DYN-6336-01
3 Person FAR Infrared Sauna
Owner’s Manual
CARBON MODEL SAUNAS
SAUNAS ARE FOR INDOOR USE ONLY
120VAC 20AMP Dedicated Circuit Required
Carefully and thoroughly read this Owner’s Manual before using/operating
the sauna. We recommend keeping this Owner’s Manual for regular review
and future reference.

2
TABLEOFCONTENTS
Packing List 2
Visual Assembly Diagram 6
Parts Description 7
Assembly Instructions 11
Operating the Sauna 19
Tips for Using Your Sauna 23
Safety Instructions 23
Safeguards for Your Sauna 25
Troubleshooting Guide 26
Warranty 32
Warranty Card 35
WARNING: Visually inspect all heaters before assembly to make sure they are
not damaged. Any excessive vibrations during transport could cause damage
to the heating elements. DO NOT START the sauna if damage is detected!
Contact your dealer or manufacturer for troubleshooting and replacement
parts.
Packing List (main panels)
1pc Front Panel 1pc Rear Panel 1pc Right Side Panel
1pc Left Side Panel 1pc Roof Panel 1pc Roof Cover
1pc Bench 1pc Bench Heat Emitter Panel 1pc Floor Panel
NOTE: Your model sauna has been completely assembled and tested prior to
packaging. The rear wall panel is intentional warped as part of the overall
design. Two adults will be needed to assemble the sauna room.
CAUTION: Exit Sauna Immediately If You Feel Dizzy, Sleepy,
Or Any Discomfort.

3
What Are Infrared Rays?
Infrared is the band of light we perceive as heat. We cannot see this band of light with
the naked eye, but we can feel this type of light in the form of heat. Our sun produces
most of its energy output in the infrared segment of the spectrum. Infrared rays heat
your body without having to heat the air in-between. This process is called conversion.
The infrared is divided into 3 segments by wavelengths measured in microns: Near
Infrared –0.76-1.5 microns; Middle Infrared –1.5-5.6 microns; and Far Infrared –5.6-
1000 microns. Among these segments, Far Infrared penetrates organic substances
such as the human body two to three inches so that the warming effect is very uniform.
ARE INFRARED RAYS SAFE?
Because infrared rays are part of sunlight, they are not only safe but also highly
beneficial to our bodies on a cellular level. Health professionals have used infrared
heat lamps for decades to treat muscle and joint problems. In hospital baby care
units, incubators are often equipped with infrared heating systems to keep newborn
babies warm.
WHAT IS AN ELECTROMAGNETIC FIELD (also known as EMF)?
An Electromagnetic Field is a physical field produced by electrically charged objects. It
is one of the fundamental forces of nature. The field can be viewed as the combination
of an electric field and a magnetic field. The electric field is produced by stationary
charges and the magnetic field by moving charges referred to as currents. The
magnetic field is measured in milligauss (mG). Our sauna products have been
developed to have low EMF. Our Low EMF sauna models range between an average
of 5mG-10mG at about two inches from the heater panel and our Ultra Low EMF sauna
models range between 3mG-5mG at the same approximate distance.

4
EMF Levels from Common Homes Sources
After many years and numerous studies on EMF exposure, no government body
including the Occupational Safety and Health Administration (OSHA) have established
permissible exposure limits (PEL). Currently, there is no consensus on the potential
health hazard from any exposure to EMF. The mainstream scientific evidence suggests
that low-power, low-frequency, electromagnetic radiation associated with household
currents like that of the infrared sauna does not constitute a short or long term health
hazard.
DISCLAIMER
The infrared rays emitted by your sauna are reported to offer a wide range of possible
therapeutic benefits based on research completed over the last 40 years from all around
the world. These benefits are presented for reference purposes only and no implication
of infrared saunas creating a cure for or treating any disease is implied nor should it be
inferred. If you have a medical/health condition, are taking prescription drugs, or have
acute joint injuries, please consult with your medical physician before using the sauna.
Persons with surgical implants (metal pins/rods, artificial joints, silicone, or other types
of surgical implants) typically do not experience any adverse effects, but should also
consult their medical physician or surgeon before using the sauna room.

