Thank you for choosing DUOREST ergonomics chair. Before using your DUOREST chair, please
read the ‘Safety Instructions’ carefully, as it explains the correct and safe handling of the chair.
Duoback_Q5_Eng (170803).indb 3 2018-03-21 오전 9:00:51

02
Contents
03
 SafetyInstructions
05
 HowtoAssemble
10
 BasicOperation
14
 TroubleshootingGuide
16
 Theproduct’swarranty
Duoback_Q5_Eng (170803).indb 2 2018-03-21 오전 9:00:51

03
Safety Instructions
Donotliftyourlegsonahighsurfacewhensitting
ontheproduct
•
Incasetheproductslips/falls,Itispossibleitmight
causeseriousinjuryandevendeath
Donotleantoofarontheproduct
•
Itposesariskofinjuryiftheproductfalls
Donotuseexcessiveforceonthearmrest.
•
Thereisariskofinjury
Donotcrawlundertheproduct
•
Thereisariskofgettinginjurediftheproductfalls
Whenusingtheproduct,sitcorrectlymaintaining
correctposition
•
Whenleaningonthebackrest,seatpan,orthearmrest,
thereisriskofinjury
Whensomeoneissittingdown,donotspinorpush
•
Thereisariskofinjury
Donotputyourhandintheproduct’sgapbetween
partsandthemechanism.
•
Yourhandcangetcaughtcausinginjury
Makesureinfants,children,andpetsdonotbiteor
suckontheproduct.
•
Thereisariskofsuffocationduetosmall,looseparts
Teachthechildhowtousetheproductproperly
andcheckuponthem
•
Thereisariskofinjury
Safety Instructions
•
Thisproductisaone-personchairthatcanbeused
indoors(intheofficeandhome).Itshouldnotbeused
outdoors.
•
Tightentheboltsandhandleboltsoftheproductonce
everymonth.
•
Whencleaningtheproduct,useavacuumcleaneror
wipeitwithsoftfabric
Thisisimportantinformationfortheuser’ssafety
andforpreventionofpropertydamage.Please
readcarefullytousetheproductcorrectly.
Ifdirectionsarenotfollowed,itcancause
deathorseriousinjury.
Ifdirectionsarenotfollowedtherecould
bepersonalinjuryorpropertydamage.
Usetheproductforitspurpose
•
Goingtosleepontheproductorusingittoexercisecan
causeseriousinjuryincludingdeathwhentheproduct
fallsover
Donotleanorstandupontheproduct
•
Therecouldbeseriousinjurywhentheproductfalls
overorrotates.
Duoback_Q5_Eng (170803).indb 3 2018-03-21 오전 9:00:51

04
Donotplaceorstoretheproductonaslope
•
Whentheproductfalls,theproductandthefloormay
bedamagedduetoimpact
Donotusetheproductwhereitiswetorpolluted
•
Iftheproductslips,itcouldcauseinjuryorcontaminate
theproduct
Donotplacetheproductnearahumidifier
•
Whenusingahumidifier,thecalcareouscomponents
dissolvedinthewatermaycausedustmatterto
accumulateontheproduct.
Useafloormatwhenusingtheproductonsurfaces
thatcanbeeasilydamaged
•
Thefloormaybecomecontaminatedordamaged
Constantlyremovethedirtcompliedonthecaster
•
Ifthedirtisaccumulatedovertime,itmaybecomethe
sourceofdamage
Whencleaningastainedfabric,donottryto
disassembletheproductorwashitoutwithwater
•
Itmayaltertheshapeandcausetheproductto
malfunctioninuse
•
Ifthefabricispartlycontaminated,rubwithmild
detergentanduseafteritcompletelydries.
Donotusethefootresttogetonthechair.
•
Itmaycausedamageandinjuryiftheproductfallsover.
Nomorethantwopeopleshouldsitontheseatpan
•
Itmaycausedamagetotheproductandseriousinjury
Becarefulnottopinchyourtoesonthecaster
•
Therecouldinflicttothetoesinjury
Donotuseasharptoolsuchasaknifewhen
assemblingtheproduct
•
Thereisariskofpersonalinjuryandproductdamage
Donotusefireontheproductorplaceitnearheat
suchasdirectsunlight
•
Thereisariskofignitingafire
Donotthroworpushtheproductwithforce
•
Itmayhurtothersandcausedamagetoproduct
Assembletheproductfollowinginstructionsonthe
manual
•
Iftheproductisbrokenbynotfollowingtheinstruction
manual,theproductcannotbefixedfreeofcharge
underthewarranty
Usegloveswhenassembling
•
Handlingwithbarehandsmayriskinjury
Donotuseexcessiveforcewhenassembling
•
Theproductitselfand/orseveralconnectinghandle
boltsmaybedamagedorbroken
Duoback_Q5_Eng (170803).indb 4 2018-03-21 오전 9:00:51

