Dumor 331 User manual

331 Gemini
Operation Manual
Guangzhou Dumor Automation System Co.,Ltd
www.dumor.cn
0086-755-2671-4393
Auto Creaser

331 Auto Creaser 2
INDEX
Chapter 1 INTRODUCTION.............................................................................1
1.1 Preface ...............................................................................................1
1.2 Specification .......................................................................................2
Chapter 2 SAFETY..........................................................................................3
2.1 Environment........................................................................................4
2.2 Do’s and Don’ts ..................................................................................4
2.3 Cautions..............................................................................................5
Chapter 3 MAIN PARTS & ASSIES .................................................................6
Chapter 4 INSTALLATION...............................................................................7
4.1 Output tray, stops and guides.............................................................7
4.2 Feeding extension ..............................................................................7
4.3 Power socket and switch ....................................................................8
Chapter 5 OPERATION...................................................................................9
5.1 Key Panel Introduction........................................................................9
5.2 Quick Start........................................................................................10
5.3 Screen Introduction...........................................................................11
5.3.1 Welcome Screen ....................................................................11
5.3.2 Ready Screen.........................................................................11
5.3.3 Crease Data Screen...............................................................12
5.3.4 Cover Hinge Screen ...............................................................13
5.3.5 Progressive Screen ................................................................13
5.3.6 Save a Job..............................................................................15
5.3.7 Recall a Job............................................................................16
5.3.8 Speed Screen.........................................................................16
5.3.9 Recalibration Screen ..............................................................17
5.4 Hardware Setting..............................................................................17
5.4.1 Skew adjustment ....................................................................17
5.4.2 Crease Depth .........................................................................18
5.4.3 Crease Bar Installation ...........................................................19
5.4.3.1 Crease Die Installation .................................................19
5.4.3.2 Perforation Bar Installation ...........................................19
Chapter 6 OPTIONAL PARTS........................................................................20
6.1 Perforating Wheel Set.......................................................................20
Chapter 7 TROUBLE SHOOTING.................................................................23
7.1 Show warning C-1 ............................................................................23
7.2 Show warning C-2 ............................................................................24
7.3 Show warning C-3 ............................................................................25
7.4 Show Error E-1.................................................................................26
Chapter 8 Maintenance..................................................................................27
8.1 User Maintenance.............................................................................27
8.2 Technician Maintenance ...................................................................27

331 Auto Creaser 1
Chapter 1 INTRODUCTION
1.1 Preface
This manual only applies to 331 Gemini Auto Creaser machine.
Before using the machine, please read the instruction manual carefully first.
Please keep the manual properly so that consulting it at any time in the future.
Any question while operating please contact our technicians.

331 Auto Creaser 2
1.2 Specification
Paper thickness for Crease about 100-350 gsm (0.1~0.35mm)
Paper thickness for Perforating about 100-250 gsm (0.1~0.25mm)
Paper length 90-900mm
Paper width 50-330mm
Speed(One crease on A4): 35~42 sheets/min
Min crease gap crease: 1mm; perforating: 10mm
Min gap from leading edge to first crease: crease: 1mm; perforating: 10mm
Crease accuracy ±0.3mm
Crease qty in one pass 0 - 32
Max program qty 30
Crease Counting reversible counter
Total counter for crease qty and paper qty
Skew adjustment Standard
Crease depth adjustment Standard
Feeding extension table Standard
Output tray Standard
Language CN/EN
Linear perforating Option
Linear scoring Option
Stand Option
Power 220V/50HZ/150W
Fuse rating 3.15A
Weight 42kg(NG) 47kg(GW)
Note: The machine is keep upgrading, specification and information in this
manual are updated as per the change without notice.

331 Auto Creaser 3
Chapter 2 SAFETY
Please shut down the machine before the maintenance.
In order avoid any mistake when re-connecting wires back, we advise you to
mark each connector before replace of any electrical component.
Mind that every connection should be firm, first hold both sides of the
connector, and then, in the middle, not firm connection is possible to damage
the electrical components.
Power supply
AC input，Voltage/Frequency is：
AC220V/50-60Hz.
！If the voltage or frequency are not in the range,
the machine may not be used normally or even may
cause unrecoverable damage
Power cord，Over 10A current is endurable
！1. Do not remove the cord when the machine is running,
illegal operation may cause component damage or machinery
jam
2. Remove the cord when you are installing components.
Ground symbol. If you see this symbol in any place,
please do not touch it anyhow, or uninstall it.
!If the ground is not well connected, it may cause
human body injury.

