Dynabrade 52674 Guide

Safety, Operation and Maintenance – Save This Document and Educate All Personnel
Parts Page Reorder No. PD13•19
Effective June, 2013
WARNING
Read and understand this tool manual before operating your air tool. Follow all safety rules for the protection of operating personnel as well
as adjacent areas. Always operate, inspect and maintain this tool in accordance with the American National Standards Institute (ANSI).
Safety Requirements for the Use, Care and Protection of Abrasive Wheels – ANSI B7.1, Compressed Air and Gas Institute (CAGI) Safety Code
for Portable Air Tools – B186.1, Code of Federal Regulation – CFR 29 Part 1910, International Organization for Standardization (ISO) Hand
Held Non-Electric Power Tools – ISO 11148, Safety Requirements and applicable State and Local Regulations.
Find The Most Current Offering of Support Documents and Accessories at www.Dynabrade.com
Read and understand tool manual before work starts
to reduce risk of injury to operator, visitors, and tool.
Ear protection to be worn when exposure to sound,
exceeds the limits of applicable Federal, State or
local statues, ordinances and/or regulations.
Practice safety requirements.Work alert, have proper
attire, and do not operate tools under the influence
of alcohol or drugs.
Air line hazard, pressurized supply lines and flexible
hoses can cause serious injury. Do not use damaged,
frayed or deteriorated air hoses and fittings.
Eye protection must be worn at all times, eye
protection to conform to ANSI Z87.1.
Respiratory protection to be used when exposed to
contaminants that exceed the applicable threshold
limit values required by law.
Some dust created by sanding, grinding, drilling, and other construction activities contain chemicals known to cause cancer, birth defects
or other reproductive harm. Some examples of these chemicals are:
• Lead from lead-based paints
• Crystalline silica from bricks and cement and other masonry products
• Arsenic and chromium from chemically treated lumber
Your risk from these exposures varies, depending on how often you do this type of work. To reduce your exposure to these chemicals: work in a well
ventilated area, and work with approved safety equipment, such as those dust masks that are specially designed to filter out microscopic particles.
DO NOT USE Tool for Anything Other Than Its Intended Applications.
Training: Proper care, maintenance, and storage of your air tool will maximize tools performance and reduce chance for accident.
Employer's Responsibility: Provide operators with safety instructions and training for safe use of tools and accessories.
Report to Your Supervisor any Condition of the Tool, Accessories or Operation you Consider Unsafe.
Tool Intent: Slow Speed Extension Die Grinders are ideal for removal and polishing of materials using deburring, cleaning
and polishing accessories.
SAFETY and OPERATING INSTRUCTIONS
Carefully Read and Understand the General
and Grinder sections found in Tool Safety
and Operating Guidelines (PN00001676)
Before Handling or Using Tool.
Carefully Read all instructions before operating or servicing
any Dynabrade
®
Abrasive Power Tool. Products offered by
Dynabrade are not to be modified, converted or otherwise
altered from the original design.
Model hp Collet
Insert RPM Exhaust
52674 16 mm 6,000 Rear
DIE GRINDER
Type 1 Die Grinder
6" Extension, Governor Controlled

2
Filter
Regulator
Lubricator
90 PSIG
(6.2 Bar)
To Tool Station
Ball
Valve
Ball
Valve
Filter
Regulator
Lubricator
Air Flow
Drain
Valve
Drain
Valve
Air Tool
Air Compressor
and Receiver
Drain Valve
Air Hose
90 PSIG MAX
(6.2 Bar)
Air Flow
Refrigerated
Air Dryer
• Dynabrade Air Power Tools are designed to operate at 90 PSIG
(6.2 Bar) maximum air pressure at the tool inlet, when the tool is
running. Use recommended regulator to control air pressure.
• Ideally the air supply should be free from moisture. To facilitate
removing moisture from air supply, the installation of a refrigerated
air dryer after the compressor and the use of drain valves at each
tool station is recommended.
