DV Signage MON-150W-SDI Assembly instructions

Page 1 of 24
Manual
MON-150W-SDI
15.6” SDI Monitor
P/N 586845700-3

Page 2 of 24
Table of Contents
1. Introduction
3
2. System
4
3. Instruction
3.1 Preparation
7
3.2 Powering On
7
3.3 Signal Input
7
4. Controls
4.1 Button control
8
4.2 OSD menu function
9
4.3 Remote control
11
4.4 Serial control
12
5. Dimensions
13
6. Specification
14
7. Appendix I – Graphic & Video Mode Support Table
15
8. Appendix II – Auto Color Gain
18
9. Appendix III - Serial control protocols
19
10. Warranty, Caution & Limitation of Liability, Trademark
23
11. Contact details
24

Page 3 of 24
1. Introduction
The DV Signage 15.6” widescreen monitor (model : MON-150W-SDI) is a single LCD display unit.
The unit provides standard video interfaces (Analog RGB, HDMI, Display Port & 3G/HD/SD-SDI).
The monitor is fit for broadcasting application.
Ordering Information :
Part Number
Model
P/N 586845700-3
MON-150W-SDI
Optional parts :
Part Number
Model
P/N 367810091-3
Stand
P/N 366845413-3 &
P/N 366845414-3
Wall mount kit
P/N 559000106-3
IR remote handset
If you have difficulties, please contact your sales representative or Digital View support, contact
details are available on www.digitalview.com/dv_contactus.php.
IMPORTANT USAGE NOTE
The manufacturer accepts no liability for damage or injury caused by the use of this product. It is the
responsibility of the developer, integrators or other users of this product to:
Ensure that all necessary and appropriate safety measures are taken.
Obtain suitable regulatory approvals as may be required.
Check power settings to all component parts before connection.
DISCLAIMER
There is no implied or expressed warranty regarding this material.

Page 4 of 24
2. System
Monitor 15.6” (MON-150W-SDI)
A robust metal housing with powder coating:
Connector definition :
(1) OSD
button
(2) IR
Sensor
(10) Audio jack (stereo) output from HDMI / Display
port/SDI
(11) Built-in Speakers
(8)
Analog
VGA
Input
(9) COM
Port
(4)
Status
LED
(3) On/Off
switch
(5) Power in (DV
12V)
(6) Display Port Input
(7) HDMI Input
(12) 3G/HD/SD-SDI
input & loop out

Page 5 of 24
Item
Description
Function
1
OSD button
Controlling the OSD menu function
2
IR Sensor
IR Sensor
3
On/Off switch
Power on/off switch of the unit
4
Status LED
Status LED
5
Power in (DC 12V)
DC 12V Power input
6
Display Port Input
Display Port Input
7
HDMI Input
HDMI Input
8
Analog RGB Input
Analog RGB Input
9
COM port
For serial command control
10
Audio jack (Stereo) output from HDMI /
Display Port
Audio jack (Stereo) output from HDMI /
Display Port
11
Built-in Speakers
Built-in Speakers
12
3G/HD/SD-SDI input and loop out
3G/HD/SD-SDI input and loop out

Page 6 of 24
Desktop stand :
Wall Mount :
Desktop stand P/N 367810091-3
Wall mounting bracket
P/N 366845414-3
Panel mounting bracket
P/N 366845413-3

