dyso V6 DC59 User manual
�ﻧﻫ طﻐﺿا �ﻧﻫ طﻐﺿا
Not charging –
contact Helpline.
Not charging –
too cold/too hot.
Fully charged.
Charging.
OPERATING MANUAL
ASSEMBLY
WASH FILTER
Wash filter with
cold water at least
every month.
REGISTER
YOUR FREE 2 YEAR
GUARANTEE TODAY
DC59
REGISTER ONLINE
Visit our website to register your full
parts and labour guarantee online.
www.sa.dyson.com
Dyson
Dyson
Dyson
Dyson
Dyson
www.sa.dyson.com
Dyson
REGISTER BY PHONE
Call our dedicated Helpline.
920 01176 6
800 Jumbo (58626)
DYSON CUSTOMER CARE
THANK YOU FOR CHOOSING
TO BUY A DYSON APPLIANCE
After registering your free 2 year guarantee, your
Dyson appliance will be covered for parts and labour
for 2 years from the date of purchase, subject to the
terms of the guarantee. If you have any questions about
your Dyson appliance, call the Dyson Helpline with your
serial number and details of where/when you bought the
appliance.
Most questions can be solved over the phone by one of
our trained Dyson Helpline staff.
Alternatively, visit www.sa.dyson.com for online help,
general tips and useful information about Dyson.
REGISTER YOUR FREE 2 YEAR GUARANTEE TODAY
Note your serial number for future reference.
This illustration is for example purposes only.
DYSON CONTACT DETAILS
SA:
Website: www.sa.dyson.com
Dyson Helpline:
920011766
Email:
dyson@abdulwahed.com
Address:
Ahmed Abdulwahed Trading Co., Al Amal Plaza, Hail Street, Al Baghdadiya,
PO Box 3611, Jeddah 2141.
UAE
Website: www.sa.dyson.com
Dyson Helpline:
800 Jumbo (58626)
Email:
Customer[email protected]
Address:
Jumbo Electronics Co. Ltd (LLC)
Mail --3,246, Dubai
United Arab Emirates
Dyson
:SA
www.sa.dyson.com
:Dyson
9200117 66
dyson@abdulwahed.com
3611
:UAE
www.sa.dyson.com
:Dyson
)Jumbo )58626 800
Customer.Svc@jumbo.ae
uae@dyson.com
3246
2141
www.sa.dyson.com
920011766
)Jumbo )58626 800
2
3
AR
1.Dyson
2.
3.Dyson
.Dyson
4.
5.
6.Dyson
7.
.Dyson
8.Dyson
9.
10.
11.
12.
13.
14.
15.
16.Dyson
17.clear bin
18.
19.
20.10 3
21.DysonDysonDyson
22.
23.
DYSON
4
READ AND SAVE THESE INSTRUCTIONS
THIS DYSON APPLIANCE IS INTENDED FOR HOUSEHOLD USE ONLY
Do not use near
naked flames.
Do not store
near heat
sources.
Do not pick up
water or liquids.
Do not pick up
burning objects.
Do not put
hands near the
brush bar when
the appliance is
in use.
5
EN
IMPORTANT SAFETY INSTRUCTIONS
BEFORE USING THIS APPLIANCE READ ALL INSTRUCTIONS AND CAUTIONARY MARKINGS IN
THIS MANUAL AND ON THE APPLIANCE
When using an electrical appliance, basic precautions should always be followed, including the
following:
WARNING
These warnings apply to the appliance, and also where applicable, to all tools, accessories,
chargers or mains adaptors.
TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR INJURY:
1. This Dyson appliance is not intended for use by young children or infirm persons with reduced
physical, sensory or reasoning capabilities, or lack of experience and knowledge, unless they have
been given supervision or instruction by a responsible person concerning use of the appliance to
ensure that they can use it safely.
2. Do not allow to be used as a toy. Close attention is necessary when used by or near children.
Children should be supervised to ensure that they do not play with the appliance.
3. Use only as described in this Dyson Operating Manual. Do not carry out any maintenance other
than that shown in this manual, or advised by the Dyson Customer Care Helpline.
4. Suitable for dry locations ONLY. Do not use outdoors or on wet surfaces.
5. Do not handle any part of the plug or appliance with wet hands.
6. Do not use with a damaged cable or plug. If the supply cable is damaged it must be replaced by
Dyson, its service agent or similarly qualified person in order to avoid a hazard.
7. If the appliance is not working as it should, has received a sharp blow, has been dropped,
damaged, left outdoors, or dropped into water, do not use and contact the Dyson Helpline.
8. Contact the Dyson Helpline when service or repair is required. Do not disassemble the appliance
as incorrect reassembly may result in an electric shock or fire.
