Instructions for TLP-102
Telephone Logger Patch
P/N 39041
FOR LEGAL USE ONLY 6-22-04
www.DynaMetric.com Page 1of 2©DynaMetric 2001 Doc 39058
The TLP-102 Telephone Logger Patch adapts most single or multiline phones, analog
or digital, to a tape recorder, sound card, or other audio device. It provides a clear
audio signal containing both sides of the phone conversation. The TLP-102 connects to
the telephone via the modular handset connector. See the diagram and installation
instructions below. Will not record speakerphone.
INSTALLATION INSTRUCTIONS
1Unplug the coil cord from the base of the phone and plug it into the modular jack on
the TLP-102.
2Plug the cable with the modular connector on the TLP-102 into the phone base
where the coil cord was plugged.
3Plug the cable with the 3.5mm plug on the TLP-102 into the tape recorder, or MIC
Input of a sound card or other audio device.
