
• Secure unit to a wall with brackets provided to prevent tipping.
• Unit may start operation with inadvertent contact with touch screen display or from other
extraneous sources. Turn off all poles mains disconnects should abnormal or unwanted operation
occur.

5
Maintenance Manual for DUKE TSC Proofer
Oven with Touch Screen Controls
• Install the Restraining Device Kit to prevent damage to main supply connections.
• This appliance can be used by children aged from 8 years and above and persons with reduced
physical, sensory or mental capabilities or lack of experience and knowledge if they have been
given supervision or instruction concerning use of the appliance in a safe way and understand the
hazards involved. Children shall not play with the appliance. Cleaning and user maintenance shall
not be made by children without supervision.
• Turn off external mains supply disconnect and allow unit to cool down before servicing or
performing maintenance.
• The procedures in this manual may include the use of chemical products. You must read the
Material Safety Data Sheets before using any of these products.
• Properly rated all poles mains protection and earthing compliance with local electric codes are
required for safe operation of this unit.
• Water supply connections to the unit must comply with local plumbing code and/or standards.
• Disposal of the unit must be in accordance with local environmental codes and/or any other
applicable codes.
• SAVE THESE INSTRUCTIONS
Technical Description and Application Notes for TSC Proofer Oven Backow Preventer Assembly
This equipment is intended to be connected to a
potable water supply system under pressure and is
to be installed with adequate backflow protection
to comply with all applicable federal, state, and
local codes.
Water supply pressure for proper operation shall be:
Minimum 40 PSIG(275 KPa)
Maximum 65 PSIG(448 KPa)
measured at water line inlet to the equipment.
If so equipped, regular maintenance is required to
replace the water filter cartridge at least once per
year, and to clean the inlet water screen at least
once per year. Consult state/local codes for any
additional requirements.
INSTALLATION OF WATER FILTER
Install new filter by removing sanitary cap from top
of cartridge, insure two black O-rings are in place,
then lift up into filter head and rotate cartridge
1/4 turn counter clockwise until it comes to a complete
stop. Flush 2 gallons (7.5 Liters) of water through the
new filter before using proofer to purge air from filter.
Remove hose from bottom of proofer by loosening
the compression nut at the disconnect fitting
and pull hose out. Place hose over container and
turn on water. It will take a minute for the filter
to fill before water flows out of hose into container.
Once filter is flushed with 2 gallons (7.5 Liters) of water,
turn off water supply again, insert hose into water line
disconnect, tighten compression nut and turn
water supply on again. Check for leaks at
connection fittings.
Patent(s) Pending
512776 D
Check with your local authority having jurisdiction
regarding approvals for connecting the Duke
TSC Proofer Oven to a potable water supply
before making any plumbing connections.
Plumbing code requirements vary, but Duke has
a kit (P/N 600187) available or installed as a
factory option, for backow prevention to protect
water supply systems by preventing the reverse
ow of non-potable water into the potable
domestic water system. The device consists of
two independently acting check valves, internally
force-loaded to a normally closed position
and designed/constructed to operate under
intermittent or continuous pressure conditions.
The two main components of the Duke backow
preventer system are:
• Dual Check Valve type backow preventer
that conforms to ANSI/ASSE standard
#1024 and is CSA standard B64.6 certied.
• Inlet water strainer equipped with 100-
mesh screen and installed up stream of
the backow preventer. The screen is
conveniently located on the rear panel of the
proofer, below the backow preventer, for
easy access during cleaning/replacement.

