Dunraven APOLLO SMART User manual

9-5565-01
APOLLO SMART PRODUCT MANUAL
1) INTRODUCTION
Thank you for selecting the Apollo Smart Heating Oil Energy Monitor. This revolutionary
home energy monitoring system allows today’s energy and environmentally conscious
consumers to monitor and track their heating oil consumption, its costs, and the heating
systems environmental impact through carbon emissions, on a daily, weekly, monthly,
and annual basis.
The Apollo Smart product from Dunraven Systems consists of the Apollo Smart
Transmitter and the Apollo Smart Monitor. The Apollo Smart Transmitter is easily
installed on your oil storage tank to measure the level of the oil. It transmits the oil level
information wirelessly to the Apollo Smart Monitor which may be located in a convenient
location inside your home.
The Apollo Smart Transmitter uses ultrasonic technology to measure the distance from the
Transmitter on top of the tank to the surface of the liquid in your oil tank. As the amount of
oil in your tank decreases the distance measured increases accordingly. The distance
information or ‘ullage’ is transmitted wirelessly to the Apollo Smart Monitor.
Litres and % fuel
Once programmed with information about your oil tank’s shape and size, the Apollo Smart
Monitor calculates and displays the amount of fuel remaining in your tank in litres or as a
percentage of the tank capacity. In addition (as oil is consumed over time) the Apollo Smart
Monitor calculates and displays usage information including the average amount of litres
used per day, per week, over the last 30 days, and over the last 365 days
Days to Empty (DTE)
As the Apollo Smart Transmitter continuously measures and transmits the oil level, the Apollo
Smart Monitor retains this information allowing it to ‘learn’ historical heating system usage
patterns and so predict the ‘Days to Empty’ for your home. With this information you can
ensure that you order your oil at the correct time –not too soon, and more importantly, not
too late.
Costs
By entering the cost you pay for your oil during the setup process of your Apollo Smart
Monitor and subsequently when you take deliveries of oil (if the price has changed), the
Apollo Smart can present your oil usage in terms of its costs, i.e. average cost per day and per
week, and the cost for the usage over the last 30 days and 365 days.
Environment
Similarly, the Apollo Smart Monitor can display your oil usage in terms of the associated
production of CO2emissions, as the equivalent quantity of KgCO2emitted per day, per week,
the last 30 days and 365 days.
The Apollo Smart Transmitter fits into the standard 32mm aperture found on most modern oil
storage tanks and is suitable for use with almost any plastic or metal tank up to 3m tall,
including Bunded and Single Skin Oil tanks. If your tank is a bunded tank, ensure that you
mount the Apollo Smart Transmitter on the inner tank.
As part of the installation the Apollo Smart Transmitter and Monitor are ‘synchronised’
together to ensure there is no interference from other nearby transmitters.

9-5565-01
11
8
913
10
12 14
1
23456
7
15
16
17
18
19
20
Apollo Smart features
1 LCD Display 11 Error code information
2 MODE key 12 Power/data cable
3 DOWN key 13 Manufacturing information
4 ENTER key 14
Location feature (see STEP 3 of the installation guide)
5 UP Key 15 USB connector
6 SETUP Key 16 Mains power plug
7 Alarm Red LED 17 Apollo Smart Transmitter
8 Wall mount feature 18 Self-tapping screws x 2
9 Beeper aperture 19 Weather seal (Gasket)
10
RESET access (pressing reset
erases all historical data.
20 Apollo Smart Transmitter oil level display
TANK TYPE
Indicates the Tank Type being selected
A, B, C
A, B, C are types of tank shapes (see diagrams in section 5)
ROOM TEMPERATURE
The value displayed is the Room Temperature
20
3
Numeric display - Shows the Room Temperature in normal mode e.g 20.
