dymax ECE Series User manual

Dymax ECE Series UV Light-Curing Lamps
User Guide
ECE 2000 & 5000 UV Light-Curing Flood Lamps
■Instructions for Safe Use
■Setup and Operation
■Maintenance
■Ordering Spare Parts and Accessories
ECE 2000 Flood Lamp ECE 5000 Flood Lamp

2
Dymax ECE Series UV Flood Lamps User Guide
About Dymax
UV/Visible light-curable adhesives. Systems for light curing, fluid dispensing, and fluid packaging.
Dymax manufactures industrial adhesives, light-curable adhesives, epoxy resins, cyanoacrylates, and activator-cured adhesives.
We also manufacture a complete line of manual fluid dispensing systems, automatic fluid dispensing systems, and light-curing
systems. Light-curing systems include LED light sources, spot, flood, and conveyor systems designed for compatibility and high
performance with Dymax adhesives.
Dymax adhesives and light-curing systems optimize the speed of automated assembly, allow for 100% in-line inspection, and
increase throughput. System designs enable stand-alone configuration or integration into your existing assembly line.
Please note that most dispensing and curing system applications are unique. Dymax does not warrant the fitness of the product for
the intended application. Any warranty applicable to the product, its application, and use is strictly limited to that contained in the
Dymax standard Conditions of Sale. Dymax recommends that any intended application be evaluated and tested by the user to ensure
that desired performance criteria are satisfied. Dymax is willing to assist users in their performance testing and evaluation by offering
equipment trial rental and leasing programs to assist in such testing and evaluations. Data sheets are available for valve controllers
or pressure pots upon request.

3
Dymax ECE Series UV Flood Lamp User Guide
Contents
Introduction............................................................................................................................................. 4
Introduction to the User Guide ............................................................................................................................... 4
Where to Get Help .................................................................................................................................................. 4
Safety....................................................................................................................................................... 4
General Safety Considerations ................................................................................................................................ 4
Safety Symbol Index ................................................................................................................................................ 5
Specific Safety Considerations................................................................................................................................. 5
Dymax UV Light-Curing System Safety Considerations ........................................................................................... 5
Product Overview .................................................................................................................................... 7
Description of the ECE Series Flood Lamps ............................................................................................................. 7
System Components................................................................................................................................................ 8
Assembly and Setup................................................................................................................................. 9
Unpacking and Inspecting Your Shipment............................................................................................................... 9
Parts Included in an ECE Series UV Light-Curing Flood Lamp .................................................................................. 9
System Interconnection ......................................................................................................................... 10
Operating the Flood Lamp ..................................................................................................................... 12
Cleaning and Maintenance .................................................................................................................... 13
Bulb Replacement Procedure................................................................................................................................ 13
Lamp Base Replacement Kit .................................................................................................................................. 15
Fuse Replacement Procedure................................................................................................................................ 15
Cleaning................................................................................................................................................................. 16
Troubleshooting..................................................................................................................................... 17
Spare Parts and Accessories................................................................................................................... 18
Optional Accessories ............................................................................................................................................. 19
Specifications......................................................................................................................................... 20
Definition of Terms ................................................................................................................................ 21
Warranty ............................................................................................................................................... 22
Index...................................................................................................................................................... 23

4
Dymax ECE Series UV Flood Lamps User Guide
Introduction
Introduction to the User Guide
This guide describes how to assemble, use, and maintain the Dymax ECE-series flood lamps safely and
efficiently.
Intended Audience
Dymax prepared this user guide for experienced process engineers, technicians, and manufacturing
personnel. If you are new to UV light sources and do not understand the instructions, contact Dymax
Application Engineering to answer your questions before using the equipment.
Where to Get Help
Additional resources are available to ensure a trouble-free experience with our products:
■Detailed product information on www.dymax.com
■Dymax Customer Support and Application Engineering teams are available in the United States,
Monday through Friday, from 8:00 a.m. to 5:30 p.m. Eastern Standard Time. You can also email
Dymax at [email protected]m. Contact information for additional Dymax locations can be found on the
back cover of this user guide.
■Dymax adhesive Product Data Sheets (PDS) on our website
■Material Safety Data Sheets (MSDS) provided with shipments of Dymax adhesives
Safety
WARNING! If you use a Dymax UV flood lamp without first reading and understanding the
information in this user guide, injury can result from exposure to UV light. To reduce the risk of
injury, read and ensure you understand the information in this user guide before assembling
and operating an ECE-series flood lamp.
General Safety Considerations
All users of Dymax ECE light-curing flood lamps should read and understand this user guide before
assembling and using the system.
To learn about the safe handling and use of light-curable formulations, obtain and read the MSDS for each
product. Dymax includes an MSDS with each adhesive sold. In addition, fluid product MSDS can be
requested through the Dymax website.

