Cima Link Manual

R
S.p.A.
27040 Montù Beccaria - Loc. Molino Quaroni - (PV) - ITALIA
Tel. [phone] r.a. - Fax [phone]
http://www.cima.it
®
Atomizzatori e Impolveratori
LINK
OPERATION AND
MAINTENANCE INSTRUCTION
LINK

Dear Customer, thank you very much!
We want to congratulate with you, for having
chosen a
®
sprayer.
Your choice shows the wisdom of the well-informed
Purchaser, aware of the fact, that the required
features of quality, technique and reliability must
be satisfied at the right price!
Our continuous engagement in R&D and in testing
our machines allows us to realize products able to
offer the best performances, a high reliability and
a great easiness of use at the same time !
Our first goal, is to get our Customers happy for
having met us!
The “Spare parts catalogue” of this sprayer/sprayhead is
available in the ‘“restricted area” on website www.cima.it.
In order to accede, use:
User name: sprayer
Password: 844719KE

Articulated Sprayers
Link
CIMAS.p.A.-27040MontùBeccaria-Loc.MolinoQuaroni-(PV)-ITALIA
Tel.[phone]r.a.-Fax[phone]
http://www.cima.it
OPERATION AND
MAINTENANCE INSTRUCTIONS
Model: ...................................................
Serial Number: .......................................
(PubblicazioneN°LUM-LINK-04-EN)
©CIMAS.P.A.-2001-2009 PRIVATEPROPERTY.
ANYREPRODUCTION,EVENIFPARTIAL,IS FORBIDDEN IF NOTPREVENTIVELY AUTHORIZED IN
WRITINGBYTHECIMAS.P.A.COMPANY.

1-2009
Link 50 - 55
III
LISTING OF VALID PAGES
This publication consists of 82 pages, subdivided as follows:
N°OFPAGE REVISION BASE
from I to VI 04 January 2009
from 1 to 76 04 January 2009
REGISTRAZIONI AGGIUNTE E VARIANTI
REVISION DESCRIPTION
00 First Edition, March 2001
01 Second Edition, January 2002
02 Third edition, March 2002
03 Fourth edition, July 2003
04 Fifth Edition, January 2009
05
06
07
08

Link 50 - 55
1-2009
IV
GENERAL INDEX
1 FOREWORD ............................................................................................................................ 1
1.1 PUBLICATIONIDENTIFICATION ............................................................................................... 1
1.2 ATTACHEDPUBLICATION ...................................................................................................... 1
1.3 PURPOSEOFPUBLICATION ................................................................................................... 1
1.4 REFERENCETOREGULATIONS ............................................................................................. 1
1.5 USINGTHEMANUAL .............................................................................................................. 1
1.6 UPDATES ................................................................................................................................2
2 GLOSSARY ............................................................................................................................ 3
2.1 TERMINOLOGY ....................................................................................................................... 3
2.2 ABBREVIATIONS .................................................................................................................... 3
2.3 DECALS .................................................................................................................................. 3
3 GENERALINFORMATION ..................................................................................................... 7
3.1 MACHINEIDENTIFICATION ...................................................................................................... 7
3.2 TECHNICALASSISTANCE ...................................................................................................... 7
3.3 SAFETYNOTICES ................................................................................................................... 7
3.4 SAFETYSYSTEMS ................................................................................................................. 8
3.5 HANDLINGOFAGRO-CHEMICALS ........................................................................................ 9
3.5.1 Storage ................................................................................................................................... 9
3.5.2 Specific equipment ................................................................................................................. 9
3.5.3 Disposal of empty containers and agro-chemical residues ................................................ 10
3.5.4 Personal means of protection .............................................................................................. 10
4 MACHINE’SSTRUCTURALANALYSIS ............................................................................. 11
4.1 FRAME................................................................................................................................... 12
4.2 FANSERVOAMPLIFIER........................................................................................................ 16
4.3 HYDRAULICCIRCUITCOMPONENTS ................................................................................... 17
4.4 TECHNICALDATA ................................................................................................................ 31
4.4.1 Sprayers dimensions and weights ...................................................................................... 31
4.4.2 Wheel’s: dimensions and operating pressures ................................................................... 31
4.4.3 CentrifugalpumpCIMACD32 ............................................................................................... 32
5 COUPLINGMODALITIES .................................................................................................... 33
5.1 HITCHINGTOTHETRACTOR ................................................................................................ 33
5.2 MOUNTINGOFTHETRANSMISSIONSHAFT........................................................................ 34
5.3 INSTALLATIONOFREMOTECONTROLS ............................................................................. 34

