DXV Modulus D12031000 Series User manual

- 1 -
INSTALLATION INSTRUCTIONS
SAVE FOR FUTURE USE
Product names listed herein are trademarks of AS America, Inc.
© AS America, Inc. 2018 755493-100 Rev. 1.0 (7/18)
Thank you for selecting DXV. To ensure this product is installed properly, please read these instructions carefully before you begin.
(Certain installations may require professional help.) Also be sure your installation conforms to local codes.
CAUTION: PRODUCT IS FRAGILE. TO AVOID BREAKAGE AND POSSIBLE INJURY HANDLE WITH CARE!
NOTE: Pictures may not exactly define contour of tub or components.
!
DXV Modulus™
Free Standing Tub
Model D12031000 SERIES
In the United States:
DXV
One Centennial Avenue
Piscataway, New Jersey 08855
Attention: Director of Customer Care
For residents of the United States, warranty
information may also be obtained by calling
the following toll free number: [phone]
www.DXV.com
In Canada:
DXV
5900 Avebury Road
Mississauga, Ontario
L5R 3M3
Canada
Toll Free: 1-800-387-0369
Local: 905-306-1093
Fax: [phone]
www.DXV.ca
In Mexico:
DXV
Via Morelos 330
Col. Santa Clara Coatitla
Ecatepec, Estado de México 55540
Toll Free: 01-800-8391200
www.DXV.mx
RECOMMENDED TOOLS AND MATERIALS
Most of the procedures require the use of common tools and materials, which are available from hardware and
plumbing supply stores. It is essential that the tools and materials be on hand before work has begun.
ROUGHING-IN REFERENCES
Tools Materials
• Level
• Square
• Tape Measure
• Pipe Wrench
• Slip Joint Pliers
• Standard Woodworking Tools
• Personal Safety Equipment
• Caulking Gun
• Suction Cups/Lifting Straps
• Silicone Caulking
• Tub & Tile Caulk
72"
(1830 mm)
31-1/2"
(801 mm)
32"
(814 mm)
21-3/8"
(543 mm)
24"
(610 mm)
4-9/16" (116 mm)
1/2"
(13 mm)
2-7/8"
(72 mm)
37-13/16"
(961 mm)
16-1/2"
(409 mm)
Freestanding tubs use wall-mounted
or freestanding faucets. The waste
and overow assembly is concealed
between the walls of the tub, eliminating
the need for a decorative exposed
drain kit.
WEIGHT
TUB 121 lbs. (54.9 kg)
WATER 676 lbs. (307 kg)
TUB + WATER 797 lbs. (362 kg) kg)

- 2 - 755493-100 Rev. 1.0 (7/18)
IMPORTANT SAFETY INSTRUCTIONS
READ AND FOLLOW ALL INSTRUCTIONS!
SAVE THESE INSTRUCTIONS
!WARNING: Risk of personal injury. Do not permit children to use this bathtub without adult supervision.
Never drop or insert any object into any opening.
!WARNING: Risk of electric shock. Do not permit electrical appliances near any bathtub
when bathtub contains water.
!WARNING: Risk of hyperthermia and possible drowning. People using medications
and/or having adverse medical history should consult a physician before using this product.
!WARNING: Risk of personal injury. Do not overll bathtub before entering. Entering tub when lled
more than 2/3 can cause overow and slippery conditions. Exercise caution when entering and exiting.
!WARNING: No Food or Alcoholic Beverages. Use of your bathtub immediately after meals is not recommended.
Avoid alcohol consumption before or during bathing. Alcoholic beverages can cause drowsiness or hyperthermia
resulting in loss of consciousness or even drowning.
!WARNING: Pregnancy. If you are or think you may be pregnant, consult your physician before using the bathtub.
Use this unit only for its intended use as described in this manual.
Do not use any attachments not recommended by DXV.

- 3 - 755493-100 Rev. 1.0 (7/18)
GENERAL INSTALLATION INFORMATION
If you have installation or warranty questions please do not return the unit to the place of purchase.
Call 800-227-2734
Always protect tub from construction damage by using a protective cover. Damage, including chips and
scratches incurred at the jobsite is excluded from warranty but may be repaired by qualied technician at
the owner’s expense. Do not stand in the tub or store materials in the tub during construction. Do not store
tub in temperatures below 32 degrees Fahrenheit.
Protect all nished surfaces of the bathtub during construction and installation using a drop cloth.
BEFORE YOU BEGIN:
!CAUTION: Risk of personal injury. This bath is heavy. Obtain sufcient help and use suction
cups/lifting straps to carefully lift or move the tub.
IMPORTAN:To ensure a successful installation it is important that you install the tub on a level nished oor.
• Observe all local plumbing and building codes.
IMPORTANT: An 8" Tail Piece, nut and washer is included in this package.
Make sure you locate and retain these pieces before discarding
the carton and packing material.
• Unpack and inspect the bath for damage.
• To simplify future maintenance, make sure all plumbing connections
around/under the tub can easily t through openings or doorways.
• Install the tub to an adequately supported, level nished oor.
Refer to the Roughing-in information.
• Carefully plan moving the tub into the installation area prior to doing so.
This tub is heavy and will not easily t through doorways.
• This tub is designed for a freestanding installation only.
• Illustrations shown may not look like your actual product but they are
still correct for this installation.

