DURKOPP ADLER 911-210 Operating manual

911-210
Additional Instructions
Neat seam beginning (NSB)

All rights reserved.
Property of Dürkopp Adler AG and protected by copyright. Any reuse of these contents,
including extracts, is prohibited without the prior written approval of Dürkopp Adler AG.
Copyright © Dürkopp Adler AG 2020
IMPORTANT
READ CAREFULLY BEFORE USE
KEEP FOR FUTURE REFERENCE

Table of Contents
Additional Instructions 911 - 00.0 - 05/2020 1
1 General information ...................................................................3
1.1 Components of the kit 0911 597494.............................................3
1.2 Components of the kit 0911 597484.............................................5
2 Assembling the neat seam beginning (NSB)...........................7
2.1 Presettings outside of the machine (optional) ..............................7
2.2 Checking and adjusting the cutting pressure................................9
2.3 Checking and adjusting the clamping spring pressure...............10
2.4 Checking the locking mechanism and the throat plate holder....11
2.4.1 Locking mechanism....................................................................11
2.4.2 Throat plate holder .....................................................................14
2.5 Assembling the NSB into the machine .......................................16
2.6 Activating the NSB in the software .............................................20

Table of Contents
2Additional Instructions 911 - 00.0 - 05/2020

General information
Additional Instructions 911 - 00.0 - 05/2020 3
1 General information
1.1 Components of the kit 0911 597494
The kit has been designed for machines with the control DAC comfort.
Check whether the scope of delivery for kit 0911 597494 is correct prior to
installation.
Part number Quantity Description
0911 597954 1 NSB assembly, consisting of:
• 0867 350363, stop block
• 0867 350423, block
• 0867 350470, plate
• 0867 350440, stop
• 9202 002067, screw M4x8
• 9330 000087, washer A4,3
• 0867 350410, counter blade
• 9202 100328, countersunk screw M4x8 (3 pieces)
• 0867 350330, thread-pulling knife
• 0867 350400, clamping spring (4 pieces)
• 9204 431657, screw M4x8 (2 pieces)
• 0867 350290, retaining bracket (4 pieces)
• 9202 002067, screw M4x8 (2 pieces)
• 9330 000087, washer (2 pieces)
• 9700 234002, screw D12x10 (2 pieces)
• 9202 001727, screw M3x30 (5 pieces)
• 9790 201000, WI-E coupling (4 pieces)
• 9790 590441, slip-on bushing (round, red)
• 9790 590442, slip-on bushing (round, green)
• 9790 590443, slip-on sleeve (round, yellow)
• 9790 590444, slip-on sleeve (round, blue)
• 0911 350820, carrier plate
• 0911 350813, holder
9202 002087 2 Screw M4x12
0911 140464 1 Kit lateral bearing, consisting of:
• 0911 140430, plate
• 9201 113297, screw (4 pieces)
• 9330 000107, washer A6,4 (6 pieces)
• 0911 140383, latching plate
• 0911 140390, block (2 pieces)
• 9202 002937, screw M6x35 (2 pieces)
• 9231 110127, hexagon nut M6
• 9201 113398, screw M6x50
0579 140074 1 Container
0506 330130 1 Damping plate
0699 979123 1 Hose PVC (1.5 m)
0999 240384 1 GD-E coupling
9790 201000 1 WI-E coupling
9710 041003 1 Valve
9710 063410 2 Throttle valve

General information
4Additional Instructions 911 - 00.0 - 05/2020
Information
The kit 0911 490484 (distribution block, pneumatic) is supplied together
withtheNSB kit.The kit must be additionally installed during the assembly
of the machine.
9790 590441 1 Slip-on bushing (round, red)
9790 590442 1 Slip-on bushing (round, green)
9790 590443 1 Slip-on bushing (round, yellow)
9790 590444 1 Slip-on bushing (round, blue)
9710 061410 1 Throttle valve
9790 212402 3 WI-E coupling
9790 201000 2 WI-E coupling
9731 005004 1 Hose PUR, gray (1.5 m)
9731 004014 1 Hose PUR, red (1 m)
9731 004024 1 Hose PUR, green (1 m)
9731 004034 1 Hose PUR, yellow (1 m)
9731 004044 1 Hose PUR, blue (1 m)
Part number Quantity Description