1-2009
Link 50 - 55
V
5.3.1 Electrical control panel - E10 ............................................................................................... 34
5.3.2 Manual 2-tap distributor - P9 ................................................................................................ 35
5.3.3 E.P.A.ControlUnit ................................................................................................................. 36
6 DISTRIBUTIONDEVICES ..................................................................................................... 37
7 ACCESSORIES ..................................................................................................................... 38
7.1 FILLERPIPE ........................................................................................................................... 38
7.2 ELECTRICALSWIVELLINGDEVICE ...................................................................................... 38
7.3 ROTARYBLADESHYDRAULICMIXER ................................................................................ 39
7.4 REARLIGHTKIT .................................................................................................................... 39
7.5 PRESSUREELECTRO-REGULATOR ..................................................................................... 39
7.4 E.P.A.KIT-DELIVERYPROPORTIONALADVANCEMENT .................................................. 40
8 FILLING ................................................................................................................................41
8.1 FOREWORD–USEOFTHEFANDISENGAGEMENT............................................................ 41
8.1.a Disengagement of the fan .................................................................................................... 41
8.1.b Fan engagement to perform the treatment........................................................................... 42
8.2 FILLINGTHROUGHPOURINGFROMTHETOP ..................................................................... 42
8.3 FILLINGWITHTHESPECIFICPIPE ......................................................................................... 43
9 AGITATION .......................................................................................................................... 46
10 OPERATINGPROCEDURES ................................................................................................. 46
10.1 PRELIMINARYOPERATIONSTOTREATMENT ..................................................................... 46
10.2 PREPARATORYOPERATIONSTOTREATMENT .................................................................. 47
10.3 THETREATMENT .................................................................................................................. 48
10.4 PRCEDURETOWASHTHEHYDRAULICCIRCUIT(Pump-Sprayhead) .............................. 49
10.5 ENDOFTREATMENT-STORAGE ........................................................................................ 50
10.5.1 Daily....................................................................................................................................... 50
10.5.2 End of seasonal cycle .......................................................................................................... 51
11 TANKANDHYDRAULICCIRCUITDRAINING .................................................................... 52
12 LIFTINGANDTRANSPORT ................................................................................................. 53
13 MAINTENANCEOPERATIONS ............................................................................................ 55
13.1 LUBRICATION........................................................................................................................ 55
13.2 ANSHAFTSUPPORTOILLEVELCHECK ............................................................................. 56
13.3 FANSHAFTSUPPORTOILREPLACEMENT ......................................................................... 56
13.4 CLEANINGOFFILTER’SCARTRIDGE ................................................................................... 57

Link 50 - 55
1-2009
VI
13.5 CLEANINGOFTHEFAN........................................................................................................ 57
13.6 FANBELTTENSIONER.......................................................................................................... 58
13.7 PUMPBELTTENSIONER ........................................................................................................ 58
13.8 MAINTANKFASTENINGBELTS ........................................................................................... 59
13.9 TABLEOFMAINTENANCEOPERATIONS............................................................................. 60
14 FAULTSFINDING ................................................................................................................. 61
15 REPAIRSALLOWED ............................................................................................................ 64
15.1 REPLACEMENTOFPUMPCONTROLBELT .......................................................................... 64
15.2 REPLACEMENTOFELECTRICALPANEL’SFUSES .............................................................. 65
15.3 PRESSUREGAUGEREPLACEMENT ..................................................................................... 65
15.4 INSPECTIONANDCLEANINGPUMPFILTER ......................................................................... 66
15.5 CHECKHYDRAUKICDELIVERY ........................................................................................... 67
15.6 TANKREMOVALORREPLACEMENT .................................................................................. 68
16 INTEGRATIVEDIAGRAMS .................................................................................................. 69
16.1 HYDRO-PNEUMATICDIAGRAM ............................................................................................ 69
16.2 WIRINGDIAGRAM ................................................................................................................. 73
17 NOISELEVEL ....................................................................................................................... 74
18 ATTACHMENT: DECLARATION OF COMPLIANCE.......................................................... 75
19 WARRANTY .......................................................................................................................... 76