5
HOW IT WORKS
Infrared Saunas differ from traditional saunas in that they use infrared radiant energy to
directly penetrate into the body's tissue to produce perspiration. Traditional saunas use
steam to heat the air inside the sauna, which then heats your body until you begin to
perspire. In order for this to be effective, temperatures would need to reach in the
upwards of 190 degrees Fahrenheit. Infrared saunas only need a temperature of up to
120 degrees Fahrenheit to obtain the same effect. This lower temperature makes the
environment more tolerable and allows you to breathe easier.
Health Benefits
Because infrared rays penetrate the body through conversion, there is a deep heating
effect in both the muscle tissues and internal organs without putting too much burden on
the heart.
Our body reacts to the increased heating through the natural cooling process of
perspiring. Through the perspiration process, acid and waste residue like toxins,
sodium, alcohol, nicotine, cholesterol, and the potentially carcinogenic heavy metals are
removed from the cells (especially zinc, lead, nickel, cadmium, etc.). The pores of our
skin open and discharge waste products shedding any old skin cells leaving the skin
glowing and clean, with improved tone, elasticity, texture, and color.
Health Benefits Include, But Are Not Limited To:
*Pain relief from Rheumatoid Arthritis *Relaxes muscle spasms *Reduces cellulite
*Increases blood circulation *Clears, rashes, acne *Enhances skin tone
*Cardiovascular conditioning *Reduces stress & fatigue *Removes toxins
Sauna Maintenance
Since infrared saunas do not require hot rocks, water, or steam to operate, they require
very little maintenance. You can simply wipe it down with water –use a damp, soft, and
clean cloth. Do not use any chemical based cleaning agents as they can be
absorbed into the wood and be released into your sauna during use.

6
*PLEASE READ INSTRUCTIONS THOROUGHLY BEFORE ASSEMBLY*
Visual Assembly Diagram
DYN-6336-01
*THE ABOVE ASSEMBLY DIAGRAM IS FOR A QUICK REFERENCE
VISUAL GUIDE ONLY. ALL SAUNA MODELS MAY NOT BE SHOWN.
PARTS AND ACCESSORIES DO VARY AND ARE SUBJECT TO
CHANGE.

7
PARTS DESCRIPTION
DYN-6336-01
*THE ABOVE ASSEMBLY DIAGRAM IS FOR A QUICK REFERENCE
VISUAL GUIDE ONLY. ALL SAUNA MODELS MAY NOT BE SHOWN.
PARTS AND ACCESSORIES DO VARY AND ARE SUBJECT TO
CHANGE.
NOTE: The pictures and diagrams shown above are for representational
purposes only. Actual model may vary.

8
I. Power Supply (Control Box)
The POWER SUPPLY is the control center of the sauna room. It is installed on the
topside of the ROOF PANEL and has inputs/outputs connected to it. (see Figure 1)
Figure 1
POWER IN - main power of the sauna room
HT1, HT2, HT3, HT4, HT5, HT6 –heat emitter cords
LAMPROOF –roof lamp power (optional)
LIGHTING –chromotherapy lights
PANEL CONTROL –control panel
FUSE RESET –protects against power
II. Component Labeling
Power Cord –Main power cord connects the POWER SUPPLY to the
dedicated wall outlet
HT1, HT2, HT3, HT4, HT5, HT6 –Heater cords connect the heat emitters
to the POWER SUPPLY at these ports (HT5 & HT6 are not used on most
models)
Lighting –Connects the interior lighting to the POWER SUPPLY at this
port
LampRoof –Connects the exterior roof lights to the POWER SUPPLY at
this port
Panel Control –Connects the Control Panel through the CTRL harness
to the Power Supply at this port
L/R Speakers –Connects the speakers through these wires to the Control
Panel
Temp Sensor –Connects the Temperature Sensor through this wire to
the Control Panel