5
Dymax ECE Series UV Flood Lamp User Guide
Safety Symbol Index
The following symbols are displayed on Dymax ECE series flood lamps and flood lamp accessories. Please
see below for their meanings.
Refer to Equipment Manual
Warning!
Gloves Required
Caution! Hot Surface
Eye Protection Required
Warning! UV Light Hazard
Warning! Electrical Shock
Hazard
Specific Safety Considerations
Dymax ECE flood lamps are designed to maximize operator safety and minimize exposure to UV light-
curing energy. To use the unit safely, it must be set up and operated in accordance with the instructions in
this user guide. Please also read and understand the safety considerations unique to UV light-curing
systems as described below.
WARNING! Looking directly at the UV light emitted by an ECE flood lamp can result in eye
injury. To prevent eye injury, never look directly at the high-intensity light and always wear
protective goggles (provided).
Dymax UV Light-Curing System Safety Considerations
Operators must understand these four concepts to use the UV light source safely:
■UV exposure
■High-temperature surfaces
■Ozone
■Bright, visible light
Each is described below.
UV Exposure
Standard Dymax UV light-curing systems and bulbs have been designed primarily to emit UVA light (Figure 1).
UVA light is generally considered the safest of the three UV ranges: UVA, UVB, and UVC. Although OSHA
does not currently regulate ultraviolet light exposure in the workplace, the American Conference of
Governmental Industrial Hygienists (ACGIH) does recommend Threshold Limit Values (TLVs) for ultraviolet
light.
The strictest interpretation of the TLV (over the UVA range) for workers’ eyes and skin is 1 mW/cm2
(intensity), continuous exposure. Unless workers are placing bare hands into the curing area, it is unusual

6
Dymax ECE Series UV Flood Lamps User Guide
to exceed these limits. To put 1 mW/cm2limit into perspective, cloudless summer days in Connecticut
regularly exceed 3 mW/cm2of UVA light and also include the more dangerous UVB light (primarily
responsible for sun tans, sun burns, and skin cancer) as well.
Figure 1. UV Spectrum
Checking the Workstation
The human eye cannot detect “pure” UV light, only visible light. A radiometer should be used to measure
stray UV light to confirm the safety of a UV light-curing process. A workstation that exposes an operator to
more than 1 mW/cm2of UVA continuously should be redesigned.
Protecting Operators
Light-curing technology can be a regulatory compliant, “worker-friendly”manufacturing process when the
proper safety equipment and operator training is utilized. There are two ways to protect operators from
UV exposure: shield the operator and/or shield the source.
Shield the Operator —UV-Blocking Eye Protection - UV-blocking eye protection is recommended when
operating UV light-curing systems. Both clear and tinted UV-blocking eye protection is available from
Dymax.
UV-Blocking Skin Protection —Where the potential exists for UV exposure upon skin, opaque, UV-
blocking clothing, gloves, and full-face shields are recommended.
Shield the Source of UV
Any substrate that blocks UV light can be used as a shield to protect workers from stray UV light. The
following materials can be used to create simple shielding structures:
Rigid Plastic Film —Transparent or translucent/UV-blocking plastics (typically polycarbonate or acrylic)
are commonly used to create shielding where some level of transparency is also desired.
Flexible Film —Translucent UV-blocking, flexible urethane films can be used to quickly create
workstation shielding. This UV-blocking, flexible urethane film is available from Dymax, call for assistance.
Ozone
Standard Dymax bulbs (UVA type) generate an insignificant amount of UVC and therefore essentially no
ozone. Some UV light-curing systems, like those used to cure UV inks, emit primarily “shortwave” (UVB

7
Dymax ECE Series UV Flood Lamp User Guide
and UVC) energy. Upon exposure to UVC light (specifically <240 nm), oxygen molecules (O2) split into
oxygen atoms (O) and recombine with O2to create ozone O3. The current, long-term ozone concentration
limit recommended by ACGIH, NIOSH, and OSHA is 0.1 ppm (0.2mg/m3).
High-Temperature Surfaces
Surfaces exposed to high-intensity curing lights will rise in temperature. The intensity, distance, exposure
time, cooling fans, and the type/color of the surface can all affect the actual surface temperature. In some
cases, exposed surfaces can reach temperatures capable of producing a burn or causing damage to a
substrate. In these cases, care must be taken to ensure either a more moderate surface temperature or
appropriate protection/training for operators.
Bright, Visible Light
The bright, visible light emitted by some UV light-curing systems can be objectionable to some workers
and can cause eyestrain. Tinted eye protection and/or opaque/tinted shielding can be utilized to address
this concern.
Summary
UV-light sources can be more “worker friendly” than many commonly accepted industrial processes,
provided the potential concerns are addressed. Both the lower working temperature and lack of spurious
frequency transmission that this system produces make it even more user friendly. Contact your Dymax
representative for information regarding the proper use of Dymax light-curing systems.
Product Overview
Description of the ECE Series Flood Lamps
Dymax ECE series UV light-curing flood lamps are general-purpose units for the curing of UV light-curable
adhesives, coatings, and inks. They have extensive use in a wide variety of applications such as bonding,
potting, sealing, and encapsulating. These light sources are extremely unique in that they offer exceptional
versatility and expandability.
The design of these units has been carefully considered to allow the light source to be successfully utilized
in a wide variety of manufacturing situations.
Each system is designed and shipped in a unitized configuration for easy bench-top mounting with all
controls and functions right at the hands of the operator. Each system can also be custom configured for
mounting of the lamp/reflector assembly housing in a remote curing location and the power supply can be
mounted several feet away within the easy reach of an operator. The lamp/reflector assembly housings
have been designed with clean, unobstructed surfaces for maximum ease of installation in existing or
specialized equipment.
Several lamp/reflector assembly housings can be mounted side-by-side in a linear configuration or a large
area array. The power supplies can then be stacked and mounted remotely to provide consolidated
operator control.