1-2009 1
Link 50 - 55
1 FOREWORD 1
1.1 - PUBLICATION IDENTIFICATION
The“OPERATIONANDMAINTENANCEINSTRUCTIONS”manualisanintegrativepartofthesprayers.
It is identified by a Publication No. located on the frontispiece, and through which the document can
be identified, traced and/or subsequently referred to.
The information elements contained herein are updated as at the date of publication. C.I.M.A. S.p.A.
reserves the right to modify its machines without notice, with the purpose of applying technical
enhancements, and it declines all responsibility for possible omissions from the publication.All righ
reserved. No parts of this book may be reproduced or utilized in any form or by any means, electronic
or mechanical, including photocopying, recording, or by any information storage and retrieval system,
without premission in writing by C.I.M.A. S.p.A.
1.2 - ATTACHED PUBLICATIONS
— Spare parts catalogue;
— Distribution devices, “Operation and maintenance instruction”
— Distribution devices, “Spare parts catalogue”
— “Low Volume - Instructions for sprayer adjustment”
1.3 - PURPOSE OF PUBLICATION
All indications contained in this manual are aimed at the user of the sprayer.
Thedurationofthemachineanditsoperation,theoperator’ssafetyandthe respectfortheenvironment
are dependent upon scrupulous observance of the stated norms.
Before making use of the sprayer, the user must read, understand and abide by all regulations listed
in this manual.
1.4 - REFERENCE TO REGULATIONS
This manual was set out conforming to the regulations contained in following documents:
— Attachment "I" to Directive 98/37/CE and subsequent modifications (letters “b”, “c” of point 1.1.2
and point 1.7.4);
— UNI EN 907 - 1998 and to all the documents in it quoted.
1.5 - USING THE MANUAL
Read every part of this manual, paying attention to the WARNING and DANGER indications both on
the text and on the machine or on components.
All operations suggested by the manual will have to be followed with the utmost care and only after
having understood the negative consequences of improper usage.

Link 50 - 55
1-2009
2
The following “symbols “ are used within the text in order to highlight and visually identify the
importance of the various types of information:
Indicates important additional information
Non observance can result in permanent damage to the sprayer.
Highlights possibly dangerous situations to people.
The manual, with relevant attachments and possible integrating issues, must be kept with the utmost
careand mustalways becomplete, integerand legiblein everypart. Shouldit bemislaid itis imperative
to immediately request a duplicate from C.I.M.A. S.p.A. Should the decals originally applied on the
machine be mislaid, damaged or become incomprehensible, they should be
promptly replaced.
For every type of distribution device (Sprayhead) delivered with the sprayer, a specific user and
maintenancemanualisattached.Alltheheadmanualsmustalwaysaccompanytheoneofthemachine.
- The manual must always be kept for the sprayer’s whole operational life.
- Any modification received must be permanently inserted in this publication.
- The manual must be ceded with the sprayer should this be sold.
1.6 - UPDATES
Possible updates that C.I.M.A. S.p.A. will provide the owner of the sprayer will be accompanied by
instructions to insert in this publication.
Should the machine be sold, the owner must inform the new purchaser that he should notify C.I.M.A
S.p.A. of his address in order to receive possible future integrating issues and/or updates.