9
III. MP3 Auxiliary Port
The MP3 Auxiliary Port allows you to connect a MP3 player or other device with the
auxiliary function to the speakers in the sauna room for your listening pleasure. (see
Figure 2)
Figure 2
IV. Buckles
A. External Buckles
The external buckles are used to connect the LEFT and RIGHT
SIDE PANELS to the REAR PANEL. (see Figure 3)
Figure 3
B. Guide and Guide Inserts
The guide and guide inserts are used to connect the FRONT
PANEL to the RIGHT SIDE PANEL and the LEFT SIDE PANEL.
(see Figure 4)

10
Figure 4
V. Panel Descriptions
For easier assembly, please understand and distinguish the differences between
each panel.
A. Floor Panel
When the FLOOR PANEL faces upward, you will find the floor heat
emitter panel on the topside and towards the front of the FLOOR
PANEL. (see Figure 5)
B. Understanding the Difference Between the Top and Bottom of
the Wall Panels
The (4) panels are in the upright position when the moldings are at
the top. The moldings will be facing inward towards the interior of
the sauna room. You will see the heat emitter cords coming from
the topside of the wall panels. (see Figure 5a)
Molding
Floor Heater
Front of Sauna Room
Figure 5
Figure 5a

11
C. Rear Panel
The REAR PANEL is the panel with the buckles. The buckles are
mounted on the exterior side of the REAR PANEL. (see Figure 6)
Figure 6
D. Understanding the Difference Between the Inside and Outside
of the Rear Panel
You will find the heat emitters on the inside of the REAR PANEL.
Assembly Instructions
A. Choose a good location to assemble the sauna
1. The location must be dry, leveled, and away from any source of water
2. MAIN POWER cord must be easily accessible
3. Two adults are required for installation
4. Wood cabin installation order: Floor Panel - Front Wall Panel with Glass
Door - Right Side Wall Panel - Left Side Wall Panel - Rear Panel - Roof -
Bench Heat Emitter Panel - Bench - Roof Cover (Order Could Vary)
5. Tools Required: Philips Screwdriver and Ladder

12
B. Installing the FLOOR PANEL
1. Place the FLOOR PANEL on the floor. (Note: The floor heater will be
located towards the front of the sauna room.) (see Figure 7)
Front of Sauna
Figure 7
C. Installing the FRONT WALL PANEL, RIGHT SIDE WALL PANEL and
LEFT SIDE WALL PANEL
1. Place the FRONT WALL PANEL up onto the FLOOR PANEL. Align the
Metal Guide Insert Brackets on the FRONT WALL PANEL and the RIGHT
SIDE WALL PANEL. The RIGHT SIDE WALL PANEL will need to be
lifted in order to lock the Metal Guide Insert Brackets onto the FRONT
WALL PANEL. Secure into place by pulling downward on the RIGHT
SIDE WALL PANEL. Make sure the Metal Guide Insert Brackets are
locked into place and the top of the FRONT WALL PANEL is flush with the
RIGHT SIDE WALL PANEL. Do the same for the LEFT SIDE WALL
PANEL. (see Figure 8)
Figure 8

13
D. Installing the REAR PANEL
1. Remove the protection paper from the buckles on the REAR WALL
PANEL. Place the REAR WALL PANEL up onto the FLOOR PANEL.
Next, attach the REAR WALL PANEL to the LEFT SIDE WALL PANEL
and use the buckles to latch together. Do the same for the RIGHT
SIDE WALL PANEL. (see Figure 9)
Figure 9
E. Installing the ROOF PANEL
1. The side of the ROOF PANEL with the power supply (control box) is the
top side of the ROOF PANEL.
2. The edge nearest the power supply is the front of the ROOF PANEL. Be
careful of the wires coming from the SIDE and REAR PANELS when you
set the ROOF PANEL down onto the panels. Feed the wires through the
holes in the ROOF PANEL. Feed the CTRL Harness up through the
ROOF PANEL.
3. Be careful not to force the ROOF PANEL into place. Make sure that the
wires are properly fed through the holes. Furthermore, make sure the
ROOF PANEL sits snugly into the RIGHT SIDE WALL PANEL and RIGHT
FRONT WALL PANEL. Pull down on the ROOF PANEL slightly to make
sure it is secured in place. (see Figure 10)