➤
➤
➤
➤
➤
➤
AIR SYSTEM
Closed Loop Pipe System, Sloped in Direction of Air Flow
1DROP/MIN.
20 SCFM
LUBRICATOR SETTING
MAINTENANCE INSTRUCTIONS
Important: To keep tool safe, a Preventative Maintenance Program is
recommended. The program should included inspection of the tool and all
related accessories and consumables, including air lines, pressure regulators,
filters, oilers, etc. refer to CAGI B186.1 for additional maintenance information.
If accessory or tool breakage occurs, investigate failure to determine the cause
and correct before issuing tool for work. Use the following schedule as a
starting point in developing a Preventative Maintenance Program. If tool does
not operate properly (RPM, Vibration, Start/Stop) after these scheduled
checks or at any time, the tool must be repaired and corrected before returning
tool to use.
INSTALLATION
• To ensure long life and dependable service, use a Closed Loop Air System
and Filter-Regulator-Lubricator as diagramed below.
• Each tool should have its own dedicated hose connected to an air supply
manifold. Quick disconnects should be installed at the manifold in an effort
to reduce contamination into the tool.
• It is strongly recommended that all Dynabrade rotary vane air tools be used
with a Filter-Regulator-Lubricator to minimize the possibility of misuse due
to unclean air, wet air or insufficient lubrication. Dynabrade recommends the
following: 10681 Air Line Filter-Regulator-Lubricator — Provides accurate
air pressure regulation, two-stage filtration of water contaminants and
micro-mist lubrication of pneumatic components.
• Dynabrade recommends one drop of air lube per minute for each 20 SCFM
(example: if the tool specification states 40 SCFM, set the drip rate on the
filter-lubricator to 2 drops per minute) Dynabrade Air Lube (P/N 95842:
1pt/473ml) is recommended.
MAINTENANCE SCHEDULE
Daily (every 8 hours):
• Inspect tool and accessories for damage or broken parts. Replace items
as necessary to ensure proper operation and safety.
• Lubricate motor as recommended. Use Dynabrade Air Lube (P/N 95842:
1pt/473ml) 10W/NR. (1 Drop per minute of air lube per 20 SCFM.)
• Check air line pressure with a gage. (MAX. 90 PSIG or 6.2 Bar operating
pressure at the air inlet of the tool.)
• Right angled gear and wick system through gear case grease fitting with
3 plunges of gear oil (P/N 95848) and grease gun (P/N 95541). (Prime
grease gun prior to greasing.)
• Check tool for proper operation: If operating improperly or demonstrates
unusual vibration, the tool must be serviced and problem corrected before
further use.
Every 20 Hours or Once a Week Which Ever Comes First:
• Check free speed of tool without the abrasive accessory mounted. Measure
RPM (speed) with tachometer and with air pressure set at 90 PSIG while the
tool is running. If a governed tool is operating at a higher speed than the
RPM marked on the tool housing, the tool must be serviced and corrected
before use. A non-governed tool may exceed the RPM marked on the tool
by 10% when operated at free speed with no accessories.
• If tool is running fast look for worn, damaged or missing governors, air
control rings and silencers. Special care must be taken when servicing
governors and speed control devices. Injection molded governor assemblies
are non-serviceable and must be replaced.
• If tool is running slow look for clogged inlet screen, air stream, silencer(s)
or a malfunctioning governor (see concerns for servicing governors).
Service as required.
Every 50 Hours:
• Lubricate planetary gears through gear case grease fitting with 3 plunges
of grease (P/N 95542) and grease gun (P/N 95541). (Prime grease gun
prior to greasing.)
REPAIR
• Use only genuine Dynabrade replacement parts to ensure quality. To order
replacement parts, specify Model#, Serial# and RPM of your air tool.
• Mineral spirits are recommended when cleaning the tool and parts. Do
not clean tool or parts with any solvents or oils containing acids, esters,
ketones, chlorinated hydrocarbons or nitro carbons.
