Dynaudio Xeo 2 User manual

Owner’s Manual
HOME
Xeo 2 English

2Dynaudio
All Apple products are trademarks of Apple Inc.
All Sony products are trademarks of Sony Electronics Inc.
All Sonos products are trademarks of Sonos Inc.
Logitech Squeezebox is a trademark of Logitech Inc.
The Bluetooth word mark and logos are registered trademarks owned by Bluetooth SIG, Inc.
Other trademarks and trade names are those of their respective owners.
An update to this manual may be necessary due to product improvements and new functions.
The latest version of this manual can be found on the Dynaudio website at www.dynaudio.com/xeo

3
Important Safety Instructions
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in accordance with the manufacturer´s
instructions.
8. Do not install near any heat sources such as radiators, heat registers, stoves, or other
apparatus (including ampliers) that produce heat.
9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has
two blades with one wider than the other. A grounding type plug has two blades and a third
grounding prong. The wide blade or the third prong are provided for your safety. If the provided
plug does not t into your outlet, consult an electrician for replacement of the obsolete outlet.
10. Protect the power cord from being walked on or pinched, particularly at plugs, convenience
receptacles, and the point where they exit the apparatus.
11. Only use attachments/accessories specied by the manufacturer.
12. Use only with the cart, stand, tripod, bracket, or table specied by the manufacturer, or sold with
the apparatus. When a cart is used, use caution when moving the cart/apparatus combination
to avoid injury from tip-over.
13. Unplug this apparatus during lightning storms or when unused for long periods of time.
14. Refer all servicing to qualied service personnel. Servicing is required when the apparatus has
been damaged in any way, such as power supply cord or plug is damaged, liquid has been
spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or
moisture, does not operate normally, or has been dropped.
15. WARNING: To reduce the risk of re or electric shock, this apparatus should not be exposed
to rain or moisture and objects lled with liquids, such as vases, should not be placed on this
apparatus.
16. To completely disconnect this equipment from the mains, disconnect the power supply cord plug
from the receptacle.
17. The mains plug of the power supply cord shall remain readily operable.

4Dynaudio
WARNING
RISK OF ELECTRIC SHOCK! DO NOT OPEN!
To reduce the risk of electric shock, do not remove the back panel and do not expose the
apparatus to rain or moisture. No user serviceable parts inside. Refer servicing to qualied
personnel. Never open the speaker housing.

5
Thank you
for choosing Dynaudio Xeo.
Xeo combines the latest wireless technology with impressive sound quality and makes listening to
music truly convenient and easy.
The next few pages contain important information on connecting the system and its operation to
ensure perfect function and the best-possible sound quality.
We hope you have a great time listening to your favorite music,
Dynaudio
About this product
The active Xeo 2 speakers are equipped with powerful integrated ampliers and allow for the direct
connection of various analog and digital audio sources. A Bluetooth interface enables the operation
of Bluetooth devices and plays them back in optimal sound quality. Optional components like Xeo
Hub or Dynaudio Connect enable setting up a wireless multiroom system without any restrictions to
the highest sound quality. The speakers can be fully controlled with a remote control while buttons on
top of the cabinet let you switch it on/off or change the volume. The operational state of the system is
indicated by two LEDs on the front.
About this manual
This manual describes the operation of the Xeo 2 speaker. Information about the optional Xeo
modules (Hub, Connect, Extender, Link) can be found in the Owner´s manual provided with these
modules.

6Dynaudio
Safety information 7
Xeo speakers 7
Remote control battery 7
Scope of delivery 8
Unpacking 9
Removing the protection cap 9
Packaging material 9
Disposal 9
Connections and control elements 10
Elements on the rear panel 10
Buttons on top of the cabinet 11
Remote control 11
Connecting and setting up 12
Positioning and connecting to mains voltage 12
Cloth cover 12
General settings 12
Connecting sources directly 13
Connecting a Bluetooth device 13
Connecting sources via Hub or Connect 13
Operation 14
Switching on 14
Playback of connected sources 14
Playback of a Bluetooth device 14
Fixing the volume 15
Standby 15
Malfunctions 16
Annex 17
Status LEDs on the front 17
Connection options 18
The Xeo system 20
Components of the Xeo system 20
Combination examples 21
Division into audio zones 23
Technical data 24
Accessories 25
Desk stand 25
Wall bracket 25
VESA 100 bracket 25
Reminding 26
IC NOTICE 27
MPE Reminding 27
Table of contents

