DURAVAC EU VH0423 SUB User manual

NOTHING IS TOUGHERNOTHING IS TOUGHER
USER MANUAL
EU VH0423 SUB WET & DRY
VACUUM CLEANER

DEAR CUSTOMER
THE CE MARK "EUROPEAN COMPLIANCE" MEANS THAT THE PRODUCT IS IN ACCORDANCE WITH
THE ESSENTIAL REQUIREMENTS PROVIDED BY THE LAW, CONCERNING SAFETY AND PUBLIC
HEALTH MEASURES, PROTECTION OF THE CONSUMER, ETC.
WARNING: THESE SYMBOLS WILL BE USED TO REMIND THE OPERATOR TO PAY ATTENTION TO
OPERATIONS THAT MAY CAUSE LESIONS, INCLUDING DEATH, TO THE OPERATOR OR TO OTHER
PEOPLE OR ANIMALS NEARBY. FURTHERMORE, THE OPERATIONS INDICATED BY THESE SYMBOLS
MAY CAUSE DAMAGES, EVEN IRREPARABLE ONES, TO THE SUCTION DEVICE.
ATTENTION: PLEASE READ CAREFULLY THE INSTRUCTION MANUAL BEFORE USING IT. IT IS
RECOMMENDED TO KEEP THIS MANUAL FOR FUTURE REFERENCES.
DO NOT DISPOSE OF POWER TOOLS INTO HOUSEHOLD WASTE! ACCORDING TO THE EUROPEAN
DIRECTIVE 2012/19/EU ON WASTE ELECTRICAL AND ELECTRONIC EQUIPMENT (WEEE) AND ITS
INCORPORATION INTO NATIONAL LAW, POWER TOOLS THAT ARE NO LONGER SUITABLE FOR USE
MUST BE SEPARATELY COLLECTED AND SENT FOR RECOVERY IN AN ENVIRONMENTA-L FRIENDLY
.RENNAM
2.
NOTHING IS TOUGHER EU VH0423 SUB

!1. INTRODUCTION
• This manual describes your vacuum cleaner features.
• It is owner's responsibility to make sure that the vacuum cleaner is used by people informed
about this handbook of instrucons.
• It is not permied to the owner modify, use or tampering with the vacuum cleaner for purposes
different from those described in this handbook, otherwise the warranty is no longer effecve
and exempt the manufacturer from every responsibility for possible damages to people or
things.
• In case of loss or damage of the handbook, please contact the manufacturing company. In case
of sale of the vacuum cleaner please aach the present handbook of instrucons to the machine
or inform the buyer about the manufacturing company.
• The vacuum cleaner is fully tested before the delivery, in order to ensure the good performances
of the appliance. This is done according to strict internal procedures and with modem yearly
cerfied electrical tests.
VERSION FITTED WITH A DISPOSAL PUMP - INTENDED USE
• This type of vacuum cleaner is designed for connuous disposal of large amounts of Liquid
(damage due to high water, vacuum of small and medium sized containers or tanks, etc), and
dry/wet cleaning.
• Solid, powerful and easy to use, it is also equipped with efficient tools, for a rapid and complete
cleaning. This vacuum cleaner is suitable for collecve use: for example, in hotels, schools,
factories, shops, etc.
ATTENTION: do not vacuum liquids that are not water I dirty water. It is forbidden to
vacuum liquids other than those specified.
ATTENTION: Only use accessories and spare parts authorised by the manufacturer. Original
accessories and spare parts guarantee safe use of the device without malfuncons.
INSTRUCTIONS THAT MUST BE STRICTLY FOLLOWED SAFE USE
• Read carefully the manual before use, in order to work in a safe environment.
Warning: Before using the appliance, the device must be correctly assembled. Check that
all the equipped filtering elements are in place and efficient.
It is recommended to only connect this device to a socket outlet provided with a30mA
differenal switch.
• This appliance must be kept out of the reach of children, of people with reduced physical
sensory or mental abilies or lacking experience and knowledge.
CAUTION: Children must be kept under control, do not allow children to use the appliance
as a toy.
WARNING: Users must be properly trained to use the machine.
CAUTION: Components used in packaging (ex: plasc bags) can be dangerous; keep away
from children, animals and people not aware of their acons.
• To correctly dispose of the packaging follow the local standards in force.
3.
NOTHING IS TOUGHER
EU VH0423 SUB