- 4 -- 4 -
1
2
NOTE: Provide adequate oor support. The tub is heavy. Obtain sufcient help and use
suction cups/lifting straps to carefully lift or move tub.
• Make sure the factory-installed drain connections
to the tub have not become loose during shipping.
Tighten as needed to prevent leakage.
• Carefully place the tub on the nished level oor
in the desired location and over the drain/waste outlet.
(Fig. A)
• Mark the desired tub position or location on the oor with
an erasable marker, then remove the tub from the oor and
drain/waste outlet.
• Place template over drain/waste outlet (keeping centered
within the tubs marked area) and mark oor where 2 tub
anchors will be installed in oor, then drill marked oor
locations (approx. 2 3/4" (70 mm)) (Fig. B)
• Place inserts into drilled oor followed by screwing
in the tub anchors. (Fig. C)
• Carefully place tub back on the nished oor,
over the drain/waste outlet and tub anchors. (Fig. D)
• Check to ensure the tub is level in several directions.
Adjustable feet under the tub can be used to further
level the tub. Also check that there is a slight gap
between the tub base and the oor. Gap shall not
exceed 1/8" (3 mm).
NOTE: The drain/waste outlet must be installed in accordance
with all local building codes.
All drain connections must be made using
an access created beneath the tub.
INSTALLATION INSTRUCTIONS:
1/8" MAX
(3 mm)
FINISHED FLOOR TUB ANCHORS
755493-100 Rev. 1.0 (7/18)
Fig. A
Fig. B
Fig. C
Fig. D

- 5 - 755493-100 Rev. 1.0 (7/18)
4
5
• Fill the tub with water and check for leaks. Re-tighten any loose connections as necessary.
• Apply a bead of Tub & Tile Caulk around the bottom
edge of the tub where it meets the oor. Remove
any excess caulking.
No xtures can be mounted on the tub deck of freestanding tubs. Floor or wall-mounted xtures are required.
Wall-Mounted - The position of the tub and the reach of the spout are critical. Pay special attention to the spout reach when
choosing your xtures. Be careful to ensure the spout will extend out far enough to clear the tub ange and the falling water will
not hit too high up on the side wall of the tub and splash
Floor-Mounted - Floor-Mounted- Some freestanding xtures must be anchored to the tub drain for stabilization. The waste and
overow on freestanding tubs are concealed so anchoring to the overow pipe (or tub structure) is not possible. Many kits (with
minor modication) can be mounted to the wall (rather than the drain pipe) for stabilization.
FIXTURES
CLEAN-UP
Caution: Risk of product damage: Do not allow cleaners containing petroleum distillates to remain in contact
with the surface for long periods of time.
Caution: Risk of product damage: Do not use abrasive cleaners, as they may scratch and dull the bath surface.
Use warm water and a liquid, non-abrasive detergent to clean the surface.
Caution: Risk of product damage: Do not use metal scrapers, wire brushes, or other metal tools to remove stains,
paint, plaster or tar.
Clean and rinse the bath completely with water immediately after applying cleaners.
Rinse and dry any overspray that lands on nearby surfaces.
3
• The tail piece assembly, consisting of a anged tail piece, drain
tail piece gasket and slip-joint nut used to connect the tub
drain to the drain/waste outlet, is included with this product.
• The 1-1/2" diameter tail piece is compatible with drain provided.
• Slide the slip-joint nut over tail piece towards the anged end as shown.
• Slide the P-trap slip-joint nut and seal over the tail piece as shown.
• Insert the tail piece into the P-trap.
• The tail piece can be cut if necessary.
• Ensure all connections to the tub, tail piece and P-Trap are
fully seated and securely tightened.
NOTE: Connecting the tail piece assembly to the drain will
require access from beneath the tub.
INSTALLING THE 1-1/2" DIAMETER TAIL PIECE ASSEMBLY
INTO P-TRAP
DRAIN TAIL PIECE GASKET
SLIP-JOINT NUT
TAIL PIECE
P-TRAP
(INCLUDED) THREADED PORTION
OF DRAIN BODY
TAIL PIECE
ASSEMBLY
FINISHED
FLOOR
SLIP-JOINT NUT
P-TRAP
& SEAL
(PROVIDED BY
INSTALLER)
(PROVIDED BY
INSTALLER)