14
Figure 10
E. Installing the BENCH HEAT EMITTER PANEL and BENCH
1. Installing the BENCH HEAT EMITTER PANEL requires sliding it
downward into the guides on the side wall panels. (see Figure 11)
2. Plug in the BENCH HEAT EMITTER connector to the corresponding inlet
located on the right side of the REAR WALL PANEL for sauna model
DYN-6220-01 and to the corresponding inlet located on the RIGHT SIDE
WALL PANEL for sauna models DYN-6306-01/DYN-6330-01/DYN-6440-
01.Also plug the FLOOR HEAT EMITTER PANEL into the left side of the
REAR WALL PANEL for sauna model DYN-6220-01 and into the LEFT
SIDE WALL PANEL on sauna models DYN-6306-01/DYN-6330-01/DYN-
6440-01.
3. Install the BENCH at an angle as seen in Figure 11. Then slide it over the
horizontal bench guides on the side panels. If your model comes with the
optional LED accent lighting on the underside of the BENCH, you will
need to connect the harness (black and white wires) coming from the right
side of the REAR WALL PANEL to the connection on the underside of the
BENCH. Next, slide the BENCH all the way in and against the REAR
WALL PANEL. Make sure to install the BENCH with the smooth and
finished side facing upward. It is optional to screw the BENCH down to
the REAR WALL PANEL.

15
BENCH HEAT EMITTER PANEL
Guides On Side Walls
Figure 11 (BENCH & BENCH HEAT EMITTER PANEL
DO VARY IN INSTALLATION & DESIGN)
PLEASE NOTE: If your sauna has the optional LED Accent Lighting above the
REAR WALL HEAT EMITTER PANELS and below the BENCH, you will need to
connect the connector from the black/white wires coming from the BENCH
(located underneath the bench) to the black/white wire connector at the REAR
WALL PANEL.
F. Installing the FRONT GLASS DOOR HANDLE
1. Now that the FRONT WALL PANEL has already been installed, the inner
and outer door handles need to be mounted to the FRONT GLASS
DOOR. According to Figure 12 - Figure 14, the FRONT GLASS DOOR
must sit between the (2) white washers. The screws are inserted from the
inside of the FRONT GLASS DOOR and screwed into the outer handle.
BE SURE NOT TO OVER TIGHTEN THE SCREWS OR YOU WILL
SHATTER THE FRONT GLASS DOOR. Next, the inner door handle
needs to be inserted over the screws. Used the provided Hex Wrench to
tighten the (4) hex screws. (see Figure 12)

16
Figure 13
Figure 14
Figure 12
H. Connecting the plugs on the ROOF PANEL (POWER SUPPLY 1)
1. Connect the plugs according to their respective labels. (see Figure 15)
2. You will need to connect the right and left speaker connectors, the MP3
connector, and the CTRL (Panel Control) harness wire connector. (see
Figure 16)
Before Connecting After Connecting
Figure 15 Figure 16

17
I. Installing the TEMPERATURE SENSOR and Optional SHELF
1. Enter the sauna and remove the protective covering from the
TEMPERATURE SENSOR. Situate the TEMPERATURE SENSOR so
that it is vertical and pointing downward. (see Figure 17)
Figure 17
Note: Some sauna models are shipped with a spare TEMPERATURE SENSOR in
case the TEMPERATURE SENSOR is damaged during transit. The manufacturer
decides this according to sauna models and packaging.
2. If your sauna comes with the optional MP3 shelf, use the two screws
provided to mount the self on either the side panels or front panel. This
shelf is not offered on all models (see figure 18)
Figure 18
J. Putting on the ROOF COVER
1. Place the ROOF COVER over the top of the sauna. Be cautious when
pulling the power cord through the hole in the roof cover. Gently place the
ROOF COVER onto the ROOF PANEL. When the edges are aligned,
screw the ROOF COVER to the roof panel. (see Figure 19)