Maintenance Manual for DUKE TSC Proofer
Oven with Touch Screen Controls
6
WARNING
ELECTRICAL SHOCK HAZARD.
DISCONNECT POWER TO SERVICE
UNIT.
TASKS MUST BE PERFORMED BY A
QUALIFIED SERVICE TECHNICIAN OR
ELECTRICIAN.
1. Remove Proofer bottom panel and verify
that the Opti-MistTM nozzle is clear of
obstructions.
TM
6. Check to make sure that the oven and
proofer fans are running.
7. Open the oven door; the oven fan should
stop.
8. Close the door; the fan should resume.
9. Allow the oven and proofer to pre-heat for
at least 30 minutes. An audible alarm will
sound (3 short chirps) when the oven and/
or proofer reach the ready state. Your Duke
Proofer Oven is now ready to operate.
If there are any problems refer to the Trouble
Shooting section of this manual.
Figure: Main Screen
5. Turn the oven and proofer ON by touching
the and buttons located at the
left of the touch screen. The Oven, Proofer
and Recipe Buttons will turn to BLUE
background. The Oven and Proofer lights
will turn on and start preheating.
PROOFER OVEN START-UP
Figure: Opti-MistTM
2. Check the door seals and make sure both
doors close completely.
3. Have a qualied service technician or
electrician connect the oven to the power
supply.
4. Turn power on to the unit with the power
switch on the left side of the unit. Boot
Screen is displayed and automatically
transitions to the Main Screen.

7
Maintenance Manual for DUKE TSC Proofer
Oven with Touch Screen Controls
PROGRAMMING CONTROLS
RECIPE EDIT PROGRAMMING
INSTRUCTIONS
1. Touch the button and then enter pin
code 5 6 7 8 and Touch the button
when prompted.
2. Touch the button for the recipe you want to
edit (i.e. BREAD ).
NOTE: The 6 oven recipes are listed in
the top 3 rows and the 6 proofer recipes
are listed in the bottom 3 rows.
3. To edit Time, Temperature or Humidity
(Proofer Only), touch the or
button adjacent to the eld you want to
change. Touch the button to save
the changes.
NOTE: You must touch the button
in each eld to save the changes you
made.
FIGURE: Recipe Edit Selection Screen
Figure: Recipe Edit Screen
Figure: Main Tool Bar
Figure: Special Functions Screen
To access the SPECIAL FUNCTIONS, touch
button on the Main Tool Bar.

Maintenance Manual for DUKE TSC Proofer
Oven with Touch Screen Controls
8
5. Touch the button to save the
changes and return to the RECIPE EDIT
Screen. If no changes are required touch
the button to go back to the RECIPE
EDIT Screen.
NOTE: You must touch the button
to save the changes you made.
6. When complete, touch the button
to go back to the previous screen. Press
multiple times to return to the main screen.
4. To edit the recipe name, touch the
button for the EDIT RECIPE NAME screen.
NOTE: Typing will add letters/characters
to the end of the text.
PRESS:
• TO TOGGLE THE KEYBOARD
BETWEEN THE UPPER/LOWER
CASE CHARACTER SET.
• , AND FOR THE
NUMBER AND SYMBOL
KEYBOARDS.
• TO SPACE
• TO CLEAR ALL TEXT
• TO DELETE/BACKSPACE
Figure: Edit Recipe Name Screen

9
Maintenance Manual for DUKE TSC Proofer
Oven with Touch Screen Controls
FILES (FILE MANAGEMENT)
1. Touch the button and then enter pin
code 3 4 5 6 and Touch the button
when prompted.
2. Insert USB drive with the le, until seated,
into the USB Host Device.
3. Select le operation from list and follow
instruction on the display screen.
Figure: Inserting USB Drive Into USB Host
Device
Figure: File Management Screen
CONFIG (CONFIGURATION S)
1. Touch the button and then enter pin
code 2 3 4 5 and Touch the button
when prompted.
2. Touch the button for the setting you want to
edit.
• DATE/TIME – Touching will display DATE/
TIME edit screen. Touch the or
button adjacent to the eld you want to
change. Touch the button to save the
changes.
• LANGUAGE – Touching will display a list of
included languages. Touch the preferred
language button to select.
• C/F SELECT – Touching will toggle
between CENTIGRADE MODE ENABLED
and FAHRENHEIT MODE ENABLED.
• DEFAULT RECIPE – Touching will reload
factory defaults.
• SYSTEM STATUS – Touching will display
Proofer Oven status.
Figure: Congurations Screen