1-2009 3
Link 50 - 55
2 GLOSSARY 2
2.1- TERMINOLOGY
The terms FRONT, REAR, RIGHT and LEFT utilised in this publication refer to the sprayer as seen by
anoperatorfrombehindtheoperativeunitalongthedrivelineandfacingit:the rear part ofthemachine
is that closest to the operator, and is where the distribution device (Sprayhead) is mounted - and the
front part is the one that gets attached to the tractor.
2.2 - ABBREVIATIONS
cm .....................................................................................................................................centimetres
g..................................................................................................................................................grams
h.................................................................................................................................................... hour
ha............................................................................................................................................. hectare
ha/h .......................................................................................................................... hectare per hour
l..................................................................................................................................................... litres
l/h................................................................................................................................... litres per hour
l/min........................................................................................................................... litres per minute
kg ............................................................................................................................................kilogram
kg/cm2..................................................................... kilograms per square centimeter (atmosphere)
km..........................................................................................................................................kilometre
km/h .................................................................................................................... kilometres per hour
Lm...............................................................................................................................width in metres
m.................................................................................................................................................metre
Mesh .................................................................................................... N° of meshes per linear inch
Micron ................................................................................................................. 1/1000 of millimetre
mm...................................................................................................................................... millimetres
PTO.............................................................................................................................. power take-off
RPM ............................................................................................................................ revs per minute
s..............................................................................................................................................seconds
2.3 - DECALS
The safety and use/maintenance decals are applied to the machine are described in the following paragraph.
Every decal is marked with its part number, in case it needs to be replaced.
Safety
1 - 95001 - STOPTHEENGINEANDREMOVETHEKEYFROMTHETRACTOR’SCONTROLPANEL
BEFORECARRYINGOUTALLMAINTENANCEORREPAIROPERATIONS
-Positioned on the left-side of the fan servo amplifier frame.
2 - 95004 - DANGEROFCONTAMINATIONBYCONTACTORPOISONOUSPRODUCTSINHALA-
TION
-Positioned on the left-side of the tank near the main filler.

Link 50 - 55
1-2009
4
3 - 95005 - DANGER,PARTSINMOTION.BEFOREREMOVINGPROTECTIONGUARDS,STOP
THETRACTOR,REMOVETHEKEYFROMTHETRACTOR’SCONTROLPANELAND
ENSURE THAT ALL MOVING PARTS HAVE STOPPED
- Positioned on the fan casing next to the outflow vent.
4 - 95008 - CAUTION:NOHAND-WASHINGTANK
Positioned on the protection case of themechanical parts, under the hand-washing tank:
this is visible when this tank has been removed.
5 - 95015 - BEFOREUTILISINGTHERELEASEDEVICE,STOPTHETRACTOR,REMOVETHEKEY
FROM THE TRACTOR’S CONTROL PANEL AND ENSURE THAT THE FAN HAS
STOPPED
- Positioned on the mobile protection cover of the access to the release device.
6 -95010 - MAXIMUM OPERATING SPEED OF THE DRIVE OUTLET (PTO): 540 RPM
- Positioned near the drive outlet.
7 - 95007 - DANGEROFSPRAYS:KEEPATASAFEDISTANCE
- Positioned on the upper part of the fan casing.
8 - 95006 - ATTENZIONE: CWARNING: CONSULT THE USE AND MAINTENANCE MANUAL
BEFOREUSINGORINTERVENINGONTHEMACHINE
-Positioned on the left hand side of the tank near the main filler.
9 - 95009 - DANGER:GLOVESMUSTBEUSEDTOEMPTYTHETANK
-Positioned on the left hand side of the sprayer near the lever tap with discarge fitting.
10 - 95077 - ITISFORBIDDENTOENTERINTOTHETANK!
Positioned on the left hand side of the tank near the main filler.
Use and maintenance
11 - 95079 - CHECKTHEOILLEVELEVERY8HOURS:FANSHAFTBEARINGS
- Positioned on forward of the chassis, near the oil level dipstick
12 - 95054 - GREASEEVERY200HOURS:FANTIGHTENERSUPPORT,FREEWHEEL,WHEELHUBS
ANDARTICULATEDJOINTS
- Positioned on the right front side frame
- Positioned in the front section, near the PTO.
- Positioned on the wheel
- On the frame, near the articulated joint.
13 - 95057 - HANDWASHINGTANKTAP
-Mark on the left-hand side of the tank, next to the tap..
14 - 95065 - WARNING:NEVEROPERATETHESPRAYERWITHOUTLIQUIDINTHETANK
-Positioned on the left hand side of the tank near the main filler.
15 - 95060 - INDICATIONOFTHEWHEELSOPERATINGPRESSURE
95056 - Positioned on the frame left and right rear sections.
16 - 95080 - INDICATION ON THE OPERATION OF THE 3-WAY TAP (P3)
- Positioned on the frame on the left side, near the cock (P3).
17 - 95094 - INDICATION ON THE OPERATION OF THE TAP (P18)
- Positionedonthe frame right side,near theadditional pump(P10)(fortheversion where
foreseen).
18 - 95086 - INDICATIONS ONTHE OPERATION OF THE PLANT-WASHING TAP (P15)
- Positioned on the frame left side, near the tap (for the versions where foreseen).
19 - 95059 - HOOKINGPOINTFORTHELIFTINGOFTHEMACHINE
- One positioned on the front side of the sprayer and two onthe rear side of the frame
near the fastening brackets.

