Dynacord Discover MP7 User manual

for Entertainer, Mobile-DJ, You & Me,
Club
& Bistro, Administration, Rental
DISCOVER
Recommended System:
Top CP 12-2
2-Way-System 12”/HFT
90°x40° CD-Horn
1 0 Watts/RMS
300 Watts/Cont. Prog.
8 Ω
70-18,000 Hz (-10 dB)
2 Speakon-Connectors
3 7x 09x33 mm (WxHxD)
17. kg net
Subwoofer CP 12-1
12“-Subwoofer (Bassreflex)
300 Watts/RMS
600 Watts/Cont. Prog.
8 Ω
60-280 Hz (-10 dB)
2 Speakon-Connectors
3 7x 09x410mm (WxHxD)
20. kg netto
CP1212
Frequency Response:
4 -18,000 Hz (-10 dB)
SPL: 122 dB/1m
Equipped:
Thermal Dynamic Speaker Protection
one fits all!
Multi-flexible Entertainment
System including mixer digital FX-unit
and 600 watts power amplifier
Mixer • 3 Mic inputs (ch 1 with talkover)
• 2 x 4 stereo inputs (two of which feature RIAA
Q for the connection of turntables)
• individually assignable crossfader
• Kill- Q (low, mid, high: -30 to +9 dB)
• 2 x 99 stereo effects (presets) for the Mic inputs. The two 18-Bit digital processors offer a total of 198 high-quality effect
combinations in well-known Dynacord-quality, but employing new 32-Bit algorithms.
Pre Outs • Master A and B, Mono, subwoofer out with low-pass-filter, record send control
• perfect headphones control via PFL/PGM/Mix (with specific 20 mm transition-fader
Power Amplifier • 2 x 300 watts/4 Ω • LPN-processor • Up to three 8 Ω loudspeakers on a single channel
• 7-Band graphic Master- Q • Power Amp In Case • Lightweight (only 13 kg) • very robust · rigid carrying handles and metal
cover (no flightcase required)
Countless possibilities – minimal effort, numerous functions – easy handling, extremely versatile – highly reliable.
This is the end of complicated and space-consuming equipment! verything is integrated and protected: special dynamic
limiters for speaker protection plus loads of sophisticated electronic protection-circuitry. You get the lot – especially
dynamic power. Well-known Dynacord-quality is guaranteed – literally, for 3 years.
We only cut backs are the price and the weight. 2 x 300 watts out of a mere 13 kg and about 46 cm of width and a depth
of just 34 cm. Plug-and-Play eliminates unnecessary cabling. The sound? LPN-Processing delivers powerful sound and
audible bass-punch. And of course, the fact that technical equipment does not necessarily have to be unattractive, you
can see for yourself.
DISCOVER
www.edelweiss-ag.de
TELEX EVI Audio GmbH · Hirschberger Ring 4 · D-9431 Straubing · Tel. [+49] (0) 94 21/706-0 · Fax [+49] (0) 94 21/706-26 · www.mp -7.com
Printed in Germany. 162037 AU

RENTAL ADMINIS
TRATION
1
Features & Specs Mixer-Section
3 Mic/Line-Inputs
• Microphone inputs provide continuous phantom power (24 VDC)
and are carried out via XLR-type connectors
• lectronically balanced Line-level inputs via phono-type connectors
• Switchable Lo-Cut filter (80 Hz/18 dB)
• Gain-Control range (+10 to +60 dB)
• 3-Band- Q (±15 dB HI/LO shelving, ±12 dB MID peaking)
• FX-Send Controls
• Pan Controls
• Mute-Switches with L D’s
• Talkover-Pushbutton with 20 dB of Attenuation (Input 1)
• PFL-Switches with L D’s
• Signal-Present-L D’s and Peak-L D’s
• High-quality ALPS-Faders and ALPS-Rotary Controls
• quivalent Input Noise <-130 dBu (A-weighted, 150 Ω)