331 Auto Creaser 4
2.1 Environment
Temperature：10°C to 35°C
Humidity: 30% to 70%
Altitude: Below elevation 1000m
There is no corrosiveness gas, flammable gas, oil mist and so on in room
2.2 Do’s and Don’ts
Do-Read this manual and fully understand before the operation.
Do-Check the plug and machine voltage and frequency to your main
supply, and that the socket has a correct working earth lead for this single
insulated machine
Douse at least a 10 amp power source at 220 V. (20Amp/100V).
Do make sure all safety covers are in place. The top covers have an
interlock switch which will disable the unit if removed
Do open or close the cover slowly
Do contact the local maintenance center before you are about to move
the machine.
Do disconnect the power before clean the inner side.
Do unplug the cord if you won’t use the machine for a long while,
Do be careful of the blade edge
Don’tinstall the machine on an unstable ground.
Don’t operating with wet hand, especially plug or unplug the cord.
Don’twear long hair, loose fitting clothes or put your fingers into the
creasing unit nip, while the operation..
Don’tplace any receptacles with any liquid on any surface of machine.

331 Auto Creaser 5
Don’t-put other pieces, especially tiny pieces on loading table.
Don’t-alter or uninstall the machine, unless by Dumor authorized
engineer.
Don’t touch any running parts while running
Don’t shut down the machine while running.
Don’t put heavy matter on machine or shock it.
Don’t put the side guide under the feeding system.
2.3 Cautions
Be careful of any metal or flammable thing in internal machine, or it may
cause fire or electronic shock. If it happens, first shut down the power,
disconnect the cord, and then contact the technician.
If machine becomes heat, smoke, or smelly, shut down at once, disconnecting
the cord, and contact the maintenance staff.

331 Auto Creaser 6
Chapter 3 MAIN PARTS & ASSIES
No.
Parts
Description
1
Power socket
For system power
2
Power switch
On/off
3
Tools Storage
Place the idle crease die or perforate die
4
Extension table
For longer sheet
5
Magnetic side guide
Flexible guide for the paper feeding
6
Fixed Side guide
For skew adjustment
7
Safety Switch
Check safety cover closed is or not.
8
Depth setting Screw
For crease depth adjustment
9
Output roller
Output the sheet and for mounting linear tools
10
Control panel
Input the data
11
Safety cover
Covering turning parts with interlock switch
12
LCD screen
Display
13
Output tray
To stack the finished products
14
Side cover
Interchange the crease die or perforate die
7
8
9
10
6
5
4
3
2
1
11
12
13
14

331 Auto Creaser 7
Chapter 4 INSTALLATION
4.1 Output tray, stops and guides
Unpack it , install the parts as per above illustration.
Note: Set guide and stops according to the paper format.
The capacity of the tray should always less than 30mm (A3 ) to keep machine
balance.
4.2 Feeding extension
We can see there are 3 screws on trail of feeding table, and there are 3 holes
on side of extension table.
Install them as per following steps:
1: Loosen 3 screw, but not remove
2: Connect extension table, with each screw head through a hole, clip the
extension table on.
3: Tighten 3 screws.
Magnetic side guide
Output tray
Side guide R/H
Back stop
Side guide L/H
Joint of tray
and machine

331 Auto Creaser 8
4.3 Power socket and switch
The power socket and switch are both on right side of operator.
Before the operation, please connect the socket to the electricity with attached
cord, press the switch (when the red point is down, the machine is power on.)
Fuse under the socket is protect the system in case the current is over 3.15A,
to replace the Fuse, we firstly clip the cartridge with a straight screw driver.
Secondly remove the broken fuse from the cartridge and load a new one
back. At last, we reload the cartridge.
Socket
Fuse
Switch
(Press
“O”is off,
press “|”
is on)