General information
Additional Instructions 911 - 00.0 - 05/2020 5
1.2 Components of the kit 0911 597484
The kit has been designed for machines with the control DAC 3.
Check whether the scope of delivery for kit 0911 597494 is correct prior to
installation.
Part number Quantity Description
0911 597954 1 NSB assembly, consisting of:
• 0867 350363, stop block
• 0867 350423, block
• 0867 350470, plate
• 0867 350440, stop
• 9202 002067, screw M4x8
• 9330 000087, washer A4,3
• 0867 350410, counter blade
• 9202 100328, countersunk screw M4x8 (3 pieces)
• 0867 350330, thread-pulling knife
• 0867 350400, clamping spring (4 pieces)
• 9204 431657, screw M4x8 (2 pieces)
• 0867 350290, retaining bracket (4 pieces)
• 9202 002067, screw M4x8 (2 pieces)
• 9330 000087, washer (2 pieces)
• 9700 234002, screw D12x10 (2 pieces)
• 9202 001727, screw M3x30 (5 pieces)
• 9790 201000, WI-E coupling (4 pieces)
• 9790 590441, slip-on bushing (round, red)
• 9790 590442, slip-on bushing (round, green)
• 9790 590443, slip-on sleeve (round, yellow)
• 9790 590444, slip-on sleeve (round, blue)
• 0911 350820, carrier plate
• 0911 350813, holder
9202 002087 2 Screw M4x12
0911 140464 1 Kit lateral bearing, consisting of:
• 0911 140430, plate
• 9201 113297, screw (4 pieces)
• 9330 000107, washer A6,4 (6 pieces)
• 0911 140383, latching plate
• 0911 140390, block (2 pieces)
• 9202 002937, screw M6x35 (2 pieces)
• 9231 110127, hexagon nut M6
• 9201 113398, screw M6x50
0579 140074 1 Container
0506 330130 1 Damping plate
0699 979123 1 Hose PVC (1.5 m)
0999 240384 1 GD-E coupling
9790 201000 1 WI-E coupling
9710 041003 1 Valve
9710 063000 2 Solenoid valve
9710 061200 1 Solenoid valve
0911 490484 1 Distribution block, pneumatic

General information
6Additional Instructions 911 - 00.0 - 05/2020
Information
The old throat plate holder and the old throat plate must be replaced by
the new throat plate holder and the new throat plate included in the kit.
9731 005004 1 Hose PUR, gray (2.5 m)
0911 200404 1 Throat plate holder
0911 200250 1 Throat plate
Part number Quantity Description

Assembling the neat seam beginning (NSB)
Additional Instructions 911 - 00.0 - 05/2020 7
2 Assembling the neat seam beginning (NSB)
When the needle exits the sewing material after the first stitch, the thread-
pulling knife pulls the initial thread into the clamp. This ensures secure
sewing.
Following the 2nd stitch, the remaining thread is cut off and removed by
the suction device.
2.1 Presettings outside of the machine (optional)
The kit has been preset at the factory and does usually NOT have to be
adjusted.
Do not check or adjust the presettings outside of the machine UNLESS
the NSB is without function.
Fig. 1: Presettings outside of the machine (1)
To complete the presettings outside of the machine:
1. Remove the clamping spring (1).
2. Loosen the nut (2).
3. Extend cylinder (4).
4. Turn the piston rod (3).
Measurement Amust be 8.8 mm with the cylinder fully extended (4).
5. Tighten the nut (2).
(1) - Clamping spring
(2) - Nut (3) - Piston rod (4) - Cylinder
①
④
②③
A