• Fader-Attenuation @ 1kHz >95 dB
4 Stereo Inputs
• Screwed RCA-type Connectors
• Double-Assignable allows connecting CD-Player, MD, Tape Deck,
Turntable (switchable, with Status-L D)
• Channels 4 and 5 offer RIAA Phono qualization
• Gain-Control range (+20 dB/-10 dB)
• 3-Band-Kill- Q (-30dB/+9 dB, HI/LO shelving, MID peaking)
• FX-Send Controls
• Balance Controls
• Transition (Crossfader), switchable,
with “active”-indication
• Transition X or Y selectable
with assign-L D’s
• PFL-Switches with L D
• Signal-Present-L D’s and Peak-L D’s
• High-quality ALPS-Faders and ALPS-Rotary Controls
• THD @ 1kHz (MBW=80 kHz) 0.006 %
• Fader-Attenuation @ 1kHz > 95 dB
Master Section
• Replaceable, high-quality ALPS-Crossfader with 60dB Fader-Attenuation
and active-/assign-L D’s
• Stereo Master-Fader
• Master-A Pre-Out Connectors
• Master-B Pre-Out, mono/stereo and pre/post, switchable
• Controllable Sub-Out with Subwoofer Filter
• Controllable Mono/Light-Out
• Record-Out via RCA-type connectors
• On/Off-switchable 7-Band Graphic- Q
offering a control range of ±10 dB
• All Line-Outs are Impedance-Balanced
Power Amplifier
2 x 340 W (1 kHz/THD 1%) into 4 Ω
2 x 200 W (1 kHz/THD 1%) into 8 Ω
2 x 300 W (20-20 kHz/THD 0.2%) into 4 Ω
2 x 150 W (20-20 kHz/THD 0.2%) into 8 Ω
• Up to three 8 Ω loudspeakers can be connected to a single
channel (min load impedance 2.7 Ω)
• Comprehensive power supply unit provides expanded headroom
• Dynamic Limiters
• Speakon-type Outputs
• THD @ 1kHz < 0.08 %
• DIM 30 < 0.03 %
• S/N-Ratio (A-weighted) 105 dB
Protection Circuitry
• Back- MF
• Short-Circuit
• HF
• D C- O f f s et
• Thermal Overload
• Initial Current Inrush Limiter
• Power-On Delay with Output Relay
• Multi-stage, Low-Noise Fan
Special Features
• 2 Dual-Stereo Digital-Processors (employing
32-Bit algorithms) offering 198 high-quality effects
• Controllable headphones output via 2 phones sockets
and low-impedance output stage
• PFL/FGM-fader
• Comprehensive VU-L D-chains with PFL/Master-split function
• Master-Inserts
• On/Off-selectable, separate FX-Return controls with peak-L D’s
• XLR-type litlight socket (+12 V)
• 2 ergonomically shaped carrying handles
• Rugged transport-cover with snap-In locks
• Low weight: 13 kg
• Compact dimensions (WxHxD):
approx. 456 mm x 176 mm x 341 mm
Wall mounting-kit optionally available (NRS 90242)
19” rack-mount-kit optionally available (NRS 90259)
Gooseneck-light (2.4 W) optionally available
1
2
4
3
2
Having just invested in new equipment, your entire gear is leased-out? Annoyed, that
recouping your investment takes at least five years? Nerved, that most customers have
sky-high expectations and requirements, little or no experience and knowledge and
even less bucks to afford all of that? The “all-in-one” MP7 puts your misery to an end!
Being the most easily to operate solution, it is almost indestructible, extremely mobile
and truly professional.
The MP7 will be every customer ’s choice from your inventory, and when it is returned from
a gig, you can tell by the look on the customer’s face that he is really thrilled. As solid as
a rock and equipped like the “ nterprise”, plus that it will repay your investment even
faster than you will be able to read this page. So, why waste time?