05
How to Assemble
•OptionComponents
Headrestx1 Backrestx1
(LumberSupport)
Fixedtypearmrest
1SET
*Theaboveillustrationsmaybedifferentfromactualpasts.
Dimension&Materials
491mm
1060/1160mm
939/1039mm
468mm
Materials
Structure:Steel,Aluminum,syntheticresins
SurfaceTreatment:PolyesterCoating
Finish:100%Polyester
Cushion:UrethaneFoam
How to Assemble
PartsDescription
•BasicComponents
(Please,checkthepartsfirstlybeforeyouassemble)
Backrestx1 Seatx1 Basex1(Star)
Casterx5
AdjustingArmrest
1SET
AllenWrenchx1EA
Bolt(M8X20)x3EA
(ForBackrest)
AllenWrenchx1EA
Bolt(M6X30)x6EA
(ForArmrest)
GasCylinderx1 User’sManual
Duoback_Q5_Eng (170803).indb 5 2018-03-21 오전 9:00:53

06
2
AfterremovingthecapfromthetopofGas
Cylinder,insertitintoStarbase.
1
Insertcastersintobase.
Duoback_Q5_Eng (170803).indb 6 2018-03-21 오전 9:00:53

07
How to Assemble
4
Insertthebackrestintoconnectionbracket
ofthebottomofseatplate.
3
Insertthearmresttotheseatbaseas
illustratedintheimagebelow.Oncethe3
connectingholesarelinedup,usetheAllen
wrenchandboltscrewstosecureArmrestto
Seat.(Bothsidesaresame)
Bolt x 3ea
(M6x30)
Lightly tighten each screw
to ensure that the seat base
and the armrest are aligned.
When aligned, screw tightly.
Duoback_Q5_Eng (170803).indb 7 2018-03-21 오전 9:00:54

08
6
InsertGasCylinderintocentralholeofSeat
core.
5
Oncethe3connectingholesarelinedup,
usetheAllenwrenchandboltscrewsto
securebackresttoseatplate.
Bolt x 3ea
(M8x20)
Lightly tighten each screw
to ensure that the seat plate
and backrest are aligned.
When aligned, screw tightly.
Duoback_Q5_Eng (170803).indb 8 2018-03-21 오전 9:00:54

09
How to Assemble
7
PressHeadrestintotheholeuntilitclicks.
•
ThissteponlyappliestomodelsforHeadrest.
Click
8
Theassemblyisfinished.
Duoback_Q5_Eng (170803).indb 9 2018-03-21 오전 9:00:54

10
SeatDepthAdjustment
1
•
Lifttheadjustingleverupontherightsideof
Seatbase.Andthen,moveseatforwardor
backwardtodesiredposition.
Basic Operation
SeatHeightAdjustment
1
2
1
•
PullupLeverfortheseatheightadjustmentwhile
yousitting(1).Toraisetheseat,liftbodyoff
theseatandpullleverup.Tolowertheseat,lift
leverupwhilesittingdown(2).Releaseleverat
desiredheight.
Duoback_Q5_Eng (170803).indb 10 2018-03-21 오전 9:00:55

11
Basic Operation
SelfTiltingtensionLock/Unlock
2
13
Lock
Unlock
•PullupLeverforthetiltangleadjustmentwhile
youaresitting(1).PulldownLeveruntilitclacks
(3)tiltingthebackresttothedesireddegree(2).
Refernce
Ifyouwanttoputthebackrestback,pressyour
backagainstandreleaseit.Whenitisunlocked,
itgetsback.
Whatis‘SelfTiltingtension’?
18
SelfTiltingtensionishelpfultokeepsittingina
comfortablepositionbecauseitisautomatically
controlledinaccordancewithyourposture,
supportingyourlumbarvertebra.
SelfTiltingtensionismoreadvancedthanfour
jointssynchronizedTilt
SelfTiltingTensionMechanism
“DONATIFROMITALY”
Withoutothercontrols,themechanismadjuststhe
tensionoftheseatandbackmaintainingcomfort.
[Synchronizedtiltingrealizedin3:1ratiobetween
Backrest&Seatpan]
Duoback_Q5_Eng (170803).indb 11 2018-03-21 오전 9:00:56