• Make sure that the voltage of electrical mains is the same as that indicated on the rang plate of
the vacuum cleaner. Verify that the socket. is compable with the plug. Power cable must
always be unrolled before using the appliance. Do not use the cable coiled.
• Do not handle/use plug or appliance with wet hands.
• Do not pick up anything that can damage the filtering elements (such as glass, metal etc.).
• Do not use the electrical cord to move or lithe machine.
• Never immersed the machine in water and never use a pressure jet of water to clean the
machine.
• Do not use this appliance beyond 2000 m (6560 ) above sea level.
WARNING: This machine is not suitable for picking up dangerous dust.
CAUTION: Don't pick up flammable, incandescent, explosive or toxic dust/blends. Maximum
temperature allowed is 40°C (104°F).
Warning: Any applicaon not described in this manual is potenally dangerous, therefore
it must be avoided.
Warning: Do not leave the unsupervised a working machine. Always unplug the machine if
the appliance is not working. Keep away from children and from people not aware of their
acons.
WARNING: This appliance must be used, assembled, fixed and moved on a safe and not sloping
plane.
WARNING: This appliance must be stored, taking its weight into consideraon, on a solid, steady,
safe and not sloping plane, indoor and in a dry area.
WARNING: Keep hands, feet, ears, loose clothing, hair and all parts of the body (human or animals)
away from openings.
WARNING: If the appliance is provided with a supplementary socket do not use a tool exceeding. the
power reported on the socket. Non-observance of these rules could result in damages and injuries
even lethal to the user.
• Do not allow the power cord to come into contact with the rotang brushes of the carpet
cleaning head.
Warning: Use only original spare parts. Using other accessories might compromise the operator’s
safety.
Warning: This machine Is not suitable for picking up dust in environments where electro- stac
discharges or spark can cause damages to electronic components and persons.
Warning: it is forbidden to tamper or modify the appliance. Failure to comply with these
instrucons could cause serious accidents and damages tothe user, that can also lead to
death. Tampering will void the warranty.
The manufacturer refuses all responsibility for damages or injuries due to improper use of the
machine or in case of failure tofailure to comply with the instrucons given in this manual.
4.
NOTHING IS TOUGHER EU VH0423 SUB

Always disconnect power cord from power source aer operang and before
servicing. Aer every use and before sending the appliance to technical assistance,
the vacuum cleaner must be disassembled, cleaned and overhauled to avoid
hazard for the maintenance staff.
• Do roune maintenance. Inspect gaskets seals, plasc parts, filters, switches and
replace those which have begun to leak or are damaged.
• Using a machine with a damaged power cord could result in an electrocuon Check
the cord looking for cut, cracks or aging signs and replace it, if it's necessary.
• Only an authorized service centre can replace power cord of the appliance.
• If extension cord are used, ensure that the cable rang is suitable for use with the
equipment. Keep dry at all mes. Avoid contact with conducve surfaces.
• Don t let children clean the appliance if they are not under supervision of an adult.
• Only an authorized service centre can do reparaon or maintenance of the
appliance. Use only original spare parts.
• To keep the appliance fully funconal it is necessary to clean polyester filter shaking
it aer every use and replace filtering bag if it's full.
• Clean every part of the appliance aer each use: empty the tank, shake the filters,
replace filtering bag if it's full and clean the machine with a damp cloth before storing the
vacuum cleaner.
• WARNING: in case of foam or liquid leak switch off the appliance immediately,
• WARNING: in case overturning, li the appliance in the upright posion before
switching the motors off.
• Don't pick up water from sink or tub. Do not use cleaner as a pump to clean out
clogged drains, sinks, or other plumbing fixtures. The vacuum cleaner is intended for
vacuuming air and water mixtures.
• Do not use or pick up aggressive soaps, they could damage the appliance.
WARNING: The floater switch has the funcon to stop the vacuuming when the tank
is full of liquids or in case of overturning; carry out cleaning roune checking that
there are no damages and change it if it's necessary.
• WARNING: Do not use outdoors or in a cold environment.
NOISE
Values measured according to EN 60704-1 (2010) / EN 60704-2-1 (2001) ISO 3744 standards.
The sound pressure level weighted A of the appliance is LpA=77.5 dB; KpA=2.5 dB.
VIBRATIONS
Hand-arm vibraons on the sucon hose are less than 2,5 m/s2 as recommended by ISO
5349-1
Under adverse network condions, the appliance may cause temporary drops in voltage.
5.
NOTHING IS TOUGHER
EU VH0423 SUB

2. COMPONENT DESCRIPTION
6.
NOTHING IS TOUGHER EU VH0423 SUB

a. Motor head
b. Motors 1-2 power supply switches
c. Pump power supply outlet
d. Pump power supply plug
e. Hooks
f. Tank
g. Inlet
h. Castor wheels
i. Main polyester filter. Use only for dry
pick up, not for wet pick up (oponal)
j. Filter bag to apply on top of deflector.
This filter does not exclude the use of
polyester filter, that sll has to be used
(oponal)
k. Wand
l. Flexible Hose
m. Hose
n. Double use Brush
o. Squeegee Brush
p. Dust Brush
q. Crevice Nozzle
r. Upholstery Nozzle
s. Round Brush
t. Adaptor
u. Pump
v. Cable retainer
w. Float valve
x. Cut wire grommet
y. Ring nut
z. Cap
1- Pump delivery fing
2- Nonreturn valve
3- Clamp
4- Pump delivery pipe
5- Fing
6- Connecon fing
7.
NOTHING IS TOUGHER
EU VH0423 SUB