1-2009 5
Link 50 - 55
Positioning of the safety, use and maintenance decals
L
ink S50
L
ink S50
basso volume
basso volume
100
200
300
400
500
600
700
800
LT
L
ink S 50
basso volume
basso volume
L
ink S 50
L
ink S50
basso volume
basso volume
®
+
-
ONON
OFFOFF
Spin RemoteControl
HO
2
Press.
Pump
1
2
8
14
73
4
11
12 12 15
10
12
13
5
16 9
18*
6
5
19
19
1
12
00320
00321
00322
NOTE: The numbers with the
asterisk (*) indicate the
adhesives relevant either
to optional components
or to accessories to be
applied ONLY on the
models and versions on
which this is foreseen.
17*

Link 50 - 55
1-2009
6
* Safety decals
* Use and maintenance decals
1 95001
00042
2 95004 3 95005
00043
00044
5 95015 6 95010
7 95007 8 95006 9 95009
00045 00046
00047 00048 00049
12 95054
13 95057 14 95065
00065
00069
00067
4 95008
00199
15 95056
10 95077
00284
15 95060
00283
11 95079
OIL MAX
MIN
8h
CONTROLLARE
CHECK
CONTRÔLER
CONTROLAR
95079
00282
19 95059
00062
COLLEGAMENTO / SCOLLEGAMENTO TUBO RIEMP .
CONNECTION / DISCONNECTION FILLING PIPE
CONNEXION / DECONNEXION TUYAU DE REMPL
.
CONEXION / DESCONEXION TUBO DE CARGA
C
A
POSIZIONE LAVORO
WORK POSITION
POSITION DU TRAVAIL
POSICION DE TRABAJO
SVUOTAMENTO SERBAT./POMPA
TANK & PUMP DRAINING
DRENAJE DE TANQUE Y BOMBA
VIDAGE CUVE ET POMPE
B
16 95080
00987
12
95094
cima
17* 95094
00319
LAVAGGIO CLEANING NETTOYAGE LIMPIEZA
HO
2
2-WAYS
x
3-WAYS
95086
®
18 95086

1-2009 7
Link 50 - 55
3 GENERAL INFORMATION 3
3.1 - MACHINE IDENTIFICATION
3.2 - TECHNICAL ASSISTANCE
C.I.M.A. S.p.A. is at the complete disposal of customers for any type of intervention. The names and
addresses of its service network, both in Italy and in foreign countries, can be requested from:
C.I.M.A. S.p.A. - 27040 Montù Beccaria - Loc. Molino Quaroni (PV) - ITALIA
tel. [phone] - fax [phone]
e.mail [email protected]
3.3 - SAFETY NOTICES
All the preparation, use, maintenance, moving and transporting operations must be carried out only
afterhaving acquireda perfectknowledge of theregulations containedin thispublication and theability
to appropriately interpret the symbols of the decals applied to the machine.
IT IS FORBIDDEN TO UTILISE THE SPRAYER FOR PURPOSES OTHER THAN FOR ITS
INTENDEDUSE,SINCEITWASMANUFACTUREDONLYFORSPRAYINGAGRICULTURAL
CROPS WITH ANTI-PARASITIC PRODUCTS.
It is necessary to scrupulously abide by the following general norms:
— always stop the tractor’s engine before carrying out any operation on the sprayer;
— check that the weight and power of the tractor are compatible with the sprayer to be used;
— before utilisation, check the correct tightening and securing of the machine’s various components,
paying particular attention to the safety protections and to the moving parts;
— only utilise protected cardan shafts provided with CE conformity certification.
Carry out the assembly only if the drive outlets of both tractor and sprayer are equipped with the
protection counter-guard;
— check that the cardan shaft is blocked by the appropriate anti-rotation chains;
— keep people and animals away from the machine before starting it up;
— don’t wear articles of clothing that might get caught in moving parts;
— keep to a low speed while negotiating bumps or crossing ditches.
00323
00070 Identification nameplate
ink S 50
ink S 50
basso volume
basso volume
100
100
200
200
300
300
400
400
500
600
600
700
700
800
800
LT

