Dunster House ATLAS P5-3050PRG User manual

INSTALLATION MANUAL
ATLAS PERGOLA
3.2m x 5.2m
P5-3050PRG
Unique Product Reference Number:
__________________________________
Manufacturer:
Dunster House Ltd.
Caxton Road
Bedford
Bedfordshire
England
MK41 0LF
Customer Service Department:
[e-mail]
www.dunsterhouse.co.uk
V2

Queries Procedure
Important Information
You will need
Please retain all documentation relating to your purchase.
In the unlikely event that you need to contact us, please do so in writing to:
Email: [e-mail]
Post: Dunster House Ltd, Caxton Road, Elms Farm Industrial Estate, Bedford, MK41 0LF, England.
Our Customer Service department is open 9 a.m. to 5 p.m. Monday to Friday. Please include your Sales Order (SO)
number or post code in any correspondence with Customer Service to enable them to locate your file.
The Nature of Wood
The wood provided for your garden building is softwood which has been kiln dried and is pressure treated for
protection against fungal decay and insect infestation. Wood is a natural product which may have knots, knot holes,
imperfections, cracks and warping.
Due to the inherent properties of wood we make no guarantees with regards to the above, nor will replace any
lengths of timber for any of the following reasons:
•Any timber that contains knots where they do not influence the structural stability of the product.
•Cosmetic appearances - colour variations e.g. caused by the structure or age of the product.
•Timber that has shakes, cracks or gaps that do not influence the structural strength of the product.
•Any timber that has been covered or buried underground.
•Twisted timber that can be installed.
•Queries arising from a neglectful manner of construction be in the foundation or erection of the product.
•Queries due to modifications by the owner causing timber to deform.
Any valid queries will be satisfied by the exchange or replacement of the defective parts only.
This product has been designed with the self build in mind. However, it is important that the assembly
instructions are followed carefully.
Precautions:
•Always use working gloves.
•It is essential to have an assistant.
•All screw holes need to be pre-drilled using a 3mm drill bit (not provided) to avoid timber splitting.
This product is pressure treated so you will not need to treat it immediately or apply a preservative.
Pressure treatment does not mean that the timbers are waterproof, so you may wish to apply water repellent.
Water repellent can also be applied to timbers treated with a preservative.
Colour Transfer
This product has been pressure treated with wood preservative and a brown colour additive. Consideration should
be given to the propensity of the material to stain light colour adjacent surfaces, such as paving flags, render or
coated timber surfaces. We recommend contact between the timber and these surfaces is limited, and careful
consideration to storing the product prior to assembly should been taken in order to prevent such discolouration.
2 People Measuring Tape Spirit Level Drill/Driver
Gloves Ladder Hammer Utility Knife
Mallet Pozidriv bits 3mm Drill bit Saw
Socket Set Spanner 16mm Masonry Drill Bit (Wall panels only)

Page 3
Components required for Atlas Pergola 5.2m x 3.2m
120x120x2260.A
6x Post (Pressure Treated)
45x140x3200.A
7x Rafter (Pressure Treated)
45x70x3200.A
2x (Pressure Treated)
45x140x2645.A
2x Rafter (Pressure Treated)
45x140x630.A
12x Rafter (Pressure Treated)
20x120x300.A
24x Post Trim (Pressure Treated)
2260 120
120
140
453200
120 20
300
630 45
140
2645 45
140
ACCESSORIES
Description QTY
70x70x55mm L Bracket 6
M10x120mm Hex. Head Screw and Washer 24
Customer Instructions 1
35mm Screws 74
100mm Screws 36
45x140x2600.A
x2 Rafter (Pressure Treated) 2500
2600
45
140
3200 45
70

Page 4
Assembly Steps for Atlas Pergola 5.2m x 3.2m
**Avoid splitting timber parts by pre-drilling all screw holes**
Step 1.
120x120x2260.A4x
45x145x3200.A2x
100mm Screws16x
•Prepare 2 assemblies of the Beams and Posts as shown in the diagram below.
•Fix by screwing through the Posts into the Beams using (2x) 100mm screws per Post.
2725
Make sure the notches in
Beam are in line with the
cut-outs in the Posts
100mm Screws
Posts and Beam Layout
100 mm Screws
2x- 45x140x3200.A
4x- 120x120x2260.A
2x- 120x120x2260.A
4x- 45x140x2600.B
x4 45x140x2600.B
x2 45x140x2645.B
45x140x2645.B
45x140x2600.A
45x140x2645.A
100mm Screws
Step 2: •Position prepared assemblies and join using (2x) 45x140x2600 and (2x) 45x140x2645 and secure using
(4x) 100mm screws. Use image below fore reference.