Page 7 of 24
3. Instructions
3.1 Preparation
This DV Signage monitor is designed to be as plug and play as possible requiring the minimum of
setup for use. The following describes the operation of this monitor unit.
Please make sure the whole package in the box includes the items below :
15.6” monitor
Power supply
Power cord
3.2 Powering On
Connect the provided external AC power supply unit.
Power on the unit using the Power on/off switch, the status LED should come on.
This LED indicates the controller status.
State
Status LED color
No signal & backlight off
RED
No signal & backlight on
ORANGE
With signal & backlight on
GREEN
3.3 Signal input
Analog VGA / HDMI / Display Port / SDI :
Analog VGA Input : As this may affect regulatory emission test results and the quality of the signal
to the controller, a suitably shielded cable should be utilized. Plug the VGA cable to “VGA” connector
on the monitor.
HDMI input : Support HDMI 1.3 input up to 1080p/WUXGA resolution. Plug the HDMI cable to
“HDMI” connector on the monitor.
Display Port Cable : Support single-link Display Port 1.1a. Plug the Display Port cable to the
“Display Port” connector on the monitor.
SDI Input : 3G/HD/SD-SDI signal input support. Plug the coaxial cable to the BNC connector.
SDI re-clock loop out : 3G/HD/SD-SDI re-clock loop out. Recommend to connect less than 100
meter in good co-axial cable (e.g Belden 1694A) between Digitalview devices.

Page 8 of 24
4. Controls
Once the system has been connected and switched on there are a number of functions available to
adjust the display image as summarized in the following sections. The settings chosen will be saved
for each mode independently.
4.1 Button control
Controls
Functions
Menu – turns OSD menu On or Off (it will auto time off) /
return to previous OSD menu page
(Function with signal input only)
Menu button
Down – Select function
(under OSD menu on state)
DOWN
Up – Select function (under OSD menu on state)
UP
+ – increase the setting / enter to the submenu
(under OSD menu on state)
+
- - decrease the setting
(under OSD menu on state)
-
Load factory default
Press and hold DOWN button to
power on the controller
Switch to the next input source
(under OSD menu off state)
+ / SOURCE
Volume adjustment (under OSD menu off state)
Up / Down

Page 9 of 24
4.2 OSD menu functions
OSD Functions
Brightnes
s
Increase/decrease brightness level.
Press – or + (-+ ) Total : 100 steps
Contrast
Increase/decrease contrast level.
Press – or + (-+ ) Total : 100 steps
Sharpnes
s
Increase/decrease sharpness level.
Press – or + (-+ ) Total : 8 steps
Color
Auto : Auto RGB Calibration ([See appendix IV] in details)
(Function in
ARGB mode only)
Color temp4(Adjust the warmness of the image displayed. The higher
temperature the
coolest image looks like. The lower temperature the
warmest image looks like.
Function in ARGB mode only)
4200k
5000k
6500k
7500k
9300k
User 4
R Press – or + (-+ ) Total :
100 steps
GPress – or + (-+ ) Total :
100 steps
BPress – or + (-+ ) Total :
100 steps
Reset
Gamma (0.4/0.6/1.0/1.6/2.2)
Display
(Function in ARGB mode only)
Auto Adjust
Auto adjust the positions, phase, frequency
Phase
Fine tune the data sampling position (adjust image quality)
Press – or + (-+ ) Total : 100
steps
Clock
Adjust the image horizontal size
Press – or + (-+ ) Total : 100
steps
Display Position
Adjust image position
Sound (Function when HDMI, Display Port, SDI
connected and selected)
Volume
Increase/decrease volume level, total: 100 steps
Press – or + (-+ ) Total : 100
steps
Mute
Mute
Output
Select audio output port
Speakers : via CN1 & J1 connector
SPDIF : via CN11 connector
System4
Input source select
Input : Select the input video signal
Display Port
VGA
DVI/HDMI
SDI
Autoscan : Enable the Auto source seek function
OSD menu

Page 10 of 24
Timer : OSD Timeout in seconds
3 sec
6 sec
12 sec
Always On
Rotation : OSD menu rotation in degree
0
90
180
270
Position : Adjust OSD menu position
Transparency : Set OSD transparency
Press – or + (-+ ) Total : 100
steps
Reset : Load factory default settings.
Press down on OSD keypad to factory reset
TEM
P
Reporting the on board temperature (0C)
Items marked 4have sub menus.
Exit the OSD menu to save the setting chosen
On board temperature reading :
This controller has a built in on board temperature sensor which can report the on board
temperature reading on
OSD menu. (See below) :