Shows the Setup mode number when in setup mode, e.g. SETUP mode 3
°C
The value displayed is temperature in degrees Celcius
cm
The value displayed is in centimetres
SETUP
Setup mode is active
H
The value displayed is the tank height
W
The value displayed is the tank width
Apollo Smart Monitor Display:
Bargraph indicator of liquid level - each bar represents 10% of tank height
Apollo Smart Transmitter Display:
Tanks 1m in height or greater - each bar represents 1/10th of the top meter of the tank.
Tanks less than 1m in height - each bar represents 1/10th of a metre
FULL
Indicates the 'Full' level of the bargraph indicator
LIQUID LEVEL
Indicates the bargraph is showing the liquid level
EMPTY
Indicates the 'Empty' level of the bargraph indicator
BUND ALARM
When flashing there has been a leak into the 'Bund' (double skinned tanks).
The 10 bars and the RED LED will also be flashing at the same time.
TANK LOW BATTERY
The Apollo Smart Transmitter battery needs to be changed.
Flashing - The remaining liquid level in the tank is at 10% or below of tank height.
(Appears on both the Apollo Smart Monitor and Transmitter)
£
The value displayed is in Sterling pounds
€
The value displayed is in Euro
%
The value displayed is the % of usable oil remaining in the tank.
675
---
Numeric display - used to show numeric values and the time.
A numeric value is not available to be displayed when '---' is shown.
KgCO2The value displayed is of Kg of CO2 (carbon emissions)
cm
The value displayed is in centimetres
Ltr.
The value displayed is in Litres
/ (Ltr.)
The value displayed is per (litre)
USB data activity.
AVERAGE PER DAY
The value displayed is the average per day based on the last 7 days usage
AVERAGE PER WEEK
The value displayed is the average per week based on the last 14 days usage
DAYS TO EMPTY
The value displayed is the estimated number of days of oil remaining in the tank. It is
computed by dividing the volume of usable oil left in the tank by the current daily
average use.
LAST 30 DAYS
The value displayed is the estimated usage over the last 30 days
LAST 365 DAYS
The value displayed is the estimated usage over the last 365 days
Apollo Smart Monitor and Transmitter Display Symbol reference
The temperature is close to or below the limit of operation of the Apollo Smart
Transmitter - the information accuracy may be affected.
3
1
Flashing - There is a problem with the RF signal from the Apollo Smart Transmitter.
(Appears on both the Apollo Smart Monitor and Transmitter)
2
MODE
When in NORMAL mode press MODE to move between the current and the historical information screens.
r
Press UP to move between screens when in NORMAL mode.
Use it to increase a setting when in SETUP mode.
ENTER
The ENTER key is used only in SETUP mode. It is used to save the setting shown on the display and then move
automatically to the next SETUP number.
s
Press DOWN to move between screens when in NORMAL mode.
Use it to decrease a setting when in SETUP mode.
SETUP
Press SETUP for 3 seconds to enter SETUP. When in SETUP, press SETUP to exit from SETUP mode.
sr
When in NORMAL mode, by pressing together and releasing, the screen will flash the current tank
configuration for 20 seconds. Press any key to return to NORMAL mode.
Apollo Smart Key Functions
+
2) APOLLO SMART –FEATURES AND FUNCTIONS
LED
The red light above the ENTER key flashes when there is an Alarm condition (see section 6) and on
receiving an RF signal from the Apollo Smart Transmitter
DISPLAY - SYMBOLS & INDICATORS
The Apollo Smart contains a display that conveys a variety of information during
normal use and during its initial setup and configuration for use with your oil
tank. The display contains three sections (1, 2, & 3) as indicated:
1- Used for SETUP and displays SETUP number, and in normal use displays room temperature.
2- Tank information including a visual bar-graph of the oil level in the tank.
3- Information about the remaining usable oil in litres or as a %, the ‘Days to Empty’, and the average
and cumulative use of oil in litres, cost and KgCO2. Time is also displayed here.

9-5565-01
Ullage
The distance from the Apollo Smart Transmitter to the surface of the liquid in the tank.
