 Indoor Antenna KH 2329
Operating instructions
IB_KH2329_E801_UK_V1 12.12.2006 16:27 Uhr Seite 2

IB_KH2329_E801_UK_V1 12.12.2006 16:27 Uhr Seite 3

e-bench KH 2329








IB_KH2329_E801_UK_V1 12.12.2006 16:27 Uhr Seite 4

- 3 - 
e-bench KH 2329
Content Page
Intended use 4
Important Instructions for your Safety! 4
Technical Data 4
Package Contents 4
Description of the appliance 4
Connection 5
Operating the Indoor Antenna 5
Receiving programme signals via the indoor antenna 5
Switching On and Regulating the Amplifier 6
What to Do in the Event of Reception Problems 6
Cleaning and Care 6
Disposal 6
Warranty & Service 7
Importer 7
Read the operating instructions carefully before using the appliance for the first time
and preserve this booklet for later reference. Pass the manual on to whomsoever
might acquire the appliance at a later date.
IB_KH2329_E801_UK_V1 12.12.2006 16:27 Uhr Seite 3

- 4 -

e-bench KH 2329
Indoor Antenna KH 2329
Intended use
This indoor antenna is intended:
• for receiving UHF/VHF and DVB-T TV
stations and UKW radio stations
• for use in dry areas protected from
rain,
• exclusively for private use and not for
use in commercial or industrial areas.
Important Instructions for your
Safety!
To avoid life-threatening electric shocks:
• Ensure that the electrical specifica-
tions given on the model plate tally
with the rating of the existing dome-
stic electricity supply.
• Do not bend or squeeze the power
cord.
• To disconnect, always pull out the
plug at the power socket, do not
pull at the power cord.
• Before cleaning, or if there is a power
supply fault, pull the plug out of the
power socket.
• Always keep the indoor antenna out of
the reach of children and pets.
• Always pull the plug out of the power
socket if you are not using the indoor
antenna for a longer period of time.
• Do not place any open sources of fire,
like candles, on the device.
• Do not place any water-filled vessels
such as e.g. flower vases on the
appliance.
• Ensure an adequate safety distance to
other objects (approx. 10 cm).
• The appliance may only be used un-
der normal indoor conditions, i.e.
protected against moisture, dirt,
extremes of heat and cold and tempe-
rature fluctuations.
Technical Data
Power supply: 230 V AC / 50 Hz
Power consumption: 3,5 Watt
Frequency range: 40-860 MHz
Amplifier gain: UHF: 28 dB
VHF: 26 dB
Output voltage: max. 100 dBµV
(variable)
Protection class: II,
Package Contents
Indoor Antenna KH2329
Adapter F-Plug/Coaxial socket
Adapter Coaxial socket/Coaxial socket
Operating instructions
Warranty card
Description of the appliance
Telescopic antennae (VHF/UKW/DVB-T)
Oval antenna (UHF)
Operation indicator
Regulator (amplifier gain)
Antenna cable
Mains cable
Adapter F-Plug/Coaxial socket
Adapter Coaxial socket/Coaxial socket
IB_KH2329_E801_UK_V1 12.12.2006 16:27 Uhr Seite 4

- 5 - 
e-bench KH 2329
Connection
➭Connect the antenna cable of the
indoor antenna "TV"  to the anten-
na jack of your television set.
➭When you want to use the room an-
tenna for radio reception, utilise the
Adapter Coaxial socket/Coaxial socket .
➭Connect the Adapter Coaxial
socket/Coaxial socket with the
antenna cable.
➭Connect the anntenna cable with
Adapter Coaxial socket/Coaxial socket
to the 75 Ohm connectore on your
stereo system.
➭To connect the room antenna to a
DVB-T-Receiver with an F-socket, the
Adapter F-Plug/Coaxial socket must
be used.
➭Connect the Adapter F-Plug/Coaxial
socket with the antenna cable.
➭Screw the antenna cable with the
Adapter F-Plug/Coaxial socket to
the F-socket of the DVB-T-Receivers.
➭Insert the power plug of the indoor
antenna into the power socket.
Operating the Indoor Antenna
Receiving programme signals via the
indoor antenna
The programme signals are received by
the indoor antenna and transmitted to
the television set.
For the reception of DVB-T programme
signals you need an additional DVB-T re-
ceiver (DVB-T signals cannot be received
everywhere).
The indoor antenna has to be positioned
correctly for the proper reception of
programme signals.
The following antennas are available for
this:
two telescoping antennas for VHF
and UKW reception that tilt and rota-
te by 180° and
 one oval-shaped antenna for UHF re-
ception that tilts and rotates by 100°.
To orient the indoor antenna:
➭Pull out both telescopic antenna 
➭and adjust these until the best recep-
tion is obtained.
➭Adjust the oval antenna by turning
or tilting until the best reception is
obtained.
IB_KH2329_E801_UK_V1 12.12.2006 16:27 Uhr Seite 5

- 6 -

Switching On and Regulating the
Amplifier
You can regulate the amplifier gain by
turning the regulator on the front of
the appliance:
➭Switch on the indoor antenna by tur-
ning the regulator  to the right.
The operating indicator  lights up red.
➭Turn the regulator  in clockwise
direction to increase the amplifier gain.
➭Turn the regulator  in anti-clockwise
direction to decrease the amplifier gain.
➭Turn the regulator  completely to
the left until it clicks to switch off the
indoor antenna.
What to Do in the Event of
Reception Problems
Reception disruptions, such as an unclear
or distorted picture could have the
following causes:
•The indoor antenna is not correctly
oriented:
Every station requires an individual
orientation. For this reason, reorient
the indoor antenna every time after
changing the station.
•There are obstacles in the reception
range of the indoor antenna:
Attempt to remove the obstructions
or place the antenna at a different
location.
•There is electromagnetic interference
in the immediate vicinity:
Try to eliminate the interference if,
for example, it is caused by other
appliances (mobile telephone, micro-
wave, etc.).
•Interference due to overmodulation:
Try to eliminate the interference by re-
ducing the amplifier gain by turning the
regulator  anti-clockwise.
The reception characteristics of the
indoor antenna are only good if you
are close enough to the broad-
casting station.
Cleaning and Care
Risk of electric shock
• Before cleaning, always pull the plug
out of the plug socket.
• Never submerge the indoor antenna
into water or other liquids during
cleaning.
➭Clean the indoor antenna only with a
dry, lint-free cloth.
To avoid damaging the appliance, never
use solvents for cleaning.
Disposal
Do not dispose of the device in
normal domestic waste.
Dispose of the device over a registered
waste disposal firm or through your
communal waste disposal facility.
Observe the currently valid regulations.
In case of doubt, consult your waste
disposal facility.
Dispose of the packaging materi-
als in an environmentally respon-
sible manner.
e-bench KH 2329
IB_KH2329_E801_UK_V1 12.12.2006 16:27 Uhr Seite 6

- 7 - 
Warranty & Service
The warranty conditions and service
centre address can be found in the
enclosed warranty slip.
Importer
KOMPERNASS GMBH
BURGSTRASSE 21
D-44867 BOCHUM
www.kompernass.com