Link 50 - 55
1-2009
8
- All maintenance and repair operations must be carried out only after having
rinsed the tank and flushed the system.
- Before operating within the tank it is necessary to wash it thoroughly with clean
water.
- It is forbidden to perform welding operations if ammonium salts were previously
used.
- It is forbidden to use the machine within a potentially explosive environment.
-The application of paints and/or solvents, the washing of closed environments
and machinery as well as the utilisation of the air flow for purposes other than
those expressly concerning the spraying of agro-chemicals is not permitted.
- It is forbidden to enter the tank.
3.4 - SAFETY SYSTEMS
All machine moving parts are suitably protected by guards and highlighted through the use of warning
decals.
- It is forbidden to use the machine with these guards removed.
- Before removing the protection, stop the tractor’s engine and remove the key
from the control panel.
he pictures illustrate the machine’s guarded parts:
PTO PROTECTION
CASING
FAN
PROTECTION
GRILL
PROTECTIONCOVER
FOR FAN
SERVO AMPLIFIER
1005
L
ink S 50
L
ink S50
basso volume
basso volume
®
+
-
ONON
OFFOFF
Spin RemoteControl
HO
2
Press.
Pump
L
ink S 50
basso volume
basso volume
REMOVABLEPROTECTION
COVER FOR THE FAN
SWITCHING-OFF DEVICE
(For versions in which
this is envisaged)

1-2009 9
Link 50 - 55
THEOWNERAND/ORTHEOPERATOROFTHESPRAYERARENOTPERMITTEDTOMODIFY
THESTRUCTUREORTHESPECIFICOPERATIONOFTHESPRAYERITSELF.ANYREPAIR-
ING INTERVENTION HAS TO BE CARRIED OUT EITHER AT THE DEALERS’ OR AT THE
C.I.M.A. S.p.A. AUTHORIZED WORKSHOPS, OTHERWISE ANY KIND OF WARRANTY
IMMEDIATELYCEASESANDC.I.M.A.S.p.A.ISCLEAREDOFANYCONSEQUENTAND/OR
IMPLIEDRESPONSIBILITY.
3.5 - HANDLING OF AGRO-CHEMICALS
The operator could become contaminated due to accidental spray, contact or inhalation of products
or crop-spraying mixtures.
The environment could become polluted by mixture over-spills, puncturing of containers, uncon-
trolled storage of used and unwashed containers or spillage into waterworks.
In order to avoid these risks the preparation and filling operations must be carried out in suitably
appointed and adequately equipped sites.
3.5.1 - Storage
Fixed / stationary: the site used must be well ventilated and secured by lockable doors in order to
prevent even accidental access by children or unauthorised persons.
Mobile: the carrier equipment must be properly locked and kept under conditions whereby access
by children or unauthorised persons can be prevented during the absence of the operator. All full or
partially utilised containers must be secured against tipping, falling or breakage during transportation.
Both types of storage must:
— have a suitable container for the storing of empty packaging materials should a specific storage
area not be available;
— have a clean water supply readily available for washing, by means of a specific container or
through connection to the waterworks system;
— have the use of fire extinguishers, should flammable products and substances be stored.
- All packages, whether whole or partially utilised, must be stored in their original
packing and with the warning instructions clearly displayed and legible.
- The storage indications must always be scrupulously adhered to, as well as their
utilisation and possible disposal as suggested on the product’s original
packaging.
3.5.2 - Specific equipment
The site at which the preparation and filling out will take place must provide for:
— all the equipment necessary to the precise measuring of both the water quantity and the dose of
product to be mixed in the tank at every filling;
— all the equipment and means useful to the preparation of the mixture and for the cleaning of the
operator in case of contamination;
— all tools necessary to facilitate the direct introduction of the agro-chemicals in the tank;
— the allocation of clothing and specific equipment in order to avoid contamination by contact or
inhalation during the whole operative phase of the intervention;
— theavailability of proper equipment able to stopthe uncontrolled spilling and flowing of themixture;
— a retaining valve on the feed pipe when the filling of the tank takes place directly from the
waterworks system.

