E-Care LCT-210 series User manual

LCT-210 SERIES
Infrared Ear Thermometer
Instruction Manual
ATTENTION, SEE
INSTRUCTIONS

Normal human body temperature is a rang, not a fixed value. It fluctuates
throughout the day; generally, lowest in the morning and highest at sunset.It
also tends to decrease with the age - infant has higher temperature than adult .
As well , different sites (oral , axilla , rectum and ear) have different
temperature - generally speaking,ear temperature is close to oral but higher
about 0.5 than axillary temperature.
Human body temperature is controlled and adjusted by the hypothalamus in
the brain and the blood flowing through hypothalamus also flows through ear
drum. Then measuring ear temperature can best reflect the body temperature
than other sites. Our Infrared Thermometer uses infrared technology to
measure infrared energy emitted from the ear drum and surrounding tissue ;
then coverts into the temperature value-safely, conveniently and precisely
measure the ear temperature for you.
Using our Infrared thermometer to take ear temperature, the normal
human body temperature range is
35.5~38.0 (96.4~100.4 )
Table of normal human body temperature range by age:
1. Knowing Body Temperature
However, the normal range is also different from person to person. To
determine your and your family members’ normal temperature
ranges is very important. It can be done easily by using our Infrared
Ear Thermometer. Please practice to take temperatures on yourself
and your healthy family members to determine their normal
temperature ranges.
Age Range( ) Range( )
0-2 years 36.4-38.0 97.5-100.4
3-10 years 36.1-37.8 97.0-100.4
11-65 years 35.9-37.6 96.6-99.7
>65 years 35.8-37.5 96.4-99.5
~1~

~2~
2.Safety Notes Prior Usage
1. Please make sure the cleanness of the optical glass inside the
probe (A-1) , and wipe it up with a cotton swab while earwax
covered (If moistened with alcohol, please wait and restart after
5 minutes; otherwise, the result of measurement will be too low and
inaccurate).
2. Please read through the instruction manual before using the
thermometer; as proper technique is critical for taking accurate
temperatures. The performance of the thermometer may be adversely
affected with improper usage.
3. Do not use the thermometer outside the operating ambient
temperature of 10 (50 )~40 (104 ).
4. Do not use the thermometer outside the operating ambient humidity
up to 95%RH.
5. Do not use the thermometer when the ear canal is wet, or when the
person is suffering from ear diseases.
6. Earwax and obstructions will affect the accuracy of the thermometer.
7. Sideway sleeping gesture will cause the ear temperature to rise,
please avoid it.
8. The thermometer is calibrated and does not require re-calibration if
used according to the instructions.
9. The measured temperatures may be different in the different ear side.
Please measure the same ear to help ensure the accurate
measurement.
10. After shower or exercise, the body temperature will rise.
11. Do not insert the probe into the ear canal with excessive force.
12. When the battery symbol" "appears,it means low battery,please
replace the new battery.
13. This thermometer is intended for household use only. The use of
this thermometer is not intended as a substitute for physician s
consultation.

~3~
3.Product Description:
Probe
2.Display
4.on/off
Memory
3.Function
button
1.
5.Measurement button
6.Battery cover

~4~
4. Usage Method:
1. Please make sure the cleanness of the optical glass inside the
probe. You can use a cotton swap to clean the optical glass; if
moistened with alcohol, waiting and restarting after 5 minutes,
otherwise the result of measurement will be too low.
If the ear temperature is over 38.0 ,it is fever.
FEVER:over 38.0
2. Measuring method (for ear):
Perform an ear tug to straighten the ear canal. This gives the
thermometer a clear view of the eardrum.
AB

Press (A-4) to turn on and the thermometer is default as ear function.
To measure forehead temperature, please press (A-3) and display will
appear " " on the top left corner. Aiming the probe at forehead or
temporal about 1cm distance from skin, press (B-5) to get the forehead
temperature. You can switch to measure ear temperature by pressing
(A-3) again and " " disappears; then it return to ear function.
~5~
D
Children under 1 year: Pull the ear
straight back.
Children aged 1 year to adult: Pull
the ear up and back.
While tugging the ear, fit the probe snugly into the ear canal as far as
possible and press the measurement button. Release it,when you hear
the Beep.
3.Measuring method (for forehead):
Our forehead measurement is really no touching the skin and only 1
second measuring time.
Since forehead (temporal) temperature is easily affected by the
ambient, if you take forehead temperature and get a reading higher
than 37.0 (98.6 ), it is better to double check if the client has
a fever by switching to ear function and measuring ear temperature.