12
ArmrestHeight/Angle/Reach
Adjustment
2
1
Caution
•
Adjusttheheightaccordingtoyourneeds,
pressthebuttonlocatedonthearmrestarm
andunderneaththearmrestinthefront.While
pressingthisbutton(1),raiseorlowerarmrestto
desiredheight(2).
•
Byholdingand“twisting”thearmresttop
sideways,youcanadjusttheangleofthe
armrests.Eachpositionclicksintoplace.
Watchoutforyourfingerswhenyouswings
armrestsinorout.
Refernce
Thissteponlyappliestomodelsforadjustable
Armrest
LumberSupportAdjustment
•
HeightAdjustment
•
Theheightofthelumbersupportcanbe
adjustedbyliftingorloweringthelumbarsupport
mechanism.
Refernce
ThissteponlyappliestomodelsforLumbar
Support.
Duoback_Q5_Eng (170803).indb 12 2018-03-21 오전 9:00:56

13
Basic Operation
HeadrestHeight/Angle
•
Tochangeheightraiseorlowerheadrestframe
todesiredheightwithinverticaladjustmenttrack.
•
Toadjustanglegraspfrontendofheadrestpad
andpivotitupordown.
Refernce
ThissteponlyappliestomodelsforHeadrest.
Duoback_Q5_Eng (170803).indb 13 2018-03-21 오전 9:00:57

14
Tilt-LockisNotWorking
•
Pleaselifttheleverallthewayup.Ifyouliftthe
tilt-lockleverallthewayup(1)youcantiltthe
backrest.(2)
2
Unlock
1
Trouble shooting Guide
Ifchairmalfunctions,youmaybeabletosolve
suchproblemwiththefollowingsuggestions
Formorehelp,youareadvisedtocontactthelocal
storewhereyoupurchasedthechair.
Seatheightadjustmentwon’twork.
•
Youmaynothaveliftedtheleverupalltheway.
Toincreaseseatheight,pullupLeverfortheseat
heightadjustmentalltheway(1)whileremoving
yourweightfromchair(2).
•
Todecreaseseatheight,pullupLeverforthe
seatheightadjustmentalltheway(1)while
seated(2).
1
2
Duoback_Q5_Eng (170803).indb 14 2018-03-21 오전 9:00:57

15
Trouble shooting Guide
DislocatedcastorfromBase
•
Insertcastorperpendicularlyintoholeofbase.
Contaminatedfabricneeds
cleaning
•
GenuineleatherorPUleather:Cleandirty
surfacewithwax.
•
Generalfabric:cleandirtysurfacewithasoft
clothsoakedinmilddetergentandwarmwater.
Rinsethoroughlyanddrywithasoftclothe
Donotwashordisassemblecontaminatedseat
orbackrestforcleansingstainsorspots.Itmay
resultinpermanentdamagetothematerial
Duoback_Q5_Eng (170803).indb 15 2018-03-21 오전 9:00:57

16
5
Ifidenticalmaterialsormodelsarenotavailable
atthetimeofrepairorreplacement,DUOREST’s
authorizedagentreservesallrightstosubstitute
partsormodelsofequalqualityorvalue.
6
THISLIMITEDWARRANTYISTHESOLE
REMEDYFORPRODUCTDEFECTANDNO
OTHEREXPRESSORIMPLIEDWARRANTY
ISPROVIDED,INCLUDINGBUTNOT
LIMITEDTOANYIMPLIEDWARRANTIES
OFMERCHANTABILITYORFITNESSFORA
PARTICULARPURPOSE.WESHALLNOTBE
LIABLEFORCONSEQUENTIALORINCIDENTAL
DAMAGESARISINGFROMANYPRODUCT
DEFECT.
WARRANTYCLASSIFICATION
Warranty
period Parts Classification
1Year Appearance Physicaldefectives
2Years Adjustment
Malfunctionofadjustable
function(height,width,
swiveling,tiltingandlocking)
3Years BodyandFrame Metallicframesandinjection
moldedparts
The product’s warranty
1
AllDUORESTproductscomplywiththehighest
standardofqualityassuranceandinspection
programs.DUORESTproductsarefabricated
usingmorethan100piecesofpartswhichhave
undergonestringentsuperioritytests.
2
ThislimitedwarrantyisvalidforONEto
THREEYEARSunderanapplicablewarranty
classification(fromthedateofpurchase)against
allpossiblemanufacturingdefectsarisingfrom
materialsandworkmanship.
3
Thiswarrantybecomesinvalidshouldthe
serialnumber(barcode)beremovedor
altered.Allrepairsandserviceworkunder
thewarrantymustbeperformedonlyby
DUOREST’sauthorizedagent.Suchservice
shallbeprovidedduringnormalbusinesshours.
CustomersareadvisedtocontactDUOREST’s
authorizedagentforfurtherdetails.
4
Thewarrantydoesnotcoverdamagecausedby
misuseorneglect,accidents,abrasions,normal
wearandtearoranymanneroftempering,self
modification,abuseorActofGod.
Duoback_Q5_Eng (170803).indb 16 2018-03-21 오전 9:00:57