18
Figure 19
Assembly Is Complete!

19
Operating the Sauna
NOTE: Before the sauna is turned on, remove plastic protective covering from
the CONTROL PANELS. Please check and confirm that the connections to the
POWER SUPPLY(includingthepowercord), HEAT EMITTERS, CD/RADIO, and
TEMPERATURE SENSOR are connected properlyandaresnugandtight. The
power supply voltage and frequency must match the requested voltage and
frequency of the sauna (120VAC 15AMP Dedicated Circuit or 120VAC 20AMP
Dedicated Circuit). Please consult a certified electrician for any electrical
modifications or repairs.
Since many materials absorb the infrared rays, minimal clothing is
recommended for maximum effect. The infrared sauna emitters are designed to
heat you and not necessarily the air inside the sauna. It is not a hot box like a
traditional sauna. The temperature gauge is a guide for your safety. It is
recommended that you drink water before, during, and after sauna use to
prevent dehydration since body fluids will be lost through perspiration. It is not
recommended to shower immediately after use since the pores in your skin will
be open and could possibly absorb anything in the water.
CAUTION: Exit Sauna Immediately If You Feel Dizzy, Sleepy,
Or Any Discomfort.
Control Panel
Power On/Off: Press to control the main power of the sauna
Power Indicator: Indicates the status of the sauna’s main
power
Work Start/Stop: Press to control the working functions of the
sauna
Work Indicator: Indicates the working status of the sauna
Heat Indicator: Indicates the status of heating function
Light: Press to control the lighting function
Time Display: Displays the heating time of the sauna in
minutes
Time: Press to adjust the setting of the timer
Temperature Display: Displays the actual interior temperature
of the sauna room in
0
C/
0
F
Temperature: Press to adjust the temperature setting
0C/0F: Press to change the temperature display between
0
C/
0
F

20
1. Plug the sauna into the wall outlet.
2. Press the POWER button once. The POWER light will come on, the TIME
DISPLAY will show 90 (minutes), the TEMPERATURE DISPLAY will show 1510F /
660C, and the control panel will flash.
3. Press the up/down arrows under the TIME DISPLAY to adjust the amount of time
you want the sauna to remain on. Press the C/F button to choose between Celsius
and Fahrenheit. Press the up/down arrows under the TEMPERATURE DISPLAY to
adjust the temperature setting. Once you have set these adjustments to the desired
settings, press the START/WORK button. If you do not press the button for 5
seconds, the control panel will stop flashing and the set-up values will be
memorized. The WORK and HEAT lights will now be on and the emitters will now
be generating heat. You can either pre-heat the sauna to the set temperature before
entering or sit inside the sauna as the temperature rises to the set temperature.
Please keep in mind that you will increase the time it takes for the sauna to reach
the set temperature if you enter the sauna room before it has reached the set
temperature.
4. During your sauna session, set-up time will count down the minutes one by one.
You can use the up/down arrows to adjust the time. If you do choose to adjust the
time, the control panel will flash and the emitters will stop generating heat. Once
you set the time to the desired setting, then press the START/WORK button twice
and the control panel will stop flashing and heat will began coming from the emitters
once again.
5. Heating times do vary. Generally, it will take approximately twenty to thirty minutes
to preheat the sauna to the average used temperature range of approximately 118
degrees Fahrenheit / 48 degrees Celsius. When the ambient temperature is low,
heating requires additional time. For the first few times of use, you may use 115
degrees Fahrenheit / 46 degrees Celsius as a reference starting point for a time
period of about 20 to 30 minutes (this represents the actual time you are in the
sauna at the desired temperature). As you become more comfortable and familiar
with the sauna, you can increase the temperature and time period according to your
personal preference.
6. When the temperature is at the set-up value, the digital control will maintain the set
temperature. The WORK light will remain on and the HEAT light will turn off. The
emitters will stop generating heat. Once the inside temperature drops
approximately 4 degrees Fahrenheit, the HEAT light will turn back on and heat will
again be generated by the emitters. With the digital control, the inside temperature
will always remain around the set-up value.
7. Reading lamps and/or roof lamps and/or color therapy lamps are operated by
pressing the respective buttons located towards the center of the control panel.
These lamps are offered on some models and are not available on all models.