9. Do not stretch the cable or place the cable under strain. Keep the cable away from heated
surfaces. Do not close a door on the cable, or pull the cable around sharp edges or corners.
Arrange the cable away from traffic areas and where it will not be stepped on or tripped over. Do
not run over the cable.
10. Do not unplug by pulling on the cable. To unplug, grasp the plug, not the cable. The use of an
extension cable is not recommended.
11. Do not use to pick up water.
12. Do not use to pick up flammable or combustible liquids, such as petrol, or use in areas where they
or their vapours may be present.
13. Do not pick up anything that is burning or smoking, such as cigarettes, matches, or hot ashes.
14. Keep hair, loose clothing, fingers, and all parts of the body away from openings and moving
parts, such as the brush bar. Do not point the hose, wand or tools at your eyes or ears or put
them in your mouth.
15. Do not put any object into openings. Do not use with any opening blocked; keep free of dust, lint,
hair, and anything that may reduce airflow.
16. Use only Dyson recommended accessories and replacement parts.
17. Do not use without the clear bin and filter in place.
18. Unplug when not in use for extended periods and before maintenance or servicing.
19. Use extra care when cleaning on stairs.
20. Do not install, charge or use this appliance outdoors, in a bathroom or within 3 metres (10 feet) of
a pool. Do not use on wet surfaces and do not expose to moisture, rain or snow.
21. Use only Dyson chargers for charging this Dyson appliance. Use only Dyson batteries: other types
of batteries may burst, causing injury to persons and damage.
22. Do not incinerate this appliance even if it is severely damaged. The battery may explode in a fire.
23. Always turn ‘OFF’ the appliance before connecting or disconnecting the motorised brush bar.
B
A
2
1
2
1
1
3
2
1
2
�ﻧﻫ طﻐﺿا
�ﻧﻫ طﻐﺿا
�ﻧﻫ طﻐﺿا
�ﻧﻫ طﻐﺿا
Charging.
Attaching to
docking station.
Removing from
docking station.
Solid blue: 'ON'.
Fully charged.
Flashing blue: No power,
charge battery.
Not charging –
too cold/too hot.
Not charging –
contact Helpline.
For futher diagnostics refer
to the 'Usage' section
Diagnostics Storage and charging in
the docking station
Emptying
6
B
A
2
1
2
1
1
3
2
1
2
�ﻧﻫ طﻐﺿا
�ﻧﻫ طﻐﺿا
�ﻧﻫ طﻐﺿا
�ﻧﻫ طﻐﺿا
Low battery.
Powerful suction
20 minutes.
6minutes. No power, temporary fault
(e.g. check filter or for
blockages).
Clearing brush bar
obstructions
Power mode and run time. Diagnostics
17 minutes.
Max mode
7
�ﻧﻫ طﻐﺿا
88
WASH FILTER
�ﻧﻫ طﻐﺿا
Looking for blockages
99
WASH FILTER
IMPORTANT!
Wash filter with cold water
at least every month.
Dyson
Dyson
•
•
•
•
•
•
•
•
•
•
Dyson
•Dyson
.Dyson
•Dyson
•
37.43
•
•clear bin
•
•
•
clear bin
clear bin
clear bin
).’clear bin
•
•
•
•
•
clear bin
•MAX
•
•clear bin
•clear bin
clear bin
•
clear bin
•clear bin
•
•clear bin
clear bin
•clear bin
•
•clear bin
clear bin
•clear bin
•clear bin
•clear
.bin
•clear bin
•
•clear bin
•clear binclear bin
•clear bin
•
•
•
•
•
•
•
•
• 24
•
•
•
•
•
•
•
•
•
•
•3
37.4
37.43
•
•
•
10
•
.Dyson
•DysonDyson
•
–
–
–
15
–
140°60
•Dyson
•
•
Jumbo Electronics Co. LtdSA
)LLCUAE
)DYSON
)DYSON
11
12
When charging battery:
BATTERY SAFETY INSTRUCTIONS
• If the battery needs replacing please contact the Dyson Helpline.
• Use only Dyson chargers for charging this Dyson appliance.
• The battery is a sealed unit and under normal circumstances poses no safety
concerns. In the unlikely event that liquid leaks from the battery do not touch the
liquid and observe the following precautions:
– Skin contact – can cause irritation. Wash with soap and water.
– Inhalation – can cause respiratory irritation. Expose to fresh air and seek
medical advice.
– Eye contact – can cause irritation. Immediately flush eyes thoroughly with
water for at least 15minutes. Seek medical attention.
– Disposal – wear gloves to handle the battery and dispose of immediately,
following local ordinances or regulations.
CAUTION
The battery used in this device may present a risk of fire or chemical burn if
mistreated. Do not disassemble, short contacts, heat above 60°C (140°F), or
incinerate. Keep away from children. Do not disassemble and do not dispose of
in fire.