Outlet
The connection point from which oil is drawn from your tank to feed to your boiler. It is typically located 8 cm
above the bottom of your tank in one of the sidewalls. Oil below the outlet level is not usable. For Top
Discharge tanks, the feed point is typically located at 8cm above the bottom of the tank.
Vent
A small chimney like feature on the top of your tank. It allows the air within the tank to be released when the
tank is being filled.
Brimful Tank Capacity
The maximum amount of liquid that can fit in the tank.
Nominal Tank Capacity
Normally 95% of the brimful capacity. This is the maximum amount to which your tank should be filled
according to OFTEC and EN standards.
Usable Capacity
The nominal capacity of the tank minus the amount of oil that is below the outlet or discharge point. If the oil
level falls to the level of the outlet, your tank is effectively empty.
Matching
The process of uniquely matching the Apollo Smart Transmitter with the Apollo Smart Monitor.
Days to Empty (DTE)
A prediction of the number of days in which the oil level will reach the outlet or the discharge point. The DTE
is calculated based on the your recent usage patterns.
RF
Radio Frequency - the tank level measurements are conveyed wirelessly to the Apollo Smart Monitor from the
Apollo Smart Transmitter using RF transmissions
KgCO2Kilogrammes of Carbon dioxide.
SETUP mode
SETUP mode is used to configure the Apollo Smart Monitor for your oil tank.
LEARN mode
LEARN mode is used to match the Apollo Smart Transmitter with the Apollo Smart Monitor
NORMAL mode
NORMAL mode is for day to day use of your APOLLO SMART. In this mode it displays current and historical
information.
CURRENT information
screens
Screens in NORMAL mode that display information about the current status of the amount of oil remaining in
your tank in Litres, as a %, and the DTE.
HISTORICAL information
screens
Screens in NORMAL mode that display information about your historical usage of oil in terms of litres, cost,
and environmental impact.
3) PRODUCT INFORMATION
a) DEFINITIONS/GLOSSARY
b) TECHNICAL SPECIFICATIONS
Tank Size
Minimum Depth : 0.5m
Maximum Depth: 3m
Display
Multi-function LCD display including:
10 bar-graph level indication on both Apollo Smart
Monitor and Transmitter*
Display of various current and historical values (Apollo
Smart Monitor only)
Display control with five control buttons.
Red LED for low level indication at 5% or less of usable fuel
remaining.
Audible alarm sounds every hour on the hour when the tank
level is low.
Max communication distance
Typically 150m in normal ‘line of sight’ conditions
Power Supply
Apollo Smart Transmitter - Transmitter: 3V LiMn cell, CR2450
Apollo Smart Monitor - Receiver: 5V DC (40mA)
Apollo Smart Monitor –Back up battery: 3V LiMn cell, CR2450
Mains Power Supply (included) for Apollo Smart Monitor
150V-240V, 50-60 Hz, meets EN60335
Battery Life
Apollo Smart Transmitter: 5 years (estimated life)
Apollo Smart Monitor –Receiver memory back-up battery: 3yr
if device is not plugged in**
Wireless com:
433MHz FM transmission (EN300-220)
Dimensions
Apollo Smart Transmitter: 140m x 70mm x 40mm
Apollo Smart Monitor: 120mm x 90mm x 50mm
Max and Min Operation (Transmitter)
Operating temperature range: -10°C to +60°C
Operating Humidity : 0 -95% non-condensing
Hole size for fitting transmitter:
32mm diameter
* The Apollo Smart Transmitter and Apollo Smart Monitor bar-graph displays may
differ (see Display symbol reference table).
** This device contains a small battery to keep time during power cuts. If the device
is left unpowered for an extended period then the battery will deplete.
c) Notes:
Please retain this product manual and the installation guide. It
contains practical instructions, technical specifications and safety
precaution warnings you should know about.
The technical specifications for the Apollo Smart, the contents of
this manual and the images herein are subject to change without
notice.