Page 5
Assembly Steps for Atlas Pergola 5.2m x 3.2m
Step 3.
45x140x630.A12x
70x70x55mm Bracket
6x
M10x120mm Hex Head Screws
24x
24x M10 Washer
24x
35mm Screws24x
**Avoid splitting timber parts by pre-drilling all screw holes**
AB
•Measure diagonals to check for squareness. Check Posts and Beams to make sure they are plumb
and level !!
•Fix 70x70x55 Brackets to Posts using (4x) 35mm screws.
•Secure the Pergola Posts to the ground using 70x70x55 Brackets. (Fixings not supplied)
•Fix (2x) 45x140x630.A Brace to each Post using (2x) M10x120
•If you have bought Atlas Single Carport/Garage or optional wall panels for your Pergola, please
refer to the instructions provided at the end of this manual to find out how to install the panels.
•You will need to fix these in place now.
•If you have bought Atlas Single Garage, please refer to the instructions provided with garage door
wall pack to assemble door.
•Make sure your posts are level vertically (use a spirit level).
•Use a tape measure to check the distance of the top and bottom diagonals (4 diagonals in total).
•Make sure they are all the same before continuing with installation.
•If they are different, slightly move posts to make all diagonals equal (A=B on the top and on the bottom of posts).
35 mm Screws
4x- 45x140x2600.B
45x140x630.A
M10 x 120mm Hex head screw

Page 6
Assembly Steps for Atlas Pergola 5.2m x 3.2m
Step 4.
45x140x3200.A
5x
45x70x3200.A2x
20x120x300.A24x
100mm Screws20x
35mm Screws48x
**Avoid splitting timber parts by pre-drilling all screw holes**
•Connect (x5) 45x140x3200.B Rafters and (x2) 45x70x3200.A Top Beams by placing them onto the
assembled frame as shown in the diagram below.
•Use 100mm Screws to fasten to the Beams.
Congratulations on your new Pergola !!
•Fix 4x 20x120x300 to each post using 8 x 35mm Screws.
5x- 45x140x3200.B
805805805
805
650
658
2x - 45x70x3200.A
45x70x3200.A
45x140x3200.A
Screw 100mm
Step 5:
45x140x2645.A
45x140x3200.A
Screw 100mm
35mm Screw

INSTALLATION MANUAL
Additional Wall Panels
Atlas Pegola
Please note:
1. These instructions will enable you to assemble additional wall panels to your Pergola.
The configuration of the panels shown on the illustrations may very from the product you have purchased.
2. For illustration purposes we have shown the 3 standard wall layout in theses instructions. You can mix and
match the panels as they are designed to work in any configuration.
3. Avoid splitting timber by pre-drilling ALL screw holes
IMPORTANT INFORMATION
Please remove component 45x140x630.A (Brace) if components CP1 and or CP8 are being installed.

Panel CP1
Page 8
Panel CP2
Panel CP8
Components required for Additional Wall Panels
908 70
1035
908 85
2120
908
85
1065

Panel CP1
Page 9
Panel CP9
Components required for Additional Wall Panels
455
2120
85
455
85
1065

Page 10
Components required for Additional Wall Panels
15x70x2120
Full Wall Panel Trim
15x70x1065
Half Wall Panel Trim
15x70x1035
Glass Wall Panel Trim
20x100x908
Glass Wall Panel Sill
2120
70
15
1065 15
70
908
100
20
1035
70
15
ACCESSORIES
Description QTY
35mm Screws for Trims Varies
60mm Screws for Panels Varies
M10x110mm Hex Head Bolt for Shield Anchors 2 per panel
M10x28mm Washers 2 per panel
M10 Shield Anchors 2 per panel
2120
15
70
455 20
100
15x70x2120
Half Panel Trim CP10
20x100x455
Post
1085 15
70
15x75x1085
Half Wall Panel Trim

Page 11
Assembly Steps for Atlas Pergola 5.2m x 3.2m
Step 1.
Panel CP1 & CP10
60mm Screws
M10x110 Bolts
M10 Shield Anchors
M10x28 Washers
•Position the Panel CP1 and CP10 between the Posts as shown in the diagram below.
•Join Panel together, using (5) 60mm screws.
•Connect the two end panels to the Posts (5 screws each) and to the Beams with (2) 60mm screws per panel.
Fix the panels into the concrete base by drilling
n16 holes 80mm deep (2 per panel) and
inserting the shield anchors into the holes.
Fix the panels by inserting M10x110mm bolts
and M10 washers and tighten until secure.
Panel
M10x110mm
bolt &washer
M10 shield anchor
(n16 hole 80mm deep required)
Concrete
Full height wall panels assembly
** Quantity of components will vary,
depending on your purchase.
20
2279
2519
2732 2972
CP10 Panel
Please Note:
•Fix the ends panel first and space the centre panel between them. (option to add sealant between the panel and
the post)
•There maybe a gap between the panels, which is covered by the external and internal trims.
60mm Screw
CP1 Panel
Please Note:
•To fit the panel the braces has to be removed.
View from inside

