DVA DVA-110DOOR User manual

Quick Guide
1. Introduction
1
V150803-2
3. Connect the Device
Insert TF memory card and fix antenna, connect power supply. It takes
30 seconds to start device.
Step 1:
2. Install the App
Download the App ‘SafeSmart’ from ‘Google Play Store’ or ‘App Store’, and install
on mobile phone.
iOS !
NOTICE:
NOTICE:
Android
Special Notice: When open the app, you will receive a tip. Please click ‘OK’ to
allow the notifications, otherwise, you cannot receive any notification.
Special Notice: Do not connect the network cable, otherwise, the device
cannot set the Wi-Fi by scanning QR code.
For the first time installation,
please tap ‘OK’. Otherwise
y o u c a n ’ t r e c e i v e a n y
notification.
Tamper switch
Reset
Thread hole
CDS Sensor
LENs
Speaker
Ring Button Microphone
IR LED light
Doorbell
Power in DC+(12V)(Red)
Antenna
Doorbell Relay COM(Gray)
Net RJ45(Orange&White)
Lock
Doorbell Relay NO(White)
Net RJ45(Orange)
Net RJ45(Green&White)
Net RJ45(Green)
Lock Relay COM(Yellow)
Lock Relay NO(Purple)
Power in DC-(12V)(Black)
Door phone
power supply
Lock Power
supply
Doorbell
Power supply
1
2
3
6
4
5
7
8
(DC12V 500mA)

Step 3: Connect your mobile phone to your router.
Set device’s wifi by scanning QR code.
Register by E-mail:
2. Input your ID
password
1. Input your e-mail Please Remember your ID
Wifi name
Input your wifi
password, then
tap ‘Next’.
Step 2: Connect your mobile phone to your router to register a user ID.
2
Special Notice: If 2 mobile phones use the same account ID to login at the same time, only 1
mobile phone can receive the push notification alarm ring. So if use 2 mobile phones to
connect the device, user should register 2 different account IDs for the 2 mobile phones.
Antenna
Power adaptar
Special Notice: Device don’t support 5Ghz WIFI,user should use 2.4GHz WIFI to connect.
Special Notice: Device don’t support WPA2-PSK (TKIP) and WPA-PSK/WPA2-PSK
(TKIP)encrypt mode, user should change to other encrypt modes like WPA-PSK(AES),
WPA2-PSK(AES), WPA-PSK(TKIP), WPA-PSK/WPA2-PSK(AES)or WEP.

Phone 10-15cm
ipad and tablet 20cm
“DING”
After you hear
the sound ‘DING’
1
23. Input your
device name
4 . I n p u t y o u r
device password,
then tap ‘Save’.
Aim the device at your smart phone’s QR code in 10-15cm distance (iPad and
tablet are 20cm). Once hear the sound ‘DING’, click ‘Heard’, it shows ‘Setting
Success’, device is connected to the Wi-Fi.
2. Click to
add device
1. Slide down to refresh
and find device.
3
Step 4: Add device. In 'Device List', slide down to find device.
Special Notice: If device have no 'Di.Di.Di.Di....' sound means the device has
scanned before. User should press the reset button for 5 seconds until hear
‘KING’ and scan after hearing the 'Di.Di.Di.Di....' notice sound.
Special Notice: Device is designed not able to scan QR code for 2 times. If want
to change Wifi in another place, user should press the reset button for 5 seconds
until hear ‘KING’ and scan after hearing the 'Di.Di.Di.Di....' notice sound.
Device will have 'Di.Di.Di.Di....' sound noticing user to scan Wifi QR code.

!
NOTICE:
If fail to scan the QR code, you could reset the device and retry. Or
connect wifi by using network cable. More details please refer to
PART9 & PART10.
NOTICE:
5. Date and Time
4
In “Device List-Device-Setting-Date and Time”, choose your Time Zone, and check if the
new time is right or not. If time is right, press apply to get network time automatically.
Scan QR code to set Wifi can be scanned only once. If user need to add device to
other mobile phones, user don’t need to scan Wifi QR code again. User should
press the button in the ‘device list’ to enter ‘Add Devices’ interface, press
‘Manual’ button and input device ID and password to add device.
4. Add device to another mobile phones.
Note: Device ID is in ‘Device List->Device->Edit’ as below.