The contents and images in this manual are subject to copyright
and may not be reproduced without the permission of Dunraven
Systems Limited.
When used according to recommendations, the Apollo Smart
monitors the oil level in your tank and calculates
and presents figures relating to the remaining oil, the historical
usage, and the related monetary and environmental costs. The
Apollo Smart must not be used as verification of a ‘Weights and
Measures’certified dispensing meter.
Patents pending or covered by one of the following patents:
S2003/0882, EP2131164 (A1), US2006261966 (A1),
US7277020 (B2), IE20030882 (A2) , S2008/0466,
US2009/0303059 A1

9-5565-01
Press rand s
The Apollo Smart Monitor is intended to be connected to a
power source continuously. It contains a small battery to keep
time during power cuts. If the Apollo Smart Monitor is left
unpowered for an extended period then the battery will deplete
and information may be lost. When you are not using your
domestic oil heating system, you may unplug the Apollo Smart
and store it until you wish to use your heating again. Its back-up
battery and internal clock keep track of the days as they pass.
When you next use it, on starting to use your heating again, the
Apollo Smart will continue monitoring your oil usage, and
calculating the financial cost and environmental impact.
When the Apollo Smart has been unplugged and is plugged in
again, it will start up in ‘Lrn’ mode. Simply press any key to exit.
When you are receiving an oil fill, the Apollo Smart Transmitter
cannot receive a reliable echo due to turbulence within the tank
and may cause the Apollo Smart Monitor to temporarily display
some error messages. Should the tank be filled above the
recommended 95% this will obstruct the transmitter signal until
the oil level drops below 120mm from the transmitter. The
transmitter will be unable to send accurate readings during this
period.
The Apollo Smart owner should note that the first fill amount of
oil into a tank will differ from the amount shown on the display.
This is due to the fact that the Apollo Smart Monitor displays the
volume of Usable oil available. The Apollo Smart Monitor in its
calculations makes an allowance of 8cm of unusable oil in the
bottom of the tank due to the location of the bottom outlet or
the top discharge pipe.
Not suitable for pressurised containers. Only use on tanks
vented to the atmosphere.
Only access the Reset Switch if instructed by customer service.
Pressing the reset will erase all historical data.
Changes in temperature can result in contraction and expansion
of the tank and hence can affect the tank capacity. Such changes
may affect your readings.
d) GENERAL PRODUCT SAFETY, CARE AND USE GUIDE LINES
To ensure that you use your product correctly and safely, please
read the warnings, safety precautions and notes below
regarding use of and caring for your Apollo Smart Monitor and
Transmitter.
Do not use this product where the use of radio frequency
products can cause malfunction in the control devices of other
equipment i.e. hospitals, aircraft, etc
Do not subject the product to excessive force, shock, dust,
temperature or humidity.
The LCD panel behind the display lens is made of glass, and may
break if the unit is dropped, impacted or subjected to shock.
Take special care when handling a damaged display, as the
liquid crystals can be harmful to your health.
Keep the product away from heat sources i.e. radiators, stoves,
heaters, etc
Do not use the Apollo Smart Monitor in or near water or
in high moisture areas i.e. Bathroom
Do not tamper with the Apollo Smart Monitor’s internal
components. This will invalidate the warranty.
Do not attempt to repair the product yourself. Contact
the retailer or our Customer Service Department.
Do not dispose of old batteries as unsorted municipal
waste, do so in accordance with your local waste disposal
regulations.
When disposing of this product do so in accordance with
your local waste disposal regulations
Do not scratch hard objects against the Apollo Smart
display as this may cause damage
Do not replace batteries in a potentially explosive
atmosphere.
4) DISPLAY SCREENS
There are two types of information displayed on the Apollo Smart Monitor:
CURRENT information screens–used in normal mode to show the current status of the oil level in your tank. Change between the
‘Ltr.’, ‘%’, ‘Days to empty’, and Clock screens using the rand skeys.