1. No Cabling
• Mixer (3 Mic, 2 x 4 Line with 2 Phono)
• 2 Digital ffect-Processors
• Power Amplifier (2 x 300 W/4 Ω RMS)
with LPN-Processor
• Master- Q
• Master-Pre-Out
2. Usage
• Live Performances
• DJ-applications
• Conference and Promotional Shows
3. Handling
• Plug-and-Play
• Light Weight,
Rugged, Safe
4. Professionally
Equipped
• Neutrik/Alps
• Replaceable
Crossfader
• Transport
Protection
• Amplifier
Protection
Circuitry
• Dynamic Limiters
• 19”-rack compatible
• Optional litlight
The MP7 represents the new compact solution for rental services. Audio-Mixer, FX-unit
and a 600 watts power amplifier with processor are integrated into a single unit. The mixer
offers inputs for the connection of turntables, CD-Players, Tape Decks, DAT-Recorders,
Drum Machines, etc. and allows – by means of an assignable crossfader – reversible mixing
of the selected audio signal sources. The two 18-Bit digital processors offer 198 natural
or artificial sounding effect combinations, which can be assigned to the three microphone
inputs.
The MP7 closes the gap in your all-round rental business.
Countless possibilities – minimal effort, numerous functions – easy handling, extremely
versatile – highly reliable. This is the end of carrying around dozens of products, stumbling
over cables everywhere and bulky flightcases! verything is integrated – including protection-
circuitry and special dynamic limiters for loudspeaker protection. You get the lot – especially
dynamic power. 2 x 300 watts, Pre-Outs, Master-B, Sub-Out, 2 x 99 digital effects, crossfader,
limiter, protections, Alps-fader and Alps-rotary controls.
thing. Third, it is a truly mobile system, which,
nevertheless, can also be employed in fixed
installations, 19” rack or wall-mounted. And last but
not least it is a genuine Dynacord product furnished
with the best components from Alps and Neutrik.
Professional equipment for cost-conscious planning.
The MP7 represents the new compact solution that
meets all corporate requirements at events like:
conventions, performances, lectures – as a mobile
appliance or in a fixed installation – for schools,
council and administration, and unions. Just about
everywhere, where the combination of several high-
quality units in a single enclosure is needed,
providing mobility and clearly structured layout.
The included devices are: audio mixer, effects unit,
Q, and a 600 watts power amplifier with processor
and limiter. The mixer provides 4 double-assignable
stereo inputs for connecting CD-Players, Tape Decks,
DAT-Recorders, turntables, keyboards, etc.
Additionally, the mixer offers an assignable
crossfader, which allows reversible mixing of two
audio signal sources.
modern technology, and it’s price is on a level that
coincides with the budgets of today’s cost conscious
customer. A litlight is available as an Option. The MP7
uncompromisingly replaces a number of single pro-
ducts, is exceptionally reliable and also extremely
compact. 11 channels, 2 x 300W/4 Ω power amplifier,
2 x 99 digital effects, crossfader, Subwoofer-Out,
processor, limiter, and protection system. The supplied
transport cover saves you from expensive, bulky and
heavy custom-made flight-
cases.
VERLEIHFIRMEN
Discover the new possibilities
of the all-new MP7 Entertain-
ment System
MIXER · EFFECTS · POWER
In a single appliance. Compact,
easy to operate, filled with ef-
fects, and extremely powerful.
And because of the MP7’s tre-
mendous versatility, you will find
a list of advantages according
to associated applications and
an overview of all features and
special functions is provided on
the sleeve-inside. Have fun...
ENTER
TAINER MOBILE DJ YOU AND ME CLUB & BISTRO
ADMINIS
TRATION
RENTAL
DISCOVE
RDISCOVER
TechSpec
visit us at web: www.mp-7.com and win
DISCOVER

CLUB &
BISTRO
1
3
4
ENTER
TAINER
1
3
PROFESSIONAL
ENTERTAINER
2
2
1
4
5
3
2
It is obvious that almost any event’s success rests on the quality of the entertainment. Now, there is a truly
easy way of improving the planning, transportation, and operation to take out the guesswork and concentrate
on the performance with total confidence in your sound system. The MP7 is the right choice.
