DV Signage POP-15N (M3-330) User manual

User Guide
PopStyle 15.6” Network Display
POP-15N (M3-330) | Version 1.1

Page 2 of 14
Revision History
Amendment Date
Version
May 31, 2013
V1.0

Page 3 of 14
Table of Contents
1 Introduction ......................................................................................4
2 System............................................................................................ 5
3 Instructions....................................................................................... 6
3.1 Preparation.................................................................................................... 6
3.2 SD card .......................................................................................................... 6
3.3 Slide switch ................................................................................................... 7
3.4 Powering On ................................................................................................. 7
3.5 Autoplay / Manual Playback at power startup ......................................... 7
3.6 Playback modes ........................................................................................... 7
3.7 OSD Configuration mode............................................................................ 8
3.8 Network setup............................................................................................... 9
4Dimensions ....................................................................................11
5Specification ...................................................................................12

Page 4 of 14
1Introduction
The DV Signage 15.6” PopStyle is a self-contained LCD display and network digital media
player for continuous (looped) playback of video stored on a SD card. The unit comprises a
widescreen 15.6” color TFT LCD, a RJ-45 LAN port and optional touch screen. A range of
other accessories and factory installed customization options are also available, these are not
to be covered in this manual.
Please note that a certain level technical knowledge and experience is assumed, if you have
difficulties please contact your sales representative or DV Signage support, contact details
are available on http://www.dvsignage.com/contact
IMPORTANT USAGE NOTE
This equipment is for use by system developers and integrators. The manufacturer accepts
no liability for damage or injury caused by the use of this product. It is the responsibility of the
developer, integrators or other users of this product to:
Ensure that all necessary and appropriate safety measures are taken.
Obtain suitable regulatory approvals as may be required.
Check power settings to all component parts before connection.
DISCLAIMER
There is no implied or expressed warranty regarding this material.

Page 5 of 14
2 System
15.6” PopStyle (POP-15N-OF)

Page 6 of 14
3 Instructions
CAUTION: Never connect or disconnect parts of the system when the system is powered up
as this may cause serious damage.
3.1 Preparation
DV Signage PopStyles are designed to be as plug and play as possible requiring the
minimum of setup for use. The following describes the operation of the standard version,
there are however a number of options available and these may affect the preparation
required.
Main components:
PopStyle unit
AC power supply
SD card – see following note
3.2 SD card
The DV Signage PopStyle uses standard SD cards to store the media (video, still images) for
playback. The following are key points to note:
The format of the digital media stored on the SD card needs to meet certain
standards as per the specifications for this device as summarized in section 5.
Media files can be stored on the SD card in two ways:
oPlaylist mode: Using DV Signage’s DV Studio software which enables
creation of a playlist with a number of options for controlling media playback.
oSimple play mode: Using a PC copy function to transfer files onto the SD card.
All content files must be stored within a folder name MEDIA. (i.e. /Media/)
Additional notes regarding the playback modes are shown below.

Page 7 of 14
3.3 Slide switch
You may only choose either one way (LAN or USB) to update content without
removing SD card
3.4 Powering On
Install the SD card, however to reduce the risk of errors it is advised to have the
power off when removing or installing a SD card.
Connect the provided external AC power supply unit.
Power on the unit, the power LED should come on.
See the following section for Power On options.
3.5 Autoplay at power startup
The DV Signage PopStyle supports AutoPlay modes at power startup
AutoPlay: This is the default mode for the unit. This means that upon power-on video will start
playing in accordance with a playlist (if DV Studio was used to transfer the media files to the
SD card) or in alpha-numeric order (if the media files were simply copied to the SD card).
3.6 Playback modes
Playlist mode, i.e. using DV Studio:
When operating in playlist mode, both project file (*.prj) and playlist file (*.pll) must be
present on the SD card. These are used to control the sequence for all video tracks.
If playback does not run as expected please check that these files are present on the
SD card.
The project and playlist file are created using DV Studio software. Using this software,
you can set simple sequences or complex sequences including “jump track“ or “next
track” actions. The software can also program buttons with different functions like
“play”, “stop”, “pause”, “mute”, “previous”, “next” and “volume”.