• DO NOT clean or maintain tools with chemicals that have a low flash point
(example: WD-40®).
• Motor Tune-Up Kit are available (when applicable) which includes high wear
and medium wear motor parts.
• Air tool markings must be kept legible at all times, if not, reorder housing
and replace. User is responsible for maintaining specification information.
• After maintenance is performed on tool, add a few drops of Dynabrade
Air Lube (P/N 95842) to the tool inlet and start the tool a few times
to lubricate air motor. Verify RPM (per 20 hr maintenance schedule),
vibration and operation.
HANDLING & STORAGE
• Use of tool rests, hangers and/or balancers is recommended.
• Protect tool inlet from debris (see Notice).
• DO NOT carry tool by air hose or near the tool throttle lever.
• Store accessories in protective racks or compartments to prevent damage.
• Follow the handling instructions outlined in the operating instructions when
carrying the tool and when changing accessories.
• Protect accessories from exposure to water, solvents, high humidity,
freezing temperature and extreme temperature changes.
END OF USE/ DISPOSAL
When tool has reached its end of useful service, disassemble tool into its
primary components (i.e. steel, aluminum and plastic part) and recycle or discard
per local, state and/or federal regulations as to not harm the environment.
NOTICE
All Dynabrade motors use the highest quality parts and metals available and
are machined to exacting tolerances. The failure of quality pneumatic motors
can most often be traced to an unclean air supply or the lack of lubrication.
Air pressure easily forces dirt or water contained in the air supply into motor
bearings causing early failure. It often scores the cylinder walls and the rotor
blades resulting in limited efficiency and power. Our warranty obligation is
contingent upon proper use of our tools and cannot apply to equipment
which has been subjected to misuse such as unclean air, wet air or a lack
of lubrication during the use of this tool.

1 hp Die Grinder
Complete Assembly
Model
52674 - 6,000 RPM
3
Adhesive: A8= Loctite #567
A10 = Loctite #243
Torque: N•m x 8.85 = In. - lbs.
Grease: G1= Lubriplate 630 AA
Oil: O1= Air Lube
O
A
T
G
KEY
Always follow adhesive manufacturers
cleaning and priming recommendations
150012 Collet Cap
250016 Collet Insert - 6 mm
350011 Collet Body
496512 Retaining Ring
551956 Felt Seal
601007 Bearing (2)
751952 Spindle Extension
851952 Handle Extension
953690 Extension Grip
10 54520 Bearing (3)
11 51982 Spacer
12 51969 Coupling Nut (2)
13 50902 Coupler
14 96498 Wave Spring (2)
15 95438 O-Ring
16 53620 Adapter
17 01041 Grease Fitting
18 04014 Set Screw
19 53695 Adapter
20 53668 Carrier
21 53661 Planetary Gears
22 96528 Bearing (3)
23 53679 Shaft (3)
24 53663 Ring Gear
25 51951 Shim Pack (3/pkg.)
26 51922 Front Bearing Plate
27 96441 Pin (2)
28 51927 Spacer
29 51926 Blade (4/pkg.)
30A 53660 Pinion
30 53680 Rotor
31 51925 Cylinder
32 51923 Rear Bearing Plate
33 02057 Bearing
34 96445 Pin (2)
35 51924 Gasket
36 51933 Governor Assembly
37 53756 Housing (Includes Warning
& Specification Labels)
38 96444 Pin
39 51949 Safety Lock Lever
40 51946 Valve Stem Assembly
(Incl. 96443 O-Ring)
41 51945 Valve Seat
42 51944 Tip Valve
43 51943 Spring
44* 96442 O-Ring
45* 51940 Spacer
46* 53682 Gasket
47* 94528 Felt Silencer
48* 53686 Muffler Cap
49* 94924 Wave Spring
50* 53683 Spacer
51* 53681 Inlet Bushing
(Incl. 2 – 51938 Screens)
52 01180 Warning Label
53 01181 Specification Label
Index Key
No. Part # Description
*Included in 53655 Muffler Assembly
35 N•m
T
20
21
23
26
27
25
10
28
30
29
31
24
19
14
27 32 33 34 33 36
53 38
52
41 42 43
40
39
37
22
10
15
14
13
16
11
10
A10
A8
2 N•m A10
T
17
18
50*
49*
48*
47*
46*
45*
44*
O1
35 N•m
T
17 N•m
T
51*
* Note: All parts
indicated by an asterisk
are included in 53655
Muffler Assembly.