Using the MP7 guarantees the success of your performance whilst making set-up simplicity itself since everything
you need is integrated: Mixer, FX-units, qualizer, and power amplifier. Cabling is reduced to a minimum, set-up
is quicker and reliability is improved. Being small in size, the MP7 cuts out transportation nightmares and will
not impose in smaller venues. In spite of it’s small size, it accepts an ample amount of input signals. Whether
keyboards, mics, CD-player, or turntable, whether live performance or pre-recorded music, solo or with accompanying
musicians, the MP7 provides you the freedom to expand your creativity. Complete control of all functions at all
times is supported through clearly arranged L D-indicators in different colours ( yellow, blue, red). The status
of the mixer can be established at a glance.
The MP7 is your personal assistant – light weight, compact, superb sound quality and with an integrated protection
system based on the highly respected Dynacord protection circuitry as employed on their concert sound
amplifiers, provides speaker protection through special dynamic limiters and mechanical protection through
rugged carrying handles and transport cover – it is virtually indestructible. Your audience is going to remember
you for quite some time for all the right reasons.
1. Professional standard connections
Easy to connect and clearly arranged
• 3 phantom powered Mic-Inputs
(channel 1 with talkover-function)
• 4 double-assignable Stereo-Inputs
for connecting MC/CD/MD + turntable
+ MIDI-File-Player + keyboards
2. High Quality Effects
• 2 x 99 presets of top-quality
32-bit algorithm effects
(hall, chorus, delay, reverb, ...)
• extremely low acoustic feedback
3. EQ
• Perfect sound in any location
• ach mic/line input offers 3-Band equalization
in the range between -30 dB to +6 dB
• 7-Band graphic Master- Q
4. Phones Output with Mixing Ability
• Master (PGM)
• Pre (PFL)
• Mix ( PGM/PFL)
Additional Outputs
• Master-B Out
• Mono Out
• Active Subwoofer Out
The MP7 is the ultimate compact solution for professional entertainers: audio mixer, 2 digital effects units,
summing- Q and 600 watt power amplifier with processor and limiter. The two 18-Bit digital effects processors
offer a total of 198 high-quality effect combinations in the quality the industry has come to expect from Dynacord,
but employing new 32-Bit algorithms. These can be assigned to the three microphone inputs which cater for
dynamic or condenser microphones by virtue of the phantom power. The double-assignable stereo inputs are
intended for the connection of CD-Player, Tape Deck, DAT-Reorder, turntable, keyboards, MIDI-File-Player, etc.,
which can be mixed via an assignable crossfader, a standard feature on any professional DJ-system. All outputs
are impedance-balanced and kill- Qs allow using standard music sources for a karaoke-like effect. The wide gain
control range between 10 - 60 dB caters for virtually any microphone. quivalent Input Noise of -130 dBu, fader
attenuation of approximately 100 dB, THD 0.006 %, etc. are specifications that are normally only found amongst
the highest quality studio mixing consoles.
Do you want your venue to become the “talk of the town”? Do you want to set a new
standard in entertainment culture? Then you will definitely need the all-new
Entertainment System MP7.
The MP7 makes it easy: today karaoke, tomorrow disco or live band, next week theatrical
performance, and next month carnival. Indoors or outdoors, it does not matter, total
flexibility and innovative technology guarantees the success of your event. Optimum ease
of operation and ultra-reliable protection are what you can expect from Dynacord, without
compromise. With 198 effects, powerful 600 watts output capacity, mastermind cross-
mixing ability, balanced carrying handles, and the integral rugged flightcase, you and your
DJ are always one step ahead of the competition.
The MP7 represents a new, flexible, and high-quality solution for all music reproduction –
especially for professional live-performances, but also for playback, background and disco
music.