Page 8 of 14
Simple play mode, i.e. files copied to SD card without using DV Studio:
In simple play mode, the user just copies all video files (.mpg) or JPEG files (.jpg)
onto the SD card. The PopStyle will play these files in alphabetical sequence.
For JPEG files, the play time is determined by the last digit of the filename. (For
example: APPLE5.mpg, where “5” means the track will be displayed for 5 seconds.)
Note: Do not use the same filename on both Video and JPEG.
Note: Make sure all capital letters in a filename defined in playlist are consistent with the
filename on SD card. All filenames should be in 16+3 format and avoid using any characters
like “~”, “_”, “-“, etc. All content files must be stored within a folder name MEDIA. (i.e. /Media/)
3.7 OSD Configuration mode
In OSD configuration mode, you may need external buttons to operate.
Use with external button.
To enter OSD configuration mode, holding button 8 and power on the PopStyle unit.
The OSD menu screen will be shown as follow:
Firmware Version: K1.04-V3.03.00
MAC address (ID): 000562FFF11B
Date (mm/dd/yy): 4 / 22 /2011
Time (hh/mm/ss): 16 : 12 : 21
GMT(+/-hh:mm): + 0 : 0
Volume: 5
OSD: On
Datalog: On
Cancel
OK
Press button 8 to select option.
Press button 7 or button 6 for change value.
Press button 7 or button 6 to confirm “OK” or “Cancel”.

Page 9 of 14
3.8 Network setup
Each PopStyle is shipped with DHCP settings (IP=0.0.0.0). In some network environment,
fixed IP could be used and you may need to change the PopStyle with the fixed IP settings.
All IP settings are set in a configuration file called “netcfg.ini”. To change the IP settings on
PopStyle, copy the netcfg.ini file with your setting on to MEDIA folder on SD card and restart
the PopStyle then you will see a boot up message with your IP information changed.
The following is an example of fixed IP settings in netcfg.ini file.
In addition to IP information, the NETCFG.INI file contains some system settings for
ViewStream 505 media player. Below is a table to show all user settings in the NETCFG.INI
ITEM
DESCRIPTION
IO_OUTPUT_MESSAGE_THROUGH_232_ENABLE
Enable message output on RS-232 port
0 = Disable message output
1 = Enable message output [Default]
VOLUME
Master volume set, Range (0-10)
[Default: 5]
FTP_UPDATE_ENABLE
Enable DV Connect mode
0 = Content pull mode
1 = Content push mode
[Default: 0]
TIME_ZONE
GMT time zone setting
Format: +/- hhmm [Default: +0000]
TIME_SERVER
Set time server
OFF = Disable time server polling
ON = Enable time server “pool.ntp.org” [Default]
DATALOG_DURATION_IN_DAY
Max. day(s) to keep data log
[Default: 31]
CLEANUP_INTERVAL_IN_MINUTE
Interval to clean up data log
IO_OUTPUT_MESSAGE_THROUGH_232_ENABLE=
1
VOLUME=5
FTP_UPDATE_ENABLE=0
JPG_TRANSITION_EFFECT=OFF
TIME_ZONE=+0
TIME_SERVER=ON
DATALOG_DURATION_IN_DAY=31
CLEANUP_INTERVAL_IN_MINUTE=1440
DAILY_END_TIME_ENABLE=1
IP_OVERWRITE=1
IP=10.1.0.123
NETMASK=255.0.0.0
GATEWAY=10.1.0.1
DNS1=10.1.0.1

Page 10 of 14
[Default: 1440]
DAILY_END_TIME_ENABLE
Stop playing End of Day
0 = disable
1 = enable [Default]
IP_OVERWRITE
Change IP settings on player
0 = Keep the old IP settings on player [Default]
1 = Overwrite with new IP settings on player
IP
IP address
0.0.0.0 = DHCP mode [Default: 0.0.0.0]
NETMASK
Subnet mask (Ignore if set to DHCP)
[Default: 0.0.0.0]
GATEWAY
Gateway value (Ignore if set to DHCP)
[Default: 0.0.0.0]
DNS1
DNS table
[Default: 0.0.0.0]