LCT-210 has forehead function and is better for checking many persons.
We suggest that using the forehead function to check temperature at
first ( aim at forehead at a distance about 1 cm-really do not touch the
skin).
If the person's forehead temperature is higher than 37 , then switch
to ear function to double check his temperature.
~6~
Note: It is recommended that you take three temperatures in the same
ear under the following circumstances. If they are different, use
the highest reading.
Infants in the first 3 months of life.
Children under three years old who have a condition such as a
compromised immune system and for whom the presence or absence
of fever is critical.
When you are first learning to use the ear thermometer until you are
comfortable with the technique and are gaining consistent readings.
Important: As with any type of thermometer,slight temperature
variations( 0.2-0.3 /0.3-0.5 )can happen
, if consecutive measurements are taken.
4.When the display ( LCD) appears" " symbol, you can measure
again. If you don’t press any button within one minute, the ear
thermometer will shut down automatically.

~7~
Display symbol instruction
Description
Ready (Ear)
When display (LCD)
displayed symbol"
"means ready Ear
Thermometer.
Work The thermometer is
working.
Turn on the unit All segments displayed.
Measurement
complete
Measurement complete,
the unit is ready again
for next measurement.
Low battery indication
The battery should be
replaced.
LCD display Display meaning

~8~
Auto Memory
1. Turn the thermometer on.
2. Press the memory button.
3. Read the temperature in last time from the display.
4. According to the same method as above, press the memory button
twice, the display will show the temperature of last two times,and so on.
Changing Temperature Scale:
1. Turn the thermometer on.
2. Press the memory button( A-3) and keep it, then press
measurement button( B-5), the temperature scale between Celsius
) or Fahrenheit ( ) is switched.
Silent Fever Alarm:
When the measured temperature is higher than 38 (100.4 ), the
LCD backlight will change color.
Replacing The Battery:
When the display appears" "symbol, meaning low battery,
please replace the new battery.
1. Prepare a lithium cell, type CR2032.
2. Remove the battery cover (B-6).
3. Be sure the <+> up and replace the new battery.
4.Put back the battery cover.
Remove the battery:

~9~
HI
LO
40
10
Error messages:
return to measurement.
When the ambient
temperature higher than
, please return to
normal area.
When the ambient
temperature lower than
, please return to
normal area.
Measuring when it is
not ready; please wait
for ready status.
LCD display Display meaning
Measured temperature
too high
Measured temperature
too low
Ambient temperature
too high
Ambient temperature
too low
Error function display
Blank display
Display when
measured temperature
higher than 50 . Please
return to measurement.
Display when
measured temperature
lower than 0 . Please
Please check if the
battery has been loaded
correctly.
Possible cause and fault
remedy

~10~
5. Storage Method
1. Do not expose to temperature extremes below(-20 (-4 ) or over 50
(122 )), or excessive humidity( over95%RH).
2. Do not expose to direct sunlight or near any fire.
3. Do not shock, vibrate, drop or step on the thermometer.
4. Do not allow any liquid into the thermometer.
5. Do not disassemble, repair or remodel the thermometer.
6. Keep out of reach of children.
7. Please take out the battery, if you do not use for a long time.
8. Clean the main body of the thermometer with a soft and dry cloth,
no containing abrasive agents.
9. Please only use lithium battery type CR2032.
10. Please do not discard the battery into fire.

~11~
6. Technical Specifications:
Subject to change without notice
European Representative:
Model
Sensor type
Displayed temperature range
Operating ambient temperature range
Operating ambient humidity range
Accuracy
Memory
Battery type
Battery life
Automatic Switch-off
Weight
Standard
CE Medical Device
LCT-210 Ear Thermometer
Thermopile
0~50 (32 ~122 )
10 ~40 (50 ~104 )
0~95% RH
02
Auto-memorized the last ten or five
measured temperature.
CR2032 lithium cell (x1)
At least 5000 measurements/ 2 years
1 minute after last measurement has
been taken.
63g (with battery)
Complies with CE EN12470-5 and
ASTM E1965-98 requirements.
Class II a

~12~
7. Guarantee
Date of purchase:
Name and full address of purchaser:
Stamp and signature of dealer:
0434 Type BF Applied Part
ISO13485
LCT-210 series Infrared Ear Thermometer
Guarantee Card
Thank you for your purchase of our Infrared Ear Thermometer.
This product is guaranteed for 1 year from date of purchase.Warranty
claims must be lodged within the guarantee period.
Damage resulting from incorrect use is not covered by the
guarantee. Battery and other consumptions, i.e. probe cover, are
excluded from the guarantee. Claims only valid if accompanied by a
stamped and dated guarantee card.