331 Auto Creaser 9
Chapter 5 OPERATION
5.1 Key Panel Introduction
The control panel consists of keys and screen, as per following picture.
No
Key
Description
1
STOP
Stop the machine.
2
START
Run the machine.
3
TEST
Machine will stop after one sheet
4
CLEAR
Clear the data or clear the error display
5
NUMBERS
Input data
6
SCROLL
Turn the page
7
INDICATOR-
NO PAPER
“C-4 No paper or Infeed Jam”，but it’s
unavailable for this machine. No C-4 waning.\
8
INDICATOR-
MOTOR ERROR
If the crease motor locks, it lighten and return a
error report ”E-1 CR Motor Error”
9
INDICATOR-
PAPER JAMMED
If the paper is jammed inside the machine, it
lights and returns an error report. ”C-2 Jam at
infeed”or “C-3 Jam at outfeed”
10
INDICATOR-
SAFETY COVER
If the safety cover is not well setting, it lighten
and returned a error report. ”C-1 CR cover
open”
11
FORWARD/REVERSE
When paper jams, press them to move rollers,
so that the paper can be easily cleared.
12
MODE
Change the modes
13
SCREEN
Display information.
14
ENTER
After the data input, press it to confirm.
1
2
10
9
8
7
6
4
5
3
11
12
13
14

331 Auto Creaser 10
5.2 Quick Start
To access to crease job
(Such as a job that crease on 10mm, 20mm and 30 mm )
1. Turn on machine, screen 1 will appear after welcome page.
Screen 1 screen2
2. Press M 1 time, screen jump to Screen 2, line [1] will flash.
3. Enter line [1] value, 1and 0 .Press Enter, line [2] will flash.
4. Enter line [2] value, 2 and 0 .Press Enter, screen jump to screen 3.
Screen3 screen 4
5. Line [3] will flash, Enter line [3] value 3 and 0, press Enter, line [4] will flash
6. Press Enter when line [4] is 0, screen will jump to screen 4
7. Press RUN, feed a sheet. Paper is creased at 10mm, 20mm, 30mm
(crease line distance from the leading edge).
8. Press STOP if you want the job stopped

331 Auto Creaser 11
5.3 Screen Introduction
5.3.1 Welcome Screen
Turn on the machine, welcome page will appear firstly as follow.
It will last for 2 sec, then jump to operation mode automatically.
All system screens are are divided into 5 MODES as per different functions,
we can scroll the mode by press the key .
In each MODE, there maybe over 1 page to display different info, we can
scroll the page by press ↓ or ↑.
5.3.2 Ready Screen
MODE 1 Ready Screen
It is divided into 4 pages:
Page 1:
Press ↓, goes to rest
Page 2,3,4,5…8…:
M
Display the machine states:
Ready: Not run, screen editable.
Running: Feed paper and crease
Note:In “Ready”state, press RUN or TEST
button will shift to “Running”state;
In “Running”state, press STOP will shift
to “Ready”state.
Display Fed qty/Preset qty,
Preset qty: Your wanted qty of
sheets. You can input it through
keyboard, and Enter to confirm.
Fed qty: It is not editable, but in
“Running”state, while sheets
passing. It counts up from 0.
Note: If Preset qty is not 0, when Fed
qty counts up to Preset qty,
machine will stop automatically.
If Press qty is 0, machine will
never stop after “Running”, until
STOP is pressed.
Display First 2 crease data of 32
Note: Crease data can’t be input in
this mode.

331 Auto Creaser 12
Press ↓, goes to page 3
Press ↓, goes to page 3
Page 9:
Press ↓, goes to page 4
Page 10:
Press ↓, return to page 1
5.3.3 Crease Data Screen
Press , goes to MODE 2
MODE 2 Crease data Input
It is divided into 2 pages:
Initially in Mode 2, Line [1] flashes, (which means can be input), input the
data, from 0-900.0, accurate to one decimal place.
Press ENTER, [1] stop flash, [2] flashes.
[1] Input a data, press Enter.
[2] Stop flashing, screen automatically jump to 2nd page.
[3] Flashes ……
Input all 6 likewise.
Note: Each value has to be greater than last value.
If all 6 lines are needed, after we Enter the 6th data, screen will
automatically jump to MODE 1, page 1. Input finished.
If less than 6 line is needed, after we finish the last data (say, the 3rd
line), Enter, Line [4] flash, press ENTER again when line[4] is 0, screen
will jump to main operation mode, input finished.
M
Display rest crease data in 32.
Note: Crease data can’t be
input in this mode.
Total counter of sheet
Total counter of crease
Ver: Software version Nr,
S/N: Serial Nr, factory setting, it
cannot be overwritten unless main
board is changed
Note: User should offer them to the dealer or
supplier to facilitate the after service.