For approximately 1 week after the Apollo Smart is installed, it collects data so that the ‘Average per day’ value may be calculated. During
this period the screen will flash ‘---‘when showing ‘Days to empty’. (In the picture ‘flashing’ is indicated by the red circle).
After the 1 week period has passed, the display may continue to show ‘---‘ (but not flashing). This
indicates that a meaningful value could not be calculated. This may occur in periods when there is no (or
extremely low) usage. The ‘---‘ may be displayed in any of the HISTORICAL information screens under
these conditions.
The screen may also show ‘---‘if the Apollo Smart Monitor had been unplugged for some time. In this
case ‘---‘ means that it has no recent reading from the transmitter with which to display a value on the

9-5565-01
Fuel cost: Avg./day Fuel cost: Avg./week Fuel cost: Last 30 days Fuel cost: Last 365 days
Press rand s
screen. Depending on how long it has been unplugged the screen will revert to normal after a period from a few hours up to a maximum
of 1 week.
HISTORICAL information screens showing ‘Fuel usage –Litres’, ‘Fuel usage –Cost’and ‘Fuel Usage –Carbon’. Presssing MODE and
r/saccesses these screens.
‘MODE’ presses
CURRENT –fuel remaining HISTORICAL –Fuel: Avg./day HISTORICAL –Cost: Avg./day HISTORICAL –Carbon: Avg./day CURRENT –fuel remaining
The Apollo Smart Monitor will automatically return to the CURRENT information screen after 30s with no key presses within the
HISTORICAL information screens.
5. APOLLO SMART - TANK SETUP
To calculate the volume in your tank the Apollo Smart Monitor
needs to know the shape of your tank. There are three basic
shapes as illustrated. Identify the shape that is closest to the
shape of your tank. Each Apollo Smart Monitor is supplied with
the default settings as shown. The Apollo Smart Monitor must
then be configured to your own tank’s dimensions (see
installation guide). Minimum and maximum allowable values for
tank dimensions are shown in this table.
6. APOLLO SMART LEVEL ALARMS/INDICATIONS
When the level in your tank is below 12 cm from the top of the tank, i.e. bottom
of the Apollo Smart Transmitter, the main display will show ‘FULL’. This will
occur when there are 10 bars showing on the bar-graph.
When the tank level falls to within 14cm of the bottom of the tank the ‘bowser’
symbol will flash.
When the tank level is such that there is below 10% of the usable volume of oil left in the tank,
the CURRENT information screen alternates between showing the ‘Ltr.’ (or % or DTE) and ‘LO’.
If the level then drops such that there is below 5% of usable oil left:
’LO’ is displayed constantly on the CURRENT information screens.
The buzzer sounds 5 times an hour at the top of the hour, i.e. 10:00, 11:00, 12:00, 13:00,
14:00...
The RED light flashes. This continues until there is an oil delivery and the level rises.

9-5565-01
Error Description Suggested remedy
• Check the transmitter is vertical on the tank.
• Check positioning of the transmitter (ensure the transmitter is not too close
to the tank sides or internal obstructions).
• Ensure that the transmitter is not too tightly attached to the tank.
• Ensure that the tank is not overfilled and that the bottom of the transmitter
is clean.
• Check the transmitter is within range of the monitor. Try and relocate the
monitor to a position that is nearer a window, remember that the transmitter
communicates with the monitor by use of an FM signal and moving the
monitor from possible metal obstructions can improve the signal
• Check that there is no metal object such as a van, truck or that there is
nothing in the fabric of the building, that may deflect the signal. Wait for an
hour to see if you have a new reading.
• Ensure the monitor is not too close or obstructed by other electrical
appliances.
• Check positioning of the transmitter (ensure the transmitter is not too close
to the tank sides or internal obstructions).
• Ensure that the transmitter is not too tightly attached to the tank.