Page 11 of 24
4.3 Remote control (Optional)
BUTTON
FUNCTION
POWER BUTTON
Soft power ON/OFF button.
ATTENTION BUTTON
Use combined with digit keys “Attention” + “1” to enable/disable
the IR function.
MUTE BUTTON ( )
Switch to mute on/off mode.
SEL UP ( ) / SEL DN ( )
Press this button to select the items in the OSD menu. Use this
button to direct control the hotkey function for volume adjustment
under OSD menu off state.
VOLUME (-/+) BUTTON
Press the “+” button to increase the volume and the “-” to
decrease the volume.
+ / - BUTTON
Use “+” button to direct control the hotkey function for switching
to next input source under OSD menu off state
In OSD menu, pressing this button to adjust the settings.
DISPLAY BUTTON
Activate the OSD menu display on screen.
STOP (VGA) BUTTON
Press this button in the non OSD menu display mode to select
VGA source.
HDMI BUTTON
Press this button in the non OSD menu display mode to select
HDMI source.
HD-SDI 1 BUTTON
Press this button in the non OSD menu display mode to select
SDI source.
P/N 559000106-3 :
Remote control unit
(without DV logo silk
screen printing)

Page 12 of 24
4.4 Serial control
Connect the serial control cable to the monitor at COM port
RS-232 Serial control (Baud rate 2400, 8 bits, 1 stop bit and no parity)
Physical connection :
Monitor side
Connector interface : Serial port
Mating connector : DB9 Female
PIN#
Description
2
RS-232 Rx Data
3
RS-232 Tx Data
5
Ground
Software connection :
The OSD function can be controlled through sending the RS-232 protocol.
The RS-232 program can be custom-made to fit for application or it can be used the program
provided by Digitalview on request. Please contact your local sales for informations.
The Serial control protocols can be found in Appendix III.
54
6
3
1
789
Mating face of RS-232 DB9 Female

Page 13 of 24
5. Dimensions
Unit : mm

Page 14 of 24
6. Specification
LCD display
Color TFT
Screen size
15.6” (Diagonal)
Screen active area
344.2(H) x 193.5(V) mm
Panel resolution
1366(H) x 768(V)
Brightness
300 cd/m2(TYP)
Contrast ratio
500 : 1 (TYP)
Viewing angle
160/170o(TYP) (Vertical/Horizontal)
Signal input
Analog RGB
HDMI
Display port
SDI
I/O
Button control
IR remote control
Serial control (COM port – 2400 baud, n81)
Control interface
Buttons, RS-232, IR remote control
Graphics Format
Standard WUXGA, UXGA, SXGA, XGA, SVGA, VGA
resolution up to 60Hz.
Supported SDI serial
interface standard
SMPTE 292M, 259M-C, 424M, 425M (Level A)
Supported SDI video mode
576i50 (PAL)
480i60 (NTSC)
720p60/59.94/50/30/29.97/25 (4:2:2)
1035i60/59.94 (4:2:2)
1080p30/29.97/25/24/23.98 (4:2:2)
1080psf30/25/24/23.98 (4:2:2)
1080i60/59.94/50 (4:2:2)
1080p60/50 (4:2:2)
Number of SDI channel
input port supported
1
SDI re-clock loop through
output
Yes
Power input
DC 12V
Dimensions
380.6(L) x 230(W) x 54(D) mm (without stand / mounting
accessories)
Casing color & materials
Aluminum with Black powder coated
Weight
About 3 Kg (without stand / mounting accessories)
Environmental
Operating temperature : 0oC to 50oC
Relative humidity : 5%-95% relative humidity
(Non-condensing)
In the Box
- 15.6” monitor, MON-150W-SDI
- Power supply
- Power cord
Options
IR Remote handset, P/N 559000106-3
Stand P/N 366845191-3
Wall mount kit P/N 366845413-3 & 366845414-3