Assembling the neat seam beginning (NSB)
8Additional Instructions 911 - 00.0 - 05/2020
Fig. 2: Presettings outside of the machine (2)
6. Extend cylinder (6).
7. Retract cylinder (4).
8. Press the pin (5) against the threaded pin (7).
9. Turn the threaded pin (7).
Measurement Bmust be 2.8 mm when the pin (5) abuts on
the threaded pin (7).
Fig. 3: Presettings outside of the machine (3)
10. Retract cylinder (6).
11. Loosen the screw (8).
12. Shift the plate (9).
Measurement Cmust be 1.3 mm when the pin (5) abuts on the
plate (9).
13. Tighten the screw (8).
14. Place the clamping spring (1).
(5) - Pin
(6) - Cylinder (7) - Threaded pin
⑦⑤⑥
(5) - Pin
(6) - Cylinder (8) - Screw (9) - Plate
⑤
⑦
⑧
⑨

Assembling the neat seam beginning (NSB)
Additional Instructions 911 - 00.0 - 05/2020 9
2.2 Checking and adjusting the cutting pressure
Fig. 4: Checking and adjusting the cutting pressure
Proper setting
Screw (1) is adjusted such that the thread-pulling knife (2) moves
smoothly and the counter blade (3) cuts the loose thread cleanly.
To check and adjust the cutting pressure:
1. Screw in screw (1) in such a way that the screw head abuts on
the counter blade (3).
2. Turn the screw (1).
• Increase the cutting pressure: Turn screw (1) clockwise
• Reduce the cutting pressure: Turn screw (1) counterclockwise
3. Carry out a cutting test.
4. Readjust the cutting pressure if necessary.
NOTICE
Property damage may occur!
Risk of knife breakage if pressure is adjusted too high.
Do not adjust the cutting pressure too high.
(1) - Screw
(2) - Thread-pulling knife (3) - Counter blade
①
②
③

Assembling the neat seam beginning (NSB)
10 Additional Instructions 911 - 00.0 - 05/2020
2.3 Checking and adjusting the clamping spring pressure
The clamping spring clamps the needle thread after the 1st short stitch
and prior to cutting.
Fig. 5: Checking and adjusting the clamping spring pressure
To adjust the clamping spring pressure:
1. Adjust screw (1) such that the needle thread is securely clamped by
the clamping spring (2).
Theclampingspringpressuredependsontheneedlethreadthickness.
Make sure that the needle thread can be effortlessly pulled out of
the clamped position.
2. Turn the screw (1).
• Increase the cutting pressure: Turn screw (1) clockwise
• Reduce the cutting pressure: Turn screw (1) counterclockwise
(1) - Screw (2) - Clamping spring
①
②

Assembling the neat seam beginning (NSB)
Additional Instructions 911 - 00.0 - 05/2020 11
2.4 Checking the locking mechanism and the throat plate
holder
Information
To assemble the neat seam beginning, you must installthe correct locking
mechanism and the correct throat plate holder.
2.4.1 Locking mechanism
Fig. 6: Locking mechanism (1)
Check if the correct locking mechanism has been assembled. The correct
locking mechanism (part number 0911 400163) is seated on the right in
the tabletop cutout.
If the locking mechanism is seated in the center of the tabletop cutout,
assemble the correct locking mechanism.
old locking mechanism:
correct locking mechanism:

Assembling the neat seam beginning (NSB)
12 Additional Instructions 911 - 00.0 - 05/2020
Assembling the locking mechanism
Fig. 7: Locking mechanism (2)
To assemble the locking mechanism:
1. Tighten the locking mechanism (2) to the stand.
2. Screw the proximity switch (4) onto the latching plate (3).
3. Screw the latching plate (3) with the block (1) in place under the base
plate.
Fig. 8: Locking mechanism (3)
(1) - Block
(2) - Locking mechanism (3) - Latching plate (4) - Proximity switch
③
②
④
①
(2) - Locking mechanism (3) - Latching plate
②
③