Link 50 - 55
1-2009
10
3.5.3 - Disposal of empty containers and agro-chemicals residues
Agro-chemicals are classified as “special” waste and their disposal must take place separately from
“urban” wastes.
Empty packaging and contaminated containers to be done away with cannot be
dispersed, burned or buried.
The washing water for the cisterns and the tools utilised for the preparation of
mixtures cannot be emptied on the ground, spilled into the sewage system or in
waterways and rivers.
The disposal of special wastes is regulated by specific norms. In order to perform this operation it is
necessary to obtain the relevant information from the Local Offices specifically appointed to rule on
this subject. The non compliance with these regulations can cause considerable damage to persons
and animals as well as polluting the environment.
3.5.4 - Personal means of protection
The toxicity of agro-chemicals forces persons working with them to wear adequate protective clothing
and accessories in order to avoid risks of contamination by contact or inhalation.
In each of the following work stages:
— filling of tanks and adding of the agro-chemical,
— dusting and spraying,
— adjusting of the sprayer,
— emptying and cleaning of the tank,
— replacement of the agro-chemical,
— maintenance interventions,
it is necessary to wear personal protection cloth-
ing and accessories.
The following must be worn:
— Polyethylene or polyvinyl gloves.
— Full, waterproof cotton overalls, in order to
guarantee transpiration, fitted with polypro-
pylene side flaps.
In commerce, one-time ‘tyvek’ overalls are
available which, after use (see picture), must
be disposed of according to the modalities
applicable to toxic waste.
— A protective half-mask in polychloroprene
rubber with 1 or 2 filters. Filters for gases and organic fumes, of European A1-class vapours, are
envisaged and these can be combined with anti-dust models of P1 European class, for harmful
mists and powders, or P2, for harmful and toxic mists and powders.
The filters must be replaced:
- when the smell/taste of agro-chemicals can be detected, and that of active A1-
class carbons;
- when difficulty in breathing is experienced for the anti-dust filters of class P1 and P2.
In any case it is necessary to make use of all personal means of protection as
suggested by the manufacturers.
00073

1-2009 11
Link 50 - 55
L
inkS50
L
ink S50
basso volume
basso volume
®
+
-
ON ON
OFF OFF
Spin RemoteControl
HO
2
Press.
Pump
L
ink S 50
basso volume
basso volume
4 MACHINE’S STRUCTURAL ANALYSIS 4
The pictures indicate the position of the main components of the sprayer.
00324
00322
PRESSURE
REGULATOR
MAIN
TANK
MAIN
FILLER (BP)
HAND WASHING
TANK (*)
PRESSURE
GAUGE
REAR
FRAME
TANK LEVEL
INDICATOR
BEARING
FEET
PTO
PROTECTION
CASING
SECONDARY
FILLER (BS)
PUMP
FORWARD
FRAME
JOINING
ELBOW
CENTRIFUGAL
FAN
AXLE
PNEUMATICAGITATOR
PLUNGERTAP
ELECTRICAL
DISTRIBUTOR (*) DELIVERY
FILTER
MANUAL
DISTRIBUTOR
00204
ADDITIONAL
AGITATION
PUMP (*)
(*) For versions
in which this
is envisaged
HAND WASHING
TANK

Link 50 - 55
1-2009
12
4.1 FRAME
The LINK trailer-mounted sprayer frame consists of two sections: the front section, supporting the
fan-servo amplifier unit, and the rear one, supporting the tank.
FRAME FRONT
SECTION
FRAME
REAR SECTION
The connection between the frame two sections is realized by means of a special articulated joint,
whichisintegral withthe framefront sectionand assuresa completelyfreemovement toboth theframe
sections.
The front section is directly coupled with the three points-hydraulic hoisting device of the tractor.
The Link 50 e 55 range frames can be coupled with the hydraulic hoisting devices of class “2”.
The piston pins’ diameter measures 28,5 mm. The third point pin diameter measures 25 mm.
00262 00263
00264
ARTICULATED
JOINT
00259
SUPPORT
FOOT