DISPOSAL INFORMATION
• Dyson products are made from high grade recyclable materials. Recycle where
possible.
• The battery should be removed from the product before disposal.
• Dispose of or recycle the battery in accordance with local ordinances or
regulations.
GUARANTEE TERMS & CONDITIONS
Please contact Ahmed Abdul Wahed Trading Co. (SA) or Jumbo Electronics Co.
Ltd (LLC)(UAE) for the terms and conditions of your guarantee.
Please keep your invoice to validate your guarantee.
Solid blue: Charging.
Lights off: Charging complete.
Solid amber: Not charging, temporary fault
(e.g. too hot/cold).
Flashing red: Fault (contact Dyson Helpline).
13
USING YOUR DYSON APPLIANCE
PLEASE READ THE ‘IMPORTANT SAFETY INSTRUCTIONS’ IN THIS DYSON
OPERATING MANUAL BEFORE PROCEEDING.
OPERATION
• Do not use outdoors or on wet surfaces or to vacuum water or other liquids –
electric shock could occur.
• Ensure the appliance remains upright in use and in storage. Dirt and debris may
be released if it is turned upside down.
• Do not operate while checking for blockages.
• For domestic indoor and car use only. Do not use it whilst the car is in motion or
while driving.
• To operate the Max mode, hold the trigger down and press the ‘Max’ button.
The ‘Max’ button will light up.
• To switch off Max mode, hold the trigger down and press the ‘Max’ button
again. Note: The appliance will retain the last used mode. So if you use it in max
mode and do not disengage it, the appliance will operate in Max mode when it
is next used until you depress the ‘Max’ button to disengage it.
• This product has carbon fibre brushes. Take care if coming into contact with
them, as they may cause minor skin irritation. Wash your hands after handling
the brushes.
CARPETS OR HARD FLOORS
• Before vacuuming your flooring, rugs and carpets, check the manufacturer’s
recommended cleaning instructions.
• The brush bar on the appliance can damage certain carpet types and floors.
Some carpets will fuzz if a rotating brush bar is used when vacuuming. If this
happens, we recommend vacuuming without the motorised floor tool and
consulting with your flooring manufacturer.
• Before vacuuming highly polished floors, such as wood or lino, first check that
the underside of the floor tool and its brushes are free from foreign objects that
could cause marking.
LOOKING AFTER YOUR DYSON APPLIANCE
• Do not carry out any maintenance or repair work other than that shown in this
Dyson Operating Manual, or advised by the Dyson Helpline.
• Only use parts recommended by Dyson. If you do not this could invalidate your
guarantee.
• Store the appliance indoors. Do not use or store it below 3°C (37.4°F). Ensure
the appliance is at room temperature before operating.
• Clean the appliance only with a dry cloth. Do not use any lubricants, cleaning
agents, polishes or air fresheners on any part of the appliance.
• Check the brush bar regularly and clear away any debris (such as hair). Debris
left on the brush bar may cause damage to flooring when vacuuming.
VACUUMING
• Do not use without the clear bin and filter in place.
• Fine dirt such as flour should only be vacuumed in very small amounts.
• Do not use the appliance to pick up sharp hard objects, small toys, pins, paper
clips, etc. They may damage the appliance.
• When vacuuming, certain carpets may generate small static charges in the
clear bin or wand. These are harmless and are not associated with the mains
electricity supply. To minimise any effect from this, do not put your hand or
insert any object into the clear bin unless you have first emptied it. Clean the
clear bin with a damp cloth only. (See ‘Cleaning the clear bin’.)
• Use extra care when cleaning on stairs.
• Do not rest the appliance on chairs, tables, etc.
• Do not press down on the nozzle with excessive force when using the appliance
as this may cause damage.
• Do not leave the cleaner head in one place on delicate floors.
• On waxed floors the movement of the cleaner head may create an uneven
lustre. If this happens, wipe with a damp cloth, polish the area with wax, and
wait for it to dry.
DIAGNOSTICS – MAIN BODY
When in use, trigger pressed:
EMPTYING THE CLEAR BIN
• Empty as soon as the dirt reaches the level of the MAX mark – do not overfill.
• Ensure the appliance is disconnected from the charger before emptying the
clear bin. Be careful not to pull the 'ON' trigger.
• To make emptying the clear bin easier, it is advisable to remove the wand and
floor tool.
• To release the dirt, push the red button by the clear bin: Press once to open the
bin base. Press a second time to release the clear bin from the main body of the
appliance.
• To minimise dust/allergen contact when emptying, encase the clear bin tightly in
a plastic bag and empty.
• Remove the clear bin carefully from the bag.