7
Safety information
Xeo speakers
WARNING
Dangerous electrical voltage
If the speakers are connected to the mains voltage, a dangerous electrical voltage is present
inside the speakers.
►Use the supplied power cable to connect the speakers to the mains voltage. Make sure that the
power supply cable is not damaged; replace it with a new one if it has been damaged.
►Never open the speaker housing.
►Do not operate defective speakers and disconnect defective speakers from the mains voltage.
Please contact your Dynaudio Xeo distributor if you have any problems. Distributor addresses
can be found in the Internet at www.dynaudio.com.
Remote control battery
WARNING
Danger of explosion
Danger of explosion if battery is incorrectly replaced.
►Replace only with the same or equivalent type.
WARNING
Chemical burn hazard
If the coin/button cell battery is swallowed, it can cause severe internal burns in just 2 hours
and can lead to death.
►If you think batteries might have been swallowed or placed inside any part of the body, seek
immediate medical attention.

8Dynaudio
Scope of delivery
2 Xeo 2 speakers
2 Xeo 2 speaker cloth covers
1 Xeo 2 remote control
2 power cables (country-specic version)
1 stereo cable (RCA – RCA)
1 optical cable (Toslink – Toslink)
1 stereo cable mini jack (3.5 mm – 3.5 mm)
1 Xeo rst time setup manual (quick guide for installation, not shown)






9
Unpacking
After unpacking, make sure the system is complete and check the device and all accessories for
transport damage. Transport damage may be expected if the packaging is already severely harmed.
Do not attempt to start up a damaged device. If the contents are incomplete or damaged, please
contact your Dynaudio Xeo distributor. Distributor addresses can be found on the Internet at
www.dynaudio.com.
Removing the protection cap
The tweeter is protected by a cap to prevent damage during transport and unpacking.
►After you have unpacked the speaker, remove the cap by just pulling it straight out.
Packaging material
The packaging has been designed so that it may be reused as long as it has not been damaged
during transport. Keep the packaging and use the original packaging for all further transport.
Disposal
Disposal of used electrical and electronic equipment (applicable in European countries with
separate collection systems for this equipment)
This symbol on the product or its packaging indicates that the product must not be treated as
household waste. Instead, it must be handed over to the applicable collection point for the recycling of
electrical and electronic equipment. By ensuring this product is disposed of correctly, you will help
prevent potential negative consequences for the environment and human health. The recycling of
materials helps to conserve natural resources. For more detailed information on recycling this product,
please contact your local authority, community waste disposal ofce, or the shop where you purchased
the product.

10 Dynaudio
Connections and control elements
This section describes the connections and control elements. Please contact your Dynaudio Xeo
distributor if you have any problems with connection and start-up. Distributor addresses can be found
in the Internet at www.dynaudio.com.
Elements on the rear panel
The Xeo 2 set consists of a master and a slave unit. The master unit carries the audio input interfaces.
A Back
plate
The plate on the back only needs to be unscrewed when mounting a Vesa 100
bracket (see „Accessories“ on page 25).
B Bottom
plate
The plate at the bottom only needs to be unscrewed when mounting a desk stand
or wall bracket (see „Accessories“ on page 25). It can be unscrewed for easier
access to the connections and control elements.
C Speaker
Position
Sound adjustment (depending on the
position of the speakers)
• Neutral = with free-standing
placement
• Wall = if placed near a wall
• Corner = if placed in a corner
Speaker placement
• Left = left speaker for stereo mode
• Right = right speaker for stereo mode
D Speaker
ID / Zone
Selection of audio zones
Speakers assigned to different zones can be controlled separately via the remote
control. The zones are identied as Red, Green, and Blue.
EAux In
To connect an analog audio source to
the speaker via mini jack.
Line In
To connect an analog audio source to
the speaker via RCA.
FOptical In (Toslink)
To connect a digital audio source to the speaker.
GUSB In
For rmware update only.
HMains socket
To connect the speaker to the mains voltage.
USB In Mains socket
Aux In Line In
R L
1
Optical In
2 3 4
Neutral
Zone
Red
Green
Blue
Wall
Speaker
Position
Speaker ID
Corner
Left
Right
C
D
E
H
F
G
II (master unit only)
I
II
I
A
B