Page 15 of 24
7. Appendix I - Graphic & Video Mode
Support Table
ARGB port :
Mode
Resolution
Clk [MHz]
Horizontal
freq [KHz]
Vertical
freq [Hz]
Sync Mode
T_70
720x400 70Hz
28.322
31.469
70.087
Digital Separate Sync
T_70
720x400 70Hz
28.322
31.469
70.087
Sync On Green
V_60
640x480 60Hz
25.175
31.469
59.940
Digital Separate Sync
V_60
640x480 60Hz
25.175
31.469
59.940
Sync On Green
V_60
640x480 60Hz
25.175
31.469
59.940
Composite Sync
SV_60
800x600 60Hz
40.000
37.879
60.317
Digital Separate Sync
SV_60
800x600 60Hz
40.000
37.879
60.317
Sync On Green
SV_60
800x600 60Hz
40.000
37.879
60.317
Composite Sync
X_60
1024x768 60Hz
65.000
48.363
60.004
Digital Separate Sync
X_60
1024x768 60Hz
65.000
48.363
60.004
Sync On Green
X_60
1024x768 60Hz
65.000
48.363
60.004
Composite Sync
SX_60
1280x1024 60Hz
108
63.81
60.020
Digital Separate Sync
SX_60
1280x1024 60Hz
108
63.81
60.020
Sync On Green
SX_60
1280x1024 60Hz
108
63.81
60.020
Composite Sync
UX_60
1600x1200 60Hz
162
75.000
60
Digital Separate Sync
UX_60
1600x1200 60Hz
162
75.000
60
Sync On Green
UX_60
1600x1200 60Hz
162
75.000
60
Composite Sync
WUX_60
1920x1080 60Hz
172.8
67.5
60
Digital Separate Sync
WUX_60
1920x1080 60Hz
172.8
67.5
60
Sync On Green
WUX_60
1920x1080 60Hz
172.8
67.5
60
Composite Sync
WUX_60
1920x1200 60Hz
193.2
74.5
60
Digital Separate Sync
WUX_60
1920x1200 60Hz
193.2
74.5
60
Sync On Green
WUX_60
1920x1200 60Hz
193.2
74.5
60
Composite Sync

Page 16 of 24
HDMI port :
Mode
Resolution
Clk [MHz]
Horizontal
freq [KHz]
Vertical
freq [Hz]
T_70
720x400 70Hz
28.322
31.469
70.087
V_60
640x480 60Hz
25.175
31.469
59.940
SV_60
800x600 60Hz
40.000
37.879
60.317
X_60
1024x768 60Hz
65.000
48.363
60.004
SX_60
1280x1024 60Hz
108
63.81
60.020
UX_60
1600x1200 60Hz
162
75.000
60
WUX_60
1920x1080 60Hz
172.8
67.5
60
WUX_60
1920x1200 60Hz
193.2
74.5
60
1080p60
1920x1080p 60Hz
135
67.5
60
1080i60
1920x1080i 60Hz
74.14
33.7
60
1080i50
1920x1080i 50Hz
74.184
28.1
50
720p60
1280x720P 60Hz
74.25
45
60
576p50
720x576P 50Hz
26.9568
31.2
50
480p60
720x480P 60Hz
26.9568
31.4
60
Display Port port :
Mode
Resolution
Clk [MHz]
Horizontal
freq [KHz]
Vertical
freq [Hz]
T_70
720x400 70Hz
28.322
31.469
70.087
V_60
640x480 60Hz
25.175
31.469
59.940
SV_60
800x600 60Hz
40.000
37.879
60.317
X_60
1024x768 60Hz
65.000
48.363
60.004
SX_60
1280x1024 60Hz
108
63.81
60.020
UX_60
1600x1200 60Hz
162
75.000
60
WUX_60
1920x1080 60Hz
172.8
67.5
60
WUX_60
1920x1200 60Hz
193.2
74.5
60
1080p60
1920x1080p 60Hz
135
67.5
60
1080i60
1920x1080i 60Hz
74.14
33.7
60
1080i50
1920x1080i 50Hz
74.184
28.1
50
720p60
1280x720P 60Hz
74.25
45
60
576p50
720x576P 50Hz
26.9568
31.2
50
480p60
720x480P 60Hz
26.9568
31.4
60