30A
A10
A10
A10
35 N•m
T
12
7
6
5
4
3
2
1
A10
17 N•m T
28 N•m T8
9

DYNABRADE, INC. www.dynabrade.com
8989 Sheridan Drive • Clarence, NY 14031-1419 • Phone: [phone] • Fax: [phone] • International Fax: [phone]
© DYNABRADE, INC., 2013 PRINTED IN USA PD13.19_06/13
MACHINE SPECIFICATIONS
LIFETIME WARRANTY
To validate Dynabrade Lifetime Warranty, you must register each tool at: www.dynabrade.com. Registration of each tool at website is required.
Dynabrade will not honor Lifetime Warranty on unregistered tools. Please view the entire Lifetime Warranty Policy at : www.dynabrade.com.
Additional Specifications: Air Inlet Thread 3/8" NPT • Hose I.D. 3/8" (10 mm)
Sound Level is the pressure measurement according to the method outlined in ISO regulation ISO-15744
Model Speed Power Sound Air Consumption Collet Size Weight Length
52674 6,000 RPM 1 hp (745 W) 90 db(A) 41 SCFM (1,161 LPM) 6 mm 4.1 lb. (1.9 kg) 16.6" (423 mm)
Government Printing Office (GPO)
Superintendent of Documents • Attn: New Orders
P.O. Box 371954 • Pittsburgh, PA 15250-7954 • Tel: [phone]
International Organization of Standards (ISO)
Case postale 56 • CH-1211 Geneva 20
Tel: + 41 22 749 01 11 • Fax: + 41 22 749 09 47
American National Standards Institute (ANSI)
1899 L Street, NW, 11th Floor • Washington, DC 20036
Tel: [phone]
Compressed Air & Gas Institute (CAGI)
1300 Sumner Ave. • Cleveland, OH 44115-2851
Tel: [phone] • Fax. [phone]
REFERENCE CONTACT INFORMATION
OPTIONAL ACCESSORIES
Dynaswivel
®
• Swivels 360° AT TWO PIVOT POINTS allowing the air hose to
drop directly to the floor while providing superb tool handling.
95461 – 3/8" NPT.
51989 Repair Collar
• Specially designed collar for use in vise to prevent damage
to valve body of tool during disassembly/assembly.
Dynabrade Air Lube
• Formulated for pneumatic equipment.
• Absorbs up to 10% of its weight in water.
• Prevents rust and formation of sludge.
• Keeps pneumatic tools operating longer
with greater power and less down time.
95842: 1pt. (473 ml)
95843: 1 gal. (3.8 L)
95542 Grease 10 oz.
• Multi-purpose grease for all types of bearings, cams, gears.
• High film strength; excellent resistance to water, steam, etc.
• Workable range 0˚ F to 300˚ F.
95541 Push-type Grease Gun
• One-hand operation.
96005 Male Plug
• Provides up to twice the air flow
compared to standard plug design.
• Plug has “ported” design to prevent
“starving” of the air tool.
95281 – 19mm Open-end Wrench.
96532 Motor Tune-Up Kit
• Includes assorted parts to help
maintain and repair motor.
53699 Carrier Wrench
• 3 Sided wrench to for use with
6,000 RPM models.
Bearing Press Tools
• Used to install bearings.
96243: For installing 02057 Bearing.
96244: For installing 01007 & 54520 Bearings.
Drop-In Motor
• Allows quick and easy replacement.
No motor adjustments needed.
01903 – 6,000 RPM