Maintenance Manual for DUKE TSC Proofer
Oven with Touch Screen Controls
10
CARE AND CLEANING
WEEKLY CLEANING INSTRUCTIONS
1. Clean Proofer. Turn the proofer off and
allow elements to cool. Remove the bottom
panel (remove screw). Remove excess
water by wiping it up with a dry cloth.
Clean bottom panel to remove any mineral
deposits and debris with hot soapy water
and follow with clean damp cloth.
2. Clean Opti-Mist proofer spray Nozzle.
A. Remove nozzle assembly by depressing
latch on quick-connect tting and pull
nozzle out toward fan blade.
B. Soak nozzle in plain white vinegar for 4-8
hours to dissolve mineral deposits. Wipe
residue from nozzle and rinse in clean
water.
C. Do not insert objects into nozzle outlet
as this can change the water spray
performance.
D. Replace nozzle assembly if mineral
deposits from hard water cannot be
removed.
E. Reinstall nozzle by inserting into quick-
connect tting until fully seated.
Figure: Opti-MistTM Quick Connect Nozzle
TM
TM
WARNING
PROOFER OVEN INTERIOR AND
RACKS ARE VERY HOT AND COOL
SLOWLY.
ALLOW TO COOL BEFORE
HANDLING.
CAUTION
ELECTRICAL SHOCK HAZARD.
DO NOT WASH WITH WATER JET
OR HOSE.
CAUTION
RISK OF CUT FROM ROTATING FAN
BLADE.
DISCONNECT POWER TO SERVICE.
CAUTION
RISK OF BURN FROM HEATING
ELEMENTS.
DISCONNECT POWER AND ALLOW
TO COOL TO SERVICE.
CAUTION
DO NOT USE OVEN CLEANERS,
CAUSTIC CLEANERS, DEGREASERS,
ACIDS, AMMONIA PRODUCTS,
ABRASIVE CLEANERS, STEEL WOOL,
OR ABRASIVE PADS CONTAINING
IRON. THESE CAN DAMAGE THE
STAINLESS STEEL, DOOR GASKETS
AND PLASTIC SURFACES.

11
Maintenance Manual for DUKE TSC Proofer
Oven with Touch Screen Controls
3. The Cool-Touch door has two window panes.
The inner window can be easily separated
from the outer window for cleaning. This is
achieved by unlatching two clips and rotating
the inner window on its hinges. After cleaning,
the inner window frame is easily clipped to the
outer window by squeezing the two windows
together. For additional detail refer to "Cool-
Touch Door Information" section of this manual.
4. Inspect oven & proofer door gaskets for
cuts, tears or any other damage. Refer
to the section on "Door Adjustments and
Gasket Maintenance" for directions.
Monthly Care and Cleaning Instructions
1. Check door handle screws for tightness.
2. Check the door gasket seal on the Oven and
Proofer for leaks. Refer to the section on "Door
Adjustments and Gasket Maintenance" for
directions.
CAUTION
HEAVY WATER FILTER CARTRIDGE
CAN PINCH HANDS.
USE CARE WHEN REMOVING.
Annual Cleaning Instructions
CAUTION
REPLACE FILTER CARTRIDGE ONLY
WITH DUKE FACTORY AUTHORIZED
REPLACEMENT PARTS TO ENSURE
PROPER OPERATION.
CAUTION
WATER FILTER CARTRIDGE IS
UNDER PRESSURE, SLOWLY
REMOVE CARTRIDGE TO RELEASE
PRESSURE.
1. Replace water lter cartridge & clean inlet
strainer.
A. Turn off water supply to oven.
B. Disconnect Wall Brackets if installed. See
Installation of wall brackets section of
manual.
C. Turn off power to Proofer Oven.

Maintenance Manual for DUKE TSC Proofer
Oven with Touch Screen Controls
12
D. Remove old lter by rotating cartridge to
the left (facing back of cabinet) slowly until
pressure starts to release, stop and let
pressure and excess water drain through
pressure release hose. Once water has
stopped draining, continue turning to the
left and pull downward.
H. Replace strainer screen and Hex Cap.
I. Flush 2 gallons of water through the new
lter before using proofer to purge air
from lter. Remove hose from bottom of
proofer by loosening the compression nut
at the disconnect tting and pull tube out.
Place tube over container and turn on
water. It will take a minute for the lter to ll
before water ows out of the tube into the
container.
J. Once lter is ushed with 2 gallons of
water, turn off water supply again, insert
tube into water line disconnect, tighten
compression nut and turn water supply on
again. Check for leaks at connection ttings
and Inlet Strainer Housing Hex Cap.
K. Reconnect Wall Brackets if installed. See
Installation of Wall Brackets section of
Owners manual.
Figure: Inlet Strainer and Screen
Figure: Water Filter System
E. Install new lter by removing sanitary cap
from top of cartridge, ensure two black
O rings are in place, then lift up into lter
head and rotate cartridge 1/4 turn counter
clockwise until it comes to a complete stop.
F. Remove Inlet Strainer by loosing Hex cap
on Inlet strainer Housing.
G. Remove and ush strainer screen with
warm water.