• Seal the bag tightly, dispose as normal.
• Close the clear bin base so it clicks into place and is secure.
CLEANING THE CLEAR BIN
• Ensure the appliance is disconnected from the charger before removing the
clear bin. Be careful not to pull the ‘ON’ trigger.
• Remove the wand and floor tool.
• Push the red button by the clear bin: Press once to open the bin base. Press a
second time to release the clear bin from the main body of the appliance.
• Remove the clear bin carefully.
• Clean the clear bin with a damp cloth only.
• Do not use detergents, polishes or air fresheners to clean the clear bin.
• Do not put the clear bin in a dishwasher.
• Clean the cyclone shroud with the brush on the combination tool to remove lint
and dust.
• Ensure the clear bin is completely dry before replacing.
• To replace the clear bin, push the clear bin up and in to the main body of the
appliance. It will click into place.
• Close the clear bin base so it clicks into place and is secure.
WASHING YOUR FILTER
• Ensure the appliance is disconnected from the charger before removing the
filter. Be careful not to pull the ‘ON’ trigger.
• Your appliance has one washable filter, located as shown.
• To remove the filter, lift it out of the top of the appliance.
• Check and wash the filter regularly according to instructions to maintain
performance.
• The filter may require more frequent washing if vacuuming fine dust or if used
mainly in ‘Powerful suction’ mode.
• Wash the filter with cold water only.
• Run water over the outside of the filter until the water runs clear.
• Squeeze and twist with both hands to make sure the excess water is removed.
• Lay the filter on its side to dry. Leave to dry completely for a minimum of 24
hours.
• Do not put the filter in a dishwasher, washing machine, tumble dryer, oven,
microwave or near a naked flame.
• To refit, place the dry filter back into the top of the appliance. Make sure it is
seated properly.
BLOCKAGES – AUTOMATIC CUT-OUT
• This appliance is fitted with an automatic cut-out.
• If any part becomes blocked the appliance may automatically cut out.
• This will happen after the motor pulses a number of times (i.e switches on and
off in quick succession).
• Leave to cool down before looking for blockages.
• Ensure the appliance is disconnected from the charger before looking for
blockages. Failure to do so could result in personal injury.
• Clear any blockage before restarting.
• Refit all parts securely before using.
• Clearing blockages is not covered by your guarantee.
CHARGING AND STORING
• This appliance will switch ‘OFF’ if the battery temperature is below 3°C (37.4°F).
This is designed to protect the motor and battery. Do not charge the appliance
and then move it to an area with a temperature below 3°C (37.4°F) for storage
purposes.
• To help prolong battery life, avoid recharging immediately after a full discharge.
Allow to cool for a few minutes.
• Avoid using the appliance with the battery flush to a surface. This will help it run
cooler and prolong battery run time and life.
DIAGNOSTICS - BATTERY
When in use, trigger pressed:
Solid blue: Max 'ON'.
Light off: Powerful suction.
Flashing blue: Low battery warning.
Fast flashing blue: No power, temporary fault (e.g. check
filter or for blockages).
Solid blue: 'ON'.
Flashing blue: No power, charge battery.
Flashing amber: No power, temporary fault
(e.g. too hot/cold).
Flashing red: Fault (contact Dyson Helpline).
14
15
JN.73073 PN.201844-34-03 03.03.15
Dyson customer care
After registering your free 2 year guarantee, your Dyson appliance will be covered for parts
and labour for 2 years from the date of purchase, subject to the terms of the guarantee. If
you have any questions about your Dyson appliance, call the Dyson Helpline with your serial
number and details of where/when you bought the appliance.
Most questions can be solved over the phone by one of our trained Dyson Helpline staff.
DYSON CONTACT DETAILS
SA:
Website: www.sa.dyson.com
Dyson Helpline:
9 20 01176 6
Email:
dyson@abdulwahed.com
Address:
Ahmed Abdulwahed Trading Co., Al Amal Plaza, Hail Street,
Al Baghdadiya, PO Box 3611, Jeddah 2141.
UAE
Website: www.sa.dyson.com
Dyson Helpline:
800 Jumbo (58626)
Email:
Customer.svs@jumbo.ae
Address:
Jumbo Electronics Co. Ltd (LLC)
Mail --3,246, Dubai
United Arab Emirates
IMPORTANT!
WASH FILTER
Wash filter with cold water at least every month.
www.sa.dyson.com
Dyson
Dyson
DysonDyson
Dyson
:SA
www.sa.dyson.com
:Dyson
dyson@abdulwahed.com
:UAE
www.sa.dyson.com
:Dyson
)Jumbo )58626 800
Customer.Svc@jumbo.ae
uae@dyson.com
3246
2141
Table of contents
Other dyso Vacuum Cleaner manuals
