Dustless Dustie User manual

13242 HEPA
Floor Tool
13141 Micro Pre Filters
16006 HEPA Vacuum
Ch pBudd e - Hook it to a hose
with the 6’ hose adaptor and
scrape. Chan e blade by usin a
Philips screwdriver. Works on
both sides of the blade for
collectin debris in both
directions. Use for scrapin
paint or popcorn ceilin s.
DUSTLESSTM EPA Lead-Safe
Compl ance K t
K t Model 16500
K t # 16500 Includes:
1 - 16006 HEPA Wet/Dry Vacuum
1 - 13141 Micro Pre Filters (2 pk )
1 - 13242 HEPA Floor Tool
1 - 60001 ChipBuddie
1 - D1836 5” Dustie
1 - D5160 6’ Adapter Hose
60001 ChipBuddie
D1836 5” Dustie
D5160 6’
Adapter Hose
HEPA Floor Tool -
The HEPA Floor Tool
features a beater bar
as specified by EPA
to meet renovation
contractor certification
requirements. Fit
easily into HEPA
Vacuum attachments.
M cro Pre-f lter -
To install the Micro
Pre-filter, flip back
the lid tabs and
remove the lid.
Put the Micro Pre-
filter inside the
canister and slide
the openin of the
cardboard mountin collar over the input port on the inside
of the canister. Press firmly around all ed es to ensure a
snu fit and air ti ht seal. Spread the Micro Pre-filter out,
makin sure no part of it ets trapped under the ed e of the
lid. Reinstall the lid and flip the lockin tabs back
to the down position.
Assembly - To install the le s and
accessory tray, undo the clips hold-
in the intermediate cover in place
and set the cover and lid assembly
aside. Turn tank upside down. Front
le s are on either side of the drain
port openin . These front le s do
not have the small hooks on either
side. The back le s do have the
hooks. These hooks are for the
hose to rest on when in stora e.
Ali n le s with openin s provided
on bottom of the canister and slide
into place. The holes will only ali n
in proper position for front and back
le s. Insert black support screw
into hole and ti hten screw with a
Phillips screwdriver.
Turn cleaner tank ri ht side up.
Attach Accessory Tray
Ali n the three slots on the ed e of
the accessory tray with the three
uides on the rear side of the tank
and press the accessory tray toward
the tank as you push the tray down.
The two lockin tabs will slide
under the rim of the tank and catch.
By pushin the tray down and
toward the tank it will lock into
place.
Place intermediate cover and lid
assembly ri ht side up and set
on top of the tank. Attach the
yellow clips from the tank onto
the intermediate cover.
The Lid Assembly with the vacuum
controls, motor, and filters are all
preassembled at the factory for your
convenience. Maintenance and
replacement of filters is described
later in this manual.
Attach hose, wands and
clean ng accessor es
Hose and accessories are stored
on the unit. The hose will loop
throu h the two outside holes of the
accessory tray and rest on the hooks
of the back le s as shown below.
For convenience, additional
accessories can be stored on
tray when not in use.
To Use Accessor es
Push hose into tank port; twist hose to
ti hten or loosen connection. The
wands and cleanin accessories
attach to hose in the same manner.
Adapter Hose -
Attaches easily to
HEPA Vacuum hose.
HEPA Vacuum - Complete
owners manual enclosed
with vacuum.
For a complete version of all owner’s manuals, please visits www.dustlesstools.com <http://www.dustlesstools.com> or call 800 568-3949.
HEPAKit16500:Layout 1 8/20/10 8:47 AM Page 2

FOR RIGHT ANGLE GRINDERS
2. Cut flanges to adjust he ght of shroud.
For best dust control, gr nd ng wheel
should be 1/4 nch below shroud.
3. Install gr nd ng wheel. See #2
for he ght.
5. Install Gr nd ng wheel. For best dust
control, wheel should be 1/4 nch
below shroud.
6. Insert hose to port.
800.568.3949
dustlesstechnologies.com
Instruct ons for Crack Chas ng/Tuckpo nt ng Appl cat on
1. Trim Flan es to adjust cuttin wheel in middle of shroud.
2. Cut the Dustie on "CC Line" or "TP Line" dependin on your
desired openin an le. Follow instructions 2-7 above.
3. Snap on Cover Plate* over open face.
*Not Included with all kits
This product was inspected and packaged carefully before being
shipped from the factory. If you should happen to need assistance
during assembly or operation, call 1-800-568-3949 for our
customer ser ice department.
Always make sure rinder is UNPLUGGED when removin
or attachin front noseclip. Before use, refer to your tool
manual for warnin s and instructions.
WARNING
4. T ghten band clamp.
Includes:
• Dustie™ shroud
• Band clamp
• Releasable zip tie
1. UN-PLUG GRINDER. Sl p shroud
on gr nder, flanges should be flush
w th attachment.
7. Secure other end of hose to the electr c cord w th
releaseable t e prov ded.
Installation Instruction
Manual082010
HEPAKit16500:Layout 1 8/20/10 8:47 AM Page 1