• When it reaches the trigger level, it acvates the pump to empty the tank;
• When the tank is emped, the float goes down again to the boom level and the
pump stops automacally;
• The pump's trigger level (pre-set on assembly) can be changed from the cable length
of the float that comes out from cable retainer T.
DRY SUCTION
•
So as not to damage the emptying pump when vacuuming solids, it is required to
remove it before starng any work;
• To remove the pump, loosen the ring nut of fing 5 situated on the pump and
remove plug D aer removing ring nut Y
• Extract the pump from tank F, then assemble cap Z instead of ring nut Y;
• For dry sucon it is required to insert filter K into the drum. This, as well as the cap,
is not a standard supply. If your vacuum is equipped with paper bag L, slide paper bag over
the deflector.
PRELIMINARY OPERATIONS
• Connect the vacuum cleaner's power supply cable plug to a suitable socket;
• Connect the pump's plug D to the outlet C situated on the head of the vacuum
cleaner;
• Connect the water drainpipe from the drum to fing 1;
• Connect the sucon accessories to the inlet of the tank F.
WET SUCTION
• When all the parts are assembled as Indicated above, start the vacuum motors by
pressing switches. Vacuum the liquids using the accessories supplied.
• During tank F filling the Float rises;
8.
NOTHING IS TOUGHER EU VH0423 SUB

5. WHAT IS NOT COVERED UNDER THIS WARRANTY:
A. Implied warranties, including those of merchantability and
FITNESS for a particular purpose are limited in duration to
this express warranty. After this period, all risks of loss, from
whatever reason, shall be on the purchaser.
B. ANY INCIDENTAL, INDIRECT, OR CONSEQUENTIAL
LOSS, DAMAGE, OR EXPENSE THAT MAY RESULT FROM
ANY DEFECT, FAILURE OR MALFUNCTION OF THIS
PRODUCT.
C. This warranty does not apply to any accessory or
consumable items included with the product which are
subject to wear from usage; the repair or replacement of
these items shall be at the expense of the owner. These
items include, but are not limited to: hose's, floor tools, filters,
bags, etc. In addition, this warranty does not extend to any
damage caused by the untimely replacement or maintenance
of any of the previously listed CONSUMABLE parts.
D. Any failure that results from accident, purchaser’s abuse,
neglect or failure to operate products in accordance with
instructions provided in the owner’s manual(s) supplied with
the product.
E. Pre-delivery service, i.e. assembly and adjustment.
6. RESPONSIBILITIES OF WARRANTOR UNDER THIS
WARRANTY: Repair or replace, at Warrantor’s option,
products or components which have failed within duration of
the warranty period.
7. RESPONSIBILITIES OF PURCHASER UNDER THIS
WARRANTY:
A. Please call your re-seller or the number listed above for
warranty assistance.
B. Provide dated proof of purchase and maintenance records.
C. All vacuum must be delivered or shipped to the nearest
Service Agent or re-seller. Freight costs, if any, must be borne
by the purchaser.
D. Use reasonable care in the operation and maintenance of the
products as described in the owner’s manual(s).
E. No warranty costs incurred will be considered for, or covered
if Euroquip has not been contacted and prior permission for
repair / replacement has been granted.
8. WHEN WARRANTOR WILL PERFORM REPAIR OR
REPLACEMENT UNDER THIS WARRANTY:
Repair or replacement will be scheduled and serviced
according to the normal work flow at the servicing location
and depending on the availability of replacement parts.
Warranty
Whilst every effort is made to ensure your complete
satisfaction with this tool, occasionally, due to the
mass manufacturing techniques, a tool may not live
up to our required level of performance and you may
need the assistance of our service department.
This product is warranted for 12 months use from the
date of the original purchase. If found to be defective
in materials or workmanship, the tool or the offending
faulty component will be replaced free of charge with
another of the same item. A small freight charge may
apply. Proof of purchase is essential.
We reserve the right to reject any claim where the
purchase cannot be verified.This warranty does not
include damage or defects to the tool caused by or
resulting from abuse, accidents, alterations or
commercial or business use. It also does not cover
any bonus items or included accessories. Only the
generator is covered under this warranty.
Please ensure that you store your receipt in a safe
place. Conditions apply to the above warranty.
1. DURATION:
The manufacturer warrants that it will repair or replace, at no
charge for parts or labour, the DURAVAC EU VH0423 SUB,
if proven defective in material or workmanship, during the
following time period(s) after date of original retail purchase:
For 12 months use - DURAVAC EU VH0423 SUB
(excluding accessories)
2. WHO GIVES THIS WARRANTY (Warrantor):
EUROQUIP NZ
Service Line:
+ + 64 3 547 8409
3. WHO RECEIVES THIS WARRANTY (Purchaser):
The original purchaser of this DURAVAC EU VH0423 SUB
4. WHAT IS COVERED UNDER THIS WARRANTY: Defects
in material and workmanship which occur within the duration
of the warranty period.
9.
NOTHING IS TOUGHER
EU VH0423 SUB

10.
NOTHING IS TOUGHER EU VH0423 SUB

11.
NOTHING IS TOUGHER
EU VH0423 SUB

Congratulations on your new DURAVAC product. We are proud to have you as our
customer and will strive to provide you with the best service and reliability in the industry.
This product is backed by our extensive warranty. To locate your nearest distributor or
service agency call 0800 387 678, or email us at [email protected].