Page 11 of 14
4 Dimensions
Unit in mm
PopStyle 15.6” OpenFrame (POP-15N-OF)

Page 12 of 14
5 Specification
POP-15N-OF (M3-330) Specification:
Playback video format
MPEG-2 (.mpg)@3Mbit/s - Recommended
JPEG (.jpg) up to 1280x720
*Note: Depending on the features desired,
customer/purchaser may be required to obtain a video codec
license with the relevant organizations.
Video storage
SD cards
LCD display
Color TFT
Screen size
15.6” (Diagonal)
Screen active area
344.2(H) x 193.5(V) mm
Panel resolution
1366(H) x 768(V)
Brightness
220 cd/m2
Contrast ratio
400 : 1
Viewing angle
45 degree (Horizontal right)
45 degree (Horizontal left)
15 degree (Vertical upper)
35 degree (Vertical lower)
Audio output (Line out)
3.5mm Stereo phone jack
Playback Functions
Standard playback: Play, Stop, Pause, Repeat,
previous, Next, Volume
I/O
USB port – Content update
IR remote control – Playback control
Remote Ext. – External button connection (#1 - #8)
Volume control (via IR control)
LAN (RJ-45) – Content update
Power input
DC 12V
Dimensions
426.3(W) x 44(D) x 223.2(H) mm
Weight
1kg
Environmental
Operating temperature : 0oC to 50oC
Relative humidity : 5%-95% relative humidity
(Non-condensing)

Page 13 of 14
WARRANTY
The products are warranted against defects in workmanship and material for a period of one (1) year from the date of
purchase provided no modifications are made to it and it is operated under normal conditions and in compliance with
the instruction manual.
The warranty does not apply to:
Product that has been installed incorrectly, this specifically includes but is not limited to cases where
electrical short circuit is caused.
Product that has been altered or repaired except by the manufacturer (or with the manufacturer’s consent).
Product that has subjected to misuse, accidents, abuse, negligence or unusual stress whether physical or
electrical.
Ordinary wear and tear.
Except for the above express warranties, the manufacturer disclaims all warranties on products furnished hereunder,
including all implied warranties of merchantability and fitness for a particular application or purpose. The stated
express warranties are in lieu of all obligations or liabilities on the part of the manufacturer for damages, including but
not limited to special, indirect consequential damages arising out of or in connection with the use of or performance of
the products.
CAUTION
Whilst care has been taken to provide as much detail as possible for use of this product it cannot be relied upon as
an exhaustive source of information. This product is for use by suitably qualified persons who understand the nature
of the work they are doing and are able to take suitable precautions and design and produce a product that is safe
and meets regulatory requirements.
SAFETY INSTRUCTION
Do not use this product near water, for example, near a bathtub, wash bowl, kitchen sink, laundry tub, in a wet
basement or near a swimming pool.
LIMITATION OF LIABILITY
The manufacturer’s liability for damages to customer or others resulting from the use of any product supplied
hereunder shall in no event exceed the purchase price of said product.
TRADEMARKS
The following are trademarks of DV Signage :
DV Signage
Video Flyer / PopStyle

Page 14 of 14
CONTACT DETAILS
USA: 18440 Technology Drive
Building 130
Morgan Hill, CA 95037
Tel: [phone] Fax: [phone]
Sales: [e-mail]
EUROPE: The Lake House,
Knebworth Park,
Hertfordshire, SG3 6PY
UK
Tel: [phone] Fax: [phone]
Sales: [e-mail]
ASIA: 16th floor Millennium City 3
370 Kwun Tong Road
Kwun Tong
Hong Kong
Tel: [phone] Fax: [phone]
Sales: [email protected]
Specifications subject to change without notice
Document No. 916330410 © DV Signage 2013