1. Applications
• Fixed installation (19” rack-kit or wall-brackets)
• Mobile applications through rigid enclosure,
comprehensive carrying handles and rugged cover
2. Live Performance
• DJ & Karaoke
• Party events
3. Features
• Summing equalizer
• Outputs for the connection of
active subwoofers or adjacent
room sound reinforcement
• Mono-Out for additional sound
distribution or sound-to-light feed
• Talk-switch for announcements
• 2 digital effect units
• Littlight connector
4. Output Power
• 2 x 300 watts (RMS into 4 Ω)
• Up to three 8 Ω cabinets
per channel
• LPN-Processor
• Dynamic Limiters
5. Characteristics
• asy Operation
• Comprehensive Protection-Circuitry-Package
• Ample set of features and functions for any application
The MP7 can be matched to perfectly fit your application and with its ample
set of features and functions, it is suitable for a huge range of uses. The layout
of the controls is clearly structured allowing you, your employees or performing
guest-acts to quickly feel confident operating the MP7. The integrated LPN-
Processor provides your sound system with the needed “drive” and since all outputs
are impedance-balanced, ground hums belong in the past.
Pubs, Clubs, Live
Venues & Restaurants
1. Suitability
• vents and Conventions
• Presentations
• Conferences
• Congresses
• Fashion Shows
2. Usage
• Authorities and
Administration
• Schools
• Unions • Hotels
• Ballroom
Dancing Schools
• Fitness Centres
• Convention Centres
3. Characteristics
• Highly Reliable
• Clearly Structured
4. Operation
• Flexible in Use
• Comprehensive Protection
Circuitry-Package
• No Wiring Problems
• Universal Hardware for Wall
and 19”-Rack Mounting
If you want to make your job easier
even when the specifications are
hard to meet. If you want to offer
superb quality to a low price. If you
love “plug and play” and at the same
time want to cover any possible
application: MP7.
Cost reduction – responsible admin-
istration and carefully handling the
budget, so that more money can be
spend on important matters. That’s
what we all want. That’s what we
designed the MP7 for. Well, what is
so special? First of all, it is an all-in-
one unit, including mixer, effects
units, and power amplifier, saving
you for additional cabling efforts
and custom-built racks. Second, the
system is easy to operate and
protected against (almost) every-
The two 18-Bit digital
processors offer 198
high-quality effect combinations,
which can be assigned to the three
microphone inputs which are sui-
table for dynamic or condenser
microphones. A talkover-push-
button automatically attenuates
the music signal by 20 dB. Upon
releasing the button the music
signal is faded back in. Gain-
Control range of 10 to 60 dB, equi-
valent input noise of 130 dBu, fader
attenuation of nearly 100 dB, THD
0,006 % – specs, that certify that
the MP7 is at the height of
CORPORATE

MOBILE
DJ
5
12
4
YOU AND ME
YOU
AND ME
1
3
2
4
MOBILE DJ
3
You can realise your ambitions to be a pro DJ! The MP7 is the “Mix-Machine” for all your party events –everything’s
included: mixer, effects, equalizer, and a really “fat” power amplifier.
You want to party? Then you have to do it right: no “which track on what CD am I looking for?”. no noises, buzzes & hums
and piles of cable lying around. No more blown power amps or loudspeaker systems. But perfect sound and the freedom
to connect the audio equipment you want: CD-Player, MC, MD, turntable, keyboards, mics, etc. Moreover, that is not all:
2 times 99 pre-programmed effects, kill- Q for karaoke, 7-Band graphic equalizer for extended “drive” and matching
the system to individual acoustic requirements.
The MP7 is the brand-new, extremely easy to operate solution for anyone who likes to party. For a house party, for
creating your own mix, but also for your own live-performance, all by yourself or with accompanying musicians. Compact
dimensions, reliability, and loads of features allow the MP7 to be universally used in any application. Whether you are
hosting a private karaoke-evening or enjoying a live-music performance, the two 18-Bit digital effects are ideal for
creating perfect sound – just as if it would come from a CD – and a crossfader allows professional mixing like it is done
in the major discotheques and dance-clubs. Connections are safe and clearly arranged, and perfectly suitable for
connecting CD-Players, Tape Decks, DAT-Recorders, etc.