331 Auto Creaser 13
5.3.4 Cover Hinge Screen
MODE 3 Cover hinge
This is a mode especially for book cover make
Following are 2 pages of this mode, in which you can input 2 parameter.
SPINE and THK, Spine means the first spine line to the leading edge, THK
means the thickness of the book, namely the spine width.
2 parameters leads to 4 line, the other 2 is 8mm outside of 2 spine lines as
hinge lines.
Following drawing illustrates.
5.3.5 Progressive Screen
MODE 4 Progressive crease
If you want to shut down the function, press 1, enter, screen will jump to the
Ready Screen.

331 Auto Creaser 14
If you want to active the function, press 2，enter，Screen will jump as follow
to setting for the progressive crease:
Progressive crease performance is as follow, each job has 4 basic parameter:
1. Initial position 2.Progress Depth
3. Progress type (Inc/Dec/Inc & Dec) 4 Total Sheet
If all the sheets creased
on same position, the
bounded book can not be
turned over lay flat like this
drawing.
With 3 kinds of crease
mode, even thick paper
can be turned over very
easily and lay flat after
binding.

331 Auto Creaser 15
The illustration for V mode is as following
Define the first position and crease gap and the qty in one
batch, The first page will be one line as reference, and
following sheets will be 2 creases that goes further
successively to the reference line .
In this way the book can be folded with a square back after
sandel stitched
Effect of above 4 parameters is as above drawing
While progress crease function is activated and all setting is
done, screen will jump to the main operation mode. But the screen is different,
and it has only 1 page. As follow:
Press , goes to MODE 5.Press again, goes to MODE 6
5.3.6 Save a Job
MODE 5 Save Job
Frequently used crease data can be saved and recalled, so that user don’t
have to input data each time. The system at most saves 30 jobs.
How to save a job?
a. See MODE 2, Let’s input a job, say, 10, 20, 30, 0 , 0 ,0.
b. Press 2 times, we go to Save job Mode.
M
M
M
Total sheet
Progressive depth
+ for Inc, - for Dec, ±for I & D, V for V
Initial position

331 Auto Creaser 16
c. Input a number between 1-30, say 10.It changes into
d. Press Enter, save success.
5.3.7 Recall a Job
MODE 6 Recall job
How to recall a job
a. See above steps about How to save a job, we take the saved job as a
example.
b. Press until we go to recall job mode, seeing following screen.
c. Input a number among 1-30(10 according to above example).
d. Press Enter, Recall success.
e. Screen jump to main operation MODE, and the data become 10 20 30.
Note: It is quite advisable for users to remember jobs of each number, because job will be
overwritten without any notice.
Press at Recall Job mode, It goes to MODE 7
5.3.8 Speed Screen
MODE 7 Speed
M
M
0
0
0.0

331 Auto Creaser 17
1. If you want low speed, Press 1, “*”become besides “Low”, Press Enter,
screen jump to main operation MODE, low speed is chosen.
2. If you want high speed, Press 2, “*”become besides “High”, Press Enter,
screen jump to main operation MODE, high speed is chosen.
5.3.9 Recalibration Screen
MODE 8 Recalibrate
If the Crease line gap is stretched or shirinked, the crease tolerance will be
accumulated as crease line increased. For a quick calibrate, we operate on
Recalibrate mode.
1. Measure the real length of a paper
2. Input the real length of the paper as following (say 420mm)
3. Press , machine runs.
4. Pass the paper. And the Recalibrate is done automatically.
Note: If the input date is more than 3% tolerant to the real length, it fails
5.4 Hardware Setting
5.4.1 Skew adjustment
If it is found the crease is skewed (not vertical to the paper side), you need to
adjust the feeding angle to get a satisfied performance.

331 Auto Creaser 18
Fixed side guide is the hardware where we adjust the skew.
As per above picture, the guide is fixed by 2 screw, rear one is through a slot
hole. We can loosen the screw , and move the side guide a bit, so that the
feeding direction is micro adjusted to compensate the skew issues.
5.4.2 Crease Depth
Crease depth is important to crease quality. It just depends on the gap
between male die and female die. Depth should be adjusted according to the
paper thickness. Low Depth will perform a not clear crease. But a high Depth
may cause cracking, causing system take it as a double feed.
The adjustment is also needed if the crease depth are not balance on both
sides.
To adjust the Depth:
Open the safety cover, you can see 3 Allen screws.
Turn the screw un-clockwise will increase the depth, Vice versa.
Normal
Not balanced
Too light
Too heavy
Crack edge