11
Buttons on top of the cabinet
Speaker on/off
►Press to switch on the speakers. The Xeo 2 will scan the inputs for a signal.
►Press and hold to switch off the speakers.
Input selection
►When switched on, press to jump to another input.
Volume control
►Press or to raise or lower the volume
level. Press and hold for faster adjustment.
Bluetooth pairing
►Press and hold both and to
start pairing (see page 13).
Remote control
Commands will always apply to both of the speakers.
MUTE Muting the speakers
►Press to mute or unmute the
speakers.
Fixing the volume
►Press for at least 2 seconds to set
a high volume for the speakers (see
page 16).
ON/OFF Speaker on/off
►Press to switch on the speakers.
►Press for standby mode. Press for
at least 5 seconds to put the speakers
in sleep mode.
Reset
►Press for at least 5 seconds to reset
the speakers to the factory settings.
VOLUME Volume control
►Press or to raise or lower the volume level.
INPUT Signal source
►Press to select a signal source.
selects a Bluetooth device or
Hub/Connect.
Bluetooth pairing
►Press for at least 5 seconds to enter
pairing mode.
Controls
►Press to control most Bluetooth 4.1
compliant devices:
= backward, = play or pause,
= forward

12 Dynaudio
Connecting and setting up
Positioning and connecting to mains voltage
►Position the speaker in the desired location.
– Do not expose the speaker to direct sunlight, heat, or moisture.
– Do not place the speaker near devices with strong electromagnetic radiation or devices that
could be destroyed or damaged by magnetic elds.
►Use the power cable to connect the speaker to the mains voltage.
TIP: For easier access, the plate at the bottom of the cabinet can be removed. Use a coin or
screwdriver to loosen the screw and attach the plate after connecting the power cable.
Cloth cover
The cloth cover has been designed so it does not inuence the sound dispersion of the speaker. It is
attached to the housing with magnets and may be removed if needed.
General settings
►In stereo mode:
– Select Left operating mode for the left speaker.
– Select Right operating mode for the right speaker.
►Set the speaker position switch that best describes the speakers´ need for acoustic compensation.
– Neutral = with free-standing placement
– Wall = if placed near a wall
– Corner = if placed in a corner
►Select the Red, Green, or Blue zone. Select the same zone for the right and left speakers (for
additional information about the audio zones see „Division into audio zones“ on page 23).

13
Connecting sources directly
►Connect your source cables to one or more of the audio inputs Aux , Line , Opt of the master speaker
(see „Connection options“ on page 18).
After it is turned on, the speaker automatically searches for an audio signal and then plays it back
immediately. If several signal sources are active, one of the signal sources will be played back.
TIP: For easier access, the plate at the bottom of the cabinet can be removed. Use a coin or
screwdriver to loosen the screw and attach the plate after connecting the power cable.
Connecting a Bluetooth device
1. To begin Bluetooth pairing, press and hold both and buttons on either one of your speakers.
▼Once available for pairing, the Xeo 2 status indicator will blink white and it will be available for
pairing for one minute.
2. Go to settings on your device, nd the submenu Bluetooth, and simply pair your device with your
Xeo 2 by selecting Red, Green, or Blue. The speaker will store your pairing.
Connecting sources via Hub or Connect
Xeo Hub and Dynaudio Connect are optional components that allow you to connect analog and digital
sources and are linked with Xeo 2 via Bluetooth. For further information about the complete Xeo
system, please see „The Xeo system“ on page 20.

14 Dynaudio
Operation
Switching on
To switch the speakers on from standby mode:
►Press on top of one of the speakers or point the remote control at a speaker and press .
▼The speakers will automatically search for an active audio signal. If found, the signal will be
output (autoplay function).
▼If there is no input signal, the speakers will continue scanning the inputs for the next 20 minutes
and enter sleep mode.
If there is no input signal, the speakers will go into standby mode after a certain period.
Playback of connected sources
►Once you have connected your Xeo 2 with a direct input, simply choose your desired source on the
remote.
▼The speakers will automatically detect the signal and start playback. Master and slave speaker
will connect wirelessly if set in the same zone.
▼If no signal is applied to either input, the speakers will continue scanning the inputs for the next
20 minutes and enter sleep mode.
Playback of a Bluetooth device
Once you have paired your device with your Xeo 2, you can connect by choosing the Xeo 2 from your
list of Bluetooth devices.
►Select Bluetooth on the remote control and press play on your Bluetooth device.
Disconnect
►Press and hold to disconnect a connected device or disconnect from the device directly.