Page 17 of 24
SDI port
Mode
576i50 (PAL)
480i60 (NTSC)
720p60 (4:2:2)
720p59.94 (4:2:2)
720p50 (4:2:2)
720p30 (4:2:2)
720p29.97 (4:2:2)
720p25 (4:2:2)
1035i60 (4:2:2)
1035i59.94 (4:2:2)
1080p30 (4:2:2)
1080p29.97 (4:2:2)
1080p25 (4:2:2)
1080p24 (4:2:2)
1080p23.98 (4:2:2)
1080psf30 (4:2:2)
1080psf25 (4:2:2)
1080psf24 (4:2:2)
1080psf23.98 (4:2:2)
1080i60 (4:2:2)
1080i59.94 (4:2:2)
1080i50 (4:2:2)
1080p60 (4:2:2)
1080p50 (4:2:2)

Page 18 of 24
8. Appendix II – Auto Color Gain
The Auto Color Gain function is supported in the ARGB mode only and is designed to
calibrate the controller to the incoming video signal. In order to calibrate correctly, the display must
be displaying an image containing both black and white data (see illustration below) when the
function is used. The internal processor of the video controller chip will then execute a process to
adjust the relative values of the RGB signals to achieve the best performance. The parameters of the
corrected RGB values are then stored in the controller and are unaffected by the Reset Factory
Defaults function.
Warning - If the Auto Color Gain is executed without an appropriate image being displayed, then the
process will set incorrect values and the display colors will be distorted. If this occurs, then it can
either be corrected by performing the process correctly or if this is not possible then the Reset Color
Gain function can be used. This function will reset the stored RGB values to a set of approximate
values.

Page 19 of 24
9. Appendix III – Serial control protocols
Function
Command
Description
Acknowledge (if enabled)
Menu
0xf7
Menu button pressed
Button equivalent
Select-down
button
0xfa
Select down button pressed
Button equivalent
Select-up button
0xfb
Select up button pressed
Button equivalent
Right/+ button
0xfc
Right/+button pressed
Button equivalent
Left/- button
0xfd
Left/- button pressed
Button equivalent
2. Parameter setting - immediate, relative, reset and query
Function
Command
Description
Acknowledge (if
enabled)
Volume control - left
+ right channel
0x80, “a” | “A”,
nn | “+” | “-“|
“r” | “R” |
“?”
Set audio (L+R) volume =
value/increment/decrement
Reset
Query
Volume left + right
Volume control -
on/off (mute)
0x80, “m” | “M”,
“0” |
“1“|
“r” | “R” |
“?”
Disable audio output
Enable audio output
Reset
Query
“0” – audio off (muted)
“1” – audio on
Brightness control
0x81,
nn | “+” | “-” |
“r” | “R” |
“?”
Set brightness =
value/increment/decrement
Reset
Query
Brightness.
Range: “0””0”-“6””4”
Default: “3””2”
Contrast control
0x82, “a” | “A”,
nn | “+” | “-” |
“r” | “R” |
“?”
Set all contrast =
value/increment/decrement
Reset
Query
Contrast.
Range: “4””0”-“6””4”
Default: “3””2”
Phase #
0x85,
nn | “+” | “-” |
“?”
Set dot clock phase =
value/increment/decrement
Query
Dot clock phase.
(In ARGB mode only)
Image H position #
0x86,
nnnn | “+” | “-” |
“?”
Set img_hpos =
value/increment/decrement
Query
Image horizontal position.
(In ARGB mode only)
Image V position #
0x87,
nnnn | “+” | “-” |
“?”
Set img_vpos =
value/increment/decrement
Query
Image vertical position.
(In ARGB mode only)
Sharpness
0x8a,
nn | “+” | “-” |”r” | ”R”
|
“?”
Set sharpness=
value/increment/decrement
Reset
Query
Sharpness
Range: “F””C”-“0””4”
Default: “0””0”
Frequency #
0x8b,
nnnn | “+” | “-“ |
“?”
Frequency =
value/increment/decrement
Query
Frequency adjustment
(In ARGB mode only)
OSD H position
0x90,
nnn | “+” | “-“ | “r” |
“R” | “?”
Set osd_hpos =
value/increment/decrement
Reset
Query
OSD horizontal position
Range: “0””0””0”-“3””E””8”
Default: “1””F””4”
OSD V position
0x91,
nnn | “+” | “-“ | “r” |
“R” | “?”
Set osd_vpos =
value/increment/decrement
Reset
Query
OSD vertical position
Range: “0””0””0”-“3””E””8”
Default: “1””F””4”
Select menu timeout
0x93,
nn | “+” | “-“ | “r” |
“R” | “?”
Select menu timeout =
value/increment/decrement
Reset
OSD menu timeout value.
“00” – Continuous.
Value – Round up to