Assembling the neat seam beginning (NSB)
Additional Instructions 911 - 00.0 - 05/2020 13
4. Align the latching plate (3) and the locking mechanism (2) such that
the cylinder head and the axle are seated flush inside the slot in the
latching plate (3).
Fig. 9: Locking mechanism (4)
5. Adjust the height of the screws (5).
When the machine head is folded down, the base plate rests on
the rubber heads.
The base plate lines up flush with the table.
6. Lock the locking mechanism (2) from the bottom using the screw (6).
(2) - Locking mechanism
(5) - Screws (6) - Screw
⑤
②
⑥

Assembling the neat seam beginning (NSB)
14 Additional Instructions 911 - 00.0 - 05/2020
2.4.2 Throat plate holder
Fig. 10: Throat plate holder (1)
Check if the correct throat plate holder (part number 0911 207514) has
been assembled together with the correct throat plate.
If not, assemble the correct throat plate holder and adjust the needle
guide.
old throat plate holder:
correct throat plate holder and throat plate:

Assembling the neat seam beginning (NSB)
Additional Instructions 911 - 00.0 - 05/2020 15
Assembling the throat plate holder and adjusting the needle guide
Fig. 11: Throat plate holder (2)
To assemble the correct throat plate holder and adjust the needle guide:
1. Tighten the throat plate holder (2) using the screws (1).
2. Assemble the throat plate (5).
3. Lock the machine in place at the looping stroke position.
Fig. 12: Throat plate holder (3)
4. To adjust the needle guide (3), turn the screw (4).
• To move the needle guide closer to the needle:
Turn screw (4) clockwise
• To move the needle guide further away from the needle:
Turn screw (4) counterclockwise
5. Useasheetofpapertocheckthedistancebetweenneedleandneedle
guide (3) and adjust it if necessary.
The space between needle and needle guide (3) must just be wide
enough to allow a sheet of paper to pass through.
(1) - Screws
(2) - Throat plate holder
(3) - Needle guide
(4) - Screw
(5) - Throat plate
①
④⑤②③

Assembling the neat seam beginning (NSB)
16 Additional Instructions 911 - 00.0 - 05/2020
2.5 Assembling the NSB into the machine
Fig. 13: Assembling the NSB into the machine (1)
To assemble the NSB into the machine:
1. Switch off the machine.
2. Insert the NSB from the top.
3. Tighten the NSB (1) using the screws.
4. Lower the needle by turning handwheel.
The needle must be positioned in the center of the needle hole of
the thread-pulling knife.
If the needle is not positioned in thecenter of the needle hole of thethread-
pulling knife:
5. Loosen the screws (1).
6. Move the entire NSB unit such that the needle is positioned precisely
in the center of the needle hole of the thread-pulling knife (see figure
above).
7. Tighten the screws (1).
When doing so, make sure that you do not move the NSB unit.
8. Raise the needle by turning the handwheel.
(1) - Screws
①

Assembling the neat seam beginning (NSB)
Additional Instructions 911 - 00.0 - 05/2020 17
Fig. 14: Assembling the NSB into the machine (2)
9. Assemble the throat plate (2).
Fig. 15: Assembling the NSB into the machine (3)
10. Assemble the suction container (6) under the tabletop.
11. Use the T-piece to connect the pneumatic hose (3) to the main air
supply (5) of the compressed air maintenance unit.
12. Lay the pneumatic hose (4) under the machine along the valve block
that is assembled in the rear section of the machine.
(2) - Throat plate
②
(3) - Pneumatic hose
(4) - Pneumatic hose (5) - Main air supply (6) - Suction container
⑤
⑥
③
④

Assembling the neat seam beginning (NSB)
18 Additional Instructions 911 - 00.0 - 05/2020
Fig. 16: Assembling the NSB into the machine (4)
13. Tighten the valve block (8) in the rear section of the machine.
• Valve block Festo for machines with the control DAC comfort
• Valve block Bürkert for machines with the control DAC 3
14. Use the T-piece (9) to connect the pneumatic hose (7) to the main air
supply.
(7) - Pneumatic hose
(8) - Valve block (9) - T-piece
Valve block Festo
Valve block Bürkert
⑦
⑦
⑧
⑨
⑦
⑧⑦ ⑨