Page 12
Assembly Steps for Atlas Pergola 5.2m x 3.2m
Step 2.
15x70x2120 Trim
35mm Screws
•Fix 15x70x2120 Trims using (8) 35mm screws per trim on the outside of the wall panels.
•Fix 15x70x2120 Trims using (8) 35mm screws per trim on the inside of the wall panels.
•The Trims will cover the joints between the panels.
View from outside
Full height wall panels assembly
View from inside
15x70x2120
35mm Screw
15x70x2120
35mm Screw

Page 13
Assembly Steps for Atlas Pergola 5.2m x 3.2m
Step 1.
Panel CP2 & CP9
60mm Screws
M10x110 Bolts
M10 Shield Anchors
M10x28 Washers
•Position the Panels between the Posts as shown in the diagram below.
•Join the together, using (3) 60mm screws per panel.
•Connect the two end panels to the Posts using (3) 60mm screws per panel.
•Fix the panels into the concrete by drilling n16 holes 80mm deep (2
per panel) and inserting the shield anchors into the holes.
•Fix the panels by inserting M10x110mm bolts and M10 washers
and tighten until secure.
View from inside
Panel
M10x110mm
bolt &washer
M10 shield anchor
(n16 hole 80mm deep required) Concrete
Half height wall panels assembly
2279
2519
2724 2964
CP9 Panel
Please Note:
•Fix the ends panel first and space the centre panel between them. (option to add sealant between the panel and
the post)
•There maybe a gap between the panels, which is covered by the external and internal trims.
60mm Screw
CP2 Panel
** Quantity of components will vary,
depending on your purchase.

Page 14
Assembly Steps for Atlas Pergola 5.2m x 3.2m
Step 2.
20x100x908 & 20x10x455
15x70x1065 & 15x70x1085
35mm Screws
•Position 20x100x908 Sills on top of Panels CP2 so that they are flush with the panel frame from inside the
gazebo.
•Fix using (3) 35mm screws per panel.
•Position 20x100x455 Sills on top of Panels CP9 so that they are flush with the panel frame from inside the
gazebo.
•Fix using (2) 35mm screws per panel
•Fix 15x70x1065 Trims using (6) 35mm screws per trim on the outside of the wall panels.
•Fix 15x70x1085 Trims using (6) 35mm screws per trim on the inside of the wall panels.
•The Trims will cover the joints between the panels.
View from outside
Half height wall panels assembly
View from inside
20x100x908
35mm Screw
15x70x1065
35mm Screw
15x70x1085
35mm Screw
20x100x455

Page 15
Assembly Steps for Atlas Pergola 5.2m x 3.2m
Step 1.
Panel CP8 & CP10
35mm Screws
15x70x1035
60mm Screws
•Remove the beading trims from one side of Panel CP8 frames.
•Position Panel CP8 on top of the Sills so that they are flush on the inside.
•Join the frames together with part 25x70x1035 Spacer in between, using (2) 60mm screws each panel.
Window panels assembly
**Assemble half height wall panels according to
the instructions given on the previous pages.
•Position glass panels into the frames and refix Beading Trims into position. (see
Glass Installation)
•Position 15x70x1035 Window Trim center of two window panels (outside) and
secure with 35mm screws.
•Position 15x70x1035 Window Trim center of two window panels (inside) and
secure with 35mm screws.
The CP10 Panel replaces the CP9 Panel
15x70x1035
35mm Screw
60mm Screw
15x70x1035
35mm Screw
Please Note:
•To fit the glass panel the
braces has to be removed.
View from
inside
View from inside
View from outside

Page 16
Assembly Steps for Atlas Pergola 5.2m x 3.2m
40mm Pin Nail
12x
19x25x840
2x
19x25x9152x
4x825x960 TGLASS
1x
Step 1:
Place 4x825x960 TGLASS into panel frame and make sure
it is centralized
Once Glass is in place apply silicone around the glass to
secure it into place.
Silicone
Silicone
Silicone
Silicone
Step 2:
Fix 2x 19x25x840 and 2x 19x25x915 parallel with their counterparts and secure using 40mm pin nails into per
timber as shown in the image below.
40mm Pin Nails
Place silicone around the edge of the frame.
Silicone
Silicone
Silicone
Silicone
Step 4:
Please note:
The glass is a smaller size compared to
panel frame to compensate for timbers
contracting, swelling and glass not being
cut square.
Step 3: Pre-drill the holes for the pin nails into the following
glass beading:
2x 19x25x840
2x 19x25x915