Page 20 of 24
Query
nearest available step.
If value > max available
step, set it to the max
available step.
“0” “0” – Always On.
“0” “C” – 12 seconds
(Default)
“0” “6” – 6 seconds
“0” “3” – 3 seconds
Input main select
* Function in Valid
mode only
0x98,
nn | “+” | “-“ | “r” |
“R” | “?”
Select input main =
PC or video or next available
Reset
Query
Main selected.
“0x41,0x31” ARGB
(Default)
“0x45 0x31” HDSDI
“0x48,0x31” HDMI
“0x50,0x31” Display Port
GAMMA value
select
0x9d,
n |
“r” | “R” |
“?”
Select GAMMA value =
Value
Reset
Query
GAMMA value:
“0” – 0.4,
“1” – 0.6
“2” – 1.0 (Default),
“3” – 1.6
“4” – 2.2
Colour temperature
select
0xb3,
n |
“r” | “R” |
“?”
Select colour temperature =
value
Reset
Query
Main selected.
“0” – user defined RGB
values.
“1” – 4200K.
“2” – 5000K.
“3” – 6500K.
“4” – 7500K. (Default)
“5” – 9300K.
Red level for
selected colour
temperature
0xb4,
nn | “+” | “-” |
“r” | “R” |
“?”
Set the level of the red channel
for the selected colour temp. =
value/increment/decrement
Reset
Query
Red level for selected
colour temperature.
Range: “0””0”-“6””4”
Default: “6””4”
Green level for
selected colour
temperature
0xb5,
nn | “+” | “-” |
“r” | “R” |
“?”
Set the level of the green
channel for the selected colour
temp. =
value/increment/decrement
Reset
Query
Green level for selected
colour temperature.
Range: “0””0”-“6””4”
Default: “6””4”
Blue level for
selected colour
temperature
0xb6,
nn | “+” | “-” |
“r” | “R” |
“?”
Set the level of the blue channel
for the selected colour temp. =
value/increment/decrement
Reset
Query
Blue level for selected
colour temperature.
Range: “0””0”-“6””4”
Default: “6””4”
Backlight brightness
control
0xe0,
nn | “+” | “-” |
“r” | “R” |
“?”
Set backlight brightness =
value/increment/decrement
Reset
Query
Backlight brightness.
Range: “0””0”-“F””F”
Default: “F””F”
e.g “1””0” 0xe0 0x31
0x30
* This control can only
function when JB5 sets 3-
4 closed
* Apply for inverter control
voltage in range of 0~5V.