15
Fixing the volume
You can set the speaker to a higher volume using the function to x the volume. This setting also
remains in effect in standby mode. If a signal source is connected to the Xeo 2 with its own volume
control, you have the option to change the output volume across a broad range with the signal source.
To x the volume:
►Point the remote control at a speaker and press for at least 2 seconds. To undo xing, press
one of the two volume buttons.
Standby
To switch speakers to sleep mode:
►Point the remote control at a speaker and press or press on top of one of the speakers.
▼The speakers will enter sleep mode.
▼The speakers also enter sleep mode if there is no audio signal for 20 minutes.
▼In this mode, the wireless network is active and all connected units remain synchronized.
▼Sleep mode power consumption is <2 W.
To switch speakers to low-power standby mode:
►Press and hold on the remote control for at least 5 seconds.
▼The speakers go to low-power standby mode.
▼In this mode, the wireless network is disabled and the speakers are not connected to each
other.
▼Low-power standby mode power consumption is <0.5 W.
To turn off auto standby:
►Press and hold Opt on the remote control for at least 5 seconds.

16 Dynaudio
Malfunctions
Interruptions, clicking noises, or other audible interference when playing music is usually not caused
by radio transmission in the Xeo system. Often, other external causes inuence the transmission
quality.
Below are a few tips for improving transmission quality:
1. Position all radio transmitters and receivers away from each other. WLAN devices, radio receivers,
and radio systems may inuence each other if they are too close together. Test out various
locations for each device.
2. Switch off the automatic search function in WLAN devices. WLAN devices and other radio
systems permanently scan for available frequencies, thus sending signals that could disrupt other
radio systems. This automatic search function can usually be switched off.
3. Xeo technology radio signals can, of course, transmit through walls. However, walls may consist of
very different materials, such as wood berboard, stone, or even steel. The walls may also contain
complex cable installations for electrics, phones, TVs, and radios, as well as water pipes and air
shafts. These can divert radio signals. This is why you should test different locations for the Xeo
Hub, Extender, and Link and favor the most direct radio path between the Xeo components.
4. Some electrical devices, such as microwaves, generate strong electromagnetic elds that could
disrupt radio systems. Do not operate such electrical devices near Xeo components.
You can ask your Dynaudio Xeo distributor for assistance at any time or contact the Dynaudio helpline
at [email protected].
Further information can also be found on the Xeo website at www.xeo.dynaudio.de

17
Annex
Status LEDs on the front
The two LEDs in the upper left corner of the cabinet front indicate the operational state of the speakers
and system with various colors and blinking functions.
On-state Illuminated in blue The speaker is switched on, a 44.1/48k transmitter connection
is established, and an audio signal is played back.
On-state Slow blinking in blue The speaker is switched on, 44.1/48k transmitter connection is
established, but an audio signal cannot be found.
On-state Illuminated in purple The speaker is switched on, a 88.2/96k transmitter/master
connection is established, and an audio signal is played back.
On-state Slow blinking in purple The speaker is switched on, 88.2/96k transmitter/master
connection is established, but an audio signal cannot be found.
Switch-on process Fast blinking dimly in red
for 40 s
The speaker is being switched on.
Connection Slow blinking in red There is no active transmitter/master or no connection possible.
Search Fast blinking in blue for 20 min Searching for an active input.
Synchronization/
Connection
Fast blinking in red for 10 s System synchronization during no transmitter/master
connection.
Blue LED is turned off for 0.2 s New transmitter ID, transmitter input, or direct input is selected.
Illuminated in red for 5 s Receiver mode is changing.
Illuminated in white Bluetooth connection is established.
Slow blinking in white Speaker is in pairing mode.
Firmware loading White LED: slow to fast blinking
during the load sequence,
Red LED: illuminated
Firmware is being loaded.