1. Professional Style Inputs and Outputs
Inputs
• 3 Mic/Line
• 4 double-assignable stereo inputs
(turntable/CD/MC/MD)
Outputs
• Master A and B (Pre Out)
• Active Subwoofer Out with crossover
• Mono (also for Light Out)
• Power Amplifier Out via Speakon-type connectors
• Record Out
• 2 Headphones jacks
2. Mix Set
• Individually assignable to stereo channels
• Optically and acoustically adjusting signal levels
of crossfader-programs
• Headphones volume and mixing controls:
Master signal (PGM)
Pre-Listening (PFL)
Mix-Signal (from PFL and PGM)
3. Features
ach Stereo Input with Kill- Q (High, Mid, Low)
• 2 x 99 Digital ffects with 32-Bit algorithms
• 7-Band Graphic Summing-Stereo- Q
4. Power Output
• True 2 x 300 watts (RMS into 4 Ω)
• Connect up to 3 Loudspeaker Systems (8 Ω) per Channel
• Dynamic Limiter
• Comprehensive Protection Circuitry-Package
High-quality faders and rotary controls ensure long-lasting, trouble-free operation. A talkover-pushbutton provides the
opportunity for spontaneous announcements with automatic attenuation of the music signal and an optionally available
litlight offers precise illumination for the controls panel.
The B-output offers the possibility for individual and separately controllable sound reinforcement in adjacent rooms
and kill- Q’s allow using conventional audio signal sources to have an entertaining karaoke-evening. The Summing-
qualizer perfectly matches your existing loudspeaker systems to any acoustics.
Are you the next Pete Tong? Well, then be prepared for more bookings than you’ve ever had! Say goodbye to
ropey sound, here comes the brand-new MP7.
It’s not a toy! Hook up all your audio signal sources and mix to your hearts content. The MP7 is all you need. But
what’s really important for any DJ? It’s no good having the best record collection and being fantastic at mixing,
you need to have your sound system under control so you can concentrate on being creative and filling the dance
floor.
The MP7 is the ultimate solution for the “mobile DJ” that wants to travel light but loves superb sound performance.
DJ-mixer, effects, and a powerful 600 watts power amplifier with processor, which can also be used for monitoring,
are all included in a single unit. The mixer offers double-assignable inputs for the connection of turntables, CD-
Players, Tape Decks, DAT-Recorders, etc. while a high-quality crossfader allows freely assigning altering sound
sources. very thing you could possibly need to be a professional DJ.
1. Professional Style Inputs
Connect all your music sources
• 3 mic/line sources
• 2 times 4 stereo sources (turntable/CD/MC/MD)
2. “Intelligent” Outputs
• Mono Sum
• Subwoofer-Out with Low-Pass Filter
• Master A / Master B (Pre Out)
• Stereo Aux
• Power Amp (also for monitoring)
• Record send
3. EQ
Creative tone enhancement or problem solving
• 3-Band Kill- Q between -30 to +9 dB (Low, Mid, High)
• 7-Band Graphic Q for the Master Out
4. Headphones Output with Mixing Function
• Master (PGM)
• Pre (PFL)
• Mix (PGM + PFL)
• 2 Phones Out (front and top)
. Transitions Set
• Cross-fading (freely assignable)
• User-replaceable high-quality Alps-Crossfader
• All functions with L D-indication, comprehensive VU-meters
• PGM and PFL via VU-meter, adjustable
The two 18-Bit digital effect units allow creating no less than 198 effect combinations, which can be assigned
to the 3 Mic-Inputs. An optionally available litlight provides all the illumination you need in the darkest venues.
The optional 19” rack-mounting-kit allows easy integration into racks with existing equipment. Master-B, Light-
Out, Sub-Out, matching gain-structure, high-quality faders, Kill- Qs providing 30 dB of attenuation, etc. – enough
control for any kind of mix. The first microphone input employs a talkover-button. While pressing this button,
the music signal is automatically attenuated.
visit us at web: www.mp-7.com and win