8
Dymax ECE Series UV Flood Lamps User Guide
System Components
Figure 2. ECE UV Flood Lamp
ECE 2000
The Dymax ECE 2000 is a general purpose UV light-curing flood lamp with an effective curing area of
approximately 8" x 8" ( 20.32 cm x 20.32 cm), making it ideal for batch processing or curing large areas.
ECE 5000
The Dymax ECE 5000 is a general purpose UV light-curing flood lamp with an effective curing area of
approximately 5" x 5" (12.7 cm x 12.7 cm). The unit is ideal for small batch processing of UV adhesives and
potting compounds.
Comparatively, it provides more than twice the output intensity of an ECE 2000 flood lamp for faster
curing capability and the additional ability to cure conformal coating resins.
ECE Solid-State Power Supply
This power supply allows external electrical inputs and provides power to the ECE Flood Lamps. The power
supply contains the on/off power switch and hour meter. The power supply also houses its own cooling
fans and power distribution for optional accessories. The rear panel has an integrally fused AC-power
receptacle and a 9-pin female connector. The solid-state power supply yields reliable and stabilized lamp
voltage in virtually any electrical system in the world. Other than ensuring a properly configured plug is
employed, no other adjustment of settings is required. The power supply also conditions the electrical
power to the lamp providing longer, more reliable lamp life.
ECE Flood Lamp
Power Supply
ECE 5000
ECE 2000

9
Dymax ECE Series UV Flood Lamp User Guide
Assembly and Setup
Unpacking and Inspecting Your Shipment
Your ECE series flood lamp arrived in one or two boxes. Inspect the boxes for damage and notify the
shipper of box damage immediately.
Open each box and check for equipment damage. If parts are damaged, notify the shipper and submit a
claim for the damaged parts. Contact Dymax so that new parts can be shipped to you immediately.
Check that the parts included in your order match those listed below. If parts are missing, contact your
local Dymax representative or Dymax Customer Support to resolve the problem.
Parts Included in an ECE Series UV Light-Curing Flood Lamp
Figure 3. ECE Series Flood Lamp Components
■ECE 2000 or 5000 Lamp/Reflector Assembly Housing (1) –Contains the reflector, UV lamp (400 Watt,
metal halide. Optional visible or mercury vapor bulbs available), lamp sockets, high-voltage starter,
and three circular connectors.
■ECE Solid-State Power Supply (2)
■Interconnection Cable (3) –Connects the power supply to the lamp/reflector assembly housing.
Power Cord (4) - Dependent on model ordered. Available options listed below:
oType G Power Cord (PN 40995 & 40935)
oNo Power Cord (PN 40965 & 40915)
■Dymax ECE-Series UV Flood Lamps User Guide (5)
■UV Protection Goggles (6)
■Bypass Connectors (7 & 8) –for the Light Shield (PN 41068) and Shutter (PN 41069)
■Hex Wrench (Not Shown)

10
Dymax ECE Series UV Flood Lamps User Guide
System Interconnection
NOTE: The only tool required for this procedure is 3/32" hex wrench which is provided with the unit.
1. Place the 400 Watt Bulb into the Lamp/Reflector Assembly Housing. Refer to the Bulb
Replacement/ Installation section of this manual for complete instructions.
WARNING! It is important to wear protective gloves when installing the Glass UV
Shield! Do not touch the Glass UV Shield with bare fingers! Fingerprints may etch into
surface and cause light transmission loss!
2. Place the Reflector Housing up-side down on a flat surface.
3. Loosen the four screws in the Filler Plate that hold the Reflector to the Housing.
4. Slide the Glass UV Shield under the Filler Plate and adjust it symmetrically over the Reflector
Aperture.
5. Tighten the four screws (Figure 4).
NOTE: Do not over tighten the screws. Doing so may crack the Glass Shield.
Figure 4. Reflector Filler Plate
ECE 2000 ECE 5000
6. Position the Power Supply and Reflector Housing so that there is free air circulation around the
sides. 12 inches (30.5 cm) of space is recommended. The Reflector may be mounted to a Dymax
flood lamp accessory such as a Mounting Stand, Light Shield, or Shutter. See the connecting
instructions in the user guide for the appropriate Dymax accessory.
WARNINGS! Always observe safety requirements when working with electrical
equipment! Electrical hazard is present!
Do not position the Light Shield on top of the Power Supply (Figure 5). The ECE Flood
Lamp System requires adequate air circulation. Setting up the system in such a
configuration can result in damage to the equipment and unsafe operating
conditions.