13
Maintenance Manual for DUKE TSC Proofer
Oven with Touch Screen Controls
L. Turn on power to Proofer Oven.
Caution: Replace lter cartridge only with
Duke factory-authorized replacement parts
to ensure proper operation. See Parts List
section of manual for part number.
Figure: Water Filter (Flushing 2 gallons of
water)
Water Line
Disconnect
Fitting
Proofer Oven With
Optional Backow
Preventer
Proofer Oven
Without Optional
Backow
Preventer
Inlet Water
Connection
Point
Figure: Opti-MistTM Nozzle Filter
2. Clean Opti-MistTM proofer nozzle screen.
A. Remove nozzle assembly by depressing
latch on quick-connect tting and pull
nozzle out toward fan blade.
B. Use 3/4" and 5/8" wrenches to remove
nozzle from body.
C. Unscrew lter screen using ngers.
D. Use 5/32 allen wrench to remove diffuser
retainer, diffuser and centering sleeve.
E. Soak all parts in plain white vinegar for 4-8
hours to dissolve mineral deposits. Wipe
residue from nozzle and rinse in clean
water.
F. Do not insert objects into nozzle outlet
as this can change the water spray
performance.
NOTE: Ensure proper orientation of the
Diffuser Retainer.
H. Replace nozzle assembly if mineral
deposits from hard water cannot be
removed.
I. Reinstall nozzle by inserting into quick-
connect tting until fully seated.
G. Reassemble nozzle.

Maintenance Manual for DUKE TSC Proofer
Oven with Touch Screen Controls
14
DOOR ADJUSTMENTS & GASKET MAINTENANCE
WARNING
REVERSING OVEN DOOR SWING
DIRECTION
1. Remove cover from hinges to expose the
screws that hold the hinge to the front of the
oven.
2. Remove the hinge screws and door from the
oven.
3. Remove the door handle screws, ip the door
handle over and replace it on the door.
4. Remove the six screws on the front of the oven
to expose the hinge screw holes for the other
swing direction.
5. Use the six screws to ll the unused hinge
screw holes on the front of the oven.
6. Remove the latch strike plate from the front
of the oven and move it to the other side. Use
the screws from the other side to ll the screw
holes that are no longer used.
7. Position the door on the front of the oven and
tighten the hinge screws. Make sure the door
is level with the oven body before the screws
are tightened permanently.
8. Adjust the door gasket seal.
Figure: Illustration – Reversing Oven Door Direction

15
Maintenance Manual for DUKE TSC Proofer
Oven with Touch Screen Controls
Proofer Drip Channel Reversal:
The proofer door has a sloped drip channel on the bottom that directs any water that drips down the
door into the water pan below the door. When the door swing is reversed this drip channel must be
replaced with a new channel that has the slope in the proper direction. Contact Duke Manufacturing
Service for a new drip channel before changing door swing direction.
Figure: Right Hinge Drip Channel Slope Towards Right
Figure: Left Hinge Drip Channel Slope Towards Left

Maintenance Manual for DUKE TSC Proofer
Oven with Touch Screen Controls
16
PROOFER DRIP CHANNEL REVERSAL:
1. Follow the directions for removing the door from the Reversing Oven Door section. When the
door is off you can then replace the drip channel.
2. Remove the screws that hold the drip channel on and remove the drip channel. Use the same
screws to ll the empty holes after the drip channel is off.
3. Locate the new drip channel on the other end of the door. Make sure that the slope is directed to
the hinge side of the door.
4. Fasten the drip channel to the door with the self-tapping screws provided with the new drip
channel.
5. Follow the directions from the Reversing Oven Door section for mounting the door.
DIRECTION
OF SLOPE
NEW POSITION OF
THE DRIP CHANNEL
Figure: Illustration – Reversing Proofer Door Direction