18 Dynaudio
Volume Fast blinking in blue Volume is being adjusted.
Mute Fading in and out Speaker is muted.
Off-state Illuminated dimly in red Speaker is in standby mode.
LED blinking code
off Illuminated
in white
Illuminated
in a colour
Slow blinking
(1 or 2 Hz)
Fast blinking
(3 or 4 Hz)
NOTE: The LED status conditions also appear in combinations, e.g. while playing back 44.1/48k audio
signals from a bluetooth device, the left LED is illuminated in blue and the right LED in white.
Connection options
►Connect your signal source to the appropriate input on the Xeo 2 speaker.
Below you will nd a selection of signal sources and options for connecting to the Xeo 2.
Your signal source Signal source
output
Xeo 2 input* Cable
(source – Xeo 2)
Notes
Notebook, MAC™, PC Optical Optical In Toslink – Toslink –
Line out Line in RCA – RCA
Headphones Aux in Jack 3.5 mm – 3.5 mm
Smartphone, other portable devices Headphones Aux in Jack 3.5 mm – 3.5 mm –
Astell&Kern Headphones Aux in Jack 3.5 mm – 3.5 mm –
Optical Optical In Toslink – Toslink
PonoPlayer Jack Aux in Jack 3.5 mm – 3.5 mm –
Docking station, network client, Sonos,
Logitech, Squeezebox, etc.
Line out Line in RCA – RCA * If available
Optical* Optical In Toslink – Toslink
Apple AirPort Express Optical Optical In Mini Toslink – Toslink –
Apple TV Optical Optical In Toslink – Toslink –

19
Your signal source Signal source
output
Xeo 2 input* Cable
(source – Xeo 2)
Notes
Hard disk, network player,
CD player
Line out Line in RCA – RCA * If available
Optical* Optical In Toslink – Toslink
Analog radio, digital radio Line out Line in RCA – RCA * If available
Optical* Optical In Toslink – Toslink
Analog record player Line out* Line in RCA – RCA * On phono preamplier
TV Headphones Aux in Jack 3.5 mm – 3.5 mm Select a variant.
Line out Line in RCA – RCA
Optical* Optical In Toslink – Toslink * If available
Stereo preamplier Pre-out, main out Line in RCA – RCA –
Stereo power amplier Tape out Line in RCA – RCA * Disconnect bridge
Pre-out, main out* Line in RCA – RCA
Second pre-out Line in RCA – RCA
Subwoofer Analog output Line in RCA – RCA –
AV receiver, AV processor Optical Optical In Toslink – Toslink –
Pre-out, main out Line in RCA – RCA
* USB for rmware update only

20 Dynaudio
The Xeo system
Xeo consists of several high-quality components that are optimally matched. When combined, they
can fulll the most demanding requirements for a wireless multi-room and multi-source system.
Components of the Xeo system
Xeo
speakers
The active Xeo speakers Xeo 2, Xeo 4, and Xeo 6 receive the wireless signals
from the Hub or Connect and play them back in optimal sound quality. In addition,
the Xeo 2 can be connected directly to various audio sources. All speakers have
an integrated amplier and can be controlled with a remote control. Display
elements indicate the operating state of the system and controls on the cabinet let
you switch it on/off or change the volume without using the remote control.
Xeo remote
control
The Xeo remote control can be used to turn the speakers on and off, change the
volume, and select a Hub or Connect and its connected signal sources.
Dynaudio
Connect and
Xeo Hub
The Dynaudio Connect and Xeo Hub are the control centers for the Xeo system.
Both offer a new level of wireless connectivity and convenience. Signal sources
such as tuners, receivers, CD players, TVs, streaming clients, network players,
MP3 players, or computers are connected to them. Signals are sent wirelessly and
lossless to the connected Xeo or Focus XD speakers (or Xeo Link) where they are
then played back.
Xeo Extender The Xeo Extender extends the reception range of the Xeo Hub. As a result, Xeo
speakers or other Xeo components can be operated further away from the Xeo
Hub or Dynaudio Connect.
Xeo Link The Xeo Link receives wireless signals from a Xeo Hub or Dynaudio Connect
and outputs analog and digital signals from its connections. As a result, you can
also connect active subwoofers, active speakers, or other components to the
Xeo system. Xeo Link can also be connected with a 1st generation Xeo Hub
(transmitter).