5
Remark:
1. Set Time Zone
2. Check time is
right or not
3. Click to confirm
Time zone example: China UTC+8
Germany/France/Spain/Poland/Italy/Netherlands/Norway/Sweden UTC+1
UK/Portugal/Ireland UTC+0 Turkey/Romania/Finland UTC+2
Mexico UTC-6 Colombia/Ecuador/Peru UTC-5
Venezuela/Chile/Manaus UTC-4 Agentina/Uruguay UTC-3
6. Push Notification Ring
In order to receive the push notification from the device, you should turn on ‘Alarm Push’.
Step 1: !
NOTICE:
NOTICE:
By tapping this icon, you
can delete the ID which
no need alarm push .
One device can push
alarm to 5 IDs at most.

Step 2: When people press the call button of the device or trigger the alarm, there
will be a notification received on the mobile phone screen. For Android,
press ‘check’ to view. For iphone, slide and press ‘view’ or to view.
!
NOTICE:
NOTICE: User must keep the app running at phone's background, user
can't force stop the app in phone's application manager, otherwise
phone can't receive any push notification.
7. View Interface
Date and
Time
Press and hold
for 3 seconds to
unlock. Then you
had to wait for 6
s e c o n d s t o
unlock again.
View HD image at
1280*720
View clear image at
640*360
View smooth image at
320*180
8. Video Record and Playback
Start recording. Insert the TF card (DO NOT insert or remove TF card when
device is power on). Enter ‘Device list→Device→Setting→Storage Info’
Click ‘Erase SD Card’ to format SD card. In ‘Device list→Device→Setting→
Record settings’ choose Record type and Record Time.
Step 1:
iOS
Android
6
Slide to view
Audio Snapshot Hangup Hear/Talk Button

7
Step 2: Playback.
view playback.
In ‘Device list→Device→Playback' , chose the video file to
‘Device List→Setting→Security Settings’, choose ‘Admin password’ to modify
device’s password.
2 . C h o o s e t h e
recording time.
1 . C h o o s e ‘ A l a r m
Recording’ to record
when visitor press ring
b u t t o n o r s e n s o r s
triggered.
9. Modify device’s password

8
10. Reset the device
Press and hold the reset button
for 5 seconds and you will hear
a voice of ‘KING’, wait 30
seconds to restart the device.
11. Connect wifi by using network cable (Only used for the
QR code scanning is not available)
Step 1: Plug in a network cable to the device and the LAN plug of the router.
Step 2: Add device. In ‘device list’ slide down to find device.
3. Input your
device name
1
2
1.Slide down to refresh
and find device
2.Click
to add
device
4. Input your device
password, then tap
‘Save’.
Tap ‘Admin password’
Tap ‘Secrity Setting’
I n p u t t h e o l d
password and the
new password, then
tap ‘Save’.

Please confirm the correct Wi-Fi setting and insure the position with
good Wi-Fi signal before mounting on the wall. Otherwise, it needs to
relocate the router or the antenna direction to receive the good Wi-Fi
signal. If the Wi-Fi signal is still not strong enough, please add the Wi-Fi
repeater or use the network cable.Make a mounting hole similar size as
the back housing of the device. Drill a hole for the wires to go through
the wall.
Remark:
9
Choose ‘WIFI’
Choose the
WIFI
I n p u t w i f i
password and
tap ‘Ok’
Step 3: Set wifi. In
to set device WIFI.
‘Device list→Device→Setting→Network settings’ Choose ‘WIFI’
Notice: The wifi antenna should be installed inside the house to have better
signal.
12. Mount on the Wall

Step 3: Lead the wires through the hole in the wall, and put the device into the back
housing. Tighten the screw in the bottom.
Step 1: Drill a hole for the wires to go
through the wall
Step 2: Fix the back housing on the wall
with two screws
Step 5: Connect the wires of power supply, unlock signal, antenna, etc. in other side
of the wall.
10
Step 4: Locate the antenna clip on the wall with screws.
A d j u s t t h e
a n t e n n a
direction to have
the good signal
L o c a t e t h e
antenna clip on
t h e w a l l w i t h
screws.