17
Maintenance Manual for DUKE TSC Proofer
Oven with Touch Screen Controls
DOOR GASKET LEAK ADJUSTMENTS:
The doors should be checked for leaks every
three months. The adjustment can be made
by following the instructions below. If the door
gasket is damaged or compressed permanently,
it should be replaced. Call Duke Manufacturing
Co. at 800-735-3853 to order a new gasket
before making adjustments.
1. To check the adjustment, close the door
with a currency bill between the gasket and
front of the oven. Resistance should be
felt when pulling the currency bill out with
the door closed. Do this check in several
places and readjust the door as necessary.
Figure: Gasket Check
2. With the door closed, remove the hinge
covers with a screwdriver and loosen the
six screws that hold the hinges to the door.
Figure: Removing Hinge Cover
Figure: Location of Hinge Screws

Maintenance Manual for DUKE TSC Proofer
Oven with Touch Screen Controls
18
Figure: Hinge Side Adjustment
IMPORTANT
Be careful not to compress the gasket
too much, or it will not allow the door to
be closed.
3. Adjust the door position by moving the door
frame in or out to seal any gaps between
the gasket and the oven. Adjustment is
made using the screws on the handle and
the hinges.
Gasket
Groove
Door
Gasket
4. To check the adjustment, close the door
with a currency bill between the gasket and
front of the oven. Resistance should be
felt when pulling the currency bill out with
the door closed. Do this check in several
places and readjust the door if necessary.
Figure: Gasket Check
GASKET REPLACEMENT:
1. Remove the old gasket by pulling it out of
the groove in the door frame.
Figure: Door and Gasket
Figure: Handle Side Adjustment

19
Maintenance Manual for DUKE TSC Proofer
Oven with Touch Screen Controls
COOL-TOUCH DOOR INFORMATION AND
CLEANING INSTRUCTIONS
The Cool-Touch door has two window panes.
The inner window can be easily separated from
the outer window for cleaning. This is achieved
by unlatching two clips and rotating the inner
window on its hinges. After cleaning, the inner
window frame is easily clipped to the outer
window by squeezing the two windows together.
2. Clean the groove with a screwdriver or
other at-bladed tool to remove any dirt or
gasket pieces.
Figure: Cleaning Gasket Groove
3. Press the new gasket into the groove.
Make sure it is fully seated in the groove
and at against the door frame.
Figure: Properly Seated Gasket
4. Check the door adjustment to make sure
there are not any leaks. Also, check that
the new gasket is not compressed too
much, making the door hard to close.
Figure: Cool-Touch Door inside view.
1. To open the windows for cleaning, unlatch
the top clip.
Figure: Unlatch Top clip

Maintenance Manual for DUKE TSC Proofer
Oven with Touch Screen Controls
20
Figure: Halogen Lamp Assembly
Turn counter-clockwise.
Remove bulb cover.
Lamp Holder
Assy.
G4 12V
Flat Lens
58mm
(502794)
Gasket -
Lens 58mm
(502795)
10W (Max.) Lamp
12V Halogen
G-4 (Bi-Pin)
(512495)
2. Unlatch the bottom clip.
CAUTION
DO NOT TOUCH LIGHT BULBS
WITH BARE HANDS AS OIL/
FINGERPRINTS WILL SHORTEN THE
LIFE OF THE BULB. USE A CLEAN
GLOVE OR CLOTH TO HANDLE
BULBS.
Figure: Door Clipped Together
After Cleaning
Figure: Unlatch Bottom Clip
3. Cool-Touch Door bottom easily swings
open for cleaning.
Figure: Door Swings Open for Cleaning
4. Cool-Touch inner door is easily
clipped to the outer door by squeezing
them together.
1. Turn the Proofer Oven OFF and allow to
cool.
2. Remove the light lens and gasket by
turning it counter clockwise.
3. Remove the burned out bulb.
4. Using clean gloves or a cloth, install the
new lamp bulb (Halogen Lamp G4, 12
Volts, 10 Watt Maximum) into the lamp
holder.
5. Replace light lens and gasket ensuring it
is fully seated and tightened or leaks will
occur.
BULB MOUNTING DETAILS