• Ensure that the tank i s not overfi lled i.e. there is a minimum of 120mm free
space between the transmitter and oil level.
• Ensure the bottom of sensor is clean.
• If a bund tank, ensure the transmitter is located on the inner tank.
E04 Received Reading greater than tank height
• Check the tank height and ensure this information is correct on the monitor,
press the rand skeys together to view your tank configuration. If
height is incorrect, enter the setup mode by pressing SETUP for 3 secs, press
ENTER until you reach screen 5 and adjust the height by using rand s
keys. Press ENTER to save. Press SETUP to exit Setup mode. Await 3 hours for
updated readings.
• Check the transmitter is vertical and positioning of the transmitter (ensure
the transmitter is not too close to the tank sides or internal obstructions
E05 Contact Vendor • This is a hardware fault and requires contact with the vendor
E06 Contact Vendor • This is a hardware fault and requires contact with the vendor
E01
Received reading is inconsistent
E02
Received Reading not received after 6 hours
E03
Received Reading received but void
7. APOLLO SMART TRANSMITTER BATTERY CHANGE
If the battery in the Apollo Smart Transmitter needs to be changed the display will provide advance warning
by showing the ‘TANK LOW BATTERY’ text below the bar-graph.
-Remove the Apollo Smart Transmitter from the tank and take it to a safe location
-The battery can be accessed by removing the 4 self-tapping screws from the base of the unit.
-Remove the old battery noting the orientation (‘+’ mark facing outwards), and replace it with a new
battery, 3V CR2450
-Re-assemble, ensuring the O-ring is undamaged and secured in position.
-Re-locate the transmitter on the tank.
There is no need to re-synchronise the transmitter with the monitor when the transmitter battery is
changed.
Disposal
The crossed out dustbin on the packaging indicates that this product and its battery shall not be treated as
household waste. Proper disposal will help prevent potentially negative consequences for the environment
and human health. For more detailed information about recycling of this product or battery, please contact
your local Recycling centre or the shop where you purchased the product.
8. TROUBLESHOOTING
If the Apollo Smart Monitor does not receive or cannot understand the
RF signal from the Apollo Smart Transmitter an error message will be
displayed on the Apollo Smart Monitor. The error message appears as
an alternating screen showing ‘Err’ and ‘E:0?’ where ? is a number.
Error codes are listed on a label on the rear of your Apollo Smart
Monitor.

9-5565-01
9. WARRANTY
This product carries a 12 month warranty from date of original purchase against any deficiency or fault in manufacture. This does not
affect your statutory rights.
This warranty does not cover normal wear and tear, damage cause by negligence, accident, improper use or incorrect installation. Any
change or modification made by the purchaser or user to the appliance will invalidate the guarantee, as would any attempted repair.
The warranty applies only when the appliance has been operated in accordance with the instructions and connected to an electricity
supply which matches that shown in the manual.
The warranty will be rendered invalid if the product is resold by the end user. The product must be used solely for domestic purposes.
Dunraven Systems obligations are limited to the repair or at its discretion replacement of the unit only.
The unit should only be returned upon receiving confirmation from the Customer Services team. To contact the Customer Services team
complete our online enquiry form found on our website www.dunravensystems.com under our contacts section. If instructed to return ,
you must return the full unit for testing upon which repair or replacement will be confirmed.
Dunraven Systems and its subsidiaries and distributors shall not be liable for indirect or consequential loss or damage resulting from the
use of this product.
10. CONTACT INFORMATION
Should you have any queries please refer to our FAQ’s section of our website www.dunravensystems.com found in our Help centre.
If your query is not featured here, please fill in our online enquiry form found under contacts on our website www.dunravensystems.com.
NOTE: The technical specifications for the Apollo Smart, the contents of this manual and the images herein are subject to change without
notice.
The contents and images in this manual are subject to copyright and may not be reproduced without the permission of Dunraven Systems
Ltd.
PLEASE NOTE:
